JUKI AMB-289/IP-420 User manual

CHAPTER @
Operation section
AMB-289/IP-420
INSTRUCTION MANUAL
* "CompactFlash(TM)" is the registered trademark of SanDisk Corporation, U.S.A.

CONTENTS
1. PREFACE.......................................................................................................Ⅱ–1
2. NAME OF EACH SECTION OF THE OPERATION PANEL..........................Ⅱ–5
(1) Body............................................................................................................................... Ⅱ–5
(2) Buttons to be used in common................................................................................... Ⅱ–6
3. BASIC OPERATION OF THE SEWING MACHINE.......................................Ⅱ–6
4. LCD DISPLAY SECTION AT THE TIME OF INDEPENDENT SEWING .....Ⅱ–12
(1) Data input screen ....................................................................................................... Ⅱ–12
(2) Sewing screen ............................................................................................................ Ⅱ–14
5. PERFORMING PATTERN No. SELECTION ...............................................Ⅱ–16
6. NAMING THE PATTERN .............................................................................Ⅱ–17
7. SEWING METHOD AND SEWING SHAPE LIST ........................................Ⅱ–18
8. PERFORMING DATA SETTING OF SEWING BUTTON WITH BLINDSTITCH
(SHANK AND MARBLE BUTTONS) ...........................................................Ⅱ–19
9. PERFORMONG DATA SETTING OF SEWING BUTTON WITH BLINDSTITCH
(FLAT BUTTON) ..........................................................................................Ⅱ–20
10. PERFORMING DATA SETTING OF SEWING BUTTON DIRECTLY TO CLOTH ..........Ⅱ–21
11. PERFORMING DATA SETTING OF SEWING FLAT BUTTON WITH
BLINDSTITCH..............................................................................................Ⅱ–22
12. PERFORMING SETTING OF COUNTER/STAY BUTTONS........................Ⅱ–23
13. PERFORMING NECK WRAPPING SEWING DATA ...................................Ⅱ–24
14. PERFORMING SEWING METHOD SELECTION........................................Ⅱ–25
15. PERFORMING SEWING SHAPE SELECTION...........................................Ⅱ–26
16. PERFORMING SETTING NUMBER OF REVOLUTIONS OF SEWING MACHINE ........... Ⅱ–27
17. PERFORMING SETTING STAY THREAD...................................................Ⅱ–28
18. PERFORMING INPUT OF BUTTON SEWING THREAD TENSION...........Ⅱ–29
(1) In case of simplied input ......................................................................................... Ⅱ–29
(2) In case of detailed input............................................................................................. Ⅱ–30
(3) Sewing data that can be changed............................................................................. Ⅱ–31
19. PERFORMING INPUT OF NECK WRAPPING THREAD TENSION...........Ⅱ–33
(1) In case of simplied input ......................................................................................... Ⅱ–33
(2) In case of detailed input............................................................................................. Ⅱ–34
(3) Sewing data that can be changed............................................................................. Ⅱ–35

20. PERFORMING DETAILED INPUT OF NECK WRAPPING.........................Ⅱ–37
21. CHANGING SEWING DATA ........................................................................Ⅱ–40
(1) Initial sewing data at the time of your purchase ..................................................... Ⅱ–40
(2) Changing procedure of sewing data ........................................................................ Ⅱ–41
(3) Sewing data list .......................................................................................................... Ⅱ–42
22. PERFORMING NEW REGISTRATION OF THE PATTERN ........................Ⅱ–46
23. COPYING SEWING PATTERN ....................................................................Ⅱ–47
24. PERFORMING CHUCK ADJUSTMENT......................................................Ⅱ–49
25. PERFORMING BUTTON CENTERING .......................................................Ⅱ–50
26. PERFORMING INPUT AND CHECK OF DATA WITH STEP MOTION..........Ⅱ–51
(1) Performing the step motion....................................................................................... Ⅱ–51
(2) Data list........................................................................................................................ Ⅱ–54
27. PERFORMING COMPENSATION OF UNEVENNESS OF BUTTON .........Ⅱ–56
28. CHANGING SEWING MODE.......................................................................Ⅱ–57
29. LCD DISPLAY SECTION AT THE TIME OF CYCLE STITCHING ..............Ⅱ–58
(1) Data input screen ....................................................................................................... Ⅱ–58
(2) Sewing screen ............................................................................................................ Ⅱ–60
30. PERFORMING CYCLE STITCHING............................................................Ⅱ–62
(1) Selection of the cycle data ........................................................................................ Ⅱ–62
(2) Editing procedure of the cycle data.......................................................................... Ⅱ–63
31. PERFORMING CHANGE OF DISPLAY OF SEWING PRODUCT ..............Ⅱ–65
32. USING COUNTER .......................................................................................Ⅱ–66
(1) Setting procedure of the counter.............................................................................. Ⅱ–66
(2) Count-up releasing procedure .................................................................................. Ⅱ–68
33. CHANGING MEMORY SWITCH DATA........................................................Ⅱ–68
(1) Changing procedure of memory switch data .......................................................... Ⅱ–68
(2) Memory switch data list ............................................................................................. Ⅱ–70
34. PERFORMING CHANGE OF NEEDLE .......................................................Ⅱ–76
35. PERFORMING CHANGE OF CHUCK.........................................................Ⅱ–77
36. CUSTOMIZING DATA INPUT SCREEN ......................................................Ⅱ–79
(1) Registering procedure ............................................................................................... Ⅱ–79
(2) Register state at the time of your purchase............................................................. Ⅱ–80
37. CUSTOMIZING SEWING SCREEN.............................................................Ⅱ–81
(1) Registering procedure ............................................................................................... Ⅱ–81
(2) Register state at the time of your purchase............................................................. Ⅱ–82
38. PERFORMING KEY LOCK..........................................................................Ⅱ–83

39. DISPLAYING VERSION INFORMATION.....................................................Ⅱ–85
40. USING CHECK PROGRAM.........................................................................Ⅱ–86
(1) Displaying the check program screen...................................................................... Ⅱ–86
(2) Performing sensor check .......................................................................................... Ⅱ–87
(3) Performing LCD check............................................................................................... Ⅱ–89
(4) Performing touch panel compensation.................................................................... Ⅱ–90
41. ERROR CODE LIST ....................................................................................Ⅱ–92
42. USING COMMUNICATION FUNCTION.......................................................Ⅱ–98
(1) Handling possible data .............................................................................................. Ⅱ–98
(2) Performing communication by using the media ..................................................... Ⅱ–98
(3) Performing communication by using USB .............................................................. Ⅱ–98
(4) Take-in of the data ...................................................................................................... Ⅱ–99
43. PERFORMING FORMATTING OF THE MEDIA........................................Ⅱ–101
44. INFORMATION FUNCTION .......................................................................Ⅱ–102
(1) Observing the maintenance and inspection information ..................................... Ⅱ–103
(2) Inputting the inspection time .................................................................................. Ⅱ–105
(3) Releasing procedure of the warning ...................................................................... Ⅱ–106
(4) Observing the production control information...................................................... Ⅱ–107
(5) Performing setting of the production control information ................................... Ⅱ–109
(6) Observing the working measurement information ................................................Ⅱ–112
45. COMMUNICATION SCREEN OF MAINTENANCE PERSONNEL LEVEL.........Ⅱ–115
(1) Data which are possible to be handledIn case of the maintenance .....................Ⅱ–115
(2) Displaying maintenance personnel level ................................................................Ⅱ–116
46. INFORMATION SCREEN OF THE MAINTENANCE PERSONNEL LEVEL ........Ⅱ–117
(1) Display of error record..............................................................................................Ⅱ–117
(2) Display of the cumulative working information......................................................Ⅱ–118

Ⅱ–1
@. Operation section
1. PREFACE
3) Folder structure of the media
 Storeeachleinthedirectoriesbelowofthemedia.
1) Kind of sewing data handled with IP-420
2) To use the data for AMB-289 (EPD data)
 InsertamediumintotheIP-420andselectpatternNo.xxxfromEPDdata.
Media drive
AMB00 .EPD
AMB00 .EPD
Parameter data:
Store in ¥AMB289.
Stores parameter data
(exclusive for AMB)
AMB289
Pattern name Description
Parameterdata Filethatextensionis".EPD"
Readfrommedia.Max.99patternscanbeused.
AMB00 .EPD
1. There is beforehand the PROG folder in the media purchased from our company.
Do not delete it.
2. Data that are not stored in the directories above cannot be read. So, be careful.

Ⅱ–2
1
2
Media
4) CompactFlash (TM)
1) TurnthelabelsideoftheCompactFlash(TM)
tothisside(placethenotchoftheedgetothe
rear.)andinsertthepartthathasasmallhole
intothepanel.
2) Aftercompletionofsettingofthemedia,close
thecover.Byclosingthecover,itispossible
toaccess.Ifthemediaandthecovercomein
contactwitheachotherandthecoverisnot
closed,checkthefollowingmatters.
 •Checkthatthemediaissecurelypressed
untilitgoesnofurther.
 •Checkthattheinsertingdirectionoftheme-
diaisproper.
 ■Inserting the CompactFlash (TM)
1) Hold the panel by hand, open the cover, and
pressthemedia2removinglever1.Theme-
diaiseject.
When the lever 1is strongly pressed,
the media 2may be broken by pro-
truding and falling.
2) When the media 2 is drawn out as it is, re-
movingiscompleted.
■ Removing the CompactFlash (TM)
1. When the inserting direction is wrong, panel or media may be damaged.
2. Do not insert any item other than the CompactFlash (TM).
3. The media slot in the IP-420 accommodates to the CompactFlash (TM) of 2 GB or less.
4. The media slot in the IP-420 supports the FAT16 which is the format of the Compact-
Flash (TM). FAT32 is not supported.
5. Be sure to use the CompactFlash (TM) which is formatted with IP-420. For the formatting pro-
cedure of the CompactFlash (TM), see "43. PERFORMING FORMATTING OF THE MEDIA" .

Ⅱ–3
■DisconnectingadevicefromtheUSBport
5) USB port
■InsertingadeviceintotheUSBport
SlidethetopcoverandinserttheUSBdevice
intotheUSBport.Then,copydatatobeused
fromtheUSBdeviceontothemainbody.
After completion of copying the data, remove
theUSBdevice.
RemovetheUSBdevice.Putthecoverbackin
place.
CAUTION :
Cautions when using the media
• Do not wet or touch it with wet hands. Fire or electric shock will be caused.
• Do not bend, or apply strong force or shock to it.
• Never perform disassembling or remodeling of it.
• Do not put the metal to the contact part of it. Data may be disappeared.
• Avoid storing or using it in the places below.
Place of high temperature or humidity / Place of dew condensation /
Place with much dust / Place where static electricity or electrical noise is likely to occur

Ⅱ–4
1PrecautionstobetakenwhenhandlingUSBdevices
• DonotleavetheUSBdeviceorUSBcableconnectedtotheUSBportwhilethesewingmachineisinopera-
tion.ThemachinevibrationcandamagetheportsectionresultinginlossofdatastoredontheUSBdeviceor
breakageoftheUSBdeviceorsewingmachine.
•Donotinsert/removeaUSBdeviceduringreading/writingaprogramorsewingdata.
 Itmaycausedatabreakageormalfunction.
• WhenthestoragespaceofaUSBdeviceispartitioned,onlyonepartitionisaccessible.
• SometypeoftheUSBdevicemaynotbeproperlyrecognizedbythissewingmachine.
• JUKIdoesnotcompensateforlossofdatastoredontheUSBdevicecausedbyusingitwiththissewingma-
chine.
• Whenthepaneldisplaysthecommunicationscreenorpatterndatalist,theUSBdriveisnotrecognizedevenif
youinsertamediumintotheslot.
•ForUSBdevicesandmediasuchasCFcards,onlyonedevice/mediumshouldbebasicallyconnected/insert-
edto/intothesewingmachine.Whentwoormoredevices/mediaareconnected/inserted,themachinewillonly
recognizeoneofthem.RefertotheUSBspecications.
• InserttheUSBconnectorintotheUSBterminalontheIPpaneluntilitwillgonofurther.
• DonotturnthepowerOFFwhilethedataontheUSBashdriveisbeingaccessed.
2USBspecications
• ConformtoUSB1.1standard
• Applicabledevices*1____ StoragedevicessuchasUSBmemory,USBhub,FDDandcardreader
• Not-applicabledevices__CDdrive,DVDdrive,MOdrive,tapedrive,etc.
• Formatsupported _____FD(oppydisk)FAT12
Others(USBmemory,etc.),FAT12,FAT16,FAT32
• Applicablemediumsize _FD(oppydisk)1.44MB,720kB
Others(USBmemory,etc.),4.1MB~(2TB)
• Recognitionofdrives __ForexternaldevicessuchasaUSBdevice,thedevicewhichisrecognizedrst
isaccessed.However,whenamediumisconnectedtothebuilt-inmediaslot,the
accesstothatmediumwillbegiventhehighestpriority.(Example:Ifamediumisin-
sertedintothemediaslotevenwhentheUSBmemoryhasalreadybeenconnected
totheUSBport,themediumwillbeaccessed.)
• Restrictiononconnection _ Max.10devices(Whenthenumberofstoragedevicesconnectedtothesewingma-
chinehasexceededthemaximumnumber,the11thstoragedeviceandbeyondwill
notberecognizedunlesstheyareoncedisconnectedandre-connected.)
• Consumptioncurrent___TheratedconsumptioncurrentoftheapplicableUSBdevicesis500mAatthemaxi-
mum.
*1:JUKIdoesnotguaranteeoperationofallapplicabledevices.Somedevicemaynotoperateduetoacompat-
ibilityproblem.

Ⅱ–5
2. NAME OF EACH SECTION OF THE OPERATION PANEL
(1) Body
[ Front ] [ Right side ]
1
2 3 4 5
7
9
!0
!1
!2
8
6
Symbol Name Description
1TOUCHPANEL,LCDdisplaysection
2READYkey Change-overofthedatainputscreenandthesewingscreenis
performed.
3INFORMATIONkey Change-overofthedatainputscreenandtheinformationscreenis
performed.
4COMMUNICATIONkey Change-overofthedatainputscreenandthecommunication
screenisperformed.
5MODECHANGEOVERkey Change-over of the data input screen and the mode change-over
screenwhichperformsvariousdetailssetting.
6Contrastcontrol
7Brightnesscontrol
8CompactFlash(TM)ejectbutton
9CompactFlash(TM)slot
!0 Coverdetectionswitch
!1 Connectorforexternalswitch
!2 Connectorforcontrol-boxconnection
1. Lightly press the target key on the touch panel with a ngertip to operate the IP-420. If
you operate with any means other than your ngertip, the IP-420 can malfunction or the
glass surface of the touch panel can be scratched or break.
2. When READY key is pressed rst after turning ON the power, origin retrieval of the
clamp foot is performed. At this time, the clamp foot moves. So, be careful.

Ⅱ–6
(2) Buttons to be used in common
ButtonsthatperformcommonoperationintherespectivescreensofIP-420areasdescribedbelow.
Symbol Name Description
CANCELbutton Pop-upscreenisclosed.Incaseofthedatachangescreen,thedata
duringchangingcanbecancelled.
ENTERbutton Datachangedaredetermined.
UPSCROLLbutton Thisbuttonscrollsbuttonordisplayupward.
DOWNSCROLLbutton Thisbuttonscrollsbuttonordisplaydownward.
RESETbutton Thisbuttonreleaseserrorandthelike.
NUMERALINPUTbutton Tenkeysaredisplayedandinputofnumbercanbeperformed.
CHARACTERINPUTbutton Characterinputscreenisdisplayed.
Referto"6." NAMING THE PATTERN .
3. BASIC OPERATION OF THE SEWING MACHINE
1) Turn ON the power switch
 When the power is turned ON rst, the lan-
guageselection screen is displayed. Set the
language you use. (It is possible to change
withMemoryswitch .)
When ending the selection screen
with CANCEL button or ENTER
button without performing the
language selection, the language se-
lection screen is displayed whenever
the power is turned ON.

Ⅱ–7
*Forthedetailedexplanationofthesewing
screen,referto"4. (2) Sewing screen".
2) Select the pattern No. you desire to sew.
 WhenthepoweristurnedON,thedatainput
 screenisdisplayed.PatternNo.button
1 whichis selectedatpresent is displayed
intheuppersectionofthescreen.Pressthe
button to select the pattern No. For select-
ingprocedureofthepatternNo.,referto
"5. PERFORMING PATTERN No. SELEC-
TION ".
 Whenyoupurchasethesewingmachine,
PatternNos.1to10describedin"21. (1)
Initial sewing data at the time of your pur-
chase have been registered".Selectthe
patternNo.youdesiretosewfromamong
thesenumbers.(TheNo.towhichthepattern
hasnotbeenregisteredisnotdisplayed.)
*Forthedetailedexplanationofthis
 screen,see"4. LCD DISPLAY SECTION AT
THE TIME OF INDEPENDENT SEWING".
3) Set the sewing machine to sewing pos-
sible state.
 PressREADYkey 2 , and POWER
OFFPROHIBITIONscreenisdisplayed.
Makepreparationsforsewingwhilethis
screenisdisplayed.
 When the sewing is in a possible state, the
back-light of LCD display changes to green
color.
1
2

Ⅱ–8
<In case of sewing flat/wrapped-around but-
ton with blindstitch or sewing at button with
blindstitch>
Setbutton1tobuttonloader2anddepressthe
backpartofthepedaltoinsertthebuttonintobut-
tonchucks3.
(Whenthebutton loaderisnotused,insertthe
buttonbyhandsincethechuckisopenedbyde-
pressingthebackpartofthepedal.)
↓
Set cloth 4 to tongue 5 and make it come in
contact with tongue stopper 6. (Release of the
tongueisperformedbydepressingthebackpart
ofthepedal.)
↓
Whenthefrontpartofthepedalisdepressed,the
buttonchuckcomesdowntothesewingposition
wherethesewingispossible.
* Bysettingthepedalmotionmodeofmemory
switch data  , the button chuck auto-
maticallycomesdowntothesewingposition.
→ Forthedetailsofthememoryswitchdata,re-
ferto"33. (2) Memory switch data list".
↓
Sewingstartswhenstartswitch7isturnedON.
1
3
2
7
4
5
6
4) Settimg of the sewing products
 Setting procedures of materials and buttons
aredifferentinsewingmethod.
 Setthemwhileoperatingthe devicebyde-
pressing front part A or back part B of the
footpedal.
* For the setting procedure of  Sewing
method, refer to "14. PERFORMING SEW-
ING METHOD SELECTION".
A
B

Ⅱ–9
<In case of sewing flat button directly to
cloth>
Setbutton1tobuttonloader2anddepressthe
backpartofthepedaltoinsertthebuttonintobut-
tonchucks3.
(Whenthebutton loaderisnotused,insertthe
buttonbyhandsincethechuckisopenedbyde-
pressingthebackpartofthepedal.)
↓
Set cloth 4 under the needle, make the tongue
come in contact with the tongue stopper, and
makeclothpresser5comedownbydepressing
thefrontpartofthepedaltoxthecloth.
(By depressing the pedal reversely, the cloth
presserisreleased.)
↓
Whendepressingthefrontpartofthepedalagain,
thebuttonchuckcomesdowntothesewingposi-
tionwherethesewingispossible.
*Bysettingthepedalmotionmodeofmemory
switchdata ,thebuttonchuckauto-
maticallycomesdowntothesewingposition.
→ Forthedetailsofthememoryswitchdata,re-
ferto"33. (2) Memory switch data list".
↓
Sewingstartswhenstartswitch6isturnedON.
45
1
3
2
6

Ⅱ–10
<In case of counter/stay button>
Set upper button 1 to button loader 2 and de-
pressthebackpartofthepedaltoinsertthebut-
tonintobuttonchucks3.
(When the button loader is not used, insert the
buttonbyhandsincethechuckisopenedbyde-
pressingthebackpartofthepedal.)
↓
Insert lower button 4 into button setting section
5ofthefeedplate.
↓
Set cloth 6 under the needle, make the tongue
comeincontactwiththetonguestopper,and
makeclothpresser7comedownbydepressing
thefrontpartofthepedaltoxthecloth.
(Bydepressingthepedalreversely,thecloth
presserisreleased.)
↓
Whenthefrontpartofthepedalisdepressed,the
buttonchuckcomesdowntothesewingposition
wherethesewingispossible.
* Bysettingthepedalmotionmodeofmemory
switchdata , thebuttonchuckauto-
maticallycomesdowntothesewingposition.
→ Forthedetailsofthememoryswitchdata,re-
ferto"33. (2) Memory switch data list".
↓
Sewingstartswhenstartswitch8isturnedON.
8
67
3
1
2
4
5

Ⅱ–11
<In case of neck wrapping sewing>
Installneckwrappingsewingunit1totheinsert-
ingholeofthefeedplate.
↓
Settongue2byhand,andmakeclothpresser3
comedowntoxneckwrappingsewingunit1.
(Tongue and neck wrapping sewing unit are re-
leasedbydepressingthepedalreversely.)
↓
Setthesewing producttoneckwrappingsewing
unit1.
↓
Transportthesewingproductuptothesewing
start position by depressing the front part of the
pedal.(Whendepressingthefrontpartofthe
pedalagain,thesewingproductreturnstotheset
position.
↓
Thesewingstartswhenstartswitch 4 is turned
ON.
2
3
1
1
4

Ⅱ–12
A B C E FD
G
K
J
I
H
L
M
N
P
O
(1) Data input screen
4. LCD DISPLAY SECTION AT THE TIME OF INDEPENDENT SEWING
PatternNo.newregisterscreenisdisplayed.
→ Referto"22. PERFORMING NEW REGISTER OF SEWING
PATTERN".
Sewingpatterncopyscreenisdisplayed.
→Referto"23. COPYING SEWING PATTERN".
Sewingpatternnameinputscreenisdisplayed.
→Referto"6. NAMING THE PATTERN".
Namewhichhasbeeninputtedtothesewingpatternbeingselected
isdisplayed.
Thisbuttonperformsoriginretrieval,makesneedlecomedown,and
displaystheneedlechangescreen.
→Referto"34. PERFORMING CHANGE OF NEEDLE".
Thisbuttonperformsclose/openofthechuck.
Chuckisopenedaslongasthebuttonispressed.
Symbol Display Description
PATTERNNEWREGISTER
button
PATTERNCOPYbutton
PATTERNNAMESETTING
button
PATTERNNAMEdisplay
NEEDLECHANGEbutton
CHUCKCLOSE/OPENbutton
A
B
C
D
E
F

Ⅱ–13
Pattern No. being selected at present is displayed on this button and
whenthebuttonispressed,thepatternNo.changescreenisdisplayed.
→Referto"5. PERFORMING PATTERN No. SELECTION".
Contentsofthe pattern which isregisteredto the patternNo.being selected at
presentaredisplayed.Therespectivedisplaysectionsconsistofbuttonsandcan
bechanged.Thecontentsofdisplaydifferinaccordancewiththesewingmethod.
* Sewingat/wrapped-aroundbuttonwithblindstitch
 →Referto
"8. PERFORMING DATA SETTING OF SEWING BUTTON
WITH BLINDSTITCH (SHANK/MARBLE BUTTON)"and
"9. PERFORMING DATA SETTING OF SEWING BUTTON WITH
BLINDSTITCH (FLAT BUTTON)".
* Sewingatbuttondirectlytocloth
 →Referto"10. PERFORMING DATA SETTING OF SEWING FLAT
BUTTON DIRECTLY TO CLOTH".
* Sewingatbuttonwithblindstitch
 →Referto"11. PERFORMING DATA SETTING OF SEWING FLAT
BUTTON WITH BLINDSTITCH".
* Counter/staybutton
 →Referto
"12. PERFORMING SETTING OF COUNTER/STAY BUTTONS"
.
* Neckwrappingsewing
→ Referto"13. PERFORMING DATA SETTING OF NECK
WRAPPING SEWING DATA".
Sewingdatalistscreenisdisplayed.
→Referto"21. CHANGING SEWING DATA".
Numberofrevolutionssettingscreenisdisplayed.Changeofnumberofrevolutions
ofsewingmachineforbuttonsewingandthatforneckwrappingcanbeperformed.
→Referto"16. PERFORMING SETTING NUMBER OF REVOLUTIONS
OF SEWING MACHINE",
Staythreadsettingscreenisdisplayed.Thisscreenisdisplayedonlyin
caseofsewingat/wrapped-aroundbuttonwithblindstitchoratbutton
withblindstitch,andsettingofstaythreadispossible.
→Referto"17. PERFORMING SETTING STAY THREAD".
Buttonsewingthreadtensionsettingscreenisdisplayed.
→Referto
"18. PERFORMING INPUT OF BUTTON SEWING THREAD TENSION"
.
Neckwrappingthreadtensionsettingscreenisdisplayed.Thisscreenisdisplayedonly
incaseofsewingat/wrapped-aroundbuttonwithblindstitchorneckwrappingsewing.
→Referto
"19. PERFORMING INPUT OF NECK WRAP THREAD TENSION"
.
Sewingdatawhicharemorefrequentlyusedcanbelaidouttofourbuttons.
Whenthisbuttonispressed,thelaid-outsewingdatachangescreenisdisplayed.
→Referto"36. CUSTOMIZING DATA INPUT SCREEN".
Chuckadjustmentscreenisdisplayed.
→Referto"24. PERFORMING CHUCK ADJUSTMENT".
When this button is pressed, the step sewing screen which performs
inputandcheckofneedleentrypointisdisplayed.
→ Referto"26. PERFORMING INPUT AND CHECK OF DATA WITH
STEP MOTION".
Symbol Display Description
PATTERNSELECTIONbutton
CONTENTSOFPATTERN
display
SEWINGDATACHANGEbutton
NUMBEROFREVOLUTIONS
SETTINGbutton
STAYTHREADSETTING
button
BUTTONSEWINGTHREAD
TENSIONSETTINGbutton
NECKWRAPPINGTHREAD
TENSIONSETTINGbutton
CUSTOMIZEbutton
CHUCKADJUSTMENTbutton
STEPSEWINGbutton
G
H
I
J
K
L
M
N
O

P

Ⅱ–14
(2) Sewing screen
Chuckadjustmentscreenisdisplayed.
→Referto"24. PERFORMING CHUCK ADJUSTMENT".
Thisisnotdisplayedintheinitialstate.
→Referto"25. PERFORMING BUTTON CENTERING".
Patternnamewhichissetinthepatterndataduringsewingisdisplayed.
Whenthisbuttonispressed,loaderworksandsetsbuttontothechuck.
Thisbuttonmakesneedlecomedown,andtheneedlechangescreenisdisplayed.
→Referto"34. PERFORMING CHANGE OF NEEDLE".
Symbol Display Description
CHUCKADJUSTMENTbutton
BUTTONCENTERINGbutton
PATTERNNAMEdisplay
LOADERMOTIONbutton
NEEDLECHANGEbutton
A
B
C
D
E
D E FA
G
MN
J
O
P
Q
K
I
L
H
R
B C

Ⅱ–15
Symbol Display Description
F
G
H
I
J
K
L
M
N
O
P
Q
R
CHUCKCLOSE/OPENbutton
PATTERNNO.display
PATTERNCONTENTSdisplay
BLINDSTITCHAMOUNT
SETTINGbutton
COUNTERVALUECHANGE
button
COUNTERCHANGEOVER
button
STEPSEWINGbutton
NUMBEROFREVOLUTIONS
SETTINGbutton
STAYTHREADSETTINGbutton
BUTTONSEWINGTHREAD
TENSIONSETTINGbutton
NECKWRAPPINGTHREAD
TENSIONSETTINGbutton
DIRECTbutton
BUTTONLOADERSELECTION
button
Thisbuttonperformsclose/openofthechuck.
Chuckisopenedaslongasthebuttonispressed.
PatternNo.duringsewingisdisplayed.
Contents of pattern registered to pattern No. during sewing are
displayed.Contentsofdisplaydependonthesewingmethod.
Blindstitchamountonlycanbesetinthesewingscreen.
Settingofblindstitchamountispossible.
* Thisisdisplayedonlyincaseofsewingat/wrapped-aroundbutton
 withblindstitchoratbuttonwithblindstitch.
Existingcountervalueisdisplayedonthisbutton.Whenthebuttonis
pressed,thecountervaluechangescreenisdisplayed.
→Referto "32. USING COUNTER".
Displayofsewingcounter/No.ofpcs.countercanbechangedover.
→Referto"32. USING COUNTER".
Whenthisbuttonispressed,thestepsewingscreenwhichperforms
inputandcheckofneedleentrypointisdisplayed.
→Referto"26. PERFORMING INPUT AND CHECK OF DATA WITH
STEP MOTION".
Numberofrevolutionssettingscreenisdisplayed.Changeofnumberofrevolutionsof
thesewingmachineforbuttonsewingandthatforneckwrappingcanbeperformed.
→
R e f e r t o " 1 6 . P E R F O R M I N G S E T T I N G N U M B E R O F
REVOLUTIONS OF SEWING MACHINE".
Staythreadsettingscreenisdisplayed.Thisscreenisdisplayedonly
in case of sewing at/wrapped-around button with blindstitch or at
buttonwithblindstitch,andsettingofstaythreadispossible.
→Referto"17. PERFORMING SETTING STAY THREAD".
Buttonsewingthreadtensionsettingscreenisdisplayed.
→ Referto"18. PERFORMING INPUT OF BUTTON SEWING
THREAD TENSION".
Neckwrapthreadtensionsettingscreenisdisplayed.Thisscreen
is displayed only in case of sewing at/wrapped-around button with
blindstitchorneckwrappingsewing.
→Referto
"19. PERFORMING INPUT OF NECK WRAP THREAD TENSION"
.
PatternNo.ischangedovertopatternNo.whichisregisteredtothebutton.
→Referto"37. CUSTOMIZING SEWING SCREEN".
Button loader being selected at present is displayed on the button.
Whenthebuttonispressed,thestateofbuttonloadercanbechanged.

Ⅱ–16
1) Display the data input screen.
 Only in case of the data input screen (blue),
thecontentsofsettingcanbechanged.In
caseofthesewingscreen(green),press
READY key 1 and display the data
inputscreen.
2) Call the pattern No. selection screen.
 PressPATTERNNO.SELECTIONbutton
2andthepatternNo.selectionscreen
isdisplayed.PatternNo.whichisselected
atpresentandthe contents are displayed in
theupperpartofthescreenandthelistofthe
pattern No. buttons which have been regis-
teredisdisplayedinthelowerpart.

3) Select the pattern No.
 When UP or DOWN SCROLL button
3 is pressed, the pattern No. buttons
4 which have been registered are changed
overinorder.Thecontentsofthesewingdata
inputtedinthepatternNo.are displayedin
thebutton.Here,pressthepatternNo.button
4youdesiretoselect.
4) Determine the pattern No.
 Press ENTER button 5, and the pat-
ternNo.selectionscreenisclosed.Thenthe
selectionhasbeennished.
* Whenyoudesiretodeletetheregisteredpat-
tern,pressDELETEbutton 6.
 However, the pattern which has been regis-
teredtothecyclestitchingcannotbedeleted.
4
5
3
6
2
1
5. PERFORMING PATTERN No. SELECTION
