User-Service Manual
Joerns®Support Surface
CairTurn RT
To avoid injury, read user’s manual before using.
Joerns Healthcare 1_Art Direction_Joerns Beds_700 Series_UltraCare 8page
5/2007_Page 1 of 8

2
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Important Precautions
Important Notice: The equipment must be installed
and operated in the manner for which it was intended.
Facility staff/user is responsible for reading and
understanding the product user manual and contacting
Joerns if anything in this manual is unclear. Joerns will
not be held responsible for any injuries resulting from
failure to comply with the instructions and precautions
in this manual.
Warning: Joerns’ specialty support surfaces are
designed as mattress replacement systems. The
risk of entrapment may occur when the equipment is
placed on bed frames that leave gaps of even a few
inches between the mattress and the headboard,
footboard, and bed or side rails. The equipment is
NOT to be used when such gaps are present.
Facility staff/user is responsible for ensuring that all
mattresses properly t the bed frames. Joerns is not
responsible for the placement of its equipment on bed
frames that leave gaps between the mattress and
the headboard, footboard or bed or side rails which
present a risk of harm to patients.
Warning: The safe use of the equipment is maximized
when used in conjunction with bed rails; there may
be an increased risk of falls when such bed rails are
not present. Serious injury or death can result from
the use (potential entrapment) or non-use (potential
patient falls) of side rails or other restraints. Local
policies regarding the use of side rails should be
taken into account. Whether and how to use side rails
is a decision that should be based on each patient’s
individual needs and should be made by the physician,
caregivers and responsible parties.
When using the mattress system, always ensure that
the patient is positioned properly within the connes
of the bed. Do not let any extremities protrude over
the side or between the bed rails when the mattress is
being used.
Danger Explosion Hazard: Do not use in the presence
of ammable anesthetics. Do not use in the presence
of smoking materials or open ame. Air owing through
the air mattress will support combustion.
Danger: To reduce the risk of shock, adhere to the
following instructions. Failure to do so could result in
personal injury or equipment damage.
• Immediately after using the CairTurn RT, unplug it
from its power source.
• Do not place or store the product where it can fall
or be pulled into a tub or sink.
• Do not place or drop the product into water or other
liquid.
• Do not remove the back of the control unit. Refer
servicing to Joerns.
Warning: To reduce the risk of burns, shock, re, or
personal injury, adhere to the following instructions.
Failure to do so could result in personal injury or
equipment damage.
1. Use this product only for its intended purpose as
described in this manual. Only use attachments
and/or accessories that are recommended by the
manufacturer.
2. If this product has a damaged power cord or plug,
is not working properly, has been dropped or
damaged, or has been dropped into water, do not
operate it. For examination and repair, return the
product to Joerns.
3. Keep the control unit and power cord away from
heated surfaces, e.g. space heaters.
4. Never block the air openings of the product. Do
not place the control unit on a surface, such as a
bed or couch, where the air opening and/or lter
compartment, located on the back of the control
unit, may be blocked. Keep the air openings free
of lint and hair.
5. Never drop or insert any object into any opening
or hose.
6. Do not spill food or liquids onto the control unit. If
a spillage does occur, turn off the unit, disconnect
it from its power supply and allow at least 24 hours
for drying.
7. Do not use the product outdoors, or where aerosol-
spray products are used.
8. Plug this product only into a properly grounded
outlet. Refer to “Grounding Instructions”.

3
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
9. Ensure nothing is placed on the power cord and
ensure it is not located where it can be stepped
on or tripped over.
10. Do not attempt to service the control unit. Please
call Joerns for any service requests.
11. The therapy pad (top cover) of this product is not
air permeable and may present a suffocation risk.
It is the responsibility of the caregiver to ensure
that the patient can use this product safely.
Save These Instructions For Future
Reference
Bed System Entrapment Information
Although common in the practice of long-term care,
bedside rails, in recent years, have also been a
subject of regulatory review and evolution in design
and use.
That focus includes not only the challenge of achieving
an appropriate balance between patient security and
unnecessary restraint, but also the additional safety
issue of entrapment.
The U.S. Food and Drug Administration (FDA),
working with Joerns Healthcare and other industry
representatives, has addressed the potential danger
of entrapment with new safety guidelines for medical
beds. These guidelines recommend dimensional
limits for critical gaps and spaces between bed
system components.
Entrapment zones involve the relationship of
bed components often directly assembled by the
healthcare facility rather than the manufacturer.
Therefore, compliance is the responsibility of
the facility.
As the leading manufacturer of long-term care beds
and a frontrunner in addressing this critical issue,
Joerns Healthcare can offer you the expertise,
assistance and products to bring your facility
into compliance.
Joerns Compliance Solutions
Matching the right bed components in order to meet
regulatory guidelines can be complex.
That’s why Joerns offers a wide array of compliance
options. We assist customers in selecting compliant
accessories recommended for their specic
bed model.
Creating a Safer Care Environment
While the guidelines apply to all healthcare settings
(hospitals, nursing homes and home care), long-term
care facilities have particular exposure since serious
entrapment events typically involve frail, elderly or
dementia residents.
For More Information
To learn more about compliance options with
Joerns products, visit our website at www.joerns.
com, or contact our Customer Care representatives
at 800.826.0270 and ask for free informational
publications.
To learn more about entrapment zones, assessment
methods, and guidelines concerning entrapment,
contact Joerns Healthcare at 800.826.0270 or consult
the FDA website: www.fda.gov/cdrh/beds.

4
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Important Precautions .................................................................................................................................2
Introduction...................................................................................................................................................5
Moisture Control
Shear and Friction Reduction
Indications for Use .......................................................................................................................................5
Spinal Cord Injury
Pressure Relief
Pain Management
Features.........................................................................................................................................................6
Therapy Control Unit Features
Therapy Mattress System Features
Therapy Pads
Grounding Instructions................................................................................................................................7
Setup..............................................................................................................................................................7
Operation.......................................................................................................................................................8
Patient Comfort Controls and Monitoring
Additional Features......................................................................................................................................9
CPR
Transport
Power Failure
Optional Accessories
Troubleshooting ...........................................................................................................................................9
Therapy Surface Not Inating
Unable to Change Therapy Mode or Adjust Comfort Control
Nursing Procedures .....................................................................................................................................9-10
Recommended Linen
Changing the Therapy Pad
Resident Positioning and Comfort
Incontinence
Safety information........................................................................................................................................10
Patient Migration
Traction
Skin Care
Bed Height
Cleaning ........................................................................................................................................................11
Control Unit
General Cleaning
Disinfecting
Therapy Pad
Steam Cleaning
Maintenance.................................................................................................................................................. 12
Storage and Care.......................................................................................................................................... 12
Control Unit
Support Surface
System Specications .................................................................................................................................12
Weight
Dimensions
Electrical Specications
Environmental Conditions
Agency Approvals
Call for Assistance ....................................................................................................................................... 12
Warranty ........................................................................................................................................................14
Table of Contents

5
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Shear and Friction Reduction
Shearing occurs when the skin is stationary in relation
to the support surface, while the underlying tissues
and vessels are stretched and damaged. When a
patient’s skin rubs against another surface, the result
is friction. The top surface of the CairTurn RT therapy
pad is constructed from a very smooth nylon fabric
with low friction and low shear properties to protect the
patient’s skin from these damaging forces.
Indications for Use
Note: The selection of a pressure-relieving surface
needs to be based on each individual patient’s clinical
condition, diagnosis and/or co-morbidities. The choice
and use of a support surface is one factor in a holistic
program of wound care and treatment.
Spinal Cord Injury
The CairTurn RT is not recommended for use by
patients with unstable spinal fractures. Advice should
be obtained from the appropriate physician before
using the CairTurn RT system for these patients.
Pressure Relief
Pressure Ulcers Respiratory Conditions
Rehabilitation Neurology
Dermatology Burns
Amputations
Pain Management
AIDS Arthritis
Oncology
Introduction
The CairTurn RT, provided by Joerns, is a unique
bilateral rotation therapy mattress replacement system.
This system is designed to meet pressure relief and
rotational therapy needs of patients up to 350 lbs. in
weight with pressure ulcers, special respiratory needs,
and those at risk of skin breakdown.
Warning: The risk of entrapment can arise when
equipment is placed on bed frames that leave gaps
of even a few inches between the mattress and the
headboard, footboard, and bed or side rails. The
equipment is NOT to be used when such gaps are
present. See “Important Precautions” section of
this manual.
The CairTurn RT mattress replacement system is
suitable for both the treatment of existing pressure
ulcers stage I through stage IV as well as those who
have been assessed at risk from the complications
of immobility. The CairTurn RT is quiet, comfortable
and simple enough for single caregiver installation.
The user-friendly controls allow for easy adjustment of
patient comfort.
Additionally, low friction and low shear materials,
together with average interface pressures well below
capillary closure levels, means that the CairTurn RT
meets the comfort and clinical requirements of your
patients up to 350 lbs.
We have ensured that the CairTurn RT addresses the
four key areas in the treatment of compromised skin:
pressure relief, moisture control, and reduction in both
friction and shearing forces.
Moisture Control
Patients are at risk for skin maceration if excess
moisture is permitted to accumulate beneath the
patient. This may be due to perspiration, incontinence
or wound drainage.
On the CairTurn RT, moisture is controlled via the
specially treated breathable, uid-proof, urethane
coated nylon therapy pad. The moisture vapor
permeable fabric of the therapy pad allows a sufcient
amount of air to circulate beneath the pad and wicks
away excess moisture.

6
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Joerns Healthcare 1_Art Direction_Joerns Beds_700 Series_UltraCare 8page
5/2007_Page 6 of 8
The CairTurn RT provides distribution of weight over
a wide surface area, which relieves pressure against
bony prominences and provides a soft, gentle therapy
surface to lie on. For patients experiencing severe
pain and discomfort due to pressure and/or positioning
limitations, consider the CairTurn RT as an adjunct to
pain management interventions.
Note: Pressure relief and pain management are
conditions and diagnoses for which the CairTurn RT
may be indicated. Occasionally, there are orthopedic
and neurological patients that require body positioning
to be maintained in specic alignment. The use of the
CairTurn RT for these patients should be considered
on an individual basis and discussed with the
attending physician.
Features
The CairTurn RT is comprised of two components:
• Therapy control unit
• Therapy mattress system
Therapy Control Unit Features
• Eight comfort control settings to maximize patient
compliance and promote healing.
• Three modes of operation – Autorm, Therapy
(static) and Turning Therapy
• Autorm mode provides maximum air
ination designed to assist both patients
and caregivers during patient transfer
and treatment.
• Six Turn Cycle times: 20, 30, 45, 60, 90 and 120
minutes
• Preset Turn Angle for optimal rotation therapy
• Compact lightweight control unit is quiet, robust
and powerful, with an integrated carrying handle
for portability.
• Crisp, easy to read graphics for intuitive set up and
therapy control.
• Automatic panel lock out to avoid unwanted or
accidental adjustments.
• Closed loop pressure sensor control system
eliminates concerns of changes in mattress
interface pressure due to ambient temperature and
pressure changes.
• Specially designed enclosure for low noise and
durability.
• Integrated swing out hanging brackets for xing to
most bed types.
• Quick disconnect hose feature allows for rapid
attach and CPR deate at the control unit.
Therapy Mattress System Features
• Twenty individual therapy cells help to evenly
distribute the patient’s weight and maximize
pressure relief.
• Modular cell design mattress for ease of cleaning,
re-assembly and cost effective service.
• Lower two-inch therapy support cell provides
additional therapeutic support and remains inated
for up to 12 hours in the event of a power failure.
• Lower mattress therapy enclosure provides
for stable ingress and egress and reduces
entrapment concerns
• Eight-inch deep therapy cells are constructed
of highly durable, polyurethane coated nylon to
provide adequate support and prevent bottoming
out for most patients within weight limit.
• Side bolsters support patient during rotation
• Durable base tub is constructed from 100% heavy
weight 1680 denier nylon with a 1.5 oz. urethane
coating and incorporates bed attachment loops
for stability.
• Maximum weight capacity of 350 lbs.
• Quick CPR deation
• Anti-kink, easy clean air supply hose set
Therapy Pads
Many healthcare facilities are facing the challenge
of infection control. Joerns’ quilted therapy covers
are treated with an antimicrobial agent to protect
the therapy pad from the growth of mold, mildew
and bacteria.
Key features and benets:
• Treated with a highly effective bacteriostat agent
to inhibit the growth of bacteria and fungus.
• Constructed from a very smooth nylon fabric
with low friction and low shear properties to
protect the patient’s skin from damaging friction/
shearing forces.
• Breathable, moisture vapor permeable fabric
allows air to circulate beneath the pad and wicks
away excess moisture. This keeps your patient dry
and helps to prevent skin maceration.
• Two-way stretch therapy pad is designed for
optimal comfort, moisture vapor transfer, stain
resistance and ease of laundering.

7
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Grounding Instructions
Warning: Use a properly grounded, three-prong, 120V
AC outlet for this product. Failure to use a grounded
outlet could result in personal injury or damage to
equipment or house wiring, including risk of re. A
qualied electrician should be contacted to correct the
wiring and ensure a properly grounded outlet.
Before installing this product, have the electrical
system checked to make sure the electrical circuits
and the electrical service are properly grounded.
Having a three-prong outlet does not necessarily
mean it is grounded. Sometimes two-prong outlets are
replaced with a three-prong type even though there is
no ground wire.
There is always a chance of a loose connection or
poor installation of a ground wire that causes the loss
of proper ground at the outlet. Inadequate grounding
at electrical outlets can occur even if there is a
ground wire. Wires can become loose over time at the
connection to the outlet.
Note: To install new wires on a circuit requires a
qualied electrician.
How to Determine if Your Outlet has the
Proper Grounding
Most hardware stores sell circuit testers
(Figure 1) that can be used to test an
outlet for proper grounding. The tester
plugs into an outlet and by observing
the indicator lights you can determine
if the outlet is properly grounded. For a
higher level of assurance, an electrician
should be requested to thoroughly test
the electrical system with more
reliable equipment.
If repair or replacement of the cord or plug is
necessary, please contact Joerns at 800.966.6662
for assistance.
Setup
Warning: For important precautions please see
page two.
Caution: Do not place the control unit on the oor.
Position the power cord to keep personnel from
tripping over it.
Note: The CairTurn RT system must be installed on
bed frames that are equipped with side rails. Please
raise side rails on the bed and lock them in position
after the patient is on the mattress. Never leave patient
unattended on mattress system with bed side rails in
the down position.
When the product is not in use, properly store the
power cord. Failure to do so could result in personal
injury.
• Remove the existing mattress from the bed.
• Unroll the mattress with the hose connection at the
foot end of the bed and the therapy cells facing up.
Secure the straps on the mattress securely to the
movable part of the bed frame.
• If the therapy pad is not already on the mattress,
place it on the mattress. Secure the therapy pad to
the enclosure with the provided zipper.
• Hang the control unit on the foot of the bed facing
away from the bed. Attach the hose connectors to
the control unit.
• Plug in the control unit and the yellow Standby
light will illuminate. Press the Power button.
The control unit will start and the green light will
illuminate. Keep the control unit ON while the
patient is on the mattress.
• Allow thirty to forty minutes for full ination. Place
the patient on the mattress.
• Position the resident’s head in the position that
the resident will be in for the largest portion of the
day. If the resident is lying at, please use three
(3) ngers for the hand check. If the resident will
be sitting up for the majority of the day, please use
two (2) ngers.
• Perform a hand check by placing ngers locally
under the resident’s buttocks between two
cushions. The resident should not bottom out. If
they do, increase the therapy control by one LED
(light), until they no longer bottom out.
Figure 1

8
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Operation
Warning: For important precautions please see page
two.
Caution: The patient’s head should be positioned in
the center of the top section of the mattress. When
using the mattress system always ensure that the
patient is positioned properly within the connes of
the bed. Do not let any extremities protrude over the
side or between the bed rails when the mattress is
being used.
Patient Comfort Controls and Monitoring
(Figure 2)
Power Switch
The power switch is used to turn the power on and off.
Standby
When the Standby light is on, it indicates that there
has been a power interruption and the therapy control
unit is ready to be turned on. Press the Power button
and set the preferred mode of therapy and comfort
level.
Modes
Autorm
Autorm mode provides maximum air ination
designed to assist both patients and caregivers
during patient transfer and treatment. The unit will
automatically return to the Therapy mode within
approximately 12 minutes.
Therapy Modes: Therapy and Turning
• Therapy: The unit starts in the Therapy mode,
which is the standard pressure relief mode.
• Turning: The Turn mode provides a continuous
rotation cycle based on selected times and a
preset angle.
Turn Cycle Time
The CairTurn RT provides a dynamic turning support
surface for the patient. The patient will turn laterally.
The cycle starts from center (at) and turns fully
to the left, the right, and then back to the center
in the chosen cycle time (20, 30, 45, 60, 90 and
120 minutes). This lateral rotation sequence will
continuously repeat until the mode or Turn Cycle
time is changed.
Therapy Adjust
The Therapy Adjust function is located on the right
side of the control panel. The CairTurn RT can be
customized to meet individual patient needs within
a therapeutic window. Use the up and down keys to
simultaneously increase or decrease pressure in
the entire mattress. This function will not work in
Autorm mode.
Lockout
This feature is to prevent any unauthorized changes
to the patient settings. To unlock and make
adjustments to the settings, press both up and down
comfort arrows at the same time to disengage the
Lockout function. The Lockout function will return in
approximately ve minutes.
Note: The unit is designed to lock out all of the
adjustment controls after the patient has been
positioned correctly. In approximately ve minutes
after the last button has been pushed, push the power
on light begins to ash indicating Lockout is enabled.
Figure 2

9
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Additional Features
Warning: A possible re hazard exists. This
product is suitable for use with oxygen administering
equipment of the nasal, mask, or half bed-length,
tent-type only. To prevent personal injury or equipment
damage, ensure that the oxygen tent does not extend
below the mattress.
CPR
The hose connection at the control unit is marked
CPR. Disconnect the hose from the control unit.
Deation times will vary based on patient weight and
prole. To resume therapy, reattach the hose to the
control unit.
Transport
To transport the patient in bed, turn the control unit
off. Unplug the power cord from the outlet. Do not
disconnect the hose connection at the control unit.
The lower support cell will prevent the patient from
bottoming out for up to 12 hours.
Power Failure
In the event of a power failure the mattress will stay
inated for up to 12 hours while connected to the
control unit. After power has been restored, the control
unit’s Standby light will be lit. Press the power button
and reset the preferred mode and comfort level as
described in the “Operation” section.
Optional Accessories
• Additional therapy pads available for purchase
Troubleshooting
Therapy Surface is not Inflating
1. Ensure the hose connection from the therapy
mattress system (mattress) to the control unit is
securely connected.
2. Ensure that the control unit is plugged into an
AC outlet.
3. Ensure that the power is not on Standby. If on
Standby, press the Power button.
4. Ensure that all air cells are connected to the
manifold.
Unable to Change Therapy Mode or Adjust
Comfort Control
Make sure the Lockout function is disabled. To
disable, press the up and down comfort adjust arrows
simultaneously.
Nursing Procedures
Recommended Linen:
Special linens are not necessary for the CairTurn RT.
There is no need for a bottom sheet as the therapy
pad should be covering the therapy cells at all times.
The patient should never be lying directly on the
therapy cells. Depending upon the patient’s specic
needs, the following linens may be utilized:
• Draw or slide sheet to aid in positioning and to
further minimize friction and shearing
• Incontinence barrier pad for patients incontinent
of urine and/or stool, and patients with heavily
draining wounds
• Add top sheet, blanket and/or bedspread as
needed for patient comfort
• Keep the amount of padding between the patient
and bed to a minimum for optimum performance
Changing the Therapy Pad
• Place the therapy pad over the therapy cells, tting
the corner of the cushions into the corner of the
therapy pad. (Similar to a tted sheet)
• Zip the therapy pad along each side of the
mattress tub.

10
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Patient Positioning and Comfort
General Repositioning
Patients should be turned and repositioned per
individual turning schedule or per facility policy. It may
be helpful to activate the Autorm mode to achieve
a rm surface for repositioning purposes. The unit
will automatically return to the mode it was in prior to
Autorm within approximately 12 minutes or you can
manually return to therapy mode once patient has
been repositioned.
Unless counter indicated, it is desirable to keep
the head of the bed in the low position to provide
optimal pressure relief and minimize the risk of
shearing injuries.
Elevating Patient into Sitting Position
The special properties of the CairTurn RT therapy
pad reduce the opportunity for shear and friction that
may occur when raising the head of other beds. As
with any surface, sliding can be expected, therefore
patients should be repositioned after elevation. The
knee gatch or foot of the bed may be elevated rst,
to help prevent the patient from sliding when the head
of the bed is elevated.
Incontinence
Moisture against the skin surface leads to maceration,
or softening of the tissues. To prevent maceration, it
is recommended that an incontinence barrier pad be
used to absorb the excess moisture.
In the event of incontinence or excess drainage on
the therapy pad, wipe off the excess uid from the
bed surface.
Safety Information
Patient Migration
Specialty bed products are designed to reduce/
relieve pressure and the shearing/friction forces on
the patient’s skin. The risk of gradual movement and/
or sinking into hazardous positions of entrapment and/
or inadvertent bed exit may be increased due to the
nature of these products.
Traction
With any traction or unstable fractures, maintain
physician-directed angle of articulation and guard
against risks of patient migration or inadvertent
deation of patient surface.
Skin Care
Monitor skin conditions regularly, particularly in areas
where incontinence and drainage occur or collect,
and consider adjunct or alternative therapies for high
acuity patients. Early intervention may be essential to
preventing serious skin breakdown.
Bed Height
To minimize the risks of falls or injury, the patient
surface should always be in the lowest practical
position when the patient is unattended. Make sure
areas under and around the frame are clear of objects,
persons and parts of body before adjusting height.

11
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Cleaning
Warning: Unplug the control unit from its power
source. Failure to do so could result in personal injury
or equipment damage.
Warning: Do not expose the unit to excessive
moisture that would allow for liquid pooling. Personal
injury or equipment damage could occur.
Caution: Do not use harsh cleansers/detergents,
such as scouring pads and heavy-duty grease
removers, or solvents, such as acetone. Equipment
damage could occur.
Control Unit
Wipe off dust. If necessary, clean the housing exterior
with a disinfectant solution or a mild detergent and a
damp cloth. Then wipe dry.
General Cleaning
If there is no visible soilage with possible body
uids, it is recommended that the mattress system
be cleaned with a mild detergent and warm water. If
disinfection is desired, a combination
cleanser/disinfectant may be used as explained in
“Disinfecting” area.
• Patient care equipment that does not come into
contact with mucous membranes or non-contact
skin, requires low-level disinfection. Wiping
surfaces with a properly prepared detergent or
disinfectant carries out low level disinfecting.
• Processing of dirty patient care equipment should
take place in a designated area away from clean
or sterile supplies and food preparation areas.
• Detergent/disinfectants should not be mixed with
other germicides or detergents. Using the proper
dilution insures the most effective killing power of
the disinfectant.
• Wash hands often and well, including after
removal of gloves.
• Patient care equipment that is used in isolation
areas should be disinfected in accordance with
all internal policies and procedures regarding
such equipment.
Disinfecting
When there is visible soilage, and between patients,
it is recommended that the unit and mattress be
disinfected with a tuberculocidal disinfectant.
Disinfectant should be registered with the
Environmental Protection Agency (EPA).
• Use rubber gloves and eye protection.
• Prepare detergent/disinfectant (registered by EPA
as hospital disinfectant) solution according to
instructions on label for correct use-dilution.
• With support surface deated, thoroughly wipe
down entire mattress, as air cells will lie at. Be
sure to reach all areas underneath and in-between
air cells. Allow to air dry.
• If dust or other soiling has accumulated along
air hoses, remove using swabs moistened with
detergent/disinfectant as necessary. Allow all
components to air dry. Wrap mattress in plastic
and return to storage area.
• Thoroughly wipe down outside of control unit and
allow to air dry. Cover with plastic and return to
storage area
• Remove gloves and dispose; wash hands.
Therapy Pad
The therapy pad can be wiped down with a disinfectant
solution or a mild detergent with a damp cloth. If
heavily soiled, the therapy pad can be laundered in a
washer and dryer with warm water (no more than 120º
Fahrenheit). A non-bleach detergent should be used
sparingly. Wipe dry or allow to air dry.
Steam Cleaning
Do not use any steam cleaning device on the unit.
Excessive moisture can damage mechanisms in
this unit.

12
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Maintenance
Warning: Only facility-authorized personnel trained
by Joerns should perform preventative maintenance.
Preventative maintenance performed by unauthorized
personnel could result in personal injury or equipment
damage.
Any maintenance done without Joerns’ authorization
will invalidate any warranties on this product.
Storage and Care
Note: Clean the CairTurn RT as described in the
previous section prior to storage.
Control Unit
The power cord may be wrapped around the unit for
convenience. Wrap the unit in a plastic bag for dust
resistance then store the unit in an area appropriate
for an electronic medical device.
Support Surface
Gently roll up the support surface, expelling any
residual air, for temporary storage. The mattress
should be wrapped in plastic and/or a clean bag
for storage.
System Specifications
Weight
Control unit: .........................12 lbs. (5.4 Kg)
Mattress:..............................22 lbs. (10 Kg)
Maximum weight capacity: ..350 lbs. (159 Kg)*
Dimensions
Control unit:
12" (30 cm) W x 9" (23 cm) H x 6.5" (16.5 cm) D
Mattress:
36" (91 cm) W x 80" (203 cm) H x 10" (25 cm) D
Electrical Specifications
USA
115V AC, 60 Hz, 0.5A
Environmental Conditions
Operating Conditions
Ambient Temperature: +10ºC to +40ºC
Relative Humidity: 30% to 75% Non-Condensing
Storage and Shipping Conditions
Ambient Temperature: -10ºC to +40ºC
Relative Humidity: 10% to 100%
Agency Approvals
• UL Classied Medical Equipment UL 60601-1
Can/CSA C22.2 No. 601.1
UL Classication refers to the power unit only, not the
complete mattress replacement system.
Call for Assistance
If you have any questions or require service on
a Joerns product, please call Joerns
at 800.966.6662
* Mattress weight capacity only; total weight must
not exceed bed frame manufacturers’ specied
load capacity.

13
Joerns® Support Surface
CairTurn RT
© 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Notes:

Joerns Healthcare Warranty Program
for Upholstered Furniture
Post Acute, Acute, HomeCare
2430 Whitehall Park Dr. Ste 100
Charlotte, NC 28273
(P) 800.826.0270
(F) 800.457.8827
VA/Government
19748 Dearborn Street
Chatsworth, CA 91311
(P) 800.966.6662
(F) 800.232.9796
Canadian Ofce
1000 Clarke Rd. Ste 6
London, ON Canada N5V 3A9
(P) 866.546.1151
(F) 519.451.8662
United Kingdom and
Other Countries
[phone]
[phone]
Netherlands
[phone]
[phone]
www.joerns.com • email: [email protected] © 2015 Joerns Healthcare • 6110068 RevC • 15-2543
Joerns Healthcare 1_Art Direction_Joerns Beds_700 Series_UltraCare 8page
5/2007_Page 8 of 8
Joerns warrants the CairTurn RT mattress to be sold
free from defects in workmanship and materials,
under normal and proper use, for a period of two
(2) years on the mattress, and one (1) year on the
cover and electromechanical mattress components
(compressors, valves, printed circuit boards, hoses,
and couplers). Damages arising from improper use will
not be covered by this warranty.
Improper use is dened as, but not limited to, those
caused by:
• Burns
• Use of improper chemical agents
• Needle punctures, cuts, or abrasions
• Excessive loads
• Staining
• Negligent or excessive usage
• Improper maintenance, handling and/or cleaning
• Failure to use in the manner indicated in the
CairTurn RT user manual
Any modication, repair or alteration done to the
CairTurn RT that was not authorized in writing by
Joerns will void this warranty.
Damage caused by use in unsuitable environmental
conditions, abuse or failure to maintain the product in
accordance with user and service instructions is not
covered.
This warranty is extended to the original purchaser of
the equipment.
Parts
Joerns’ CairTurn RT contains various parts that wear
from normal use. Joerns’ obligation under this warranty
is limited to supplying replacement parts, servicing or
replacing, at its option, any product which is found by
Joerns to be defective. When requested by Joerns,
parts must be returned for inspection at the customer’s
expense. Credit will be issued only after inspection.
Service
Most service requests can be handled by the facility
Maintenance Department with assistance from the
Joerns Product Service Department.
Most parts requested can be shipped next day air at
the customer’s expense.
Should a technician be required, one will be provided
by Joerns, at our discretion. Only the Joerns Product
Service Department can dispatch authorized
technicians.
Manufactured by:
Joerns Healthcare, LLC
2100 Design Rd.
Arlington, TX 76014
