Juniper CV-4 User manual

CV-4
4-Person Open
Meeting Pod
General Installation Guide

ii
4-PERSON OPEN MEETING POD
2 | Secure Connecting Steel Dowels to Top Panel
Insert connecting steel dowel plate into marking hole on bottom side of top panel and
insert four 3/4” screws through flat plate to secure. Repeat step for all 10 steel dowels.
1 | Measure to Approximate Width
Measure 85” from outer edge of pod of 78.7” from inner wall of pod to find approxi-
mate width. Once positioned, roof panel may be installed.
78.7”
85”

iii
4-PERSON OPEN MEETING POD
3 | Connect Main Power
Assemble connector joint by securing male and female halves together and se-
cure with connector clips on top and bottom of assembly.
4 | Connect Power to Top Panel
Assemble connector joint by securing male and female halves together and secure
with connector clips on top and bottom of assembly. Once connected, tuck completed
assembly into slot at top of side panel.

iv
4-PERSON OPEN MEETING POD
5| Secure Top Panel
Line up steel dowels so they are flush with joint holes on adjacent panel. Push against
outer walls of pod until panels are flushed.
6 | Secure Legs to Table
Secure 4 screws through pre-drilled holes of each table base and into bottom of table
surface.

v
END OF 4-PERSON OPEN MEETING POD SECTION
8 | Place Table Inside Pod
7 | Place Seats Inside Pod
Tilt seat at a 45 degree angle. Slide into pod while tilting seat back so seat sits flat
on floor. Repeat for other side.

1-866-999-0955 | hello@juniperoffice.com | juniperoffice.com
© 2023 Juniper Office | Version 23.0.0
