Jupio BVM0009 User manual

Specifications Rechargeable Li-ion Battery Pack
Type: BP-type Li-ion rechargeable battery for Professional Video Camera
Maximum Voltage DC 16.8V
Nominal Voltage: DC 14.4V Model: BVM0009
Nominal Capacity: 9.2Ah 132Wh
Battery Protection Circuit: Over-discharge, over-charge and over-current Replace for below models:
Maximum Discharge Current: 6.0A IDX E-7S, E-10S, E-50S, E-70S, E-80S
Operation Time to shoot without a Light: Approx 290min SONY BP-65H, BP-90, BP-GL65, BP-GL95, BP-IL75, BP-L40, BP-L40A,
Internal Resistance (maximum):
≦
260mΩ SONY BP-L60, BP-L60A, BP-L60S, BP-L80S, BP-L90, BP-L90A
Power Indicator 5-LED Power Status
DC output: 12V 3.0A User Manual
End Voltage: 11V
Operating Temperature: Thank you for purchasing this rechargeable Li-ion battery pack. We recommend
Charging: 0°C to 45°C (-10°C to 30°C recommended) that you read this User Manual with care before using the battery and keep this
Discharging: -20°C to 50°C manual for yout future reference.
Storage: -20°C to 60°C (-0°C to 20°C recomended)
Dimension: Approx. 85(W)X141.8(D)X66(H)mm Features
Weight: Approx. 942g
• High capacity, compact and light-weight.
Storage • Five-step LED indicator for easy checking the battery capacity.
• Storage temperature range is -20C 60C. For prolonged battery life, store at • With LCD operation display to monitor the battery status.
0C 20C is recommended.
• To store the battery for a short period, the battery should be stored in discharged Configuration
condition.
• To store the battery for a long period, charge teh battery for about 20 minutes
every five months.
• Before re-use it, it is advisable to recharge the battery fully.
Caution
• Do not puncture or short-circuit the battery.
• Do not burn the battery pack or immerse it in water.
• Always keep the battery in dry place and stay away from humid.
• Do not attempt to break or dismantle the battery pack.
IDX
SONY

Operating Instruction Battery Capacity Status LED Indication
Charge LED indicators Battery Capacity
•
Charge time may vary depending on different conditions and charger used. ● ● ● ● ◌ Below 20%
•
Operating temperature range of 0°C~45°C. For optimum charging performance ● ● ● ◌ ◌ Below 40%
10°C~30°C is recommended ● ● ◌ ◌ ◌ Below 60%
• If the temperature of the battery is below 0°C, the battery will not fully charge ● ◌ ◌ ◌ ◌ Below 80%
even if designated charge time has lapsed. The battery must be charged within ◌ ◌ ◌ ◌ ◌ 100% charged
the recommended temparature range.
● OFF ◌ ON
Discharge Instruction for LCD operation display
• Maximum continuous discharge current is 6.0A
(Note: When using the battery with video or lighting equipment power consump-
tion of te equipment must be 6.0A or below. For the protection of the battery, a
load of 6.0A or over may activate the internal protection circuit and terminate the
supply of power.)
• The normal operating temperature should be in the range of -20°C~50°C. If
the temperature drops below -20°C, discharge may stop.
•
The operating voltage range of this battery is 13V~16V. At the end of discharge
and when its voltage reached 13V and beyond, the voltage will drop sharply.
(For battery voltage alarm setting, please refer to camera manual)
Charge the battery
Battery Protection Circuitry
• Over-charge protection:
If during charge the battery voltage exceeds a preset level, charging is auto-
matically stopped to prevent the battery from being overcharged. The charger
will show a charging fault, though the batteries LEDs will continue to show the
battery charge capacity. If this happens contact your supplier.
Disharge the battery
• Over-discharge protection:
If the battery voltage reaches 9.2V during discharge, the protection circuit will
operate. Then the LED indicators will not operate. When the battery is recharge
and the voltage reaches 12.0V, the LEDs will reset and operate again.
• Over-current protection:
When exposed to a high discharge current, large in-rush current or an external
short circuit, the protection function is activated preventing battery discharge.
Then the LED indicators will not operate. The over-current protection is auto-
Error message
matically reset by disconnecting the battery from equipment in use.
• Thermal protection:
If the internal temperature of the battery pack exceeds preset level, the
thermal fuse will activate and power supply will be terminated. In such
cases the battery cannot be reset. If this happens contact your supplier.
