KD-DV5000
Installation/Connection Manual
• This unit is designed to operate on 12 V DC, NEGATIVE ground electrical systems.
WARNINGS
• DO NOT install any unit in locations where;
– it may obstruct the steering wheel and gearshift lever operations, as this may result in a traffic
accident.
– it may obstruct the operation of safety devices such as air bags, as this may result in a fatal
accident.
– it may obstruct visibility.
• DO NOT operate any unit while manipulating the steering wheel, as this may result in a traffic
accident.
• The driver must not watch the monitor while driving.
If the driver watches the monitor while driving, it may lead to carelessness and cause an accident.
• The driver must not put on the headphones while driving. It is dangerous to shut off the outside
sounds while driving.
• If you need to operate the unit while driving, be sure to look ahead carefully or you may be
involved in a traffic accident.
• If the parking brake is not engaged, “DRIVER MUST NOT WATCH THE MONITOR WHILE
DRIVING.” appears on the monitor, and no playback picture will be shown.
– This warning appears only when the parking brake wire is connected to the parking brake
system built in the car.
0503MNMMDWJEIN
EN
LVT1055-004A
[A]
J
V
C
1 Before mounting: Press (control panel release button) to detach the control panel if
already attached.
* When shipped from the factory, the control panel is packed in the hard case.
2 Remove the trim plate.
3 Remove the sleeve after disengaging the sleeve locks.
1Stand the unit.
Note: When you stand the unit, be careful not to damage the fuse on the rear.
2Insert the 2 handles between the unit and the sleeve, as illustrated, to disengage the
sleeve locks.
3Remove the sleeve.
Note: Be sure to keep the handles for future use after installing the unit.
4 Install the sleeve into the dashboard.
* After the sleeve is correctly installed into the dashboard, bend the appropriate tabs to hold
the sleeve firmly in place, as illustrated.
5 Fix the mounting bolt to the rear of the unit’s body and place the rubber cushion over the end
of the bolt.
6 Do the required electrical connections.
7 Slide the unit into the sleeve until it is locked.
8 Attach the trim plate.
9 Attach the control panel.
INSTALLATION
(IN-DASH MOUNTING)
• The following illustration shows a typical installation. However, you should make adjustments
corresponding to your specific car. If you have any questions or require information regarding
installation kits, consult your JVC car audio dealer or a company supplying kits.
2
Trim plate
9
8
Trim plate
7
Sleeve
Mounting bolt
5
4
Dashboard
Rubber cushion
Control panel
3
Handle
Fuse
Slot
Lock Plate
Sleeve
1
Control panel
See “ELECTRICAL CONNECTIONS.”
4
6
*
Washer (ø5)
Lock nut (M5)
Mounting bolt
(M5 x 20 mm)
Rubber cushion
Parts list for installation and connection
The following parts are provided with this unit.
After checking them, please set them correctly.
Hard case/Control panel Sleeve Trim plate Power cord
• When using the optional stay
Sleeve
Dashboard
Fire wall
Washer
Stay
(option)
Lock nut
Mounting bolt
Screw
(option)
Note : When installing the unit on the
mounting bracket, make sure to use
the 8 mm long screws. If longer
screws are used, they could damage
the unit.
• When installing the unit without
using the sleeve
In a Toyota for example, first remove the car
radio and install the unit in its place.
Install the unit at an angle of less than 30˚.
Less than 30˚
* Not included with this unit.
Bracket*
Pocket
Bracket*
Flat type screws
(M5 x 8 mm) *
Flat type screws
(M5 x 8 mm) *
Removing the unit
• Before removing the unit, release the rear section.
1 Remove the control panel.
2 Remove the trim plate.
3 Insert the 2 handles into the slots, as shown. Then, while gently pulling the handles away
from each other, slide out the unit. (Be sure to keep the handles after installing it.)
3
1
Trim plateControl panel
2
Handle
TROUBLESHOOTING
•The fuse blows.
* Are the red and black leads connected correctly?
•Power cannot be turned on.
* Is the yellow lead connected?
•No sound from the speakers.
* Is the speaker output lead short-circuited?
•Sound is distorted.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
•Unit becomes hot.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
Handles
Battery
Remote controller
CR2025
Crimp connector
Connecting the leads CAUTION
• To prevent short-circuit, cover the
terminals of the UNUSED leads with
insulating tape.
Solder the core wires to
connect them securely.
Twist the core wires
when connecting.
PRECAUTIONS on power supply and speaker connections:
• DO NOT connect the speaker leads of the power cord to the car
battery; otherwise, the unit will be seriously damaged.
• Connect the black lead (ground), yellow lead (to car battery, constant
12 V), and red lead (to an accessory terminal) correctly.
• BEFORE connecting the speaker leads of the power cord to the
speakers, check the speaker wiring in your car.
–If the speaker wiring in your car is as illustrated in Fig. 1 and Fig.
2 below, DO NOT connect the unit using that original speaker wiring.
If you do, the unit will be seriously damaged.
Redo the speaker wiring so that you can connect the unit to the
speakers as illustrated in Fig. 3.
–If the speaker wiring in your car is as illustrated in Fig. 3, you can
connect the unit using the original speaker wiring in your car.
– If you are not sure of the speaker wiring of your car, consult your car
dealer.
L
R+
-
+
-
+
-
+
-
L
R+
-
+
-
+
-
+
-
L
R+
-
+
-
+
-
+
-
Fig. 1
Fig. 2
Fig. 3
Instal_DV5000[A]f.pm6 03.5.19, 15:051

2
INPUT
R
L
L
R
L
R
R
L
R
L
LINE OUT
REAR FRONT
R
L
2
1
3
15
1
2
3
4
5
6
8
9
7
(ILLUMINATION)
(PARKING BRAKE)
ELECTRICAL CONNECTIONS
To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and
make all electrical connections before installing the unit. If you are not sure how to install this unit
correctly, have it installed by a qualified technician.
Note:
This unit is designed to operate only on 12 V DC, NEGATIVE ground electrical systems. If your
vehicle does not have this system, a voltage inverter is required, which can be purchased at JVC
car audio dealers.
•Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC
car audio dealer.
•If noise is a problem...
This unit incorporates a noise filter in the power circuit. However, with some vehicles, clicking or
other unwanted noise may occur. If this happens, connect the unit’s rear ground terminal (see
connection diagram) to the car’s chassis using shorter and thicker cords, such as copper braiding
or gauge wire. If noise still persists, consult your JVC car audio dealer.
•Maximum input of the speakers should be more than 50 W at
the rear and 50 W at the front, with an impedance of 4 Ω to 8 Ω.
•Be sure to ground this unit to the car’s chassis.
•The heat sink becomes very hot after use. Be careful not to
touch it when removing this unit. Heat sink
About sounds reproduced through the rear terminals
• Through the analog terminals (Speaker out/LINE OUT/2nd AUDIOOUT):
2-channel signal is emitted.
When playing a multi-channel encoded disc, multi-channel signals are downmixed. (AUDIO—
ANALOG DOWN MIX: see page 46 of the Instructions)
• Through DIGITAL OUT (optical):
Digital signals (Linear PCM, Dolby Digital*, DTS**, MPEG Multichannel) are emitted through
this terminal. (For more details, see page 71 of the Instructions.)
To reproduce multi-channel sounds such as Dolby Digital and DTS, connect an amplifier or a
decoder compatible with these multi-channel sources to this terminal, and set “DIGITAL AUDIO
OUTPUT”to the correct value. (See page 46 of the Instructions)
* Manufactured under license from Dolby Laboratories. “Dolby”and the double-D symbol are trademarks of
Dolby Laboratories.
** “DTS”and “DTS Digital Out”are trademarks of Digital Theater Systems, Inc.
Before connecting: Check the wiring in the vehicle carefully not to fail in connecting this unit.
Incorrect connection may cause a serious damage to this unit.
The leads of the power cord and those of the connector from the car body may be different in
color.
1 Connect the colored leads of the power cord to the car battery, speakers and automatic
antenna (if any) in the following sequence.
1Black: ground
2Yellow: to car battery (constant 12 V)
3Red: to an accessory terminal
4Blue: to automatic antenna if any (250 mA max.)
5Blue with white stripe: to remote lead of other equipment (200 mA max.)
6Light green: To parking brake, metallic body or chassis of the car
7Orange with white stripe: to car light control switch
8Brown: To cellular phone system (For details, refer to the instructions of the celluar
phone.)
9Others: to speakers
2 Connect the antenna cord.
3 Finally connect the wiring harness to the unit.
A Typical Connections
Fuse block
To a live terminal in the fuse
block connecting to the car
battery (bypassing the
ignition switch)
To an accessory terminal in
the fuse block
To metallic body or
chassis of the car
Right speaker
(rear)
Left speaker
(rear)
Right speaker
(front)
Left speaker
(front)
White with
black stripe
White Green
with black
stripe
Gray
Gray
with black
stripe
Green Purple with
black stripe
Purple
*1
*1
*1Not supplied with this unit.
To parking brake, metallic body or
chassis of the car
To remote lead of other equipment
We recommend you to connect the JVC MP3-
compatible CD changer. You can also connect other
CH-X series CD changers (except CH-X99 and CH-
X100).
•You cannot use the KD-MK series CD changers
with this unit.
You can also use an external component such as a
portable MD player by connecting the Line Input
Adapter KS-U57 (not supplied). (See diagram .)
JVC CD
changer
Ignition switch
To automatic antenna
Blue with white stripe
Red
Yellow*2
Black
To antenna
Light green
JVC CD
changer jack
15 A
fuse
Rear ground
terminal
Antenna terminal
VIDEO OUT
(See diagram B)
Before connecting the CD changer, make sure that the unit is turned off.
*2: Before checking the
operation of this unit prior
to installation, this lead
must be connected,
otherwise power cannot
be turned on.
2nd AUDIO OUT
(See diagram B)
LINE OUT (FRONT)
LINE OUT (REAR)
DIGITAL OUT
(See diagram B)
To cellular phone system
Brown
Blue
To car light control switch
Orange with white stripe
Connecting the parking brake wire
When installing the monitor in a location where it can be seen by the driver
Connect the parking brake wire to the parking brake system built in the car.
To metallic body or chassis of the car
Crimp connecter
Parking brake switch
Parking brake wire (light green)
Parking brake
*3
When installing the monitor in a location where it cannot be seen by the driver
Connect the parking brake wire to metallic body or chassis of the car.
*3 Not included with this unit.
Parking brake wire (light green)
*3
*3
How to connect the crimp connector
Contact the metallic part of the
crimp connecter to the wires inside.
Attach the parking
brake wire to this point.
Wire connecting the battery and
the parking brake switch
Pinch the crimp
connecter firmly.
You can connect an amplifier and other equipment to upgrade your car stereo system.
•Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so
that it can be controlled through this unit.
•For amplifier:
–Connect this unit’s line-out terminals to the amplifier’s line-in terminals.
– Disconnect the speakers from this unit, connect them to the amplifier. Leave the
speaker leads of this unit unused.
B Connections Adding Other Equipment
Required connections for DVD playback
When using JVC’s KV-MR9000 and KS-HP1K, connect
using a conversion cable of this type (not supplied).
Headphones (not supplied) *4
Audio/video control amplifier or
the decoder compatible with the
multichannel digital sources
RCA Pin
plugs
PARKING
BRAKE
PARKING
BRAKE
External component
KD-DV5000
External component
JVC CD changer jack
*6Line Input Adapter KS-U57 (not supplied with this unit)
KS-U57 *6
Amplifier
Signal cord (not supplied with this unit)
L
R
L
R
L
R
L
R
Signal cord
(not supplied with this unit)
Rear speakers
Front speakers
Remote lead
(Blue with white stripe)
KD-DV5000
Remote lead
Y-connector
(not supplied with this unit)
To automatic
antenna if
any
JVC
Amplifier
You can connect another power amplifier for front
speakers.
*5
Front speakers
JVC Amplifier
*5Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place not
coated with paint (if coated with paint, remove the paint before attaching the wire). Failure to
do so may cause damage to the unit.
*5
KS-HP1K
Cordless headphones
(not supplied) *4
KV-MR9000
Wide color monitor
(not supplied)
Video cord
(not supplied)
Digital optical cable
(not supplied)
Stereo
mini plug
*4To listen to disc playback sound while in Dual Zone operations
(See page 30 of Instructions.)
VIDEO OUT
2nd
AUDIO
OUT
R
L
15
See “About sounds
reproduced through the
rear terminals.”
DIGITAL OUT
Instal_DV5000[A]f.pm6 03.5.19, 15:052
