John Lewis Scandi Solution User manual

Scandi Solution Dresser
H:92 W:99.8 D:54.9cm
INSTRUCTION MANUAL

01
Important safety
information
Introduction Thank you for purchasing this scandi solution dresser.
Please read the instructions carefully before
use to ensure safe and satisfactory operation
of this product.
Tools required
Warning: In order to prevent overturning, this product must be used
with the wall attachment device provided.
Serious or fatal crushing injuries can occur from furniture tipping over.
To help prevent topple over, please observe the following:
1. Use the wall attachment device provided
2. Never allow children to climb or hang on drawers, doors or shelves.
3. Place heaviest items in the lower drawers or shelves.
4. Never open more than one drawer at a time.
An attachment device is provided with your product; however, you will need
Always ensure the wall to be drilled is free from hidden electrical wires,
water and gas pipes.
Time to assemble
2.5hours
People to assemble

02
Warnings
Keep small parts out of reach of children.
Ensure the product is fully assembled as illustrated before use.
Care should be taken that no screws are loose because a child could trap
parts of their body, or clothing (e.g. strings, necklaces, ribbons, dummies, etc)
which could pose a risk of strangulation.
Ensure that the wall strap is used to securely attach the dresser to the wall
to prevent tipping.
Any additional or replacement parts must only be obtained from
John Lewis & Partners.
Do’s
Check the pack and make sure you have all the parts listed.
Check all screws or bolts are tightened and inspect regularly.
Make sure the legs remain in contact with the ground at all times.
Don’ts
Do not over tighten screws or bolts.
Do not stand on the product.
Do not use power tools to construct as over tightening and panel failure
may occur.

03
Parts list
Ref Descriptions Dimensions(cm) Qty
1
Top panel
1
2
Middle panel 1
3
1
4
1
5
back panel
1
6
front panel
1
7
side panel
1
8
1
9
Back upper rail
2
10
1
11
1
12
13
14
15
1
3
3
3
16
17
3
3
Internal dimensions
Stock number: 32431901 Drawer siz e: H:59.9 W:44.6 D:22.5cm
Cabinet overall size: H:83.6W:99.8 D:54.9cm size: H:89.4 W:49.9 D:8.4cm
Side panel / L
Back panel
H 99.8 W50.3 D6
H 99.8 W48 D11
H 70.5 W48 D4.8
H 70.5 W45.8 D 4.8
H 70.5 W48 D4.8
H 97 W39.4 D0.5
H 89.4 W10.2 D1.8
H 89.4 W8.4 D1.8
H 46.3 W8.4 D1.8
H 96 W16 D1.8
Back lower rail H 96 W16 D1. 8
H 52.3 W16.8 D1.2
H 40 W16.8 D1.2
H 40 W16.8 D1.2
H 53.3 W39.8 D0.5
H59.9 W22.5 D1.8
18
19
Hanging rail 1
Base panel
H 68.1 W39.6 D1.8
Door
base panel 1
H 86.8
W47.3 D0.5
H 361 W30 D15
Changing table
Changing table
Changing table
Changing table
Changing table
L side of drawer
Front of drawer
R side of drawer
Back of drawer
Base of drawer
Side panel / R

04
Fixtures and fittings
supplied
Ref Descriptions Dimensions Qty (not actual size)
A
Cam heals
BCam rods
C
D
Clothes holder
E
Screw
F
G
H
Allen key M4
O
Metal ‘L’ Bracket
and screws to attach
to product
12
12
4
Ф12*10.5mm
Ф7*27.5mm
Ф4*30mm 12
2
Ф4*30mm
50*20*22mm
1
I
Cam heals
21
Ф15*13.5mm
J
Cam rods
21
Ф7*42mm
K
Wooden handle 4
Screw Ф3.5*16mm 14
L
Ф6*40mm 6
M
Hinge 2
N
34*34*28mm
1
Ф5*30mm 2
Ф6*13mm 1
120*55*20mm
65*25mm
Connecting bolts
Connecting bolts
Connecting bolt
Connecting bolts

05
Product assembly

06
Product assembly

07
Product assembly

08
Product assembly

09
Product assembly

10
Product assembly

11
Product assembly

12
Product assembly

13
Product assembly

14
Product assembly
WARNING:
DO NOT LEAVE THE CHILD UNATTENDED.
FALL HAZARD:
To prevent death or serious injury, always keep child within arm's reach.







15
Wall mounting
and fixings Warning
In order to prevent overturning this product must be used with the wall
attachment device provided.
Installation shall be carried out exactly according to the instructions provided -
otherwise a safety risk can occur if incorrectly installed. Failure of the product
Important: When drilling into the walls always check that there are no hidden
wires or pipes etc.
Types of walls
You can use one of the following types of wall plug if your walls are
made of brick, breezeblock, concrete, stone or wood.
1. General Purpose wall plug
（Generally aerated blocks should not be used to support heavy)
(purpose wall plugs can be used.)
2. Plasterboard wall plug
(For use when attaching light loads on to plasterboard partitions.)
3. Cavity Fixing wall plug
(For use with plasterboard partitions or hollow wooden doors.)
4. Cavity Fixing- Heavy Duty wall plug
(wall cabinets and coat racks.)
5. Hammer Fixing wall plug
6. Shield Anchor wall plug - Heavy loads
(For use with heavier loads such as 1V and Hi-Fi speakers and
satellite dishes etc.)
Care and maintenance
Safety:
(they have not come loose and retighten as necessary.)

Care and
maintenance
Wood furniture
Wood displays different grain patterns depending on which way they are cut —
a nac hcihw ’yar yralludem‘ eht ,elpmaxe rof ppear on oak furniture is a mark of
good quality timber — these are just characteristics of the natural beauty of the
wood. Some furniture is also deliberately aged and rustic.
Wood veneers also allow a distinctive pattern to be created on some surfaces,
such as tabletops and drawer fronts by the way slivers are arranged.
All timber and veneer surfaces will change .emit revo wollem dna ruoloc
neeb evah taht smeti morf edahs ni yrav yllaitini lliw erutinruf weN
previo s .deahcrup ylsu
erutinruf doow ruoy rof erac ot woH
Furniture with a hard lacquer, wax polish or painted surface should be dusted
with a dry cloth.
Waxed furniture will need to be given a coat of beeswax a couple of times a
year to help maintain it’s lustre. Spray polishes are best avoided as they contain
silicones which may spoil the furniture’s surface when building up over time.
Make sure all surfaces are protected from heat and liquids by mats and coasters.
Wipe up spills immediately and ensure that a mat or pad Is placed under paper if
you are writing.
Our furniture will endure most temperatures in the home, but it is best to avoid
)
(
(
careful with solid wood as the lack of humidity caused by home heating can
cause damage such s warpi .gna
snoitcurtsni ytefaS
to ensure none have come loose and retighten when n ces ekat esaelP .yrase
care when handling or moving the furniture as careless handling may cause
damage or injury.
Furniture can be dangerous If incorrectly installed. Assembly should be carried
out by a competent person. No liability will be accepted for damage or injury
caused by incorrectly installed or a s .erutinruf delbmes
Your feedback is very important to us and we would love to hear your
comments on your new furniture. Please visit our website to leave a review.
Thank you.
16
)

John Lewis Partnership
171 Victoria Street
London SW1E 5NN
johnlewis.com
anihC ni edaM Please retain these instructions for future reference.
17
Safety notes WARNING:
* All assembly fittings shall always be correctly tightened and checked
regularly.
* Be aware of the risk of open fires and other sources of strong heat, such
as electric bar fires, gas fires, etc. in the near vicinity of the changing unit.
* Recommended pad size is shown on carton marking.
* This changer is intended for children under 12 months,and lighter than
11kg.
* Any additional or replacement parts shall only be obtained from the
manufacturer or distributor.
* Not to use the changing unit when any part is broken, torn or missing.
* Assembly to be carried out by a competent adult only.
* During assembly children should be kept away from the product due to
possible risk of injury.
* Do not use this item if any components are missing or damaged.
* This dresser is suitable for children in 3–12 years.
* Do not leave the child unattended.
* This product is not intended to be used as a table. Use of the product
* Follow all instructions on attaching and using the changer.
* When lockable castors/wheels are fitted, they shall be locked when the
changing units is in use.
without instruction may result in death or serious injury to your child
from falling.
