JVC S15U - DLA - D-ILA Projector User manual

ENGLISHFRANÇAIS
DLA-S15U INSTRUCTIONS
PROJECTOR
MANUEL D’INSTRUCTIONS : PROJECTEUR
OPERATE
VOL.
PAGE
BACK
PRESET
FOCUS
COMPUTER VIDEO
QUICK
ALIGN. AV MUTING
RM-M10SG REMOTE CONTROL UNIT
MENU/ENTER
For customer Use:
Enter below the Serial No. which is located
on the side panel of the cabinet. Retain this
information for future reference.
Pour l’utilisateur:
Inscrivezci-dessousleNodesériesituésur
le panneau latéral du coffret de l’appareil.
Conservez cette information à titre
d’information.
Model No.
No de modèle DLA-S15U
Serial No.
No de série
S15U/EN[ Cover] 99.12.22, 15:213

1
ENGLISH
PROJECTOR
DLA-S15U
INSTRUCTIONS
S15U/EN[ subcover] 99.12.22, 13:421

2
Thank you for purchasing this projector. Before using it, read and follow all instructions carefully to take full
advantage of the projector's capabilities.
SAFETY PRECAUTIONS
WARNING :
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION :
To reduce the risk of electric shock, do not remove cover.
Refer servicing to qualified service personnel.
FCC INFORMATION (U.S.A. only)
CAUTION:ChangesormodificationnotapprovedbyJVC
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to
complywiththelimitsforaClassAdigitaldevice,pursuant
toPart15of the FCCRules. These limits aredesigned to
providereasonableprotectionagainstharmfulinterference
when the equipment is operated in a commercial
environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will
berequiredtocorrectthe interferenceathisownexpense.
IMPORTANT SAFEGUARDS
Electrical energy can perform many useful functions. This
unithas beenengineered andmanufacturedtoassureyour
personal safety. But IMPROPER USE CAN RESULT IN
POTENTIAL ELECTRICAL SHOCK OR FIRE
HAZARD. In order not to defeat the safeguards
incorporated into this product, observe the following basic
rulesfor itsinstallation, useand service. Pleasereadthese
“Important Safeguards” carefully before use.
– All the safety and operating instructions should be read
before the product is operated.
– The safety and operating instructions should be retained
for future reference.
– All warnings on the product and in the operating
instructions should be adhered to.
– All operating instructions should be followed.
– Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
– Donotuse attachmentsnot recommendedby theproduct
manufacturer as they may be hazardous.
– Do not use this product near water. Do not use
immediately after moving from a low temperature to high
temperature, as this causes condensation, which may
result in fire, electric shock, or other hazards.
– Do not place this product on an unstable cart, stand, or
table. The product may fall, causing serious injury to a
child or adult, and serious damage to the product. The
product should be mounted according to the
manufacturer’s instructions, and should use a mount
recommended by the manufacturer.
– When the product is used on a cart, care
should be taken to avoid quick stops,
excessive force, and uneven surfaces
which may cause the product and cart to
overturn, damaging equipment or causing
possible injury to the operator.
– Slots and openings in the cabinet are provided for
ventilation. Theseensurereliableoperation of theproduct
and protect it from overheating. These openings must
not be blocked or covered. (The openings should never
be blocked by placing the product on bed, sofa, rug, or
similar surface. It should not be placed in a built-in
installation such as a bookcase or rack unless proper
ventilationisprovided and themanufacturer’s instructions
have been adhered to.)
For proper ventilation, separate the product from other
equipment, which may prevent ventilation and keep
distance more than 50 cm (19-3/4”).
IMPORTANT INFORMATION
This projector is equipped with a 3-blade grounding-type
plug to satisfy FCC rule. If you are unable to insert the
plug into the outlet, contact your electrician.
About burning-in of the D-ILA device
Do not allow the same still picture to be projected for a long
time or an abnormally bright video picture to be projected.
Do not project video images with high-intensity or high-
contrast on a screen. The video image could be burned in to
the D-ILA device.
Use special care when projecting video games or computer
program images. There is no problem with ordinary video-
cassette playback images.
S15U/EN[ Safety] 12/22/99, 10:522

3
ENGLISH
– This product should be operated only with the type of
power source indicated on the label. If you are not sure
of the type of power supply to your home, consult your
product dealer or local power company.
– This product is equipped with a three-wire plug. This
plug will fit only into a grounded power outlet. If you are
unable to insert the plug into the outlet, contact your
electrician to install the proper outlet. Do not defeat the
safety purpose of the grounded plug.
– Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them. Pay particular attention to cords
at doors, plugs, receptacles, and the point where they
exit from the product.
– For added protection of this product during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the cable system. This will prevent damage
to the product due to lightning and power line surges.
– Do not overload wall outlets, extension cords, or
convenience receptacles on other equipment as this can
result in a risk of fire or electric shock.
– Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or
short out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
– Donot attempt toservicethis product yourselfasopening
or removing covers may expose you to dangerous
voltages and other hazards. Refer all service to qualified
service personnel.
– Unplug this product from the wall outlet and refer service
to qualified service personnel under the following
conditions:
a) When the power supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen on the
product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the Operation Manual, as an
improperadjustment of controlsmayresult in damage
and will often require extensive work by a qualified
technician to restore the product to normal operation.
e) If the product has been dropped or damaged in any
way.
f ) When the product exhibits a distinct change in
performance – this indicates a need for service.
– Whenreplacementparts arerequired, besure theservice
technician has used replacement parts specified by the
manufacturer or with same characteristics as the original
part. Unauthorizedsubstitutionsmay result infire,electric
shock, or other hazards.
– Uponcompletion ofanyservice orrepairsto thisproduct,
ask the service technician to perform safety checks to
determinethattheproductis in proper operatingcondition.
– The product should be placed more than one foot away
from heat sources such as radiators, heat registers,
stoves, and other products (including amplifiers) that
produce heat.
– When connecting other products such as VCR’s, and
personal computers, you should turn off the power of this
product for protection against electric shock.
– Do not place combustibles behind the cooling fan. For
example, cloth, paper, matches, aerosol cans or gas
lighters that present special hazards when over heated.
– Do not look into the projection lens while the illumination
lamp is turned on. Exposure of your eyes to the strong
light can result in impaired eyesight.
– Do not look into the inside of this unit through vents
(ventilationholes),etc. Do notlook atthe illuminationlamp
directlyby opening thecabinetwhile the illuminationlamp
isturnedon.The illuminationlamp also containsultraviolet
rays and the light is so powerful that your eyesight can
be impaired.
– Xenongas is enclosedwithhigh pressureinsidethe light-
source lamp (lamp unit) of this projector. If you drop or
impart a shock to the lamp, or discard it as is, there is the
possibility of explosion, leading to personal injury. Use
special care when handling the lamp. For any unclear
points, consult your product dealer.
– Use only the accessory cord designed for this product to
prevent shock.
The power supply voltage rating of this product isAC
120 V, the power cord attached conforms to the
following power supply voltage. Use only the power
cord designated by our dealer to ensure Safety and
EMC.
When it is used by other power supply voltage, power
cable must be changed.
Consult your product dealer.
Power cord
Power supply voltage: AC 120 V
SAFETY PRECAUTIONS (Cont.)
* DO NOT allow any unqualified person to in-
stall the unit.
Be sure to ask your dealer to install the unit
(e.g. attaching it to the ceiling) since special technical
knowledge and skills are required for installation.
If installation is performed by an unqualified person, it
may cause personal injury or electrical shock.
S15U/EN[ Safety] 99.12.22, 13:543

4
Contents
SAFETY PRECAUTIONS ....................... 2
Accessories ........................................... 5
Controls and Features .......................... 6
Front Side / Top Surface / Right Side....................6
Left-hand side .......................................................7
Bottom Surface .....................................................8
Control Panel ........................................................9
Connector Panel ................................................. 11
Remote Control Unit............................................13
Installing Batteries...............................................14
Installing the Projector ....................... 15
Precautions for installation ..................................15
Projection Distance and Screen Size..................16
Relationship between Projection Distances
and Projection Screen Sizes..........................17
Effective Range and Distance of the Remote
Control unit.....................................................18
Setting the Position Selecting Screw
for Ceiling Mounting .......................................18
Connecting toVarious Devices.......... 19
Signals that Can Be Input to the Projector ..........19
Connecting to Video Devices ..............................20
Connecting to Hi-Vision Devices.........................20
Connecting to Other Devices ..............................21
Connecting to Devices
which Control the Projector............................21
Connecting to Computer Devices .......................22
Connecting the Power Cord (Supplied)...............24
When Turning On the Devices
Connected to the Projector ............................25
Basic Operations................................. 26
1. Turning on the Power ......................................26
2. Select the video input to be projected.............27
3. Adjust focus.....................................................28
4. Adjust sound volume .......................................28
• For Operating Other Functions .........................29
* This manual is divided into two language sections:
English and French.
Operating the Setting Menu ................. 31
Making Basic Settings........................................... 31
Operating the Main Menu ..................... 32
Configuration of the Main Menu ............................ 32
Operating the Main Menu
(Basic Operation of the Main Menu) ................ 34
Changing the Color System .................................. 35
Changing the Language Display........................... 36
Adjusting the Pixel Clock....................................... 37
Adjusting the Screen Position ............................... 38
Adjusting Picture Quality ....................................... 39
Adjusting Sound Quality........................................ 42
Setting and Adjusting Other Functions
(OPTIONS) ...................................................... 43
Changing (Setting) the Source.............................. 46
Replacing the Light-Source Lamp....... 48
Resetting the Lamp Use Time............................... 50
Cleaning and Replacing the Filter ....... 51
Troubleshooting .................................... 52
Specifications........................................ 54
S15U/EN[ Safety] 12/22/99, 10:524

5
ENGLISH
Remote control unit (RM-M10SG) AAA/R03-size dry cell battery (×2)
(for checking operation) Power code [approx. 2.5 m (8.2 ft)]
Personal computer connection cable
[approx. 2 m (6.56 ft)]
(D-sub, 3-row 15 pin)
Conversion adapter for Mac
(for Macintosh)
Audio cable
[approx. 3 m (9.84 ft)]
(3.5 mm dia. stereo mini plug)
AV connection cable
[approx. 1.5 m (4.92 ft)]
BNC-RCA conversion plug
Accessories
The following accessories are included with this projector. Check for them;if any item is missing,please contact your
dealer.
S15U/EN[05-09] 12/22/99, 10:555

6
Controls and Features
Front Side /Top Surface / Right Side
1Control panel
For details, refer to “Control Panel” (page 9).
2Exhaust vents
Vents for cooling fans through which warm air comes out.
CAUTION
• Do not block the exhaust vents, or heat builds up inside,
possibly causing a fire. Also, do not touch the vents, or this
could cause a low-temperature burn.
3Carrying handle
Raise this handle when carrying the projector.
Carrying handle
How to use the carrying handle
CAUTIONS
• When carrying the projector, do not give a shock to it. Be
careful to keep its balance.
• Do not carry it while the light source lamp is on or the cooling
fan is operating. This could cause personal injury.
5Built-in speaker (left)
6Built-in speaker (right)
7Lens
Before projection, remove the lens cap.
8Lens cap
The cap has a string attached and the string is fixed to the
projectorwhenshippedfromthe factory.It is recommended
that the cap be fitted on to prevent the lens becoming dirty
when the projector is not used.
9Remote sensor
When operating with the remote control, aim it toward this
sensor.Youcanalsooperatetheremotecontrol by pointing
it to a screen and allowing the remote sensor to receive
the reflected light.
Extend Shorten
+7˚
4Adjustable foot (for adjusting upper/lower angles)
It is adjusted to be level when shipped from the factory.
Turning to extend the foot allows adjustment up to +7˚.
* This adjustable foot can be removed. Turn the foot and
extendituntilremoved.(ScrewsizeavailablehereisM8.)
STANDBY
OPERATE
LAMP
TEMP
EMERGENCY
VIDEO
COMPUTER
SETTING
QUICK
ALIGN
-
+
9
1
8
7
65
2
3
4
STANDBY
OPERATE
LAMP
TEMP
EMERGENCY
VIDEO
COMPUTER
SETTING
QUICK
ALIGN
-
2
+
3
COMPUTERIN-1
COMPUTERIN-2
AVIN
CONTROL
MAIN
POWER
ON
OFF
AC IN ~
S15U/EN[05-09] 12/22/99, 10:566

7
ENGLISH
Controls and Features (cont.)
Left-hand side
eAdjustable foot (for horizontal angle adjustment)
It is set at the shortest position when shipped from the
factory.Turnthe foottomaketheprojector level.Adjustment
can be made in the range of + 1.5° and – 1.5° from the
horizontal position.
* This adjustable foot can be removed. Turn the foot and
extendituntilremoved.(Screwsizeavailablehereis
M5 .)
Extend Shorten
pAC IN (power input) terminal
This is the power input terminal where the supplied power
cord is connected. For details, refer to page 24.
qMAIN POWER switch
This is the main power switch. When it is turned on, the
projector goes into stand-by state, and the STAND BY
indicator on the control panel comes on.
ON [❙]: The main power turns on.
OFF [‡‡
‡‡
‡]: The main power turns off.
wConnector panel
For details, refer to “Connector Panel” on page 11.
p
q
w
e
−1.5°
+1.5°
S15U/EN[05-09] 99.12.22, 14:577

8
tOpening for replacing the light-source lamp
Forreplacing the light-source lamp, refer to“Replacing the
Light-Source Lamp” on page 48.
yFixing foot
Under the rubber seal of the$‰7ttom of this foot, there is
a tapped hole. (Screw size available here is M8.)
uPosition selecting screw for ceiling mounting
When using the projector in an upside-down, ceiling-
mountedposition (inverted top-to-bottom and right-to-left),
the “position selecting screw for ceiling mounting” must be
turned to switch to ceiling mounting.
This will correct variance in color images (shading), which
otherwise would occur in ceiling mounting.
For more information, refer to “position selecting screw for
ceiling mounting” on page 18.
CAUTION
• To ceiling-mount and adjust the projector, special expertise
and technique are necessary. Be sure to ask your dealer or
a specialist to perform this work.
rAir intake area (filter)
Air is taken in through this area to cool the light-source
lamp. If this area is blocked or if something that obstructs
taking in or exhausting air is placed around the projector,
heatmaybuildupinsideandcouldcauseafire.Fordetails,
refer to “Precautions for Installation” on page 15.
CAUTIONS
• Be careful as paper, cloth or soft cushion could be drawn in
if placed nearby. Do not block the intake area, or heat may
build up and could cause a fire.
• Clean the filter periodically. For details, refer to “Cleaning
and Replacing the Filter” on page 51.
Deposition of dirt on the filter works to reduce the cooling
effect, causing heat to build up inside, which could cause a
fire or malfunction.
Controls and Features (cont.)
Bottom Surface
u
r
t
y
S15U/EN[05-09] 99.12.22, 13:488

9
ENGLISH
Controls and Features (cont.)
Control Panel
1STAND BY Indicator
ON : When in stand-by mode.
Blinking: When in cool-down mode.
Memo
About the cool-down mode:
This projector has a function to cool down the heated lamp for a fixed
period oftime after projection is finished.Thisfeature isreferred to as
the cool-down mode.
CAUTION
• The purpose of the cool-down mode is to prevent inner parts
frombeingdeformed or broken by heat from theheated lamp
as well as to prolong the life of the lamp. Do not turn off the
main power switch while in the cool-down mode. Also, do
notplace the projector onits sideorstand it upright; thismay
block the exhaust vents.
2OPERATE indicator
ON: When the projector is in operation (projecting)
3OPERATE button
When the projector is in the stand-by mode, press this
button, and the main power switch is turned on, causing
the OPERATE indicator to light. Press it again, and the
projector goes into the cool-down mode, then stand-by
mode.
Memo
While in the cool-down mode:
If you press the OPERATE button, the projector is not tuned on.
4Lamp indicator
ON : After the light-source lamp has been used for
more than approx. 900 hours.
Blinking : Replacethelamp.Referto “Replacing theLight-
Source Lamp” on page 48.
5TEMP indicator
ON: The temperature inside the projector has abnormally
risen.
Note
• While the TEMP indicator is on (during abnormal temperature), the
power is automatically cut off, and an emergency mode is shown
(with the EMERGENCY indicator blinking).
6EMERGENCY indicator
Blinking: Something abnormal has occurred with the
projector.
Memo
About the emergency mode:
The emergency mode is shown when the following anomalies have
occurred with the projector (the EMERGENCY indicator blinks). In
the emergency mode, projection is automatically interrupted and the
cooling fans operate for about 20 seconds.
• When the air filter is displaced.
• When the filter is clogged.
• When the light-source lamp has suddenly gone off.
• When the fans have stopped.
• When the temperature inside has risen abnormally high.
CAUTION
• When an emergency mode is shown:
After the cooling fans have stopped, turn off the main power
switch and unplug the power cord from the wall outlet.
Make sure the lamp-replacement cover and the air filter are
correctly installed. Then, plug in the power cord again and
operate the projector.
If it goes into an emergency mode again, after the cooling
fans have stopped, turn off the main power switch, unplug
the power cord, and call your dealer for repair.
OPERATE
p
STAND BY
LAMP
TEMP
EMERGENCY
VIDEO
COMPUTER
SETTING
QUICK
ALIGN.
-
2
+
3
1
2
3
4
5
6
7
8
9
S15U/EN[05-09] 12/22/99, 10:569

10
Controls and Features (cont.)
Control Panel (Cont.)
7VIDEO button
Use this button to select a device such as a video deck
connectedto theAV IN terminalof theprojector. Each time
you press the button, the device selected changes as
follows:
Y/C VIDEO Y,P
B /B-Y,P R /R-Y
8COMPUTER button
Use this button to select a device connected to the
COMPUTER -1 or -2 terminals. Each time you press the
button, the selection changes as follows:
COMPUTER 1 COMPUTER 2
9SETTING button
Use this button to call up the setting menu. For details,
refer to “Making Basic Settings” on page 31.
pQUICK ALIGN. button
While a menu screen is shown, use this button to adjust
the values for the item selected. When no menu is shown,
the quick alignment function works.
• When a menu is shown
+3button: The value for the selected item increases.
–2button: The value for the selected item decreases.
• When no menu is shown
Press the +3button and –2button at the same time:
QUICK ALIGNMENT is displayed on the screen and the
quick alignment function works (TRACKING, PHASE, H.
POS.and V. POS. are automatically adjusted). Whenthe
adjustmentis finished, the display goesoffautomatically.
Memo
The quick alignment function :
• Works for computer input (COMPUTER- 1 and - 2 input terminals)
signals.
• Does not work for video input (AV IN input terminal) signals.
CAUTION
• Automatic adjustment with the quick alignment function
should be done on a bright still-picture screen. This function
may not work correctly on a dark screen or motion-picture
screen. If adjustment with this function is not satisfactory,
adjust TRACKING, PHASE, H. POS. and V. POS. manually
(see pages 31, 37 and 38).
OPERATE
p
STAND BY
LAMP
TEMP
EMERGENCY
VIDEO
COMPUTER
SETTING
QUICK
ALIGN.
-
2
+
3
1
2
3
4
5
6
7
8
9
S15U/EN[10-14] 12/22/99, 11:0710

11
ENGLISH
Controls and Features (cont.)
Connector Panel
1Y/C (S video) input terminal (Mini DIN 4 pin)
Connect this terminal to the S video output terminal of a
video deck, etc.
2VIDEO (composite video) input terminal (BNC)
Connectthis terminal tothecompositevideooutput terminal
of a video deck, etc.
3Y, PB/B-Y, PR/R-Y input terminals (BNC)
These are input terminals for component (Y, B-Y, R-Y)
signals or DTV-format (Y, PB, PR) signals.
Device with component output terminals can be
connected.
* For details about DTV-format signals (480i, 480p, 720p,
1080i) compatible with this unit, refer to page 56.
4AUDIOL/R(Audio • left/right) input terminals(pinjacks)
Of devices connected to the video input terminals, such
as a video deck, etc., the audio output terminals of the
device to be projected is connected to these terminals.
The input audio signal is reproduced by the speakers of
the projector. The signal is also output from the AUDIO
OUT terminal of the projector.
* Whenthe input signal isstereo signal,connection should
be made to both L and R.
* Signals from a monaural device should be connected to
only L. That way, the projector’s speakers and theAUDIO
OUT terminal produce the same sound from both L and R.
Memo
To select the proper audio input for video input:
The video input terminals (AV IN input terminals) can be switched
with the projector’s or remote control’s VIDEO button. However, since
this projector has only single audio input terminal, reconnect audio
input in accordance with the AV device to be used.
5AUDIO OUT (audio output) terminal (stereo mini jack)
Of input signals inputted to the projector, the audio signal
of the device being projected is output. Volume should be
adjustedusingtheVOL.(+/–) buttons on the remote control
or VOLUME on the setting menu. When a cable is
connected to this jack, no audio sound is produced from
the projector’s speakers.
6REMOTE terminal (mini jack)
Connect an infrared remote control extension unit, etc. to
this jack.
* For details, consult your dealer.
7RS-232C terminal (D-sub 9 pin)
This is a RS-232C interface-specified terminal. This
projector can be controlled by a computer connected
externally.
* For details, consult your dealer.
8COMPUTER OUT (computer output) terminal (D-sub
3-row 15 pin)
Thecomputerinput signal projectedonthescreenis output.
Adisplay unit can be usedby connectingit tothis terminal.
Y
PC
AUDIO
AUDIO
AUDIO
AUDIO OUT
REMOTE
Y/C VIDEO
Y
P
B
/B-Y
P
R
/R-Y
L
R
H/C
S
V
R
G
B
COMPUTER
OUT
RS-232C
w12
q
p
9
8765
3
4
S15U/EN[10-14] 12/22/99, 11:0711

12
Controls and Features (cont.)
Connector Panel (Cont.)
9COMPUTER IN (computer input) -2 terminal (BNC)
These are input terminals for analog RGB signals, vertical
sync(V) signals, andhorizontalsync(H) signals/composite
signals(Cs).DeviceswhichhaveanalogRGBsignaloutput
terminals can be connected.
* Input of external sync signals is automatically
detected.
Detection of H/V signals or Cs signals causes automatic
switch to external sync. The priority order is H/V > Cs.
Note
• DTV-format (480i, 480p, 720p, 1080i) signals can be input.
When the source is set to “AUTO”, signals of 480i and 1080i can
automatically be detected, but 480p and 720p signals can not be
detected.
To be able to input 480p or 720p signal, the source should be set to a
dedicated source mode “SDTV(480p)” or “HDTV1(720p)”. For setting
the source, refer to “Chenging (setting) the source” on page 46.
CAUTION
• When computer-related signals are input, the uppermost edge of
thescreenmayappearbowingifthesyncsignalinputiscomposite
sync (Cs) or G on sync signal. In that case, use separate sync
signals for vertical sync (V) and horizontal sync (H).
pAUDIO input terminal (stereo mini jack)
This is an audio input terminal for COMPUTER IN
(computer input) -2 terminal. Connect the audio output
signalof a device connected toCOMPUTER IN (computer
input) -2 terminal.
* Wheninputto COMPUTER -2isselected,theaudio signal
input is reproduced by the projector’s speakers. Also,
signalscanbeoutputfromtheAUDIOOUT(audio output)
terminal.
(However, if a cable is connected toAUDIO OUT (audio
output) terminal, audio sound does not come out from
the projector’s speakers.)
qCOMPUTER IN (computer input) -1 terminal (D-sub 3-
row 15 pin)
This is an input terminal (PC) dedicated for computer
signals (RGB video signals and sync signals).
Connectthe display output terminal ofthe computer tothis
terminal. When a Macintosh computer is to be connected,
use the Conversion adapter for Mac supplied.
CAUTION
• When computer-related signals are input, the uppermost
edge of the screen may appear bowing if the sync signal
input is composite sync (Cs) or G on sync signal. In that
case, use separate sync signals for vertical sync (V) and
horizontal sync (H).
wAUDIO (audio) input terminal (stereo mini jack)
This is an audio input terminal for COMPUTER IN
(computer input) -1 terminal. Connect the audio output
signalof a device connected toCOMPUTER IN (computer
input) -1 terminal.
* Wheninputto COMPUTER -1isselected,theaudio signal
input is reproduced by the projector’s speakers. Also,
signalscanbeoutputfromtheAUDIOOUT(audio output)
terminal.
(However, if a cable is connected toAUDIO OUT (audio
output) terminal, audio sound does not come out from
the projector’s speakers.)
Y
PC
AUDIO
AUDIO
AUDIO
AUDIO OUT
REMOTE
Y/C VIDEO
Y
P
B
/B-Y
P
R
/R-Y
L
R
H/C
S
V
R
G
B
COMPUTER
OUT
RS-232C
w12
q
p
9
8765
3
4
S15U/EN[10-14] 12/22/99, 11:0712

13
ENGLISH
Controls and Features (Cont.)
Remote Control Unit
1Remote control’s signal transmitter
2COMPUTER button
Use this button to select the devices connected to the
projector’sCOMPUTER IN (computer input) -1 and -2 input
terminals. Each time you press the button, the selection
changes as follows:
COMPUTER 1 COMPUTER 2
3VIDEO button
Use this button to select the devices such as a video
connectedtotheprojector’sAV IN(AV input) terminal. Each
timeyoupressthe button, the selection changes asfollows:
Y/C VIDEO Y,P
B /B-Y,P R /R-Y
4FOCUS (+/–) button
Usethesebuttons to a
dju stthefocus of the projectedvideo.
+: The focus point becomes more distant.
–: The focus point becomes nearer.
5MENU/ENTER button
Use this button to display the main menu. While the main
menu is displayed, pressing this button displays a details
setting (submenu) for items with details settings.
6Cursor (5/∞/2/3) button
While the main menu is displayed, use these buttons to
select an item to adjust or make adjustment.
7AV MUTING (On/Off) button
Usethisbuttonto turn offthevideoimageandaudio sound
temporarily. Pressing it again makes the video image and
audio sound to resume.
8QUICK ALIGN. (Quick Alignment) button
Use this button to automatically adjust TRACKING,
PHASE, H. POS. and V. POS. of the projected video.
During the automatic adjustment, QUICK ALIGNMENT
appears on the screen, and disappears after it is finished.
Memo
Quick alignment function:
Does not work for video input (AV IN input terminal) signals.
Worksonlyforcomputer-related (COMPUTER-1 and-2inputterminals)
signals.
CAUTION
• Automatic adjustment with the quick alignment function should be
done on a bright still-picture screen. This function may not work
correctly on a dark screen or motion-picture screen. If adjustment
with this function is not satisfactory, adjust TRACKING, PHASE, H.
POS. and V. POS. manually (see pages 31, 37 and 38).
9PRESET button
While making adjustment on the main or setting menu,
use this button to reset the setting of the selected item to
the factory-set value. This button works only for numerical
settings and does not work for switching ON to OFF.
pPAGE BACK button
While a details setting is displayed, use this button to go
back to the previous page.
qVOL. (Volume) (+/–) button
Use these buttons to adjust the sound volume:
+: Increase the volume level.
–: Decrease the volume level.
wOPERATE button
To turn on the power, press this button for one second or
more.
* About 30 seconds after the power has turned on, video
image will appear on the screen.
OPERATE
VOL.
PAGE
BACK
PRESET
FOCUS
COMPUTER VIDEO
QUICK
ALIGN. AV MUTING
MENU/ENTER
1
8
9
p
q
w
2
3
4
5
6
7
RM-M10SG REMOTE CONTROL UNIT
S15U/EN[10-14] 12/22/99, 11:0713

14
Controls and Features (cont.)
Installing Batteries
Install batteries in the remote control. If the remote control has started to work erratically, replace the batteries.
1Open the back cover.
While pushing on the back cover, slide it in the direction
of the arrow.
2Install the batteries.
Place the two batteries (AAA/R03-size) supplied in the
remote control as illustrated below.
3Close the back cover.
Slide the back cover in the direction of the arrow until a
click is heard.
Precautions for using batteries
If batteries are used incorrectly, they may crack or
leak liquid. This could cause a fire, burn, malfunction,
or staining or damaging the surrounding.
Beware of the following:
• Do not mix new and old batteries.
• Do not mix different types of batteries as they differ in
characteristics.
• Place batteries so they match the polarities indicated:
(+) to (+) and (–) to (–).
• Be sure to put the minus (–) end in first to avoid short-
circuiting.
• Use only designated batteries.
• Remove the batteries if not used for a prolonged period
of time.
• When the batteries are exhausted, replace them
immediately. Otherwise, liquid could leak, ormalfunction
could occur due to leaked liquids. If the leaked liquid
contacts the skin, wipe it off with a cloth, otherwise the
skin could become rough.
• Do not put batteries into fire or try to recharge them.
• Batteries run for six months to one year in normal use.
But the batteries supplied are for confirming operation
andmaynot run that long. Whentheremotecontrolstarts
failing to work properly, replace the batteries with new
ones.
S15U/EN[10-14] 12/22/99, 11:0714

ENGLISH
1515
Installing the Projector
Precautions for Installation
■When installing the projector, observe the followings:
• Do not use the projector placed on its side.
Avoid using the projector placed on its side. This could cause a malfunction.
• Use the projector within the installed angle.
Avoid using the projector inclined ±30°or more right-to-left or left-to-right.This could cause color variation or harm the lamp
life.
• Do not block the exhaust vents.
Do not use a cover which encloses the projector air-tight or blocks the exhaust vents. Allow sufficient space around the
projector. When the projector is enclosed in a space of the following dimensions, use an air conditioner so the temperature
inside becomes equal to the outside temperature.
Allowable minimum space required
CAUTION
Do not install the projector in the following places :
• There is much water, humidity or dust.
• The projector may be subjected to oil smoke or cigarette smoke.
• On a soft surface such as a carpet or cushion.
• The projector may be subjected to direct sunlight.
• Temperature is high or humidity is low.
Allowable operation temperature range: + 5°C to + 35°C (41°F to 95°F)
Allowable relative humidity range: 20% to 80% (no condensation)
Allowable storage temperature range: –10°C to +60°C (14°F to 140°F)
50cm (19 -
3
/ 4 ”)20cm (7 -
7
/ 8 ”)
20cm (7 -
7
/ 8 ”)
20cm (7 -
7
/ 8 ”)
20cm (7 -
7
/ 8 ”)
S15U/EN[15-25] 99.12.22, 11:3815

16
Installing the Projector (Cont.)
Projection Distance and Screen Size
■This projector uses a fixed forcal length lens.
■The projection distance that can be focused is approx. 0.76 to 4.14 m. Install the projector within this range.
Screen
Install the projector so the center
of the projection screen is at the
same height as the lens’ center
line.
Screen with 4 : 3 aspect ratio
■Change of projection screen
according to aspect ratio
Screen with 16 : 9 aspect ratio
Center line of the lens
90° 90° 90°
*Also, refer to the table of “Relationship Between Projection Distances and Projection Screen Sizes” on page 17 as a reference.
CAUTIONS and NOTES
• Install the screen so the center of the projected picture aligns with the extended center line of the projector’s lens. That
way, the center of the picture projected on a 4 : 3 aspect ratio screen aligns with the extended center line of the lens.Also,
the screen must be at right angles with the extended center line of the lens (so that projection occurs at right angles with
the screen).
• When installing the screen, use a 4 : 3 aspect ratio picture.
(A 16 : 9 aspect ratio picture is projected based on the width of the range in which a 4 : 3 aspect ratio picture is projected.)
• The diagonal length of a 16 : 9 aspect ratio picture is about 91.8% that of a 4 : 3 aspect ratio picture. This value is a guide
and should be used as a reference.
• If sunlight or lamp light strikes the projection screen directly, the picture becomes whitish and dim. Be sure to use a
curtain, etc. to shield the light.
• Trapezoidal distortion may not be corrected.
Adjust the projector within the range of angle adjustment (up/down adjustment angle: +7°; horizontal adjustment angle:
±1.5°) so that it is set up level.
• The numeric values listed in the table of Relationship between Projection Distances and Screen Sizes on page 17 are
provided only as a guide or reference. The projection sizes may vary within manufacturing tolerances of the projection
lens.
Projection screen size
(diagonal length) Projection distance
When screen aspect ratio is 4 : 3 When screen aspect ratio is 16 : 9
36.7” (approx. 93 cm) approx. 2.49 ft (0.76 m)
50” (approx. 127 cm) approx. 3.15 ft (0.96 m) approx. 3.44 ft (1.05 m)
100” (approx. 254 cm) approx. 6.46 ft (1.97 m) approx. 7.09 ft (2.16 m)
150” (approx. 381 cm) approx. 9.74 ft (2.97 m) approx. 10.69 ft (3.26 m)
200” (approx. 508 cm) approx. 13.06 ft (3.98 m)
S15U/EN[15-25] 99.12.22, 11:3816

ENGLISH
17
Installing the Projector (Cont.)
Relationship between Projection Distances and Projection Screen Sizes
■Use the table below as a guide or reference when installing the projector.
Projection screen size
(diagonal length) Projection distance
When screen aspect ratio is 4 : 3 When screen aspect ratio is 16 : 9
36.7” (approx. 93 cm) approx. 2.49 ft (0.76 m)
40” (approx. 101 cm) approx. 2.49 ft (0.76 m) approx. 2.72 ft (0.83 m)
50” (approx. 127 cm) approx. 3.15 ft (0.96 m) approx. 3.44 ft (1.05 m)
60” (approx. 152 cm) approx. 3.81 ft (1.16 m) approx. 4.17 ft (1.27 m)
70” (approx. 177 cm) approx. 4.46 ft (1.36 m) approx. 4.89 ft (1.49 m)
80” (approx. 203 cm) approx. 5.12 ft (1.56 m) approx. 5.64 ft (1.72 m)
90” (approx. 228 cm) approx. 5.77 ft (1.76 m) approx. 6.36 ft (1.94 m)
100” (approx. 254 cm) approx. 6.46 ft (1.97 m) approx. 7.09 ft (2.16 m)
110” (approx. 279 cm) approx. 7.12 ft (2.17 m) approx. 7.81 ft (2.38 m)
120” (approx. 304 cm) approx. 7.76 ft (2.37 m) approx. 8.53 ft (2.60 m)
130” (approx. 330 cm) approx. 8.43 ft (2.57 m) approx. 9.25 ft (2.82 m)
140” (approx. 355 cm) approx. 9.09 ft (2.77 m) approx. 9.97 ft (3.04 m)
150” (approx. 381 cm) approx. 9.74 ft (2.97 m) approx. 10.69 ft (3.26 m)
160” (approx. 406 cm) approx. 10.43 ft (3.18 m) approx. 11.42 ft (3.48 m)
170” (approx. 431 cm) approx. 11.09 ft (3.38 m) approx. 12.14 ft (3.70 m)
180” (approx. 457 cm) approx. 11.75 ft (3.58 m) approx. 12.86 ft (3.92 m)
190” (approx. 482 cm) approx. 12.40 ft (3.78 m) approx. 13.58 ft (4.14 m)
200” (approx. 508 cm) approx. 13.06 ft (3.98 m)
S15U/EN[15-25] 99.12.22, 11:3817

18
CAUTIONS
• To ceiling-mount and adjust the projector, special expertise and
technique are necessary. Be sure to ask your dealer or a specialist to
perform this work.
• To turn the “position selecting screwfor ceiling mounting”, use a Phillips
screwdriver with a 30-mm or longer shank.
The screw is located in the hole shown in the illustration.
Installing the Projector (Cont.)
Effective Range and Distance of the Remote Control Unit
The operable distance of the remote control unit is about 10 m (32.8 ft) for direct reception. The remote control can be used by
having it reflected on the screen, etc. When you use the remote control by reflecting it at the screen, the total distance ofA + B
should be about 10 m (32.8 ft) or less. The operable angles of the remote control unit is 50° right to left, and 15° up and down.
The effective range and distance of the remote control unit
Screen
• Use the projector with A+B about 10 m (32.8 ft) or less.
Note
• Depending on the type of the screen used, the effective distance of the remote control may be reduced.
Setting the position selecting screw for Ceiling Mounting
When using the projector in an upside-down, ceiling-mounted position (inverted top-to-bottom and right-to-left), the “position
selecting screw for ceiling mounting” must be turned to switch to ceiling mounting.
This will correct variance in color images (shading), which otherwise would occur in ceiling mounting.
To revert to normal desltop setting, turn the “position selecting screw for ceiling mounting” back to the initial position (factory-
shipped).
[When using the projector in an upside-down, ceiling mounting position (inverted top-to-bottom and right-to-left)]
■Turn the “position selecting screw for ceiling mounting” counterclockwise fully (until it is turning idly).
[To again use the projector in a normal desktop setting]
■Turn the “position selecting screw for ceiling mounting” clockwise fully (until it tightens firmly).
For normal desktop mounting:
Turn clockwise.
For upside-down, ceiling-mounting:
Turn counterclockwise.
Remote control unit
Projector
(DLA-S15U)
50°
15°
15°
50°
A
B
Position selecting screw for ceiling mounting
S15U/EN[15-25] 99.12.22, 11:3818

ENGLISH
19
Connecting toVarious Devices
The following signals can be input to the projector:
■Video signals
(1) Response to color systems
*1: Responds if Y/C output is available.
*2: Signifies that component signals (“Y, PB, PR ” / “ Y, B-Y, R-Y” / “G, B, R, H/CS, V”) conform to the signal timing (synchroniza-
tion and video period) of each color system. The color systems are used for convenience only.
(2) Response to double density (*1), high-vision signals
Color system NTSC NTSC4.43 PAL SECAM
Input terminal
VIDEO ‡‡‡‡
Y/C ‡‡*1‡- - - - -
Y, PB/B-Y, PR/R-Y ‡*2‡*2‡*2‡*2
G, B, R, H/CS, V ‡*2‡*2‡*2‡*2
*1: Signals whose density of scanning lines/field is twice as high.
*2: Responds to signals whose horizontal scanning frequency is 31.5 kHz. NTSC can be made twice as dense by a line doubler
(separately available: recommended article).Also, possible to respond to fully-specified, decoded wide-clear-vision signals
and 525P progressive signals.
*3: Responds to signals whose horizontal scanning frequency is 33.5 kHz. PAL can be made twice as dense by a line doubler
(separately available: recommended article).
Note
• DTV-format signals (480i, 480p, 720p, 1080i) can be input into this unit (Y, PB/B-Y, PR/R-Y input terminals). For details about DTV-format
signals (480i, 480p, 720p, 1080i) compatible with this unit, refer to page 56.
■Computer signals
• Signals with the following resolutions can be input to the input terminal of COMPUTER IN-1 (PC) or COMPUTER IN-2 (G,
B, R, H/Cs, V). (The following signals are preset.)
Input terminal NTSC*2PAL*3High-vision signal
Y, PB/B-Y, PR/R-Y ‡‡‡
G, B, R, H/CS, V ‡‡‡
Screen resolution (standard name) Horizontal frequency Vertical frequency Scanning method
640 ×400 (PC-9801) 24.8kHz 56.4Hz Non-interlace
640 ×350 (VGA1) 31.5kHz 70.1Hz Non-interlace
640 ×480 (VGA3) 31.5kHz 59.9Hz Non-interlace
640 ×480 (Macintosh 13”) 35.0kHz 66.7Hz Non-interlace
640 ×480 (VGA VESA) 37.5kHz 75.0Hz Non-interlace
800 ×600 (SVGA1) 37.9kHz 60.3Hz Non-interlace
800 ×600 (SVGA2) 48.1kHz 72.2Hz Non-interlace
832 ×624 (Macintosh16”) 49.7kHz 74.6Hz Non-interlace
1024 ×768 (XGA1) 48.4kHz 60.0Hz Non-interlace
1024 ×768 (XGA2) 56.5kHz 70.1Hz Non-interlace
1024 ×768 (Macintosh 19”) 60.2kHz 74.9Hz Non-interlace
1152 ×870 (Macintosh 21”) 68.7kHz 75.0Hz Non-interlace
1280 ×1024 (SXGA1) 64.0kHz 60.0Hz Non-interlace
1280 ×1024 (SXGA2) 70.8kHz 67.0Hz Non-interlace
1360 ×1024 (SXGA3: Mac Board) 80.0kHz 75.1Hz Non-interlace
Signals that Can Be Input to the Projector
* Before connection, be sure to turn off the projector and connected devices.
* Read the manual which comes with each device thoroughly.
Notes
• Interlace signals are not handled.
• Some signals other than listed above can be displayed. But they require adjustment. Even some of the signals listed above may require
adjustment depending on the video board used.
• When a signal other than listed above is input, the screen could be partially erased or an unneeded fold-over screen could appear.
• Even signals in the frequency range that can be input may not be displayed normally depending on the type of the signal.
• Composite sync.(Cs) and G on sync. signals can not handled depending on the devices connected.
S15U/EN[15-25] 99.12.22, 11:3819
