Jmaz Lighting Galaxy Tube User manual

User Manual
Galaxy Tube
WWW.JMAZLIGHTING.COM

User Manual
1010mm
200mm
220mm
04 - Runs the built-in programs, use the ‘+’ and ‘-’ buttons
to go through the programs and then the ‘Speed’ button
followed by the ‘+’ and ‘-’ buttons to adjust the
program speed
05 - Runs the sound programs, use the ‘+’ and ‘-’ buttons
to go through the programs
06 - Sets the LEDs to flash, use the ‘+’ and ‘-’ buttons to
change the flash speed
07 - Sets the built in program speed. Press this button
followed by the ‘+’ and ‘-’ buttons to adjust the
program speed
08 - Adjusts the built-in programs and built-in program
speed, sound program, flash speed for static colour,
brightness of static colour
A - Red
B - Green
C - Blue
D - Orange
E - Lime Green
F - Pink
G - Amber
H - Cyan
I - Magenta
J - Yellow
K - Purple/Blue
L - White
B
ON
R
OFF
+
03
01 02
06
08
05
04
07
A B C
D E F
G H I
J K L
.Power Supply: 100 -250 VAC, 50/60 Hz
.Light Source: 30 SMD 3 IN 1 LEDs
.Strobe Rate: 0 to 30 Hz
.Control: Auto, Flash, Fade, Sound & Static
Color
.Material: Plastic housing
.Li-battery:12V 2500MA
.Recharging time:4-5hours
.Working time: 8hours(All ON)
.Input Voltage: 12.6 VDC/1A
.Product dimensions: 220x200x1010mm
8.7"x7.9"x39.8"
.N.W: 0.5 kgs/1.1lbs
.Controller: IR Remote Controller
IR remote functions:
01 - Sets the unit into blackout off (LED on)
02 - Sets the unit into blackout on (LED off)
03 - Sets the static colour (see chart key for colours)
Power ON/OFF
Specifications:
Galaxy Tube - Battery-Powered LED Tube Bar Light
Galaxy Tube
The Galaxy Tube is a color changing LED effect that can be mounted vertically, horizontally or free standing with the
included easy fit feet. The rechargeable lithium battery offers a run time of up to 12 hours from a single charge, and
with no power cables to connect you are free to set up the unit wherever you want.The tube will opearate in chase,
fade,static and sound active modes and is supplied with a handle IR remote.
