Jole litetrax 3 User manual

litetrax™3
stroller
gemm™
0+ (0–13kg)
birth to 15kg/(birth - 36 months)
GB Instruction Manual

12
FIGURE 1 ~ 3
FIGURE 1 ~ 3
11 2
3
2
1
4
5
10
7
11 12
1
1
1
2
2
2
FIGURE 1 ~ 3FIGURE 1 - 5
FIGURE 7 - 12
FIGURE 12 - 16FIGURE 12 - 16FIGURE 12 - 16FIGURE 1 ~ 3
FIGURE 1 - 6
1
2
1
8
6
1
2
9

34
16
15
14
3
1
A
2
B
13
1 2 3
17
1
3
2
22
18
1
2
1
2
19
20 21
FIGURE 13 - 17
FIGURE 18 - 22

5
26
25
NOISE
1
2
Care and Maintenance
6
23
1
2
29
27
30
28
a4
a2
a1
a3
Accessories (May not be included in purchase)
Accessories may be sold separately or may not be available depending on region.
24
FIGURE 23 - 26
FIGURE 27 - 30

78
GB Welcome to Joie™
Congratulations on becoming part of the Joie family! We are
so excited to be part of your journey with your little one. While
traveling with the Joie Litetrax™, you are using a high quality, fully
certified stroller, approved to Australian Trade Practices Act 1974
Consumer Protection Notice No 8 of 2007. This product is suitable
for use with children weighing under 15kg. Please carefully read
this manual and follow each step to ensure a comfortable ride and
best protection for your child.
IMPORTANT - Keep these instructions for future reference.
Visit us at joiebaby.com to download manuals and see more excit-
ing Joie products!
Contents
Figures 1-6
WARNING 9
Stroller Assembly 11
Open Stroller 11
Assemble Front Wheel 11
Assemble Rear Wheels 11
Assemble Armbar 11
Stroller Operation 11
Adjust Backrest 11
Use Buckle 12
Use Shoulder & Waist Harnesses 12
Adjust Calf Support 12
Use Front Swivel Lock 13
Use Brake 13
Use Hood 13
Use Tether Strap 13
Fold Stroller 13
Use Accessories 13
Care and Maintenance 14
Emergency
In case of emergency or accident, it is most important to have your child
taken care of with first aid and medical treatment immediately.
Product Information
Read all the instructions in this manual before using this product. If you
have any further questions, please consult the retailer. Some features may
vary depending on model.
Product Litetrax Stroller
Suitable for Child weighing under
15kg (birth - 36 months)
Materials Plastics, metal, fabrics
Patent No. Patents pending
Parts List
Make sure all parts are available before assembly. If any part is missing,
please contact local retailer. No tools are required for assembly.
6
4
5
7
8
9
10
11
1
2
3
Accessories
(Non-included)
1 Rain Cover (on certain models)
2 Footmuff (on certain models)
3 Armbar Cover (on certain models)
2
1
3
16
17
14
12
13
15
18
Made in China
Brand Name Joie
Website www.joiebaby.com
Manufacturer Allison Baby UK Ltd
1 StrollerFrame
2 Front Wheel
3 Rear Wheels
4 Hood
5 Seat Pad
6 Armbar
7 Calf Support
8 Front Wheel
9 Swivel Lock
10 Storage Basket
11 Shoulder Harness
12 Handle
13 Window
14 Rear Wheel
15 Brake Lever
16 Storage Mount
17 Storage Latch
18 Tether Strap

910
!Never allow your child to stand on the stroller or sit in the stroller with
head toward front of stroller.
!Never place the stroller on roads or dangerous area.
!The stroller is designed for use on flat or gently sloping surfaces and
may be unstable on higher sloping and uneven surfaces, and users
should be made aware of the possibility of the stroller tipping over.
!Do make sure all parts are assembled and fastened properly before
using the stroller.
!To avoid strangulation, do not place items with a string around your
child’s neck, suspend strings from this product, or attach strings to
toys.
!To prevent tipping, do not put anything on the handle. Always lift the
child in and out of the stroller.
!Do not lift stroller while child is in stroller.
!Do not use storage basket as a child carrier.
!To prevent tipping, never let child climb the stroller.
!To avoid finger entrapment, use care when folding and unfolding the
stroller.
!Be sure the stroller is fully open or folded before allowing child near the
stroller.
!To ensure your child’s safety, please make sure all parts are assembled
and fastened properly before using the stroller.
!Check that the child restraint attachment device is correctly engaged
before use.
!To avoid strangulation, do make sure your child is clear from the hood.
!Discontinue using your stroller if it is damaged or broken.
!Stroller to be used only at walking speed. This product is not intended
for use while jogging.
!To avoid suffocation, remove plastic bag and packaging materials
before using this product. The plastic bag and packaging materials
should then be kept away from babies and children.
!This product is not suitable for running or skating.
!Pushchair designed to be used from birth shall recommend the use of
the most reclined position for new born babies.
!The parking device must be engaged when placing and removing
children.
!For child restraints used in conjunction with a chassis, this vehicle does
not replace a cot or a bed. Should your child need to sleep, then it
should be placed in a suitable pram body, cot, or bed.
WARNING
!TO AVOID INJURY OR DEATH: ALWAYS APPLY THE BRAKES
WHENEVER THE STROLLER IS STATIONARY.
!DO NOT LEAVE CHILDREN UNATTENDED. ALWAYS KEEP CHILD IN
VIEW WHILE IN STROLLER.
!ALWAYS USE THE CROTCH COMBINATION WITH THE WAIST BELT.
IT IS SUGGESTED THAT THE SHOULDER HARNESSES BE USED AS
WELL.
!DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS STROLLER.
!MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS IF YOU
ADJUST THE STROLLER.
!TO AVOID SERIOUS INJURY FROM FALLING OR SLIDING OUT,
ALWAYS USE SEAT BELT.
!USE THIS TETHER STRAP TO STOP THE STROLLER ROLLING AWAY.
!Ensure that all the locking devices are engaged before use.
!Do not let your child play with this product.
!A warning to never leave the harness buckled when not fitted to a child
in the stroller because the harness can form loops which may pose a
strangulation hazard.
!It is unsafe to use accessories other than those approved by the vehicle
manufacturer.
!Adult assembly required.
!Use of the stroller with a child weighing more than 15kg will cause dam-
age to the stroller.
!To prevent a hazardous, unstable condition, do not place more than
4.5kg in the storage basket.
!Overloading, folding incorrectly, or using component parts from other
manufacturers may cause the stroller to be damaged, broken or unsafe.
Please read the instruction manual carefully.
!Please read all the instructions in the manual before using the product.
Please save instruction manual for future use. Failure to follow these
warnings and instructions may result in serious injury or death.
!Safety belts and restraint system must be used correctly.
!Child may slip into leg openings and be strangled if the harness is not
used.
!Never use stroller on stairs or escalators.
!The stroller not be used near an open fire or exposed flame.
!

11 12
Stroller Assembly
Please read all the instructions in this manual before assembling and
using this product.
Open Stroller
Separate storage latch from storage mount 1, and then lift the handle
upwards 2, a click sound means the stroller is open completely.
!Check that the stroller is completely open before continuing.
Assemble Front Wheel
Assemble front wheel to front leg. Check that the front wheel is securely
attached by pulling on wheel assembly. 3
To disassemble front wheel, detach front wheel from front leg 4- 2 while
pressing the release tabs outwards. 4- 1
Assemble Rear Wheels
Align the axle of the rear wheel with the rear wheel mount, and then insert
to assemble the rear wheel 5. Check that wheels are securely attached by
pulling on wheel assemblies.
To disassemble rear wheel, detach rear wheel from rear wheel mount 6- 2
while pressing the release button. 6- 1
Assemble Armbar
Align the armbar end slider with matching fixing slot, and then insert to
lock. 7
To disassemble armbar, press armbar release button 8- 1, and then pull
up the armbar. 8- 2
The completely assembled stroller is shown as 9
Stroller Operation
Adjust Backrest
Recline Backrest
Pull the backrest backwards, while pressing the button in the center of the
angle adjuster. 10
Raise Backrest
Push the backrest forwards, while pulling the webbing at the end of the
angle adjuster. 11
!Make sure the recline is set properly for use.
Use Buckle
Release Buckle
Press the center button to release the buckle. 12
Lock Buckle
Match the waist belt buckle with the shoulder buckle 13 - 1, and click into
the center buckle. 13 - 2
A “click” sound means the buckle is locked completely. 13 - 3
!To avoid serious injury from falling or sliding out, always secure your
child with harness.
!Make sure your child is snugly secured. The space between the child
and the shoulder harness is about the thickness of one hand.
!Do not cross the shoulder belts. This will cause pressure on child’s neck.
Use Shoulder & Waist Harnesses
!In order to protect your child from falling out, after your child is placed
into the seat, check whether the shoulder and waist harnesses are at
proper height and length.
14 - 1 Shoulder harness anchor A
14 - 2 Shoulder harness anchor B
14 - 3 Slide adjuster
For larger child, use shoulder harness anchor A and the highest shoulder
slots. For smaller child, use shoulder harness anchor B and the lowest
shoulder slots.
To adjust the position of the shoulder harness anchor, turn the anchor to
be level with the side facing forward. Thread it through the shoulder
harness slot from back to front. 15
Rethread it through the slot that is closest to child's shoulder height. 16
Use slide adjuster to change the harness length. 17 - 1
Press the button 17 - 2, while pulling the waist harness to proper length.
17 - 3
Adjust Calf Support
The calf support has 2 positions.
Raise Calf Support
To raise the calf support, just push it upwards. A "click" sound means the
calf is locked completely.
Lower Calf Support
Press the adjustment buttons on both sides of the calf support 18 - 1, and
rotate the calf support downwards. 18 - 2

14
Use Front Swivel Lock
Push down the front swivel locks to maintain the moving direction. 19
Tip It is recommended to use swivel locks on uneven surfaces.
Use Brake
To lock wheels, step the brake lever downwards. 20
To release wheels, just lift the brake lever upwards. 21
Tip Always apply brake when stroller is in stopped position.
Use Hood
The hood can be opened or folded, pull it toward front or back.
The hood can be opened completely to protect your child from the sun
uttermostly, just unzip the hook 22 -1, and then pull the hood toward front.
There is a window on the hood, through which you can view your baby.
Roll up the backward panel and stick the hook and loop fastener, then you
can view your baby. 22 -2
Use Tether Strap
Use the tether strap to prevent the stroller inadvertently rolling away.
If you cannot easily control the stroller move the tether to a different
position.
1. To disassemble tether strap. Select a position high up on the handle and
wrap the tether strap around the handle and thread the larger loop
through the smaller loop, pull tight. 23
2. Check that when your hand is through the loop, the position selected
allows you to easily control the stroller.
Fold Stroller
!Please fold the hood before folding the stroller.
Pull the folding webbing upward, the frame will automatically fold
backward. 25 -1
The storage latch will automatically hook onto the storage mount, then the
stroller is folded and locked completely. 25 -2
Use Accessories
Accessories may be sold separately or may not be available depending on
region.
Use Footmuff
The soft footmuff can provide your child with a warm and comfortable
environment.
Assemble the footmuff by following these steps.
1. Place the footmuff over the seat after unziping it, thread the shoulder
harnesses, waist harnesses and crotch harness through respective
slots. 27
2. Thread loop fastener on the top of the footmuff through the backrest, and
then stick it to the hook fastener.
28
3. Place baby into the footmuff, lock the safety buckle, and then rezip
the footmuff.
The assembled footmuff is shown as 29
Use Rain Cover
To assemble the rain cover, place it over the stroller, and then attach the 8
pairs of hook and loop fasteners on the rain cover. 30
!Before using the rain cover, please make sure the backrest has been
adjusted to the lowest position and the infant child restraint has been
fastened.
!When using the rain cover, please always check its ventilation.
!When not in use, please check that the rain cover has been cleaned and
dried before folding.
!Do not fold the stroller after assembling the rain cover.
!Do not place your child into the stroller assembled with rain cover during
hot weather.
Care and Maintenance
!Removable seat pad may be washed in cold water and drip-dried. No
bleach.
!To clean stroller frame, use only household soap and warm water. No
bleach or detergent.
!From time to time, check your stroller for loose screws, worn parts,torn
material or stitching. Replace or repair the parts as needed.
!Excessive exposure to sun or heat could cause fading or warping of
parts.
!If stroller becomes wet, open hood and allow to dry thoroughly before
storing.
!If wheels squeak, use a light oil (e.g., Silicon Spray, antirust oil, or sewing
machine oil). It is important to get the oil into the axle and wheel
assembly. 26
!When using your stroller at the beach, completely clean your stroller after
use to remove sand and salt from mechanisms and wheel assemblies.
13

JK030_S1112$F
Share the joy at joiebaby.com
gemm™
0+ (0–13kg)
Allison Baby UK Ltd,
Venture Point, Towers Business Park
Rugeley, Staffordshire, WS15 1UZ
