Judo QUICKSOFT MEGA User manual

Read before use and store!
Operating instructions
JUDO QUICKSOFT MEGA
Water softening unit
Valid for: EU countries and Switzerland
Language: English

2 JUDO QUICKSOFT MEGA
Queries, orders, customer service
JUDO Wasseraufbereitung GmbH
Postfach 380
D-71351 Winnenden
e-mail: [email protected]
judo.eu
Office address
JUDO Wasseraufbereitung GmbH
Hohreuschstraße 39 - 41
D-71364 Winnenden
Trademarks:
Trademarks used in this document are the protec-
ted and registered trademarks of the respective
owner.
© JUDO Wasseraufbereitung GmbH
D-71364 Winnenden
All rights reserved.
Reprinting, even in excerpt form, is only
permitted with special approval.
Dear customer,
Thank you for the confidence you have
shown in us by purchasing this device. In
purchasing this water softening system
you have procured a state of the art device.
This device is suitable for use in cold
drinking water up to a maximum water
and ambient temperature of 30 °C.
Every device has been carefully checked
prior to supply. Nevertheless, if difficul-
ties occur, please contact your respon-
sible customer service representative
(see back page).
The remote control of the JUDO
QUICKSOFT MEGA via mobile
phones and tablets using the con-
nectivity module and the JU Con-
trol App requires a stable internet
connection at the place of installa-
tion of the water softening system.
The JU Control App is available for
iOS- and Android.

JUDO QUICKSOFT MEGA 3

4 JUDO QUICKSOFT MEGA
Contents
1 About these operating instructions. 5
1.1 Symbols used .............................. 5
1.2 Safety instructions and dangers
due to non-observation................ 6
1.3 Units used.................................... 6
2 Intended use ...................................... 6
2.1 Indication of particular dangers ... 7
3 Product information .......................... 8
3.1 Application ................................... 8
3.2 Materials used ............................. 8
4 Installation ......................................... 8
5 Operation ........................................... 9
5.1 Control panel ............................... 9
5.2 Menu functions ............................ 9
5.3 Operating mode......................... 10
5.4 Menu structure........................... 13
5.5 Function description .................. 14
5.6 Filling with salt ........................... 15
5.7 Potential-free fault indication ..... 16
5.8 Integration of the water
softening system
in building control systems ........ 16
5.9 Connectivity module
(accessories) ............................. 16
5.10 Conversions / changes / spare
parts........................................... 17
5.11 Service/repair ............................ 17
5.12 Interruption of operation ............ 17
5.13 Resetting to factory setting ........ 17
5.14 Overview of display messages.. 18
6 Fault.................................................. 18
7 Maintenance..................................... 18
7.1 Cleaning .................................... 18
8 Warranty and service ...................... 19
8.1 Inspection by the operator every
two months (visual inspection) .. 19
8.2 Six-monthly maintenance
by the operator .......................... 19
8.3 Annual maintenance
by customer service .................. 19
9 Data sheet ........................................ 20
9.1 Type .......................................... 20
9.2 Technical data ........................... 20
9.3 Scope of supply......................... 21
10 Spare parts....................................... 23
11 Disposal ........................................... 24
12 Customer service ............................ 28

JUDO QUICKSOFT MEGA 5
About these operating instructions
1 About these operating in-
structions
These operating instructions must always
be available at the place of use of the water
softening system.
These operating instructions should simplify
getting to know your water softening system
and inform you of its intended applications.
The operating instructions contain important
information so that you can use the water
softening system safely, professionally and
economically. They contain basic informa-
tion that must be observed during installa-
tion, operation and maintenance. Obser-
vance of this information will help to avoid
dangers, reduce repair costs and increase
the reliability and service life of the water
softening system.
The operating instructions must be read by
each person charged with working on the
water softening system, e.g. for:
–Installation
–Operation
– Maintenance
(service, inspection, repair)
Installation and maintenance must only be
performed by personnel who have been au-
thorised by the manufacturer to do so, i.e.
who are able to fulfil the instructions referred
to in the installation and operating instruc-
tions as well as country-specific regulations.
Alongside the operating instructions and the
legal regulations applicable in the country
and place of use in respect of accident pre-
vention, the recognised technical regula-
tions for safe and professional work must be
observed.
Therefore, these operating instructions must
be read by the installer and the responsible
technical personnel/operators prior to instal-
lation, commissioning and maintenance.
Not only must the general safety instruc-
tions listed in chapter „Intended use“ be
observed, but also the specific safety in-
structions that are included under the
other main points.
1.1 Symbols used
The safety instructions contained in these
operating instructions are labelled with the
following symbols:
Instructions attached directly to the rotary
flange fitting or the water softening system,
such as:
– Direction of flow (see fig. 1)
– Type label
– Cleaning information
must be observed without fail and main-
tained so that they are always legible.
ATTENTION
Indication of
existing dan-
gers
Warning of electric voltage
Torques specified by the manu-
facturer
User tips and other information
Fig. 1: Rotary flange fitting

6 JUDO QUICKSOFT MEGA
Intended use
1.2 Safety instructions and dan-
gers due to non-observation
In particular, non-observation of the general
danger symbols is associated with the fol-
lowing typical hazards:
– Failure of important water softening sys-
tem functions.
– Endangering of persons due to electrical
and mechanical effects.
– Endangering of persons and the envi-
ronment due to leaks.
Any working methods that might endanger
safety must be avoided.
Non-observation of these operating instruc-
tions and the safety instructions herein may
endanger persons, as well as the environ-
ment and the device itself.
1.3 Units used
The following units which do not form part of
the SI (Système International d’Unités) sys-
tem are used:
2 Intended use
Both installation and use of the water soften-
ing system are subject to the applicable na-
tional regulations.
Alongside the operating instructions, the le-
gal regulations applicable in the country and
place of use in respect of accident preven-
tion, the recognised technical regulations for
safe and professional work must be ob-
served.
The water to be softened must comply
with the European Drinking Water Direc-
tive!
The manufacturer/supplier must be consult-
ed before using water of a different quality or
water with additional additives!
The water softening system is suitable for
use in cold drinking water up to a maximum
ambient temperature of 30 °C.
It is manufactured according to the state of
the art and recognised German safety regu-
lations.
The water softening system may only be
used as described in the operating instruc-
tions. Any other use or use beyond the spec-
ified use is considered to represent incorrect
use.
Additional dangers exist in the event of incor-
rect use and in the event of non-observation
of the danger symbols and safety instructions.
The manufacturer/supplier shall not be re-
sponsible for any resulting damage. All risks
are borne solely by the user.
Intended use includes observance of the op-
erating instructions.
The manufacturer/supplier must be consult-
ed before using the water softening system
outside the limits of use described in these
operating instructions.
Quantity Unit Conversion
Nominal
diameter
1" Corresponds to DN 25
Pressure bar 1 bar = 100000 Pa
= 0.1 N/mm²
≈14.5 psi
Water
hardness
°e 1 °e = 0.142 mmol/l
Alkaline earth
ions (hardness
producing ions)
= 14.2 ppm
CaCO3

JUDO QUICKSOFT MEGA 7
Intended use
The water softening system must only be
used as intended in a technically fault-free
state, while maintaining safety and hazard
awareness, and in compliance with the oper-
ating instructions.
Ensure that malfunctions are rectified
immediately!
The spent regenerating salt is removed from
the water softening columns together with
waste water. Therefore it must not be used
for irrigation or similar purposes.
The designed capacity of the water softening
system is such that it is capable of partially
softening the entire water requirement for a
single or multiple family house as well as cor-
responding partial water quantities for hot
water, swimming pool, washing machine and
dishwasher.
2.1 Indication of particular dan-
gers
2.1.1 Electrical devices/installations
Electrical devices/installations that are not
splash-proof and are located in the vicinity of
the water softening system may be dam-
aged by water that escapes during regener-
ation or in the event of incorrect use of the
water softening system. If the electrical de-
vices/installations are connected to the pow-
er supply, it is also possible that a short-cir-
cuit could occur. Should this occur there is a
risk of electric shocks to people. Therefore
electrical devices/furnishings and equip-
ment in the vicinity must be splashproof and/
or comply with the legal regulations for wet
areas.
Caution when touching without the cover!
During operation, electronic components
can become hot. Also there is a danger due
to moving parts.
Potential-free output
Switching voltage............. maximum 24 V
Current ................................ maximum 1 A
(see chapter 5.7 “Potential-free fault indica-
tion”)
No electrical cables and equipment
may be located below or in the im-
mediate vicinity of the water soften-
ing system!
In the power supply unit the mains
voltage is reduced to a safe low volt-
age of 24 V which is then used to op-
erate the system electronics. No oth-
er power supply units must be used.
Only low voltages can be used for
the remote transmission of the fault
indication via the potential-free out-
put!

8 JUDO QUICKSOFT MEGA
Product information
3 Product information
3.1 Application
The water softening system is suitable for use
with cold drinking water having a maximum
water temperature of up to 30 °C.
ATTENTION
(see chapter 1.2 “Safety instructions and
dangers due to non-observation”)
Usage limitations see chapter 2 “Intended
use”.
This water softening system is for protection
of water pipes and the water heater against
limescale deposits.
With partially softened water, devices and
fittings are preserved and the consumption
of washing and cleaning agents reduced.
3.2 Materials used
The materials used are resistant to the phys-
ical, chemical and corrosive loads expected
to be encountered in drinking water and fulfil
the specifications required by DIN EN
14743 and DIN 19636-100 (“Water soften-
ing systems (cation exchangers) in drinking
water installations”). All materials are hy-
gienically and physiologically harmless.
Plastics fulfil the KTW Guideline (Guideline
for the Hygienic Assessment of Organic Ma-
terials in Contact with Drinking water) of the
German Federal Environmental Agency
(UBA). Metallic materials fulfil the require-
ments of DIN 50930-6 (Effect of metallic ma-
terials on the quality of drinking water).
4 Installation
All information required for installation is
contained in the installation instructions
1703525 for the QUICKSOFT MEGA 6 wa-
ter softening unit.
Limescale deposits block the water
supply and therefore can result in in-
creased energy consumption.

JUDO QUICKSOFT MEGA 9
Operation
5 Operation
5.1 Control panel
Operation of the water softening system
takes place via the keypad and display (see
fig. 2).
Key functions:
Display background lighting:
– None: normal operation
– Alternating light blue/dark blue:
With a water flow
– White: when pressing a key
– Yellow: for warning messages
– Red: for fault indications
5.2 Menu functions
Pressing the key calls the main menu:
The next or previous sub-menu is displayed
using keys and and called using the
OK key.
In the sub-menu individual values are in-
creased or decreased using keys and 
and then accepted using the OK key.
Sub-menus:
Raw water hardness
– Raw water hardness setting (see
chapter 5.3.3 “Setting the raw water
hardness”)
Regeneration
– manual regeneration start (see
chapter 5.3.2 “Manually starting regen-
eration of the water softening system
manual”)
Settings
– Language:
DE, EN, FR, NL, IT
– Water hardness unit:
°dH, °e, °f, gpg, ppm, mmol/l, mval/l
– Lighting, contrast, tone
– Functioning of the fault indication relay
(see chapter 5.7 “Potential-free fault in-
dication”)
– Factory setting
(see chapter 5.13 “Resetting to factory
setting”)
Fig. 2: Water softening system control panel
Access to the main menu (see
chapter 5.2 “Menu functions”)
- Scroll up in the menu
- Increase value
- Scroll down in the menu
- Reduce value
One menu level back
without saving
- Access to the sub-menu
- Accept value and save
and one menu level back
- Acknowledge message
Two line display
Keypad
Main menu
• Raw hardness

10 JUDO QUICKSOFT MEGA
Operation
Operating data
– Total soft water volume since commis-
sioning [m³]
– Total number of regenerations since
commissioning
– Total number of services since commis-
sioning
Info
Various information is displayed here such
as device type, device number, customer
service telephone number, history of the
warning messages and fault indications,
software version, hardware version and the
date for the next necessary service.
5.3 Operating mode
(see fig. 8)
– Fill approximately 5 litres of water into
the salt reservoir (4),until just above the
intermediate bottom.
– Fill 25 - 50 kg of regenerating salt into
the salt reservoir.
The regenerating salt must as a minimum
comply with the requirements of DIN EN 973
and be of food-grade.
Our recommendation: Broxo or Solvay
salt, either as blocks, tablets or coarse
grains 7 - 15 mm. If other regenerating salts
are used, then the salt reservoir must be
cleaned at shorter intervals and the intake
strainer replaced more frequently.
– Remove the cover.
– Enter the date of installation on the label
(see fig. 3).
– Open the water supply (stopcock or
shut-off valve).
– Ensure that the bypass valve (if in-
stalled) is set to “Operate”.
ATTENTION
For safety reasons, the water softening sys-
tem must be immediately flushed and re-
generated for venting.
See chapters 5.3.1 and 5.3.2 for this pur-
pose!
5.3.1 Flushing the water softening
system
– To do so open a tap (as close as possi-
ble to the water softening system) and
create a volume flow of about 500 l/h.
– After a minute’s flushing (both resin con-
tainers are vented), plug the power sup-
ply unit into the socket.
After connection to the power supply, the
electronics automatically perform a self-test.
Status display:
After a successful conclusion, the following
text is output to the display:
Fig. 3: Device and order no. plus
Label ‘Date of installation’
Fig. 4: Status display
Device-no.
Order no.
Label
Label ‘Date of installation’
Operating
QUICKSOFT-P

JUDO QUICKSOFT MEGA 11
Operation
5.3.2 Manually starting regeneration
of the water softening system
manual
To do so, the water softening system must
be in an operating situation. The status dis-
play is output to the display (see fig. 4).
Press key 1x and then key 1x. The
display indicates the following:
Press the <OK> key. The display indicates
the following:
Pressing <OK> starts regeneration.
Then ‘Regeneration’ is output to the display.
Regeneration is completed after about 15
minutes. The status display is output again
(see fig. 4).
The water softening system is now ready for
operation.
The following parameters must then be set:
– Raw water hardness (see chapter 5.3.3
“Setting the raw water hardness”)
– Mixing (see chapter 5.3.4 “Adjusting the
mixing”)
5.3.3 Setting the raw water hard-
ness
The value depends on the installation loca-
tion. It can either be requested from the wa-
ter supply company or determined using a
suitable measuring instrument (in the scope
of supply). If the raw water hardness fluctu-
ates, the higher value should be set. The
same quantity of brine is always used for re-
generation. If the raw water hardness is
high, a reduced water volume is treated. If
the raw water hardness is low, a greater wa-
ter volume is treated.
The water softening system is pre-set to a
raw water hardness of 25 °e. Another raw
water hardness is set as follows:
Press key . The display indicates the fol-
lowing:
Press the <OK> key. The display indicates
the following:
Press the <OK> key. The display indicates
the following:
Use the key to reduce the raw water
hardness and the key to increase the
hardness. The step size is 1 °e.
The set raw water hardness value is saved
by pressing <OK>.
5.3.4 Adjusting the mixing
In the factory the set screw of the mixing
valve is set to slightly open (see fig. 5). First
a check must be performed to determine
what mixing water hardness exists with this
setting. The water hardness measurement
is performed with a measuring instrument (in
the scope of supply).
The sample water for measuring and setting
the water hardness can be drawn at the by-
pass valve or from a water tap connection
downstream of the water softening system.
It must be ensured that the set mixing water
hardness in the water softening system
reaches the drawing point. For a correct
measuring value comparison, the samples
should be taken with a normal water flow
Main menu
• Regeneration
Regeneration
start
Main menu
• Raw hardness
Setting
Raw hardness
Raw hardness
25 °e

12 JUDO QUICKSOFT MEGA
Operation
(one tap fully open). During drawing, no
large volume of water should be drawn at
another point.
If the desired mixing water hardness is not
achieved, then it can be corrected by turning
the set screw of the mixing valve within the
marked adjustment range by no more that
one half turn. A value of about 10 °e is re-
commended.
If necessary, the setting must be changed
and re-measured a number of times until the
desired value is achieved.
After the softening, the sodium concentra-
tion in the mixing water increases, depend-
ent on the raw water hardness and the set
mixing water hardness.
According to current drinking water legisla-
tion, the limit value for sodium in drinking
water is 200 mg/l. Mineral and table water
are not affected by this. Their limit values
are much higher, partially greater than 1000
mg sodium per litre.
If the calculated total sodium content ex-
ceeds the valve permitted by the drinking
water legislation of 200 mg/l, then it can be
corrected by increasing the mixing water
hardness.
The calculation of the sodium content must
then be repeated.
Fig. 5: Adjusting the mixing
Calculation of the sodium content
°e Raw water hardness (ask
the water supply company
or measure with hardness
measuring instrument)
- °e Residual hardness (meas-
ured value)
= °e Difference in water hardness
x6.4 mg Na+/l x °e
Sodium ions exchange value
= mg/l Increase of the sodium con-
tent by softening
+ mg/l sodium already present in
the raw water (ask the water
supply company)
= mg/l Total sodium content in the
mixing water
Example calculation of the sodium con-
tent
25 °e Raw water hardness
- 10 °e Residual hardness
= 15 °e Difference in water hardness
x6.4
= 96 mg/l Due to softening:
+ 10 mg/l From the water supply
company
= 106 mg/l In total

JUDO QUICKSOFT MEGA 13
Operation
5.4 Menu structure
Fig. 6: Menu structure

14 JUDO QUICKSOFT MEGA
Operation
5.5 Function description
5.5.1 Method of operation
The filter containers are filled with ion-ex-
change resin. This comprises small plastic
resin balls on which the calcium ions, which
make the water ‘hard’, are exchanged for
sodium ions. Consequently the water be-
comes soft. In the control head an adjusta-
ble quantity of not-softened raw water is ad-
mixed to obtain the desired mixing water
hardness downstream of the system. How-
ever the ion-exchange resin only absorbs a
limited quantity of these hardness compo-
nents. Dependent on the water hardness
and the treated water volume, sooner or lat-
er it is exhausted. The time at which it be-
comes exhausted is measured with the wa-
ter meter and regeneration automatically
triggered. To do so, diluted brine (sodium
chloride) is used to remove the hardness
components from the resin.
5.5.2 System design
The water softening system is designed as a
parallel system that is regenerated in two
stages. During regeneration, the two resin
containers are alternately responsible for
soft water provision. In this way soft water is
always available for the consumer, even
during regeneration.
5.5.3 Regeneration
With a very short regeneration period of
about 7.5 minutes per resin container (total:
15 minutes) high volume continuous draw-
ing is possible.
The soft water volume is precisely meas-
ured using a water meter in the system’s soft
water pipe and in this way triggering of re-
generation is controlled. Regeneration is
performed according to DIN EN 14743 and
DIN 19636-100 using miser salting. Disin-
fection of the system takes place at regular
intervals to prevent microbe contamination.
The small quantity of chlorine required for
this is created electrolytically during regen-
eration from the absorbed brine.
5.5.4 Control of regeneration
Regeneration is performed automatically via
wear-free ceramic disc valves. The regener-
ation sequence is fixed by the geometry of
the discs and therefore need not be re-en-
tered after a power failure.
5.5.5 Overflow valve
If because of very high drawing of water
(e.g. pressure washer) the pressure loss in
the water softening system is greater than
1.0 bar, then an overflow valve integrated in
the control head opens so that hard water
can bypass the system to limit the pressure
loss. This means that the residual hardness
temporarily increases in the pipe down-
stream of the water softening system.

JUDO QUICKSOFT MEGA 15
Operation
5.6 Filling with salt
The water softening system works automat-
ically. Approximately 180 g of salt is needed
for each regeneration. The regenerating salt
must be replenished at regular intervals.
Our recommendation: Broxo or Solvay
salt, either as blocks, tablets or coarse
grains 7 - 15 mm. If other regenerating salts
are used, then the salt reservoir must be
cleaned at shorter intervals and the intake
strainer replaced more frequently.
The stock of salt should not decrease so far
that the liquid level is above the regenerat-
ing salt, as otherwise when replenishing the
salt, it rises excessively.
The regenerating salt is normally replen-
ished in sacks of 25 kg. This salt quantity is
sufficient for at least 120 regenerations.
5.6.1 Message upon low salt level
The salt concentration of the brine reservoir
is automatically regularly checked. If the salt
reservoir is not filled up early enough and
consequently the brine concentration de-
creases too much, a message is output to
the display:
After this message, replenishment with a
quantity of 25 kg of regenerating salt is re-
quired. Then the <OK> key must be briefly
pressed. The warning message is then re-
set.
If the salt is only replenished once the salt
stock is completely used up, the brine level
may temporarily increase. The suction pro-
cess then lasts correspondingly longer.
If there is no longer any regenerating salt
available or if the regenerating salt is not re-
plenished early enough, the water softening
system switches to miser operation.
The remaining salt stock is then primarily
used for disinfection of the ion-exchange
resin and the softening effect is reduced.
In this way, the water softening system re-
mains in a hygienic condition for weeks after
the low regenerating salt state first occurs.
This message can also appear if the
salting process is not performed cor-
rectly during regeneration, e.g. if the
waste water hose is routed at a too-
high level, if the mains water pres-
sure is too low or if the suction hose
connection to the salt/brine tank is
not made correctly.
Attention!
Salt deficit

16 JUDO QUICKSOFT MEGA
Operation
5.7 Potential-free fault indication
A general error message can be forwarded
by the potential-free relay in the following
cases:
– In the event of a water softening system
fault indication
– If there is a power loss
– If a low salt condition exists
Chapter 2.1 „Indication of particular dan-
gers“ must be observed without fail!
Adhere to the maximum switching current
and maximum voltage (see chapter 2.1.1
“Electrical devices/installations”)!
The contacts of the potential-free relay are
shown in the zero-current state in fig. 7.
Setting the switching function:
Press key 1x and then key 2x. The
display indicates the following:
Press key <OK> 1x and then key as often
as necessary, until the display indicates the
following:
Press the <OK> key. The display indicates
the following:
Press key or to change between <Nor-
mally open> and <Normally closed>.
The chosen setting is saved by pressing
<OK>.
5.8 Integration of the water
softening system
in building control systems
The water softening system can be integrat-
ed via the potential-free relay into a building
control system (e.g. EIB, LCN or LON).
For example, the potential-free relay is con-
nected to a binary bus coupler. This allows a
fault indication to be forwarded to the build-
ing control system.
5.9 Connectivity module
(accessories)
A retrofittable connectivity module is used to
connect the water softening system via a
LAN connection to the home network and
the Internet.
Using the available iOS/Android app, world-
wide access to comprehensive information,
automated messages and functions of the
water softening system is possible.
Prior to electrical installation, pull the
power supply unit out of the socket!
Main menu
• Settings
Setting
• Fault relay
Fault relay
Normally open
The fault signalling cable is not
part of the scope of supply.

JUDO QUICKSOFT MEGA 17
Operation
5.10 Conversions / changes / spare
parts
Only original spare parts may be used!
Unauthorised conversions and changes are
forbidden for safety reasons! These could
impair the function of the water softening
system. The imprinted approval marks are
only valid if original spare parts are used.
5.11 Service/repair
ATTENTION
Before performing work on the water sof-
tening system that goes beyond pure oper-
ational use, the water softening system
must be depressurised!
If this is ignored, the result may be uncon-
trolled egress of water resulting in water
damage to the building/home. Therefore the
instructions given in chapter 4 “Installation”
and chapter 7 “Maintenance” must be strict-
ly observed.
5.12 Interruption of operation
The water supply to the water softening sys-
tem is interrupted. The main stopcock is
closed or the bypass valve is switched over.
– When disassembled, the water softening
system must be stored in a dry and frost-
free location.
– The connection flange must be protect-
ed against dirt and damage.
– Once the water softening system is fitted
and started again, it must be flushed and
regenerated (see chapter 5.3 “Operating
mode”).
5.13 Resetting to factory setting
All customer settings can be reset to the fac-
tory setting in the following way:
Press key 1x and then key 2x. The
display indicates the following:
Press key <OK> 1x and then key  as often
as necessary, until the display indicates the
following:
Press the <OK> key. The display indicates
the following:
Press key or to change between
<yes> and <no>.
The following default values are recreated
by pressing key <OK> with <yes> selected.
– Raw water hardness 25 °e
– Fault indication relay: NOC function
– Lighting 80 %, contrast 50 %
Pull the power supply unit out of the
socket! (If present, also pull out the
power supply unit of the downstream
dosing pump!)
Main menu
• Settings
Setting
• Factory setting
Factory setting
<no>

18 JUDO QUICKSOFT MEGA
Fault
5.14 Overview of display messages
6Fault
Opening of devices and replacement of parts subject to water pressure must only be
performed by licensed persons to ensure device safety and leak-tightness.
Deleting the fault indication:
– Press <OK> key.
or
– Pull the power supply unit out of the
socket and plug back in after about 5 s.
7 Maintenance
7.1 Cleaning
Only use clear drinking water to clean the
housing.
Standard all purpose cleaners and glass
cleaners can contain up to 25 % solvent or
alcohol (methylated spirits).
These substances can chemically attack the
plastic parts resulting in embrittlement and
even breakage.
Therefore do not use these types of
cleaner!
Indication Description Further info
Regeneration Message is displayed during regen-
eration of the resin container.
see chapter 5.5.3 “Re-
generation”
Maintenance/
Service req.
Message appears after the one-year
service interval has elapsed.
see chapter 8.3.1
“Message “Mainte-
nance/Service””
Attention!
Salt deficit
Message appears after exceeding of
the minimum chlorine flow.
see chapter 5.6.1 “Mes-
sage upon low salt lev-
el”
Indication on the display Cause Remedy
Attention! Error
Reg. drive
Regeneration drive
defective.
Notify customer service! Unplug the pow-
er supply unit! If fitted, switch the bypass
valve to bypass!
Attention! Error
Salification
Salting process de-
fective, container
overfilled or leak.
Check the brine level in the salt reservoir!
Reset fault indication! If the fault occurs
again, notify customer service!
Attention! Error
Lso-electrode
Level electrode
defective.
Reset fault indication! If the fault occurs
again, notify customer service!
Attention! Error
Keypad
Keypad defective. Reset fault indication! If the fault occurs
again, notify customer service!
When communicating with customer
service, please always have the de-
vice number and order number avail-
able (see fig. 3).

JUDO QUICKSOFT MEGA 19
Warranty and service
8 Warranty and service
To ensure the process operates successfully
for many years after first use, regular inspec-
tion and routine servicing of the system are
essential. Where home automation is con-
cerned, this is governed by DIN EN 806-5.
We recommend that you agree a service
contract.
A service contract is the best way of ensur-
ing correct operation even after the warranty
period has elapsed.
It is desirable that the regular maintenance
work and the supply of consumables, miner-
al solutions, salt or wear parts, etc. is per-
formed by the JUDO factory customer ser-
vice team or by an approved technical
service provider.
8.1 Inspection by the operator
every two months (visual in-
spection)
To retain your legal warranty rights, it is nec-
essary that an inspection be performed at
least every two months.
The operator checks:
– The salt filling level.
– The leak-tightness of the softening sys-
tem (escaping water).
– For damage to the water softener. De-
fective parts must be replaced by cus-
tomer service.
– Messages on the display.
Dependent on the consumed water volume,
the corresponding salt consumption must be
regularly monitored. If necessary, replenish
the regenerating salt (only use quality ac-
cording to DIN EN 973). When replenishing
the salt take appropriate hygiene measures.
Thus, for example, the salt packs should be
cleaned before use so that no impurities can
get into the salt dissolving container. The re-
generating salt must be shaken into the salt
dissolving container directly after undoing
the packaging. In doing so, ensure that the
salt dissolving container is not overfilled and
that after completing the work, it is again
carefully closed and sealed. Do not use par-
tial packs. The salt must only be stored in
clean and dry rooms.
8.2 Six-monthly maintenance
by the operator
In addition to the checks of the 2-month in-
spection, the operator must also check the
following every six months:
– Leak-tightness of the softener to waste
water connection.
No water must flow out of the waste wa-
ter hose (see fig. 8) in the operating po-
sition.
– Salt deposits inside the water trap.
Deposits or incrustations inside the wa-
ter trap must be removed so that the
waste water does not get blocked.
– Soft water hardness.
Checking is performed with a hardness
measuring instrument (in the scope of
supply).
8.3 Annual maintenance
by customer service
Once yearly, a service must be performed
by a licensed technical service provider or
the JUDO factory customer service team.
8.3.1 Message
“Maintenance/Service”
After an operating period of one year, the
water softening system signals the required
service. The following message is output to
the display:
After performing the maintenance, the mes-
sage is reset by pressing the <OK> key for
at least 5 s.
Maintenance/
Service req.

20 JUDO QUICKSOFT MEGA
Data sheet
9 Data sheet
9.1 Type
JUDO QUICKSOFT MEGA
Water softening system
9.2 Technical data
– Maximum ambient temperature and wa-
ter temperature: 30 °C
– The water to be softened must comply
with the European Drinking Water Di-
rective!
The rated pressure refers to the pressure
range that the water softening system
meets. The maximum operating pressure is
lower to ensure the optimum function of the
water softening system. Further information can be found in the in-
stallation instructions 1703525 for the
QUICKSOFT MEGA 6 water softening unit.
Operating pres-
sure Rated pressure
2 - 7 bar PN 10
Pipe connection 1"
Nominal flow rate as per DIN
EN 14743 at 1 bar pressure
loss
1.8 m³/h
Nominal capacity 0.9 mol
Salt supply tank content 50 kg
Volume of the exchanger res-
in
5l
Water consumption
per regeneration
25 l
Electrical connection 230 V/
50 Hz
Power consumption:
Operation
Regeneration
1W
max. 15 W
Max. raw water hardness 125 °e
