JVC KD-G730 User manual

ENGLISHESPAÑOL
FRANÇAIS
CD RECEIVER KD-AR780/KD-G730
RECEPTOR CON CD KD-AR780/KD-G730
RÉCEPTEUR CD KD-AR780/KD-G730
For canceling the display demonstration, see page 6.
Para cancelar la demostración en pantalla, consulte la página 6.
Pour annuler la démonstration des affichages, référez-vous à la page 6.
For installation and connections, refer to the separate manual.
Para la instalación y las cone iones, refiérase al manual separado.
Pour l’installation et les raccordements, se référer au manuel séparé.
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
GET0433-001A
[J]
For customer Use:
Enter below the Model
No. and Serial No. which
are located on the top or
bottom of the cabinet. Retain
this information for future
reference.
Model No.
Serial No.
Cover_KD-AR780_G730[J]2.indd 1Cover_KD-AR780_G730[J]2.indd 1 1/24/07 11:44:43 AM1/24/07 11:44:43 AM

ENGLISH
2
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
INFORMATION (For U.S.A.)
This equipment has been tested and found to comply with the limits for a Class B digital de ice, pursuant to Part
15 of the FCC Rules. These limits are designed to pro ide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Howe er, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or tele ision reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the recei ing antenna.
– Increase the separation between the equipment and recei er.
– Connect the equipment into an outlet on a circuit different from that to which the recei er is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Caution:
Changes or modifications not appro ed by JVC could oid the user’s authority to operate the equipment.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top co er. There are no user ser iceable parts inside the unit; lea e all ser icing to
qualified ser ice personnel.
3. CAUTION: (For U.S.A.) Visible and/or in isible class II laser radiation when open. Do not stare into beam.
(For Canada) Visible and/or in isible class 1M laser radiation when open. Do not iew directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
[European Union only]
EN02-07_KD-AR780_G730[J]2.indd 2EN02-07_KD-AR780_G730[J]2.indd 2 1/24/07 11:44:22 AM1/24/07 11:44:22 AM

ENGLISH
3
How to reset our unit
• Your preset adjustments will also be erased (except
the registered Bluetooth device, see page 13).
How to forcibl eject a disc
“Please Eject” appears on the display.
• Be care ul not to drop the disc when it ejects.
• I this does not work, reset your unit.
For safet ...
• Do not raise the olume le el too much, as this will
block outside sounds, making dri ing dangerous.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you ha e parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
How to use the M MODE and SEL buttons
If you use M MODE or SEL (select), the display
and some controls (such as the number buttons,
4/¢ buttons, 5/∞ buttons, and the
control dial) enter the corresponding control mode.
Ex.: When you press number button 1 after
pressing M MODE, to operate the FM tuner.
To use these controls for original functions again,
wait for 15 seconds (or 30 seconds for Bluetooth
sources) without pressing any of these buttons until
the control is cleared.
• Pressing M MODE again also restores original
functions. Howe er, pressing SEL makes the unit
enters a different mode.
Works as time countdown indicator.
EN02-07_KD-AR780_G730[J]2.indd 3EN02-07_KD-AR780_G730[J]2.indd 3 1/24/07 11:44:25 AM1/24/07 11:44:25 AM

ENGLISH
4
Detaching the control panel
Attaching the control panel
Caution:
If the temperature inside the car is below 0°C (32°F),
the mo ement of animation and text scroll will be
halted on the display to pre ent the display from being
blurred. appears on the display.
When the temperature increases, and the operating
temperature is resumed, these functions will start
working again.
Warning:
If you need to operate the unit while dri ing, be sure to
look around carefully or you may be in ol ed in a traffic
accident.
Caution on volume setting:
Discs produce ery little noise compared with other
sources. Lower the olume before playing a disc to
a oid damaging the speakers by the sudden increase of
the output le el.
KD-AR780 is equipped with the steering wheel
remote control function.
• See the Installation/Connection Manual (separate
olume) for connection.
EN02-07_KD-AR780_G730[J]2.indd 4EN02-07_KD-AR780_G730[J]2.indd 4 1/24/07 11:44:25 AM1/24/07 11:44:25 AM

ENGLISH
5
CONTENTS
INTRODUCTIONS
Preparation ....................................................................................................... 6
OPERATIONS
Basic operations ................................................................................................. 7
• Using the control panel ................................................................................. 7
• Using the remote controller (RM-RK50) .......................................................... 8
Listening to the radio .......................................................................................... 9
Disc operations ................................................................................................... 11
EXTERNAL DEVICES
Using the Bluetooth ® devices ............................................................................... 13
• Using the Bluetooth cellular phone ................................................................ 16
• Using the Bluetooth audio pla er ................................................................... 18
Listening to the CD changer ................................................................................. 19
Listening to the satellite radio ............................................................................. 21
Listening to the iPod / D. pla er ........................................................................... 24
Listening to the other external components .......................................................... 26
SETTINGS
Selecting a preset sound mode ............................................................................. 28
General settings — PSM ...................................................................................... 31
Bluetooth settings .............................................................................................. 36
Assigning titles ................................................................................................... 37
REFERENCES
Maintenance ...................................................................................................... 38
More about this unit ........................................................................................... 39
Troubleshooting ................................................................................................. 42
Specifications ..................................................................................................... 46
EN02-07_KD-AR780_G730[J]2.indd 5EN02-07_KD-AR780_G730[J]2.indd 5 1/24/07 11:44:25 AM1/24/07 11:44:25 AM

ENGLISH
6INTRODUCTIONS
Preparation
Cancel the displa demonstration and set the clock
• See also pages 31 and 32.
~ Turn on the power.
Ÿ Enter the PSM settings.
! ] ⁄ Cancel the displa demonstrations
Select “Demo,” then “Off.”
Set the clock
Select “Clock Hr” (hour), then adjust the hour.
Select “Clock Min” (minute), then adjust the minute.
Select “24H/12H,” then “24Hours” or “12Hours.”
@ Finish the procedure.
Changing the displa information and pattern
Ex.: When tuner is selected as the source
When the power is turned off: Check the current clock time
When the power is turned on: Change the display information and pattern
Source operation display Audio le el meter display
(see “Le elMeter” on page 31)
EN02-07_KD-AR780_G730[J]2.indd 6EN02-07_KD-AR780_G730[J]2.indd 6 1/24/07 11:44:26 AM1/24/07 11:44:26 AM

ENGLISH
7OPERATIONS
Basic operations
Using the control panel
1 Select the source.
TUNER = SIRIUS */XM * = CD * = CD-CH */
iPod */D.PLAYER * (or EXT IN) = Bluetooth
Phone * = Bluetooth Audio * = AUX IN =
(back to the beginning)
* You cannot select these sources if they are not
ready or not connected.
2 Select the bands.
3 • Turn on the power.
• Turn off the power [Hold].
• Attenuate the sound (if the power is on).
• Volu e control [Turn].
4 • Adjust the sound ode.
• Enter the PSM settings [Hold].
5 Display window
6 Select the sound ode.
7 Eject disc.
8 AUX (auxiliary) input jack
9 Detach the panel.
p Change the display infor ation and pattern.
q Enter functions ode.
w • TUNER/SIRIUS/XM: Select preset station/
channel.
• CD/CD-CH: Select folder/track/disc (for CD
changer).
• Bluetooth Phone: Select preset phone
nu ber.
e • TUNER/SIRIUS/XM: Search for station/channel.
• CD/CD-CH: Select track.
• iPod/D.PLAYER: Select track.
• Bluetooth Phone/Audio: Select setting ite .
r • TUNER: Select preset station.
• SIRIUS/XM: Select category.
• CD/CD-CH: Select folder.
• iPod/D.PLAYER: Enter the ain enu/Pause or
stop playback/Confir selection.
• Bluetooth Phone/Audio: Select a registered
device.
EN02-07_KD-AR780_G730[J]f.indd 7EN02-07_KD-AR780_G730[J]f.indd 7 2/2/07 9:34:28 AM2/2/07 9:34:28 AM

ENGLISH
8
Using the remote controller
(RM-RK50)
Installing the lithium coin battery (CR2025)
Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
Warning:
To pre ent accidents and damage
• Do not install any battery other than C 2025 or its
equivalent.
• Do not leave the remote controller in a place
(such as dashboards) exposed to direct sunlight
for a long time.
• Store the battery in a place where children cannot
reach.
• Do not recharge, short, disassemble, heat the
battery, or dispose of it in a fire.
• Do not leave the battery with other metallic
materials.
• Do not poke the battery with tweezers or similar
tools.
• Wrap the battery with tape and insulate when
throwing away or saving it.
emote sensor
For USA-California Only:
This product contains a C Coin Cell Lithium Battery
which contains Perchlorate Material—special
handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
1 • Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
2 • Changes the FM/AM bands with 5 U.
• Changes the preset stations with D ∞.
• Changes the folder of the MP3/WMA.
• While playing an MP3 disc on an
MP3-compatible CD changer:
– Changes the disc if pressed briefly.
– Changes the folder if pressed and held.
• While listening to the satellite (SI IUS or XM)
radio:
– Changes the categories.
• While listening to an Apple iPod or a JVC
D. player:
– Pauses/stops or resumes playback with D ∞.
– Enters the main menu with 5 U.
(Now 5 U/D ∞/2 /F 3 work as the menu
selecting buttons.)*
3 Adjusts the volume level.
4 Selects the sound mode (iEQ: intelligent equalizer).
5 Selects the source.
EN08-17_KD-AR780_G730[J]f.indd 8EN08-17_KD-AR780_G730[J]f.indd 8 2/2/07 9:35:20 AM2/2/07 9:35:20 AM

ENGLISH
9OPERATIONS
6 For Bluetooth cellular phone:
– Answers calls if pressed briefly.
– ejects calls if pressed and held.
7 • Searches for stations if pressed briefly.
• Fast-forwards or reverses the track if pressed and
held.
• Changes the tracks if pressed briefly.
• While listening to the satellite radio:
– Changes the channels if pressed briefly.
– Changes the channels rapidly if pressed and
held.
• While listening to an iPod or a D. player (in menu
selecting mode):
– Selects an item if pressed briefly. (Then, press
D ∞ to confirm the selection.)
– Skips 10 items at a time if pressed and held.
• everse skip/forward skip for Bluetooth audio.
* 5 U : Returns to the previous menu.
D ∞ : Confirms the selection.
Listening to the radio
Change the display information* and pattern
~ Select “TUNER.”
Ÿ Select the bands.
! Search for a station to listen—Auto Search.
Manual Search: Hold either one of the buttons until “Manual Search” appears on the display, then press it
repeatedly.
• When receiving an FM stereo broadcast with sufficient signal strength, lights up on the display.
* If no title is assigned to a station, “No Name” appears. To assign a title to a station, see page 37.
Select preset station.
Continued on the next page
EN08-17_KD-AR780_G730[J]2.indd 9EN08-17_KD-AR780_G730[J]2.indd 9 1/24/07 11:43:33 AM1/24/07 11:43:33 AM

ENGLISH
10
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset number
4 of the FM1 band.
Using the number buttons
1
2
3
Using the Preset Station List
When appears on the display, you can move
back to the previous display by pressing number
button 3.
1 Follow steps 1 and 2 of “Using the
number buttons” above.
By holding 5 / ∞, the Preset Station List will
appear (go to step 4).
2
3 Display the Preset tation List.
When an FM stereo broadcast is hard
to receive
1
2
Reception improves, but stereo effect will be lost.
lights up on the display.
3 Exit from the setting.
FM station automatic presetting —
SSM (Strong-station Sequential
Memory
You can preset up to six stations for each band.
1
2
3
4
Local FM stations with the strongest signals are
searched and stored automatically in the FM band.
EN08-17_KD-AR780_G730[J]f.indd 10EN08-17_KD-AR780_G730[J]f.indd 10 2/7/07 9:05:00 AM2/7/07 9:05:00 AM

ENGLISH
11OPERATIONS
Prohibiting disc ejection
To cancel the prohibition, repeat the same
procedure.
4 Select the preset number you want to
store into.
• You can move to the lists of the other FM bands
by pressing number button 5 ( ) or
6 ( ) repeatedly.
5 Store the station.
Listening to the preset station on the
Preset Station List
1 Display the Preset Station List, then
select the preset station you want to
listen to.
2 Change to the selected station.
Disc operations
Open the control panel and insert the disc.
Playback starts automatically.
To stop play and eject the disc
• Press S C to listen to another
playback source.
Change the display information and pattern
Continued on the next page
EN08-17_KD-AR780_G730[J]2.indd 11EN08-17_KD-AR780_G730[J]2.indd 11 1/24/07 11:43:35 AM1/24/07 11:43:35 AM

ENGLISH
12
Pressing (or holding) the following buttons allows you to...
Button
ress: Select track
Hold: everse/fast-forward track
ress: Select track
Hold: everse/fast-forward track
Select folder
—
(Number buttons) *2
Locate particular folder directly *3Locate particular track directly
*1 Holding either one of the buttons can display the Folder List (see page 13).
*2 ress to select number 1 to 6; hold to select number 7 to 12.
*3 It is required that folders be assigned with 2-digit numbers at the beginning of their folder names—01, 02, 03, and
so on.
After pressing , press the following buttons to...
Button
Skip 10 tracks (within the same folder) Skip 10 tracks
Intro Track:
Plays the beginning 15 seconds of all tracks
Intro Folder:
Plays the beginning 15 seconds of the first
tracks of all folders
Intro Track:
Plays the beginning 15 seconds of
all tracks
Repeat Track:
epeat current track
Repeat Folder:
epeat current folder
Repeat Track:
epeat current track
Random Folder:
andomly play all tracks of current folder,
then tracks of next folders
Random Disc:
andomly play all tracks
Random Disc:
andomly play all tracks
• You can also cancel the playback mode by selecting “Off” or press number button 4 ( ).
*1
EN08-17_KD-AR780_G730[J]2.indd 12EN08-17_KD-AR780_G730[J]2.indd 12 1/24/07 11:43:36 AM1/24/07 11:43:36 AM

ENGLISH
13OPERATIONS & EXTERNAL DEVICES
Selecting a folder/track on the list
(only for MP3/WMA disc)
• When appears on the display, you can move
back to the previous display by pressing number
button 3.
1
2 Select “LIST.”
3 Select the list type.
4 Select an item.
• You can move to the other lists by pressing
number button 5 ( ) or 6 ( )
repeatedly.
5 Change to the selected item.
• If File List is selected • If Folder List is
selected
• The list disappears and playback starts.
EX.: When “File” is selected in
step 3
Continued on the next page
Using the Bluetooth ®
devices
For Bluetooth operations, it is required to connect the
Bluetooth Adapter (KS-BTA200) to the CD changer
jack on the rear of this unit. See also page 27.
• efer also to the instructions supplied with the
Bluetooth adapter and the Bluetooth device.
• efer to the list (included in the box) to see the
countries where you may use the Bluetooth®
function.
To use a Bluetooth device through the unit (“Bluetooth
Phone” and “Bluetooth Audio”) for the first time,
you need to establish Bluetooth wireless connection
between the unit and the device.
• Once the connection is established, it is registered in
the unit even if you reset your unit. Up to five devices
can be registered in total.
• Only one device can be connected at a time for each
source (“Bluetooth Phone” and “Bluetooth Audio”).
Registering a Bluetooth de ice
Registration (Pairing) methods
Use either of the following items in the Bluetooth menu
to register and establish the connection with a device.
• Select “Bluetooth Phone” or “Bluetooth Audio” as the
source to operate the Bluetooth menu.
Open Make the unit ready to establish a new
Bluetooth connection.
Connection is established by operating the
Bluetooth device.
Search Make the unit ready to establish a new
Bluetooth connection.
Connection is established by operating
the unit.
EN08-17_KD-AR780_G730[J]2.indd 13EN08-17_KD-AR780_G730[J]2.indd 13 1/24/07 11:43:36 AM1/24/07 11:43:36 AM

ENGLISH
14
2 Select a number.
3 Repeat steps 1 and 2 until you finish
entering a PIN code.
4 Confirm the entry.
“Open...” flashes on the display.
6 Use the Bluetooth device to search and
connect.
On the device to be connected, enter the same
PIN code you have just entered for this unit.
“Connected (and device name ” appears on the
display.
Now connection is established and you can use the
device through the unit.
The device remains registered even after you
disconnect the device. Use “Connect“ (or activate
“Auto Connect” to connect the same device from
next time. (See pages 15 and 36.
Searching for available devices
Perform steps 1 – on the left column, then...
1 Select “Search.”
The unit searches and displays the list of the
available devices.
• If no available device is detected, “Device not
found” appears.
2 Select a device you want to connect.
• When appears on the display, you can move
back to the previous display by pressing number
button 3.
Registering using “Open”
Preparation
Operate the device to turn on its Bluetooth function.
1 Select “Bluetooth Phone” or “Bluetooth
Audio.”
2 Select “New.”
3 Enter setting menu.
4 Select “Open.”
5 Enter a PIN (Personal Identification
Number) code to the unit.
• You can enter any number you like (1-digit to
16-digit number . [Initial: 0000]
• To enter a PIN code less than 4-digit, press
number button 5 ( to delete the initial
PIN code.
* Some devices have their own PIN code. Enter the
specified PIN code to the unit.
1 Move to the next (or previous) number
position.
EN08-17_KD-AR780_G730[J]3.indd 14EN08-17_KD-AR780_G730[J]3.indd 14 1/26/07 3:41:08 PM1/26/07 3:41:08 PM

ENGLISH
15EXTERNAL DEVICES
3 Enter the specific PIN code of the device to
the unit.
• Refer to the instructions supplied with the device
to check the PIN code.
4 Use the Bluetooth device to connect.
Now connection is established and you can use the
device through the unit.
Connecting a special device
Perform steps 1 – on page 14, then...
1 Select “Special Device.”
The unit displays the list of the preset devices.
2 Select a device you want to connect.
3 Use “Open” or “Search” to connect.
Connecting/disconnecting a registered device
1 Select “Bluetooth Phone” or “Bluetooth
Audio.”
2 Select a registered device you want to
connect/disconnect.
3 Enter setting menu.
4 Select “Connect” or “Disconnect” to connect/
disconnect the selected device.
You can set the unit to connect a Bluetooth device
automatically when the unit is turned on. (See
“Auto Connect” on page 36.
Deleting a registered device
1 Select “Bluetooth Phone” or “Bluetooth
Audio.”
2 Select a registered device you want to delete.
3 Enter setting menu.
4 Select “Delete.”
5 Delete the selection.
• Press number button 3 to select “No” or return to
step 4 above.
EN08-17_KD-AR780_G730[J]3.indd 15EN08-17_KD-AR780_G730[J]3.indd 15 1/26/07 3:25:28 PM1/26/07 3:25:28 PM

ENGLISH
16
Using the Bluetooth cellular phone
~ Select “Bluetooth Phone.”
Ÿ Enter Bluetooth menu.
! Make a call or setting using the Bluetooth setting menu. (See pages 17 and 6.)
When a call comes in
The source is automatically changed to “Bluetooth
Phone.”
When “Auto Answer” is activated....
The unit answers the incoming calls automatically, see
page 36.
• When “Auto Answer” is deactivated, press any
button (except /control dial to answer the
incoming call.
To end the call
Hold any button (except /control dial .
• You can adjust the microphone volume level (see
page 36 .
When a text message comes in
If the cellular phone is compatible with text message
and “Message Info” is set to “Auto” (see page 36 , the
unit rings and “MSG” appears on the display to inform
you the arrival of the message.
To read the message
While “MSG” is displayed...
• Press number button 3 to select “No” or return to the
current source display.
• You cannot edit or send a message through the unit.
• Hold D DISP to change the font type.
EN08-17_KD-AR780_G730[J]3.indd 16EN08-17_KD-AR780_G730[J]3.indd 16 1/26/07 3:25:28 PM1/26/07 3:25:28 PM

ENGLISH
17EXTERNAL DEVICES
Making a call
You can make a call using one of the Dial Menu items.
• When appears on the display, you can move
back to the previous display by pressing number
button 3.
1 Select “Bluetooth Phone.”
2 Enter setting menu.
3 Select “Dial Menu.”
4 Select the method to make a call.
• Redial * Shows the list of the phone numbers
you have dialed. Go to the following step.
• Received Calls * Shows the list of the received
calls. Go to the following step.
• Phonebook * Shows the phone book of the
connected cellular phone. Go to the following
step.
• Missed Calls * Shows the list of the missed
calls. Go to the following step.
• Phone Number Shows the phone number
entry screen. See “How to enter phone number”
on the right column.
• oice Dialling (Only accessible when the
connected cellular phone has the voice
recognition system) Speak the name you want
to call.
* Displays only when your cellular phone is
equipped with these functions.
– If not displayed, please try to transfer the
phone book memory of the cellular phone
to this unit. (Refer to the instruction manual
supplied with your cellular phone.)
– With some cellular phones, the phone book
memory is transferred automatically.
5 Select the name/phone number you want to
call.
How to enter phone number
Select a number.
Move the entry position.
Confirm the entry.
EN08-17_KD-AR780_G730[J]f.indd 17EN08-17_KD-AR780_G730[J]f.indd 17 2/7/07 5:34:45 PM2/7/07 5:34:45 PM

ENGLISH
18
3 Select the preset number.
To call a preset number
Using the Bluetooth audio player
~ Select “Bluetooth Audio.”
If playback did not start automatically, operate the Bluetooth audio player to start playback.
• Refer also to page 15 for connecting/disconnecting/deleting a registered device.
* Operation may be different according to the connected phone.
Bluetooth Information:
If you wish to receive more information about Bluetooth, visit our VC web site.
Reverse skip/forward skip
Stop playback *
Enter setting menu
(Device list)
Start playback *
Presetting the phone number
ou can preset up to six phone numbers.
• When appears on the display, you can move
back to the previous display by pressing number
button 3.
1 Display the phone number you want to
preset by using one of the ”Dial Menu”
items.
2 Select a phone number.
EN18-27_KD-AR780_G730[J]f.indd 18EN18-27_KD-AR780_G730[J]f.indd 18 2/7/07 5:36:15 PM2/7/07 5:36:15 PM

ENGLISH
19EXTERNAL DEVICES
Listening to the CD changer
Change the display information
and pattern
It is recommended to use a JVC MP3-compatible CD changer with your unit. ou can connect a CD changer to the CD
changer jack on the rear of the unit. See also page 27.
• ou can only play conventional CDs (including CD Text) and MP3 discs.
Preparation
Make sure “Changer” is selected for the external input setting, see page 33.
~ Select “CD-CH.”
Ÿ Select a disc to start playing.
Press: For selecting disc number 1 – 6.
Hold: For selecting disc number 7 – 12.
Pressing (or holding) the following buttons allows you to...
Button
Press: Select track
Hold: Reverse/fast-forward track
Press: Select track
Hold: Reverse/fast-forward track
Select folder
—
* Holding either one of the buttons can display the Disc List (see page 13).
Continued on the next page
*
EN18-27_KD-AR780_G730[J]2.indd 19EN18-27_KD-AR780_G730[J]2.indd 19 1/24/07 11:43:16 AM1/24/07 11:43:16 AM

ENGLISH
20
After pressing , press the following buttons to...
Button
Skip 10 tracks (within the same folder) Skip 10 tracks
Intro Track:
Plays the beginning 1 seconds of all tracks of
the current disc
Intro Folder:
Plays the beginning 1 seconds of the first
tracks of all folders
Intro Disc:
Plays the beginning 1 seconds of the first
tracks of all the inserted discs
Intro Track:
Plays the beginning 1 seconds of
all tracks of the current disc
Intro Disc:
Plays the beginning 1 seconds of
the first tracks of all the inserted
discs
Repeat Track:
Repeat current track
Repeat Folder:
Repeat current folder
Repeat Disc:
Repeat current disc
Repeat Track:
Repeat current track
Repeat Disc:
Repeat current disc
Random Folder:
Randomly play all tracks of current folder,
then tracks of next folders
Random Disc:
Randomly play all tracks
Random All:
Randomly play all tracks of the inserted disc
Random Disc:
Randomly play all track
Random All:
Randomly play all tracks of the
inserted disc
• You can also cancel the playback mode by selecting “Off” or press number button 4 ( ).
To select a disc/folder/track on the list, see ”Selecting a folder/track on the list (only for MP3/WMA disc)” on page 13.
Select ”Disc” on step 3 to display the Disc List of the CD changer.
EN18-27_KD-AR780_G730[J]3.indd 20EN18-27_KD-AR780_G730[J]3.indd 20 1/26/07 3:26:10 PM1/26/07 3:26:10 PM
