John Lewis Apollo 803/41301 User manual

John Lewis
Apollo Bedstead
SINGLE
Pre-assembly Preparation
Please ensure instructions are read in full before attempting to assemble this product
Necessary Tools
Please check the pack contents before attempting to assemble this product. A full checklist of
components is given in this leaflet.If any components are missing, please contact the John Lewis Helpline.
This product is Heavy, it should be assembled as near as possible to the point of use. TAKE CARE
WHEN LIFTING to avoid personal injury and (or) damage to the product.
This product takes approximately 40 MINUTES to assemble with 2 PEOPLE.
The fittings pack contains SMALL PARTS which should be KEPT AWAY FROM YOUNG
CHILDREN.
Read this leaflet in full before commencing assembly.
If you require any additional information or have any issues with this product please call the John Lewis
Helpline on 01244 - 689949 or e-mail: [email protected]
For product support or spare parts
please call the John Lewis Helpline;
Tel: 01244 - 689949
e-mail:[email protected]
Stock number: 803/41301

N
Wooden Slats
Fitting and parts checklist
Bolt 2
Bolt 8

1
2
3
3
Step by step assembly instructions
Step One
Attach the Side Rails (3) to the Headboard (1) and Footboard (2) using Washer (A) and
M6 x 25mm Bolt (C). Tighten using Allen Key (F) as shown in the diagram below.
Repeat this for all 4 corners.
Step Two
Place the Cross Bar (5) onto the Side Rails (3) and secure using M6 x 20mm Bolt (B) and
M6 Nut (D). Tighten using Allen Key (F) as shown below.
A
C
F
3/5
Note: Please ensure the Side Rails (3) are assembled correctly,
there is a label indicating the left and right hand side.
Note: In order to attach the Cross Bar (5) please ensure
the Side Rails (3) are assembled correctly.

Step Three
4
3
3
1
E
E
E
This bed is now ready to use.
Starting at the head end, take a Wooden Slat (4) ensuring the curved side is facing up and place a Side
Plastic Holder (E) onto each end of the Slat (4). Secure to the bed by pushing each end into the pre-drilled holes
along the Side Rail (3) as shown in the diagram below. Repeat this step until all of the Slats (4) are secured.

This product complies with BS 1725:1998
