Jura Impressa Xs9 OT Classic Configuration guide

My Coffee Shop Pty Ltd
ACN 102 850 037
1473-1475 Malvern Road
len Iris VIC 3146
ph: 03 9946 4160
fax: [phone]
93/1-5 Harwood Street
Pyrmont NSW 2009
ph: 02 9034 6580
fax: [phone]
[e-mail] 1300 365 487 www.mycoffeeshop.com.au
Jura Impressa Xs9 OT
Operating & cleaning instructions

4
Control elements
Figure: IMPRESSA XS95 One Touch
Control elements
1 Bean container cover
2 Bean container with aroma preservation
cover
3 Water tank with handle
4 Power switch and power cable
(back of machine)
5 Coffee grounds container
6 Cup platform
7 Drip tray
8 Fineness of grind switch
9 Cup tray
10 Cover of filler funnel for pre-ground coffee
11 Filler funnel for pre-ground coffee
12 Connector System©
for removable frothers
13 Professional Cappuccino Frother
14 Height-adjustable coffee spout
15 Hot water spout
12
1
2
3
13
14
4
8
11
10
15
9
5
6
7

5
Control elements
Front left
1Display
2Rotary Switch cover
3f Rotary switch
Q On/off button
c Maintenance button
i 1 Espresso button
4 2 Espressi button
o1 Coffee button
d 2 Coffees button
e Coffee à la Carte button
vPre-ground coffee button
Front right
4 öSelector switch
5 Professional Cappuccino Frother
6 Easy Cappuccino Frother
a Hot water portion symbol
m Hot water symbol
p Cappuccino button
z Milk portion symbol
n Milk symbol
qLatte Macchiato button
The Connector System©permits the use of different frothers. These are available from stockists.
2
3
4
1
5
56

Operating Instructions – Jura Impressa Xs9
My Coffee Shop Pty Ltd
ACN 102 850 037
1473-1475 Malvern Road
len Iris Vic 3146
ph: 03 9946 4160
fax: [phone]
93/1-5 Harwood Street
Pyrmont NSW 2009
ph: 02 9034 6580
fax: [phone]
[e-mail] 1300 365 487 www.mycoffeeshop.com.au
Cappuccino
1. Place your cup / mug under the milk / coffee spout on the right.
2. Turn the milk selector to the foam milk position – See diagram below.
3. Press the cappuccino key. Your cappuccino will now be poured
Flat white
1. Place your cup/mug under the spout on the right.
2. Turn the milk selector to the flat milk position – See diagram below.
3. Press the Latte macchiato key. Your flat white will now be poured
Café Latte
1. Follow the procedure for making a cappuccino.
2. When your cup or glass 1/3 full of foam milk, turn the milk selector to the flat milk position.
Espresso or Long Black
1. Place your cup / mug under the middle spouts and press espresso or coffee key. Your drink
will now be poured. Press the button twice for a double espresso or two long blacks.
Note: Each key is fully programmed however you can stop the milk and coffee flow short by pressing
any key while it is pouring. Adjustments to suit personal preference can also be made using
the rotary dial. These changes do not affect the programmed settings.

Cleaning Products – Jura Impressa Xs9
My Coffee Shop Pty Ltd
ACN 102 850 037
1473-1475 Malvern Road
len Iris Vic 3146
ph: 03 9946 4160
fax: [phone]
93/1-5 Harwood Street
Pyrmont NSW 2009
ph: 02 9034 6580
fax: [phone]
[e-mail] 1300 365 487 www.mycoffeeshop.com.au
Daily
See procedure – Daily milk system clean
Must be performed at the end of each day just before the machine is turned off
Purpose: To ensure the milk system is clean overnight so milk does not go off blocking the pathways
Use Cafetto daily milk cleaner – 1 litre bottle (Prod no. 71144)
Weekly
See procedure – Weekly milk system clean
Performed once per week
Purpose: To remove any build up of milk fats to ensure the milk frother works correctly
Use Cafetto weekly milk cleaner – 1 litre bottle (Prod no. 71145)
When prompted
Clean machine – See procedure (Coffee system clean)
Performed only when prompted (Every 220 coffees)
Purpose: Removes coffee oil from the brewing unit and coffee path to maintain the quality of the coffee
Use Jura cleaning tablets
- 6 pk (Prod no. 71111)
- 25 pk (Prod no. 71112)
See procedures – Changing the filter or Descaling the machine
Perform a filter change or descale only when prompted.
Purpose: Protects against lime scale build up inside the machine maintaining water & steam paths
Prod no.71131
9 pk – Prod no. 71121
36 pk – Prod no. 71122

Precondition: COFFEE READY
1
2
MAINTENANCE
3
CLEAN CAPPUCCINO
4
CLEANER FOR CAPPU.
5
6
7
8
CAPPUCCINO /CLEANS
WATER FOR CAPPUCCINO
250 ml
1x 15 ml
9
10
11
CAPPUCCINO /CLEANS
COFFEE READY
c250 ml
JURA Elektroapparate AG, Kaffeeweltstraße 10, CH-4626 Niederbuchsiten, www.jura.com
IMPRESSA Xs9 Classic
Daily milk system clean
J
These short instructions do not replace
the ‘IMPRESSA Xs9 Classic Instructions for
Use’. Make sure you read and observe the
safety information and warnings first in
order to avoid hazards.
Equipment required:
JURA Cappuccino Cleaner
1000 ml (Art. 62536)

Weekly milk system clean
My Coffee Shop Pty Ltd
ACN 102 850 037
1473-1475 Malvern Road
len Iris Vic 3146
ph: 03 9946 4160
fax: [phone]
93/1-5 Harwood Street
Pyrmont NSW 2009
ph: 02 9034 6580
fax: [phone]
[e-mail] 1300 365 487 www.mycoffeeshop.com.au
Complete this procedure once a week after the daily milk system clean
1. Remove the automatic milk frother from the machine. (Fig 1 - 2)
2. Separate the automatic milk frother into 4 parts. (Fig 3)
3. Soak plastic / rubber parts in 250ml of warm water & 15ml of Cafetto red weekly solution for 20 min.
4. Remove the parts from the solution and rinse them under cold tap water.
5. Re-assemble the auto frother and refit onto the machine.
Important: Do not soak metal / chrome parts to avoid possible damage.
Figure 1
Figure 2
Figure 3

IMPRESSA Xs9 Classic
Precondition: COFFEE READY /
CLEAN MACHINE
1
DURATION 20 MIN. /
START YES
2
EMPTY TRAY
3
4
5
PRESS RINSE
6
7
CLEANS
ADD TABLET /PRESS
RINSE
8
9
10
11
REINIGT
EMPTY TRAY
12
13
14
COFFEE READY
JURA Elektroapparate AG, Kaffeeweltstraße 10, CH-4626 Niederbuchsiten, www.jura.com
Cleaning the machine
Approximate duration 20 min.
J
These short instructions do not replace
the ‘IMPRESSA Xs9 Classic Instructions for
Use’. Make sure you read and observe the
safety information and warnings first in
order to avoid hazards.
Equipment required:
2-phase cleaning tablets
Tub of 25 (Art. 62535)
Pack of 6(Art. 62715)

IMPRESSA Xs9 Classic
Precondition: COFFEE READY /
DECALCIFY MACHINE
1
DURATION 45 MIN. /
START YES
2
EMPTY TRAY
3
4
5
SOLVENT IN TANK
6
7
8
SOLVENT IN TANK /
PRESS RINSE
3x
9
10
11
DECALCS
EMPTY TRAY
12
13
14
RINSE WATER TANK /
FILL WATER TANK
15
16
PRESS RINSE
c
JURA Elektroapparate AG, Kaffeeweltstraße 10, CH-4626 Niederbuchsiten, www.jura.com
Descaling the machine
Approximate duration 45 min.
J
These short instructions do not replace
the ‘IMPRESSA Xs9 Classic Instructions for
Use’. Make sure you read and observe the
safety information and warnings first in
order to avoid hazards.
Equipment required:
Descaling tablets
Tub of 36 (Art. 70751)
Pack of 3 (Art. 61848)

17
18
19
DECALCS
HEATING UP
MACHINE RINSING
EMPTY TRAY
20
21
22
COFFEE READY

48
6 Display messages
6 Display messages
Message Cause/Result Action
FILL WATER TANK The water tank is empty.
You cannot prepare any coffee
products, hot water or milk
products.
TFill the water tank (see
Chapter 1, ‘Preparing and using
for the first time – Filling the
water tank’).
EMPTY GROUNDS The coffee grounds container
is full. You cannot prepare any
coffee products, but you can
prepare hot water or milk.
TEmpty the coffee grounds
container and the drip tray.
EMPTY TRAY The drip tray is full. You cannot
prepare any coffee products,
hot water or milk products.
TEmpty the drip tray.
TRAY MISSING The drip tray is not inserted
correctly or is not inserted at
all. You cannot prepare any
coffee products, hot water or
milk products.
TInsert the drip tray.
TClean the metal contacts on
the back of the drip tray.
FILL BEANS The bean container is empty.
You cannot prepare any coffee
products, but you can prepare
hot water or milk.
TFill the bean container (see
Chapter 1, ‘Preparing and using
for the first time – Filling the
bean container’).
PRESS RINSE The IMPRESSA is prompting
you to start a rinse operation
or continue a started mainte-
nance programme.
TPress the maintenance button
to start rinsing or to continue the
maintenance programme.
COFFEE READY /
RINSE CAPPUCCINO
The IMPRESSA is prompting
you to start cappuccino
rinsing.
TPress the maintenance button
to start cappuccino rinsing.
COFFEE READY /
CLEAN MACHINE
After 220 preparations or
80 switch-on rinses, the
IMPRESSA will prompt you to
clean it.
TClean the machine (see
Chapter 5, ‘Maintenance –
Cleaning the machine’).

49
6 Display messages
Message Cause/Result Action
COFFEE READY /
CLEAN NOW
After 250 preparations the
IMPRESSA will prompt you
to clean it.
TClean the machine (see
Chapter 5, ‘Maintenance – Clean-
ing the machine’).
COFFEE READY /
DECALCIFY MACHINE
The IMPRESSA is prompting
you to descale it. TDescale the machine (see
Chapter 5, ‘Maintenance – Des-
caling the machine’).
COFFEE READY /
DECALCIFY NOW
The IMPRESSA is prompting
you to descale it. TDescale the machine (see Chapter 5, ‘Maintenance – Des-
caling the machine’).
COFFEE READY /
CHANGE FILTER
After 50 litres of water have
flowed through, or after two
months, the filter will cease
to work.
TReplace the CLARIS filter
cartridge (see Chapter 5
‘Maintenance – Changing the
filter’).
COFFEE READY /
CHANGE NOW
After 55 litres of water have
flowed through, the filter will
cease to work.
TReplace the CLARIS filter
cartridge (see Chapter 5
‘Maintenance – Changing the
filter’).
NOT ENOUGH
PRE-GROUND
There is too little pre-ground
coffee in the filler funnel. The
IMPRESSA stops the operation.
TThe next time you make coffee
use more pre-ground coffee
(refer to Chapter 3, ‘Preparation
at the touch of a button –
Pre-ground coffee’).

Troubleshooting:
Milk flow
 No milk flow
 Milk spluttering
 Not filling cups
 Froth milk is flat & cool
My Coffee Shop Pty Ltd
ACN 102 850 037
1473-1475 Malvern Road
len Iris Vic 3146
ph: 03 9946 4160
fax: [phone]
93/1-5 Harwood Street
Pyrmont NSW 2009
ph: 02 9034 6580
fax: [phone]
[e-mail] 1300 365 487 www.mycoffeeshop.com.au
Solution:
1. Remove the air suction. (Fig 1)
2. Check the valve on the tip of the air suction is clean and is able to open and close freely. Squeeze the valve
between your figures, it should open, release it and it should close. (Fig 2)
3. Refit the air suction. Turn the milk selector to the froth position (Fig 3), and test the milk. If the problem is
still occurring replace the air suction and test again. If the problem has been solved, order in a spare air
suction (Part no. 71210) otherwise go to step 4.
4. Remove the auto frother from the machine. (Fig 4)
5. Separate the auto frother into 4 parts. (Fig 5)
6. Soak plastic / rubber parts in 250ml of warm water and 15 ml of Cafetto red weekly cleaner for 30 min.
7. Clean the milk and air paths with the cleaning brush (Part no. 71161) (Fig 6 – 9)
8. Rinse parts under tap water, re-assemble the auto frother and refit onto the machine.
9. Test the milk. If the problem has not been solved contact customer support on 1300 365 487.
Important: Do not soak metal / chrome parts to avoid possible damage.
Figure 1
Figure 2
Figure 3 Froth Figure 4
Figure 5
Figure 6 - Milk
Figure 7 - Milk Figure 8 - Air Figure 9 - Milk

My Coffee Shop Pty Ltd
ACN 102 850 037 1473 - 1475 Malvern Rd
Glen Iris VIC 3146
ph: 03 9946 4160
fax: [phone]
93 / 1-5 Harwood Street
Pyrmont NSW 2009
ph: 02 9034 6580
fax: [phone]
Welcome to My Coffee Shop!
Our hours of operation are Monday – Friday 9am to 5pm. Or you can visit us at your
convenience on the web at www.mycoffeeshop.com.au. Orders and service requests can
be placed by:
Phone:
Fax:
E-mail:
Online:
Remittances:
1300 365 487
02 9692 8046
[e-mail]
www.mycoffeeshop.com.au/shop-online
[e-mail]
Service enquiries: [email protected]
Once again, welcome to My Coffee Shop and remember we are here to help. If you have
any questions please don’t hesitate to contact us.
We look forward to exceeding your expectations and making your day easier and more
enjoyable.
Kind regards,
My Coffee Shop
Client Services
My Coffee Shop Pty Ltd
Next business day delivery via Toll Priority to:
Adelaide Canberra Melbourne Sydney
for orders placed by 1.30pm
Please note you will be advised when
ordering if delivery charges apply to your
order
