JUKI HZL-UX8 User manual

Attention
Please read this instruction manual before using
the machine as it contains important operational
and safety information.
Keep this manual accessible so that you may refer
to it at anytime while operating the machine.
INSTRUCTION MANUAL
COMPUTER SEWING MACHINE
HZL-UX8
EN

1
“IMPORTANT SAFETY INSTRUCTIONS”
When using an electrical appliance, basic safety precautions should always be followed, includ-
ing the following: Read all instructions before using this sewing machine.
“DANGER ____ To reduce the risk of electric shock:”
1. The appliance should never be left unattended when plugged in.
2. Always unplug this appliance from the electric outlet immediately after using and before
cleaning.
“WARNING ____
To reduce the risk of burns, re, electric shock, or injury to persons:”
1. Do not allow this appliance to be used as a toy. Close attention is necessary when this appli-
ance is used by or near children. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concerning use of the appli-
ance in a safe way and understand the hazards involved. Children shall not play with the appli-
ance. Cleaning and user maintenance shall not be made by children without supervision.
2. Use this appliance only for its intended use as described in this manual. Use only attach-
ments recommended by the manufacturer as contained in this manual.
3.
Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it
has been dropped or damaged, or dropped into water. Return the appliance to the nearest au-
thorized dealer or service center for examination, repair, electrical or mechanical adjustment.
4. Never operate the appliance with any air openings blocked. Keep ventilation openings of the
sewing machine and foot control free from the accumulation of lint, dust, and loose cloth.
5.
Keep ngers away from all moving parts. Special care is required around the sewing machine needle.
6. Always use the proper stitch plate. The wrong plate can cause the needle to break.
7. Do not use bent needles.
8. Do not pull or push fabric while stitching. It may deect the needle causing it to break.
9. Switch the sewing machine o󰀨 “O” when making any adjustments in the needle area, such as
changing needle, threading bobbin, or changing presser foot.
10. Always unplug the machine from the electrical outlet when removing covers, when lubricating
or when making any other user servicing adjustments mentioned in the instruction manual.
11. Never drop or insert any object into any opening.
12. Do not use outdoors.
13.
Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
14. To disconnect, turn all controls to the o󰀨 “O” position, then remove plug from outlet.
15. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
16. Basically, the machine should be disconnected from the electricity supply when not in use.
17. If the power cord of this appliance is damaged, it must be replaced with a special cord by
your nearest authorized dealer or service center.
18. (Except USA/Canada) This machine is provided with double insulation.
Use only identical replacement parts. See instructions for servicing Double-Insulated machine.
“SERVICING DOUBLE-INSULATED PRODUCTS”
In a double-insulated product, two systems of insulation are provided instead of grounding. No
grounding means is provided on a double-insulated product nor should a means for grounding be
added to the product. Servicing a double-insulated product requires extreme care and knowledge
of the system and should only be done by qualied service personnel. Replacement parts for a
double-insulated product must be identical to those parts in the product. A double-insulated prod-
uct is marked with the words DOUBLE INSULATION or DOUBLE INSULATED.
The symbol may also be marked on the product.
“SAVE THESE INSTRUCTIONS”
“This sewing machine is intended for household use only.”

2
Danger
warning
which is not
specied
There is a
risk of elec-
trical shock
There is a
risk of re
There is
a risk of
injury to
hands, etc.
Prohibit-
ed matter
which is not
specied
Disas-
sembly/
alteration is
prohibited
Do not
place n-
gers under
the needle
Do not
pour oil,
etc.
Generally
required
behavior
Disconnect
the power
plug
Congratulations on your purchase of a JUKI sewing machine.
Please be sure to read safety precautions in “To use the sewing machine safely” in the Instruc-
tion Manual before use to fully understand the functions and operating procedures of the sewing
machine so as to use the sewing machine for a long time.
After you have read the Instruction Manual, please be sure to keep it together with the warranty
so that you can read it whenever necessary.
The instruction manual is subject to change without prior notice for improvement.
Please visit the JUKI website for the latest version.
https://www.juki.co.jp/household_en/hsm/pdf/HZL-UX8_EN_manual.pdf
To use the sewing machine safely
Marks and pictographs included in the Instruction Manual and shown on the sewing machine are
used so as to ensure safe operation of the sewing machine and to prevent possible risk of injury
to the user and other people.
Warning marks are used for di󰀨erent purposes as described below.
WARNING Indicates that there is a possible risk of death or serious injury if this
mark is ignored and the sewing machine is used in a wrong manner.
ATTENTION
Indicates the operation, etc. which can cause a possible risk of person-
al injury and/or physical damage if this mark is ignored and the sewing
machine is used in a wrong manner.
Pictographs mean the following:

3
● Do not wipe the sewing machine with solvent such
as thinner.
When the sewing machine
is soiled, put a small quan-
tity of neutral detergent on
a piece of soft cloth and
carefully wipe o󰀨 the sew-
ing machine with it.
● Be sure to use the sewing machine
in the temperature range from 5ºC
to 40ºC.
If the temperature is excessively
low, the machine can fail to operate
normally.
WARNING
For the combination of the material and the thread and needle, in particular, refer to the explana-
tion table in “Replacement of the needle”.
If the needle or thread does not match the material used such as in the case that an extra heavy-
weight material (e.g., denim) is sewn with a thin needle (#11 or higher), the needle can break
resulting in an unexpected personal injury.
Other precautions
● Do not put the sewing machine
under the direct sunlight or in a
humid place.
Be aware that the following state can take place since the sewing machine incorporates
semi-conductor electronic parts and precise electronic circuits.
* The operating temperature of the sewing machine is between 5ºC and 40ºC. Do not use the
sewing machine under the direct sunlight, near the burning things such as a stove and candle,
or in a humid place. By so doing, the temperature in the interior portion of the sewing machine
can rise or the coating of the power cord can melt, causing re or electrical shock.
● The safety device of the sewing machine will work
to stop the sewing machine in order to prevent the
generation of abnormal heat in the case the sew-
ing machine is continuously engaged in sewing at
a low sewing speed for a long time or it is continu-
ously engaged in sewing for a long time under the
high temperature environment. In this event, Start
and Stop button will not light.
The sewing machine will
return to working condition
after about 10 minutes.
Stop!

4
Basic screen operation method
● Tap
Tap the screen with your ngertip
once.
● Pinch the screen
Pinch with two ngers.
・
Pinch in
Squeeze your ngers together.
・
Pinch out
Spread your ngers
● Swipe
Tap the screen and slide your
ngertip.
● Be sure to move the sewing machine by holding its handles.
Do not hold portion A when you lift the
sewing machine.
If the sewing machine is heavy, lift it by put-
ting your arm through the arm section.
AA

5
CAUTION
For customers in the USA
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment o󰀨 and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
・
Reorient or relocate the receiving antenna.
・
Increase the separation between the equipment and receiver.
・
Connect the equipment into an outlet on a circuit di󰀨erent from that to which the receiver is
connected.
・
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled en-
vironment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the
IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that is
deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable
that it should be installed and operated keeping the radiator at least 20 cm or more away from
person’s body.
This equipment must not be co-located or operated in conjunction with any other antenna or
transmitter.
For customers in the Europe
This radio equipment is intended to be used with the approved version(s) of software that are
indicated in the EU Declaration of Conformity.
The software loaded on this radio equipment is veried to comply with the essential requirements
of the Directive 2014/53/EU.

6
“IMPORTANT SAFETY INSTRUCTIONS” ..1
Contents...................................................6
1. Conguration and functions ..............8
1.1. Operating buttons .................................... 9
1.2. Operation panel ...................................... 10
2. Accessories .......................................12
3. Set-up .................................................14
3.1. How to install Wide Table....................... 14
3.2. Changing the position of
the foot switch........................................ 15
3.3. Installation of knee lifting lever............. 15
4. Basic settings and
basic operations .............................16
4.1. Connecting to the power supply .......... 16
4.2. Speed control.......................................... 18
4.3. Lifting/lowering of the presser foot ...... 19
4.4. Changing the presser foot..................... 20
4.5. Placing and releasing
“JUKI Smart Feed” ................................ 22
4.6. Changing the throat plate and the feed
dog .......................................................... 23
4.7. How to use the throat plate for straight
stitch ....................................................... 24
4.8. Attaching the needle .............................. 25
4.9. Fabric, thread and needle table............. 26
4.10. Bobbin thread preparation .................... 27
4.11. Needle thread preparation ..................... 31
4.12. How to adjust thread tension ................ 36
4.13. Setting the presser foot pressure ......... 38
4.14. Setting the micro-lifter ........................... 38
4.15.
Setting the automatic back tacking, thread
trimming and presser foot lifting
........... 39
4.16. When changing the needle position ..... 40
4.17. When changing the zigzag width .......... 41
4.18. When changing the stitch length .......... 42
4.19. Setting the stop position of needle....... 43
4.20. Pivot setting ............................................ 43
Contents
5. Setting for the pattern sewing..........44
5.1. Single mode / Combination mode......... 44
5.1.1. Single mode..................................... 44
5.1.2. Combination mode.......................... 45
5.2. Types of patterns under the single mode,
and how to selected a pattern .............. 46
5.2.1. Practical ........................................... 46
5.2.2. Buttonhole ....................................... 48
5.2.3. Appliqué ........................................... 49
5.2.4. Tapering ........................................... 49
5.2.5. Quilt line........................................... 50
6.2.6. Scallop ............................................. 50
5.2.7. One-point ......................................... 51
5.2.8. Decorative........................................ 52
5.2.9. Vintage ............................................. 53
5.2.10. Feather / Lace ................................ 53
5.2.11. Letters ............................................ 54
5.3. Combination of patterns under the com-
bination mode ........................................ 55
5.4. Types of edit functions and how to use
them ........................................................ 58
5.4.1. Pattern inversion............................. 59
5.4.2. Setting the interval between
patterns ................................................. 60
5.4.3. Reset settings.................................. 60
5.4.4.
Writing / capturing the pattern data .. 61

7
6. Sewing................................................62
6.1. Straight stitch ......................................... 62
6.2. Inserting zippers..................................... 67
6.3. Patchwork piecing.................................. 68
6.4. Overcasting stitch .................................. 69
6.5. Blind stitch .............................................. 70
6.6. Shell tuck................................................. 73
6.7. Bartacking ............................................... 74
6.8. Eyelet ....................................................... 76
6.9. Decorative stitches................................. 77
6.10. Lace / feather / overlapping and tiling
(blackwork) patterns.............................. 78
6.11. Scallop stitches ...................................... 79
6.12. Random pattern ...................................... 80
6.13. Tapering................................................... 81
6.14. Buttonhole stitches ................................ 84
6.15. Manual 2-step buttonhole ...................... 91
6.16. Sewing buttons....................................... 93
6.17. Quilting (free motion) ............................. 94
6.18. Hand look quilt stitches ......................... 96
6.19. Quilting (quilt guide) .............................. 97
6.20. Elongation ............................................... 98
6.21. Stitch in ditch quilting............................ 99
6.22. Attaching a quilt sleeve........................ 100
7. Operation of the operation panel... 102
7.1. Support.................................................. 102
7.2. Setting ................................................... 103
① Darning adjustment............................ 104
②Stop position of needle...................... 105
③Pivot..................................................... 105
④Sound volume..................................... 106
⑤Brightness........................................... 106
⑥Stitch speed ........................................ 107
⑦Presser foot lifting height .................. 107
⑧Cancel safety ...................................... 108
⑨Foot switch functions ........................ 108
⑩Two needles ........................................ 109
⑪Wireless LAN....................................... 110
⑫Factory data reset................................111
⑬Software version..................................111
⑭Machine log......................................... 114
⑮Language............................................. 115
⑯Accessibility (Black-and-white inversion
of display) ........................................... 115
⑰Shutdown ............................................ 116
7.3. Sewing ................................................... 117
7.4. History ................................................... 117
7.5. JUKI Sewing Net ................................... 117
8. Message catalog.............................. 118
9. Machine Maintenance .....................123
10. Introduction of optional accessory
parts ...............................................124
11. Performance check list .................126
12. List of stitch patterns....................128
Specication list..................... back cover

8
1. Con guration and functions
Spool cap (large)
Spool pin
Operation panel
Face plate cover
Threading lever
⑧Start/stop button
Presser foot lifting lever
Needle setscrew
Needle
Presser foot
Sensor pinhole for buttonholing
Presser foot releasing button
Feed dog
Throat plate
Hook cover
Bobbin winding
shaft
Hook cover release but-
ton
Presser foot holder
①Thread trimming button
Auxiliary bed
(accessory case)
Thread cutter
⑥ Lock stitch
button
⑤Speed controller
②Needle up/down button
Knee lifting lever
hole
Light under arm
⑦ Reverse stitch
button
③ Feed dog UP/DOWN /
LOCK MODE button
Hand wheel (pulley)
Power switch
Machine-socket-inlet
Foot-controller-jack
USB insertion slot
“JUKI Smart Feed”
Presser foot holder setscrew
④Presser foot auto lift button
Wide table
Handle

9
1.1. Operating buttons
Name Function
①
Thread trim-
ming button
After sewing, press this button to trim both threads automatically.
The sewing machine stops with its needle up after thread trimming.
In the case of 2-needle setting, this button will not operate even if the
thread trimming button is pressed.
②
Needle up/down
button
When machine stops, press this button to change the needle position.
When the needle is up, the needle moves down and vise versa.
The sewing machine performs sewing at a low speed by keeping this
button held pressed for a long time.
③
Feed dog UP/
DOWN / LOCK
MODE button
When you press this button while the sewing machine is at rest, the feed
dog position is changed over.
Lamp lights up: The feed dog is at its lower position
Lamp goes out: The feed dog is at its upper position
*1 If you keep this button held pressed, all operations can be disabled (lock
mode). If you keep it held pressed again, the lock mode will be reset.
③
Presser foot
auto lift button
When this button is pressed while the sewing machine is at rest, the
presser foot position is changed.
When the presser foot is in its upper position,it comes down to its lower
position and vice versa.
④
Speed control-
ler
Sewing speed can be adjusted with the sliding lever of Speed Controller
freely. The sewing speed is increased by moving the speed controller to
the right, or decreased by moving it to the left.
When sewing with foot controller, Max. sewing speed can be set by
Speed Controller.
⑤
Lock stitch but-
ton
When this button is pressed, the sewing machine performs lock stitch.
When this button is pressed while the sewing machine is engaged in pat-
tern sewing, the sewing machine stops after it has completed the sewing
of the one-cycle/one-point of the pattern.
⑥
Reverse stitch
button
For straight stitch/zigzag stitch: The sewing machine performs reverse
stitch as long as this button is held pressed.
For other stitch types: The sewing machine performs lock stitch.
⑦
Start/stop but-
ton
When pressing this button, machine starts to sew slowly and then up to
the speed set by speed controller. Another press of this button stops the
sewing machine.
Color of button indicates machine status.
Green: Ready to start and/or while sewing
Red: Not ready to start
Orange: When the lock stitch button is pressed while the sewing
machine is engaged in pattern sewing (The sewing machine
performs lock stitch after it has completed the sewing of the
pattern by one cycle. Then, the sewing machine stops.)
* When the foot controller is plugged in, the start/stop button cannot be
used to start sewing.
Start button: Can not operate to start sewing.
Stop button: Can operate to stop sewing.
* 1 Lock Mode given in the Instruction Manual refers to the
operation to “keep the feed dog UP/DOWN / LOCK MODE button held
pressed to disable operation of the all keys”. (Refer to page 17)

10
1.2. Operation panel
Tap the screen with
your ngers.
Name Function
A
Tab Select the screen according to your purpose.
Support Main usage of the sewing machine can be checked.
(Refer to page 102)
Setting Setting of the functions (17 kinds) can be changed.
(Refer to page 103)
Sewing Selection and adjustment of the pattern can be carried out.
History Information on the patterns you have sewn remains as history.
If you want to sew the pattern using the condition you have set previously, you
may select it from the history.
JUKI Sewing Net JUKI website is displayed.
B
Adjusting Dial Function of the adjusting dial di󰀨ers with the selected pattern.
Function and the numeric value are displayed on the screen.
Type: “Presser foot pressure”, “Stitch length”, “Zigzag width”, “Tapering length”,
“Elongation”
When you have
changed the set-
ting, the color of
the screen display
changes.
White: Initial value
Blue: Changed value
A
B
❶
❷
❸
❹
❻
Ⓐ
Ⓓ
❺
ⒷⒸ
❼
❽
❾
󱢳󱢴

11
Name Function
ⒶPresser Foot Suitable presser foot for the stitch pattern is displayed.
ⒷNeedle Position Needle position is displayed.
Ⓒ
Type of Throat Plate The type of throat plate is displayed.
: Standard throat plate
: Throat plate for straight stitch
Ⓓ-Sewing Condition Stitch Pattern which is sewn currently or to be sewn is displayed.
❶Sewing-start back
tacking icon
Automatic back tacking at the start of sewing can be set.
: OFF : Reverse stitch : Lock stitch
❷
Thread tension icon Press the thread tension icon when you want to change the thread ten-
sion.
The thread tension set value will be returned to the initial value by select-
ing a di󰀨erent pattern.
❸Sewing-end back
tacking icon
Automatic back tacking at the end of sewing can be set.
: OFF : Reverse stitch : Lock stitch
❹Pattern selection
icon
Press this icon to select a pattern.
Pattern number of the selected pattern is displayed.
❺Pattern edit icon Stitch patterns can be edited.
❻“JUKI Smart Feed”
adjustment icon
Adjustment value of “JUKI Smart Feed” can be set.
❼Presser foot auto lift
icon
Presser foot lifting after thread trimming can be set.
: OFF : ON
❽Automatic thread
trimmer icon
Back tacking and thread trimming can be set.
: OFF : ON
❾Needle position icon Press this icon to change the needle position.
󱢳
USB icon This icon is displayed on the pattern edit screen when a USB thumb drive
is inserted into the USB slot of the sewing machine.
Patterns can be “captured” from and “written” in the USB thumb drive by
pressing this icon.
󱢴
Repetition sewing This icon can be used to set for sewing a combination pattern in repetition
or for sewing a single pattern by one cycle.
In the case of sewing the pattern by one cycle, “1” is displayed.
Initial setting
Single pattern: Repetition
Combination pattern: 1

12
BI
CQR
D
2. Accessories
E
COPQ
IS
DB
4
1
7
R
Auxiliary box
Accessories in the accessory box can also be
stored in the auxiliary bed.
Refer to the gure given below for the storage
procedure (storage location).
Slightly draw the auxiliary bed cover toward
❶ side, then open it toward ❷ side.
Inside of the auxiliary bed
❶❶❷❷
❶❶
❷❷

13
● Inside the auxiliary box.
Cleaning brush
Ripper
T-shape
screwdriver
Zipper presser
foot (B)
Blind stitch presser
foot (D)
Overcasting
presser foot (C)
Bobbin (3)
Manual buttonhole
presser foot (I)
Buttonhole
presser foot (E)
Needle set
HA × 1 # 11 (1)
# 14 (1)
# 16 (1)
for knit # 11 (1)
Spool cap (Middle)
Auxiliary spool pin
Open toe presser
foot (O)
Straight feed dog
7mm guide foot or
1/4" guide foot
Spool cap (Small)
Quilt presser foot
(for the ruler) (Q)
Quilt guide
Patchwork
presser foot (P)
Straight throat plate
Straight presser
foot (S)
Edge Sewing
presser foot (R)
Standard presser
foot (A)
● Supplied with the machine
Bobbin (1)
Spool cap (large)
Sewing machine cover
● It is contained in the packing.
Foot Controller
Quick Reference
Guide
(This manual)
Knee-lifting lever
Power cord
Wide table

14
Adjust the height of legs so that the top
surface of Wide Table is the same height
of sewing machine body.
3.1. How to install Wide Table
2Open legs of Wide Table until they stop
securely at the stopping position.
3Assemble Wide Table to sewing machine
body.
Attach it to free arm of sewing machine.
4
* Don't put any heavy materials on the Wide Table.
* Don't move sewing machine with Wide Table attached.
3. Set-up
1Draw the auxiliary bed out to the left.

15
The lateral position of the foot switch in reference to the pedal can be changed.
Use the foot switch at your desired position.
3.2. Changing the position of the foot switch
1Remove pedal setscrew ❶and block
setscrew ❷.
2Attach pedal ❸and block ❹to the
opposite side while turning them in the
other way around, and tighten the pedal
setscrew and block setscrew.
❶
❷
❺ Foot switch
❸
❹
Insert the knee lifting lever ❶ so that concave ❸
and convex ❷meet.
3.3. Installation of knee lifting lever
❺
Unplug the controller before you
change the position of the foot
switch.
Attention
❶
❷
❶
❷
❸

16
4.1. Connecting to the power supply
●Not-using foot-controller that using
start/stop-button:
② Insert cord-connector ❷ into machine-socket-inlet ❶.
Insert plug ❸ into socket-outlet.
●Using the foot-controller:
② Insert the foot-controller-plug ❺ into the foot-control-
ler-jack ❹.
③ Insert cord-connector into machine-socket-inlet. Insert
plug into socket-outlet.
* When the foot controller is plugged in, the start/stop button
cannot be used to start sewing.
● Start button: Can not operate to start sewing.
● Stop button: Can operate to stop sewing.
WARNING • Disconnect the plug and turn o󰀨 the power switch (turn to “O”) that al-
ways sewing machine is not to use.
4. Basic settings and basic operations
■Connecting the codes
① Turn OFF the power switch (turn to “O”)
WARNING (For U.S.A.,Canada only)
This appliance has a polarized plug (one blade wider than
the other). To reduce the risk of electric shock, this plug
is intended to t in a polarized outlet only one way. If the
plug does not t fully in the outlet, reverse the plug. If it
still does not t, contact a qualied electrician to install the
proper outlet. Do not modify the plug in any way.
❶
❷
❸
❹❺

17
* Be aware that the presser foot goes up automatically
when the power to the sewing machine is turned ON.
The screen shown on the left when the power to the sewing
machine is turned ON.
The needle moves and the screen shown on the left disap-
pears by pressing [OK] .
■Turning the power ON
Turn ON the power switch. (Turn to “I”)
Do not place ngers under
the needle
●Lock mode
The power to the sewing machine should be turned OFF for the sake of safety when changing the presser foot,
changing the throat plate and feed dog, changing the needle or taking care of the sewing machine. However,
those kinds of work can be carried out while retaining the current settings of the sewing machine by putting the
sewing machine in the lock mode.
・
When you want to put the sewing machine in the lock mode, keep the feed dog UP / DOWN / LOCK MODE
button held pressed for two seconds.
・
When you want to reset the lock mode, keep the feed dog UP / DOWN / LOCK MODE button held pressed
for two seconds.
・
When turning o󰀨 the machine, lock mode is disengaged.
If the sewing machine is put in the lock mode, operation of
all operating buttons, operating keys and operation panel
will be disabled. In addition, the sewing machine itself will
also be disabled.
The screen shown on the left is dis-
played when you turn ON the power
to the sewing machine for the rst
time after the delivery.
1. Select the language for display.
2. Press [Start].
3. Set the wireless LAN to which the
sewing machine is connected.
4. Enter the password for the wire-
less LAN.
5. Press [CONNECT] .
* This screen is not displayed when you turn ON the power to the sew-
ing machine next time.

18
To run the machine, press the foot controller.
The harder you press, the faster the machine sews.
Speed controller will set the maximum sewing speed.
❶Pressing harder → faster speed
❷Pressing weaker → slower speed
* Always clean the foot controller.
It is important that you do not place any objects on the
foot controller as it may cause injury to the user and may
cause malfunctions.
4.2. Speed control
Maximum sewing speed can be freely set by the speed
controller.
❶ : Faster speed
❷ : Slower speed
When the needle up/down switch is held pressed, the sewing
machine performs sewing at a low speed.
❶
❷
■Low-speed inching sewing
■Foot controller
■Speed controller
Setting > Stitch speed
Adjustable starting stitch speed
From the setting, the sewing speed at the start of sew-
ing can be changed. (Refer to page 107)
Setting > Stitch speed
Adjustable reverse stitch speed
From the setting, the sewing speed for the reverse
stitching can be changed. (Refer to page 107)
❶❶
❷❷
