JUNO JDK7450E Technical manual

1
Montage- und Gebrauchsanweisung
für den Dunstabzug
Instruction on mounting and use of the cooker hood
JDK 7450
JDK 8450

2
Abb. 1
Fig. 1 Abb. 2
Fig. 2
Abb. 3
Fig. 3 Abb. 4
Fig. 4
1-2
33
4
I
Abb. 5
Fig. 5

3
Abb. 6 - Fig. 6 - Installation -

7
Hood Description
1) Control panel
2) Grease filters
3) Work-lights
Use
The hood may be used as follows:
— Exhausting version
— Recycling version
Exhausting version
The air is vented outdoors by a duct which
must be connected to the coupling ring S
(See figure 6 “Installation”).
Choosing the exhausting pipe
The coupling ring Shas a diameter of
150mm.
We suggest to use Ø 150 mm exhausting
pipe.
Recycling version
The air is filtered through two carbon
filters (to install them see paragraph -
Carbon filter -) and recirculated into the
room through the grating on the lower
chimney part.
Attention!
If the hood is not supplied with carbon
filter, then it must be ordered and
mounted.
Thisversionisusedwhenthereisnoexhaust
duct for venting outdoors or when it is
impossible to install one.
Installation
When installed, the hood must be not less
than60cm.aboveelectricburnersor75cm.
above gas or mixed-fuel burners.
Warning!
— Thehoodcannotbeconnectedtofluesof
other appliances that run on energy
sources other than electricity.
— When the hood is used at the same time
of other appliances that run on energy
sources other than electricity, provision
must be made for an adequate supply of
air.
—No food must be cooked flambé
underneath the hood.
The use of an unprotected flame is
dangerousforthefiltersandcouldcause
fires.
Therefore,neveruseanopenflameunder
thehood.Whenfryingfoods,neverleave
the pan alone because the cooking oil
could flare up.
— Please, keep to the provisions of official
directivesregardingthequestionoffume
discharge.
— The manufacturers refuse to accept any
responsibility for damage to the hood or
its catching on fire because of failure to
observe the above instructions.
Suggestions for the installation and
use of the hood
— The horizontal sections of the pipe must
be slanted slightly upwards (about 10%)
toensureaneasyflowoftheairoutwards.
— The best performance of the unit is
obtained in the external exhaust model
(suction), therefore in the limits of the
possibilitiesitisadvisedtousetheexternal
exhaust (suction) type.
— Thebestperformancesareobtainedwith
short pipes (max. 4 m) and with few
curves.
Electric connection
Before completing any connection, make
sure the house voltage corresponds with
the voltage indicated on the label affixed
inside the hood.
The hood is supplied with a standard plug;
connect it to a correspondingly standard
socket.
In the case is intended to connect the
appliance permanently to the mains after
having removed the plug supplied, must be
fitted a two-pole switch conforming to
regulations with an opening distance
between contacts of not less than 3mm.
The manufacturers are not liable for any
problems caused by the user’s failure to
observe the above instructions.

8
Mounting the hood - Fig. 6
a. Putthetemplateontothe wall (1)anddrill
two Ø12mm holes (2).
b. Fit two hooks (3) on the drilled holes.
c. Remove the metal filters.
d. Hang the hood on the hooks and adjust
the position of the hood using the two
screws on the bottom of the hooks (5).
e. On the top of the cooker hood mark two
holes (6),
Remove the hood and drill two Ø8mm
holes on the marked points.
Fit two Ø8mm wall dowels (7), Hang
againthehoodandfixthehooddefinitively
with two screws 5X45 (8) from the inside
of thehood.
f. Refit the metal filters
Mounting the chimney
g. Fix the chimney support (10) with two
screws 5 x 45 mm (11) and two wall
dowels(9)onthewallclosetotheceiling.
h. For exhausting version: Fit the
connection ring on the top of the hood
with two screws Ø 3,5 x 6,5 mm (12S)
then fit an axhausting pipe long enough
to reach the outside (13S).
For recycling version: first insert the
fixing nooses of the deflector (K) on the
rear slot (12K) then fix definitively the
deflector (K) on the top of the hood with
two screws Ø 3,5 x 6,5 mm on the front
holes (12K).
i. Preparetheelectricconnection(14) (see
relative chapter).
j. Fit the chimney (15) and fix it on the
chimney support with two screws 3,0 x 9
mm (16).
The lower part of the chimney must be
slided down and inserted on the housing
on the upper part of the hood (17).
Remove the plastic film that protects the
chimney.
k. Fitthetwogrids(18) onboth sides of the
chimney.
Operation
Thehoodhasonevariablespeedmotor.For
thebestperformance,werecommendusing
thelowspeedsin normalconditionsandthe
high speeds in particular cases of strong
odour and vapour concentration.
We recommend starting up the hood a few
minutes before cooking and keeping it
running until all the odours have been
eliminated.
A- Motor OFF button
B- ON button and motor speed selection
button 1 - 2 - 3 - 1 - 2 - . . . .
C- Speed 1 LED
D- Speed 2 LED
E- Speed 3 LED
F- Intensive speed indicator LED
G- Intensive speed ON switch
This speed should be used when the
concentration of cooking fumes or
odours is particularly strong (for
example when frying, cooking fish
etc.). The fast speed will run for
about 5 minutes and then return to
the speed previously set
automatically (1, 2 or 3), or switch off
if no speed was selected.
To turn off the fast speed, before the
end of the 5 minutes, press button A
or button B.
H- OFF-ON lamp button
If the hood fails to operate correctly, briefly
disconnect it from the mains power supply
for almost 5 sec. by pulling out the plug.
Then plug it in again and try once more
before contacting the Technical Assistance
Service.

9
Maintenance
Before performing any maintenance
operation, disconnect the hood from the
electricity.
Metal grease filter
The cooker hood is fitted with metal filters.
Remove the metal filter using the handles
designed for this purpose by pulling them
backwards and then downwards (Fig. 2).
The metal grease filter lasts forever and
must be washed either by hand or in the
dishwasher(65°C) withsuitabledetergents.
The grease filters must be washed at
least once a month.
Before refitting the filter ensure that it is
perfectly dry.
Position of filters is interchangeable.
Carbon filter (2 pieces)
This filter dissolves cooking odours.
The carbon filter must never be washed.
It should be changed every 4 months in
normal use.
Mountingandreplacingthecarbonfilter:
a) Disconnect the hood from the electricity.
b) Remove the grease filters (Fig. 2).
d) If the charcoal filters have already been
installed (covering the grates protecting
the rotor on the motor) and must be
replaced, turn the central handle in the
counter-clockwisedirectionuntilthefilters
are unlocked.
e) Refit the exhaust grate or the grease
filter.
Replacing the lamp
a) Disconnect the hood from the electricity.
b) Remove the grease filters (Fig. 2).
c) Always replace burnt-out lamps with
9Watt max. (PL).
d) Fit again the grease filters.
e) Before calling for repair service because
the hood fails to light up, make sure the
bulbs are screwed in tightly.
Before calling for Repair Service because
the hood fails to light up, make sure the
lamp is well-inserted.
Cleaning
To clean the outside of the hood use a cloth
moistenedwithdenaturedalcoholorneutral
liquid detergents.
Never use products containing abrasive.
Attention
Failure to observe the rules for cleaning the
appliance and changing and cleaning the
filters may cause fires.
Therefore, we recommend observing these
instructions.
Fastening of shelves (optional)
FastenthefoursidesupportsItotheadjacent
cabinetsandplacetheshelfonthesupports
(Fig. 4).

10
L 931 Ed.: 06/97
