Juniper JOT Desk BL-6 User manual

BL-6
JOT Desk
U-Shape Workstation
Includes Add-Ons: A1 | A2 | A3 | A4
General Installation Guide

TABLE OF CONTENTS
Edition Code
BL-6-1 :: JOT U-Shape............................................................................. 1
BL-6-2 :: JOT U-Shape with 72” Surface...................................7
BL-6-3 :: JOT U-Shape with Steel Storage........................... 15
Add-ons
A1 :: Surface-Mount Cable Management Tray................. 23
A2 :: Modesty Panel ..............................................................................27
A3 :: Laminate Inset End Panels.................................................... 31
A4 :: Steel Inset End Panels............................................................ 35

Workstation with
54"W Bridge Surface
or Smaller
Overview
JOT U-Shape Workstation
All parts listed are for a U-Shape workstation;
additional parts will be needed for additional U-Shape
workstations.
1

2
54"W BRIDGE OR SMALLER
Code Qty. Description
GBXXXX 2Main Surface
GBXXXX 1Bridge Surface
BLPB2
2Long Beam
4Lock Plate
8Cap Screw
2Locking Screw and Lever
BL30
430”End Leg
12 Wood Screws
BL24
224”End Leg
6Wood Screws
BASB72
1 or 3 42”Support Bar*
20 Wood Screws
BFB1 4Flat Bracket
Parts List
*Support bars will be added to surfaces 72”and longer.

3
54"W BRIDGE OR SMALLER
2 | Bolt Down Beam-to-Leg Lock Plate
Note: Beam lock plates will not fit if there is a gap between beam and leg.
1 | Join Main Surface 30”End Legs with Beam
Insert beam tabs into leg brackets. Guide beam tabs into bracket holes, ensuring
that there is not a gap between beam and legs. Using a rubber mallet, hammer
beam to lock in place.

4
54"W BRIDGE OR SMALLER
3 | Measure and Adjust Beam Width
Measure from end leg to end leg until you find the approximate width of
work surface. Insert the screw through overlapping beam slots and into locking
screw and lever. Slightly tighten screw. DO NOT fully tighten. Insert beam
grommet covers.
4 | Secure Main Surface
Position surface on frame. Align outer sides of surface flush and parallel with outer
sides of end legs, adjust if not flushed. Insert wood screws into leg brackets and
secure to underside of surface.
Align Flush
Align Flush

5
54"W BRIDGE OR SMALLER
5 | Secure Support Hardware to Main Surface for Bridge Surface
Using wood screws for each flat brackets secure brackets to edge of main surface with
half of brackets extended over edge of surface. Using wood screws, secure support bar
to underside of surface centered between flat brackets.
6 | Attach Bridge to Main Surface
Align return surface with main surface and secure flat plates and supported
bar with wood screws into underside of surface. Tighten screw on main profile beam.

6
END OF 54"W BRIDGE OR SMALLER SECTION
8 | 9 | Secure Extra Support Bars
NOTE: Support bars will be added to surfaces 72”and longer. Place support bars as
shown below and secure to underside of surface using wood screws. Tighten screw on
main profile beam.
7 | Attach Second Workstation to Bridge
Align second workstation with return so that back edge is flush. Secure flat brackets
with wood screws into underside of both surfaces. Insert final wood screws and tighten
beam locks.

Workstation with
60” W or Longer
Bridge Surface
Overview
JOT U-Shape Workstation
All parts listed are for a U-Shape workstation;
additional parts will be needed for additional U-Shape
workstations.
7

8
60"W BRIDGE OR LONGER
Parts List
CODE QTY Description
GBXXXX 1Main Surface
GBXXXX 1Bridge Surface
BB3
& BBC1
2Extra Long Beam
4Lock Plate
8Cap Screw
2Locking Screw and Lever
BLPB2 1Long Low Profile Beam
BL30
230”End Leg
12 Wood Screws
BL24
124”End Leg
6Wood Screws
BASB72
242”Support Bar*
20 Wood Screws
BFB1 4Flat Bracket
*Support bars will be added to surfaces 72”and longer.

9
60"W BRIDGE OR LONGER
1 | Join Main Surface 30”End Legs with Beam
Insert beam tabs into leg brackets. Guide beam tabs into bracket holes, ensuring
that there is not a gap between the beam and legs. Using a rubber mallet, hammer
beam to lock in place.
2 | Bolt Down Beam-to-Leg Lock Plate
Note: Beam lock plates will not fit if there is a gap between beam and leg.

10
60"W BRIDGE OR LONGER
3 | Measure and Adjust Beam Width
Measure from end leg to end leg until you find the approximate width of work
surface. Insert screw through overlapping beam slots and into locking screw and
lever. Slightly tighten screw. DO NOT fully tighten. Insert beam grommet covers.
4 | Attach Connector Brackets to BB3 Beam
Place beam connector on the facing edges of each frame. Guide beam tabs
into bracket holes, ensuring that there is not a gap between beam and leg.
Using a rubber mallet, hammer beam to lock in place.

11
60"W BRIDGE OR LONGER
5 | Secure First Surface
Position surface on frame. Align outer sides of surface flush and parallel with outer
sides of end legs. Adjust beam positions if sides are not flush. Fasten surface to
frame with wood screws through leg brackets into underside of surface.
6 | Secure Second Surface
Position second surface on frame. Align outer sides of surface flush and parallel with
outer sides of end legs. Adjust beam positions if sides are not flush. Fasten surface to
desk frame with wood screws through leg brackets into underside of surface.
Align Flush
Align Flush
Align Flush
Align Flush

12
60"W BRIDGE OR LONGER
7 | Secure Bridge Surface
Secure flat brackets to edge of each surface, facing towards inside of workstation,
with half of brackets extended over edge surface. Place final surface over
exposed beam and align with back edge of workstation and secure with wood
screws to flat brackets.
8 | Tighten Beam Locks
Align Flush

13
60"W BRIDGE OR LONGER
9 | Secure Support Bars
NOTE: Support bars will be added to surfaces 72”and longer. Place support bars as
shown below and secure to underside of surface using wood screws.

14
END OF 60"W BRIDGE OR LONGER SECTION

Workstation with
Steel Storage
Overview
JOT U-Shape Workstation
All parts listed are for a U-Shape workstation
with steel storage; additional parts will be needed for
additional U-Shape workstations with steel storage.
15

16
STEEL STORAGE
Code Qty. Description
GBXXXX 2Main Surface
GBXXXX 1Bridge Surface
BB3
1Extra Long Beam
2Lock Plate
4Cap Screw
1Locking Screw and Lever
BL30
330”End Leg
18 Wood Screws
BASB72
1 or 2 42”Support Bar*
20 Wood Screws
BFB1 4Flat Bracket
BLLF42 1Steel Lateral Storage
Parts List
*Support bars will be added to surfaces 72”and longer.

17
STEEL STORAGE
1 | Join Main Surface End Legs with Beam
Insert beam tabs into leg brackets. Guide beam tabs into bracket holes,
ensuring that there is not a gap between the beam and legs.
Using a rubber mallet, hammer the beam to lock in place.
2 | Bolt Down Beam-to-Leg Lock Plate
Note: The beam lock plates will not fit if there is a gap between the beam
and the leg.
