JOYTECH SW300DC User manual

SW300DC
Swing Gate Opener
User Manual

CONTENTS:
1. Safety Instruction.....................................................................................................................1
2. Packing List.............................................................................................................................2
3. Technical Parameters..................................................................................................................3
4. Installation Drawing.................................................................................................................4
5. Tools Needed for Standard Installation....................................................................................4
6. Cable List.................................................................................................................................5
7. Direction of Gate Opening.......................................................................................................6
7.1 Gate Opens Inwards.......................................................................................................................6
7.2 Gate Opens Outwards....................................................................................................................6
8. Installation Steps.....................................................................................................................7
8.1 Preparation before Main Machine Installation..........................................................................7
8.1.1 Cable Bury.........................................................................................................................7
8.1.2 Mounting Brackets Fixing.........................................................................................................7
8.2 Accessory Installation..................................................................................................................7
8.3 Dimension of Control Box.............................................................................................................10
9. Wiring and Debugging......................................................................................................................11
9.1 Wiring Instructions.........................................................................................................................11
9.2 Control Board Drawing and Instructions.......................................................................................12
9.3 Digital Screen Setting....................................................................................................................13
9.4 Travel Setting................................................................................................................................13
9.5 Trimmer Setting.............................................................................................................................14
9.6 Learning Remote Control & Delete Remote Control.....................................................................14
9.6.1 Learning Remote Control.......................................................................................................14
9.6.2 Delete Remote Control..........................................................................................................14
9.6.3 Special Remote Control Key-button.......................................................................................15
9.7 Control Board Settings........................................................................................................15
9.7.1 Base Menu.............................................................................................................................15
9.7.2 Base Menu Instruction...........................................................................................................17
9.7.3 Advanced Menu.....................................................................................................................19
9.7.4 Advanced Menu Instruction....................................................................................................21
10. Others..................................................................................................................................23
10.1 Maintenance................................................................................................................................23
10.2 Troubleshooting...........................................................................................................................22

1
Dear users,
Thank you for choosing this product. Please read the manual carefully before assembling and using it.
Please do not leave out the manual if you send this product to a third party.
1. Safety Instruction
Please read this manual carefully before installation, in which involves with important information about
installation、using、maintenance and safety.
Any undefined operations under this manual is not allowed, incorrect using may damage the product
even causing the injuries or property losses.
To consider the possible danger during the installation or using process of swing gate operator,
installation must strictly comply with the construction standard and electrical operating procedure.
Before installation, please make sure that the power voltage being used matches with the supply
voltage of this product. Please check if the leakage protection switch is installed and the grounding
system is correct.
Please check if additional equipment or materials are required to meet the specific requirements.
The disposal of packaging material must be complying with the local regulation.
Please do not change any parts except for those defined under this manual. Any undefined changes
may cause the malfunction. Any damages to the product arising therefrom shall be beyond the liability
of the company.
Please do not leak water or any liquid into the controller or any other open devices. Please disconnect
the power immediately if any mentioned cases happened.
Please keep this product away from heat and open fire. Or it may damage the components; cause the
failure or other hazards.
Please make sure there is no vehicles、passengers and objects passing through while the swing gate is
moving.
Anti-clip equipment like infrared protection switch must be installed to avoid injuries to person and
property losses. The company shall not be liable for any damage or accident arising therefrom.
The installation、using and maintenance of this product must be carried out by professionals.
Children are not allowed be touch the control devices or remote transmitters.
A warning sign must be placed somewhere on the swing gate according to the national standard.
Please keep this instruction properly for future reference.

2
2. Packing List (Standard)
No.
Name
Quantity
1
Main machine
2
2
Control box
1
3
Manual release key
2
4
Remote control
2
5
Wall bracket
4
6
Front mounting bracket
2
7
Connecting bracket
2
8
Screw M8X25
4
9
Mounting screw (short)
2
10
Screw M8×45
2
11
Self-locking Nut M8
8
12
Limit stopper
1

3
Packing List (Optional)
No.
Name
Quantity
1
Infrared sensor
1
2
0
8
5 6
97
4
1 2 3
Wireless keypad
1
3
Alarm lamp
1
4
Electric lock
1
5
Storage battery
2
Due to the difference of installation environment, our company does not provide the installation
accessories to fix and connect gate openers and wall. Please prepare the these installation accessories
according to actual site situation.
3. Technical Parameters
Model
SW300DC
Power supply
220V/50Hz;110V/60Hz
Motor power
50W
Gate moving speed
18~22s/ 90°
Max.single-leaf weight
300kg
Max.single-leaf length
2.5M
Max.force
2600N
Max.piston stroke
32cm
Remote control distance
≥≥30m
Remote control mode
Single/Four button mode
Storage battery (optional)
DC24V(4.5Ah or 9Ah)
Noise
≤≤58dB
Recording of up remote controls
20pcs
Remote frequency
433.92 MHz
Working temperature
-20°C - +70°C
Package weight
14kg

4
4. Installation Drawing
Figure 1
SW300DC swing gate opener is applicable to single leaf gate weight less than 300kg, and the length shorter
than 2.5m. The drive mode adopts planetary transmission to combine with the screw rod transmission.
This gate opener must be installed inside the enclosure or yard for protection.
5. Tools Needed for Standard Installation
No.6 Allen
Wrench
Spirit Level
Slotted
Screwdriver
Tape
Phillips
Screwdriver
Adjustable Wrench X
2
Hatching Pen
Note: the cables must be suitable for outdoor use.

5
6. Cable List
Cable Application
Cable Material
Max. Length
1
Cable of 220V controlbox’s power supply
3×2.5mm² (＞30m)
3×1.5mm² (＜30m)
Unlimited
2
Cable of gate opener’s power supply
2×1.5mm²
15m
3
Cable of infrared sensor
2×0.5mm²
10m
4
Cable of alarm lamp
2×0.5mm²
10m
5
Cable of electric lock
2×0.5mm²
10m
6
Extension cable of storage battery
2×1.5mm²
10m
7
Cable of solar power
2×1.5mm²
10m
Due to different installation environments, installer need to prepare power cables for control box and for
gate openers.
Note: cable outlet should be downward to prevent rainwater from entering wire along the cable.

6
7. Direction of Gate Opening
7.1 Gate Opens Inwards
Figure 2
7.2 Gate Opens Outwards
Figure 3
A
B
100mm
120 mm
140 mm
160 mm
180 mm
200 mm
100mm
102°
101°
99°
98°
97°
97°
120mm
111°
108°
106°
104°
103°
99°
140mm
118°
115°
112°
102°
93°
96°
160mm
117°
107°
98°
91°
180mm
103°
96°
90°
200mm
94°

7
A
B
100mm
120 mm
140 mm
160 mm
180 mm
200 mm
100mm
103°
101°
99°
98°
97°
97°
120mm
111°
108°
106°
104°
103°
96°
140mm
118°
115°
112°
102°
92°
160mm
117°
108°
98°
91°
180mm
103°
96°
90°
200mm
94°
8. Installation Steps
8.1 Preparation Before Main Machine Installation
a) Before installing the gate opener, please confirm that the gates were installed correctly, please
ensure that the gate can be manually operated smoothly, and the gate safety stopper can effectively
prevent the gate to continue moving.
b) Please keep a distance of 45-50mm between the gate bottom and the ground for installing the
electric lock. If electric lock is not required, the distance between the gate bottom and the ground should
be ≥20mm;
c) The recommended mounting height of the 2 main machines is around 300 ~ 800mm above the
ground, and make sure there are reliable fixed points for mounting brackets.
8.1.1 Cable Bury
In order to ensure the normal operation of the gate opener and protect the cable from damage, please
use two PVC pipes to bury the motor and power cables, and the control cables separately. One PVC
pipe for motor and power cables, the other one for control cables.
8.1.2 Mounting Brackets Fixing
In order to install the SW300DC main machines firmly, it is recommended to use the expansion screws
to fix the mounting brackets.
8.2 Accessory Installation
A) Before installing the main machines, please install the wall bracket on the wall first, then fix the
connecting bracket, finally install the front mounting bracket on the gate.
Note: Please detect by gradienter before fixing to ensure that the front mounting bracket and the connecting
bracket are in the same level.
Connect the connecting bracket and two wall brackets, please refer to Figure 4.

8
Figure 4
B) The connecting bracket and the wall bracket can be connected according to different conditions,
please refer to figure 5.
Figure 5
C) Before the installation, please unlock the two main machines. Unlock method: Open the manual
release cover, insert the manual release key, rotate the key until it’s released, as shown in Figure 6,
then turn the telescopic arm, you’ll find it’s stretched by hand easily.
Figure 6
D) Connect the main machine with connecting brackets by screw and nut as shown in Figure 7.

9
Figure 7
E) As shown in figure 8 below, connect wall bracket with wall according to marked position. Then,
connect main machine with wall bracket by screw and nut. (Please use spirit level to make sure the
installation levelness.)
Figure 8
Figure 9

10
8.3 Dimension of Control Box
Figure 10
Note
To ensure safety and protect the machines, please install a gate stopper at the open limit position
when the gate opens outward to prevent the gate from running over its travel. Meanwhile, to
enable the 2 swings to close to its accurate limit position, please install a limit stopper at the closed
limit position (as shown in figure 3). Similarly, when the gate opens inward, please install a limit
stopper at the closed limit position (as shown in figure 2).
Before installing the main machine, please make sure the main machine and components are in
good mechanical performance and the gate can be manually operated flexibly.
One control unit can optionally drive one main machine or two main machines.
Earth leakage circuit breaker must be installed on where the gate movement can be seen, and the
minimum mounting height for the control box should be over 1.5m to avoid being touched by kids.
After installation, please check whether the mechanical property is good or not, whether gate
movement is flexible or not after unlocking, and whether the infrared sensor (optional) is installed
correctly and effectively.

11
9. Wiring and Debugging
9.1 Wiring Instructions
MOTOR1MOTOR1
AC24VINAC24VIN
FORCEFORCE SLOWSLOW
PROGPROG ＋－SETSET
DOWNDOWN SPEEDSPEED
MOTOR2MOTOR2 －ELOCK＋－ELOCK＋ －BLK＋－BLK＋ 24V24V
＋SOLAR－＋SOLAR－ ＋BATT－＋BATT－
12V12V COMCOM COMCOM COMCOM OSCOSC GNDGND ANTANTPHPH PEDPEDEM1EM1 LM1LM1 EM2EM2
L
LM2LM2
M1M1 M2M2
Motor1Motor1
MainsMains
inputinput
FUSEFUSE 10A10A
24V24V batterybattery inputinput +
24V24V batterybattery inputinput -
SolarSolar powerpower inputinput -
SolarSolar powerpower inputinput +
Motor2Motor2
ElectricElectric LockLock
AlarmAlarm LampLamp
24V+24V+
12V+12V+
Motor1Motor1 LimitLimit signalsignal
CommonCommon
Motor1Motor1 LimitLimit powerpower supplysupply Motor2Motor2 LimitLimit powerpower supplysupply
Motor2Motor2 LimitLimit signalsignal
GroundGround
AntennaAntenna
PhotoPhoto SensorSensor
SingleSingle ChannelChannel
SingleSingle GateGate
CommonCommon
Figure 11

12
9.2 Control Board Drawing and Instructions
MOTOR1MOTOR1
AC24VINAC24VIN
FORCEFORCE SLOWSLOW
PROGPROG ＋－SETSET
DOWNDOWN SPEEDSPEED
MOTOR2MOTOR2 －ELOCK＋－ELOCK＋ －BLK＋－BLK＋ 24V24V
＋SOLAR－＋SOLAR－ ＋BATT－＋BATT－
12V12V COMCOM COMCOM COMCOM OSCOSC GNDGND ANTANTPHPH PEDPEDEM1EM1 LM1LM1 EM2EM2 LM2LM2
Figure 12
Terminal
Description
1. AC24VIN
24VAC Power Supply Input
2. +SOLAR-
Solar Power Input
3. +BATT-
24V Battery Input
4. FORCE
Resistance Force
5. SLOW DOWN
Slow Stop Distance
6. SPEED
Moving Speed
7. MOTOR1
Motor1 Output
8. MOTOR2
Motor2 Output
9. -ELOCK+
Electric Lock Output
10. -BLK+
Alarm Lamp Output (Note: pay attention to
the negative and positive.)
11. +24V
24V Output Positive
12. +12V
12V Output Positive (No output under dormant
state)
13. EM1
Motor1 Hall Sensor Power Output
14. LM1
Motor1 Hall Sensor Limit Signal Input
15. EM2
Motor2 Hall Sensor Power Output
16. LM2
Motor2 Hall Sensor Limit Signal Input
17. PH
Photo Sensor Input Active
18. PED
Single Gate/Pedestrian Mode Input Active
19. OSC
Single Channel Input Active
20. ANT
Antenna
21. COM
Common

13
9.3 Digital Screen Setting
When the control board is working, the users can check working state of gate opener by digital screen
on the control board.
: no input;
: under opening state;
: under closing state;
: error;
:manual mode;
: travel setting;
9.4 Travel Setting (VERY IMPORTANT)
In the first installation of gate openers, the installer need to set open and closed limit switch positions
for running the travel.
Fully open both sides of the gate and lock the clutch, and then press and hold the "-" button on the
control board until the digital screen shows "SU". After this step, the gate will firstly run towards the
closing direction and stop, and then the gate will automatically open. When the two swing gates are fully
open, the gates will automatically close for the second time, and the travel setting will be completed
when the gates are closed. If the distance of starting slow speed of gate is not appropriate, adjust the
"SLOW DOWN " button to revise the distance.
Note:
If the gate suddenly stops during travel setting, please increase the resistance force.
If the gate didn’t stop when meets the obstacles during travel setting, please appropriately reduce
the resistance force.
Installer must redo travel setting after modifying the "SPEED" trimmer.

14
9.5 Trimmers Setting
Obstacle Sensibility Trimmer
To adjust the sensitivity of obstacle -- clockwise to increase, counterclockwise to reduce the sensitivity
of obstacle. If there are environmental effects, such as heavy winds, adjust the trimmer according to
environment.
Slow Speed Distance Trimmer
To adjust slow speed distance -- clockwise to increase, counterclockwise to decrease slow speed
distance. Please do not set very short slow speed distance, to avoid the gate collision.
Gate Moving Speed Trimmer
To adjust gate moving speed -- clockwise to accelerate, counterclockwise to slow down. The trimmer
can be adjusted to change the opening and closing travel time. This adjustment must be finished before
travel setting.
Figure 13
9.6 Learning Remote Control & Delete Remote Control
9.6.1 Learning Remote Control
Press and hold "+" button, the alarm light will keep flashing, and digital screen displays remote control
mode -- “PO” -- two swing gates single channel mode; “Pd" -- single gate four channel mode; Press the
button of the remote control to be learned, the digital screen will show the number of current learned
remote control, then the remote control learning is completed. (The default of new paired remote control
is two swing gates single channel mode).
9.6.2 Delete Remote Control
Enter into “AE” in the digital screen and then to choose “rE” to delete the remote controls.
Figure 14
Counterclockwise
reduce
FORCE
Obstacle Sensibility Trimmer
Clockwise
Increase
SLOW DOWN
Slow Speed Distance Trimmer
SPEED
Gate Moving Speed Trimmer
Counterclockwise
reduce
Clockwise
Increase
Counterclockwise
reduce
Clockwise
Increase

15
9.6.3 Special Remote Control Key-button
Press and hold the combination keys for 5S.
C(stop)+D(single gate) combination key -- enter into remote control learning.
9.7 Control Board Settings
9.7.1 Base Menu
Press "PROG" to enter into base menu;
Digital screen shows “NE”, select other functions of this menu by “+” and “-” buttons.
Press "SET" to confirm or to enter into sub-menu.
To exit menu, press "PROG".
If no command for one minute, the menu will automatically exit.
Base Menu
Automatic closing mode
Standard mode
Open/Close/Stop
Dual gates mode
To switch single
gate mode/dual
gates mode
Single gate mode
Community mode
Open gate
time interval
3 seconds (default)
15 seconds (default)
Automatic
closing time
To select
working mode
Initial screen

16
Remote
control mode
Dual gates single
channel mode
Four channel mode
Single gate single
channel mode
Delete remote
control

17
9.7.2 Base Menu Instruction
Menu
Press "PROG" to enter
into base menu.
Option
Press “+”(up) or “-”(down) to select;
Press “SET” to confirm.
Default/Attention
Working Mode
Standard mode; O/C/S
(Open/Close/Stop).
O/S/C standard mode with automatic
closing function. When the gate opens, it will
automatically close after automatic closing
time. If a “close the gate” command is sent
during the automatic closing time waiting time,
the automatic closing function will be
canceled.
Community mode(with automatic
closing function). When the gate opens, any
gate command will not be responded until it
closes automatically. If user sends gate
command during the closing process, then the
gate will reopen. If a gate command is sent
during the automatic closing waiting time, this
waiting time will be recalculated. If the gate is
not closed completely for more than three
consecutive times, the automatic closing
function will be canceled and the gate will be
closed by re-sending the gate closing
command. Note that in community mode, the
gate still has the automatic closing function in
case of meeting obstacles.
Standard mode;
O/C/S (Open/Close/Stop).
Single Gate/Dual Gates
Switch
Dual gates mode(default).
Single gate mode.
Dual gates mode.

18
Open Gate Time Interval
00-10: Open gate time interval is 0-15
seconds(default 3 seconds). If the interval
shorter than 2 seconds, then the electric lock
cannot be used.
3 seconds.
Automatic Closing Time
Automatic closing time can be set as
15(default), 30, 60, 90 seconds.
15 seconds.
Remote Control Mode
Dual gates single channel mode.
Four channel mode.
Single gate single channel mode.
Delete all paired remote controls
