Computer-controlled, Eyelet Buttonholing Machine
〈for jeans and cotton pants〉
MEB-3810
The machine achieves a maximum sewing speed as high as 2,500 sti/min
and is provided with a cloth cutting knife which operates at an increased speed,
thereby promising increased productivity.
The machine is a newly developed highly-durable
eyelet buttonholing machine for jeans/cotton pants.

MEB-3810 The machine achieves not only a maximum sewing speed as high as 2,500 sti/min,
but also reduced vibration and noise. The machine is a newly developed
highly-durable simple-design eyelet buttonholing machine for jeans/cotton pants.
Part name Overedging width Needle size Part No. Application
J00 J01 C00 C01
Projection of the arm frame of the machine head has been reduced. In
addition, the cloth cutting knife is located closer to the operator side as
compared with the conventional model. Viewability, when placing the
material on the sewing machine, is improved, thereby contributing to
improved workability. In addition, the thread clamp mechanism of the
needle thread clamp (optional) has been improved for better viewability.
The surface onto which the material is placed is flattened (for the machine
with an overall thread trimmer). The material can, therefore, be placed on
the machine with ease to improve workability.
Increased productivity
Throat plate
Part name Part No. Application
J00 J01 C00 C01
Work clamp (for eyelet buttonhole)
Part No. Application
Max. cutting
length (mm)
J00 J01 C00
Pattern (mm)
X Y C01
Application
J00 J01 C00 C01
Cloth cutting knife (for eyelet buttonhole)
Part No. Application
Max. cutting
length (mm)
J00 J01 C00
Pattern (mm)
X Y C01
Cloth cutting knife (for straight buttonhole)
Improved workability and operability
LIST OF THE REPLACEMENT GAUGES ◎: Provided as standard No symbol : Optional △: Accessory 㽎: Installation is invalid
Part No.
Size
(mm)
Knife guard (for eyelet buttonhole)
Application
J00 J01 C00 C01
Part No.
Size
(mm)
Knife guard (for straight buttonhole)
X
Y
Shape
An LED light is provided as standard on the underside of the jaw of the
machine head. The area around the needle entry is thus brightened to improve
workability.
A retractable bottom cover is
adopted. Daily maintenance
(threading, adjustment of the
looper thread, cleaning, etc.)
can be carried out without
raising the machine head.
Photo: Provided with the needle thread clamp (optional)
A00 (for narrow stitch bite)
B00 (for wide stitch bite)
A01 (for narrow stitch bite)
B01 (for wide stitch bite)
2.0〜3.2mm
2.0〜4.0mm
2.0〜3.2mm
2.0〜4.0mm
Nm90〜Nm110
Nm90〜Nm110
Nm90〜Nm110
Nm90〜Nm110
40115403
40115405
40115404
40115406
◎
㽎
㽎
㽎
㽎
◎
◎
㽎
㽎
㽎
㽎
◎
Work clamp (left) 22mm
Work clamp (right) 22mm
Work clamp (left) 32mm
Work clamp (right) 32mm
Edging work clamp (left) 22mm
Edging work clamp (right) 22mm
Edging work clamp (left) 32mm
Edging work clamp (right) 32mm
Edging work clamp (left) 34mm
Edging work clamp (right) 34mm
Edging work clamp (left) 38mm
Edging work clamp (right) 38mm
Compensating work clamp (left) 34mm
Compensating work clamp (right) 34mm
Compensating work clamp (left) 38mm
Compensating work clamp (right) 38mm
14059802
14059703
14059604
14059605
40039844
40039843
40035239
40035238
40115241
40115240
40115239
40115238
40115325
40115324
40115309
40115316
◎
◎
◎
◎
㽎
㽎
㽎
㽎
◎
◎
㽎
㽎
◎
◎
㽎
㽎
40115664
40115665
32063604※1
32063703※1
32063802※1
32063901※1
32064008※1
32064107※1
32064206※1
32064305※1
32066904※1
28
38
24
32
38
24
32
38
24
32
38
◎◎
㽎
㽎
㽎
㽎
◎◎
㽎
㽎
㽎
㽎
㽎㽎
2.8
2.8
2.9
2.9
2.1
2.1
2.1
3.2
3.2
3.2
2.7
4.3
4.3
4.4
4.4
3.2
3.2
3.2
5.4
5.4
5.4
5.1
14041404※1
32065302※1
32065401※1
38
24
32
0
0
0
0
0
0
△
◎
△
◎
㽎
㽎
△
◎
△
◎
㽎
㽎
㽎
㽎
㽎
㽎
40115670
40115669
40115668
40115667
40115666
32067209※2
32067308※2
32067407※2
32067506※2
32067605※2
32067704※2
32067803※2
32067902※2
32068009※2
32068108※2
32068207※2
32068306※2
32068405※2
32068504※2
32068603※2
38
26
22
20
16
38
36
34
32
30
28
26
24
22
20
18
16
14
12
10
14042501※2
32064404※2
32064503※2
14042600※2
32064602※2
32064701※2
14042808※2
32064800※2
14042907※2
32064909※2
32065005※2
14043109※2
32065104※2
32065203※2
14043301※2
38
36
34
32
30
28
26
24
22
20
18
16
14
12
10
