SERVICE MANUAL
COPYRIGHT © 2009 Victor Company of Japan, Limited No.MB699<Rev.003>
2009/10
MICROCOMPONENTSYSTEM
MB699<Rev.003>200910SERVICE MANUAL
UX-G357E, UX-G357EN, UX-G357EV, UX-G357UT,
UX-G355B, UX-G355E, UX-G355EN, UX-G355EV,
UX-G355A, UX-G355US, UX-G355UB, UX-G355UW,
UX-G355UP, UX-G355UT
COPYRIGHT © 2009 Victor Company of Japan, Limited
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
VOLUME
DISPLAY
DIMMERREPEATRANDOM
PROGRAM
AUDIO IN
TUNERMODE
RESUME
CANCEL
AUTOSTBY
SLEEP
PTY
HBS
REMOTE CONTROL
RM-SUXG355R
SOUBDTURBOBASS/TREBLE
CLOCK/
TIMER
FADE
MUTING
UP
CD USB
TUNER
SET
DOWN
CA-UXG357 SP-UXG355
CA-UXG355 SP-UXG355
SP-UXG355
SP-UXG355
(for Europe)

1-2 (No.MB699<Rev.003>)
SPECIFICATION
For Europe
Specifications and appearance are subject to change without prior notice.
Amplifier section
OUTPUT POWER 60 W (30 W + 30 W) at 6 Ω(10% THD)
Speakers/Impedance 6 Ω- 16 Ω
Audio input AUDIO IN 500 mV/47 kΩ(at “LEVEL 1”)
250 mV/47 kΩ(at “LEVEL 2“)
125 mV/47 kΩ(at “LEVEL 3“)
Digital input USB MEMORY REC/PLAY
Tuner section
FM tuning range 87.50 MHz - 108.00 MHz
AM (MW) tuning range 522 kHz - 1 629 kHz
CD player section
Dynamic range 88 dB
Signal-to-noise ratio 85 dB
Wow and flutter Immeasurable
USB section
USB specification Compatible with USB 2.0 Full Speed
Compatible device Mass storage class
Compatible file system FAT16, FAT32
Output power DC 5 V 500 mA
General
Power requirements AC 230 V , 50 Hz
Power consumption 30 W (power on)
8 W (standby)
1 W or less (ECO Mode)
Dimensions (W ×H ×D) 165 mm ×251 mm ×245 mm
Mass 1.9 kg
Speakers
Speaker units 10 cm cone ×1; 1.5 cm ×1
Impedance 6 Ω
Dimensions (approx.) 140 mm ×251 mm ×141 mm (W/H/D)
Mass (approx.) 1.3 kg each

(No.MB699<Rev.003>)1-3
For Asia
Specifications and appearance are subject to change without prior notice.
Amplifier section
OUTPUT POWER 60 W (30 W + 30 W) at 6 Ω(10% THD)
Speakers/Impedance 6 Ω- 16 Ω
Audio input AUDIO IN 500 mV/47 kΩ(at “LEVEL 1”)
250 mV/47 kΩ(at “LEVEL 2”)
125 mV/47 kΩ(at “LEVEL 3”)
Digital input USB MEMORY REC/PLAY
Tuner section
FM tuning range 87.50 MHz - 108.00 MHz
AM tuning range 531 kHz - 1 710 kHz (in 9 kHz spacing)
530 kHz - 1 710 kHz (in 10 kHz spacing)
CD player section
Dynamic range 88 dB
Signal-to-noise ratio 85 dB
Wow and flutter Immeasurable
USB section
USB specification Compatible with USB 2.0 Full Speed
Compatible device Mass storage class
Compatible file system FAT16, FAT32
Output power DC 5 V 500 mA
General
Power requirements AC 110 V-127 V/AC 220 V-240 V adjustable with the voltage selec-
tor, 50 Hz/60 Hz
AC 240 V , 50 Hz (only Australia)
AC 220 V , 50 Hz (only Hong Kong)
Power consumption 30 W (power on)
8 W (standby)
1 W or less (ECO Mode)
Dimensions (W ×H ×D) 165 mm ×251 mm ×245 mm
Mass 1.9 kg
Speakers
Speaker units 10 cm cone ×1; 1.5 cm ×1
Impedance 6 Ω
Dimensions (approx.) 140 mm ×251 mm ×141 mm (W/H/D)
Mass (approx.) 1.3 kg each

1-4 (No.MB699<Rev.003>)
SECTION 1
PRECAUTION
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purpos-
es. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be per-
formed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by us-
ing replacement components rated for higher voltage, watt-
age, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Ser-
vice Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety charac-
teristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassem-
bling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isola-
tion check on the exposed metal parts of the product (an-
tenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particular-
ly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage cur-
rent must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ωper volt or more sensitivity
in the following manner. Connect a 1,500Ω10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE

(No.MB699<Rev.003>)1-5
1.5 Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.5.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1.6 Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the
replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a
time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) I t is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.
1.7 Attention when traverse unit is decomposed
*Please refer to "Disassembly method" in the text for the pickup unit.
• Apply solder to the short land sections before the card wire is disconnected from the connecto on the servo board. (If the card wire
is disconnected without applying solder, the pickup may be destroyed by static electricity.)
• In the assembly, be sure to remove solder from the short land sections after connecting the card wire.
1M
Conductive material
(conductive sheet) or iron palate
(caption)
Anti-static wrist strap
Solder short land

1-6 (No.MB699<Rev.003>)
1.8 Important for laser products
1.CLASS 1 LASER PRODUCT
2.CAUTION :
(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.
4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
REPRODUCTION AND POSITION
!Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
CAUTION:
INVISIBLE LASER RADIATION WHEN OPEN
DO NOT STARE INTO BEAM
DANGER:
INVISIBLE LASER RADIATION WHEN OPEN
AVOID DIRECT EXPOSER TO THE BEAM

(No.MB699<Rev.003>)1-7
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.

1-8 (No.MB699<Rev.003>)
SECTION 3
DISASSEMBLY
3.1 Main body (Used figure are UX-G355E)
3.1.1 Removing the Rear cabinet (See Fig.1 to 4)
(1) Remove the four screws Aattaching the Rear cabinet.
(See Fig.1)
Fig.1
(2) Remove the four screws Battaching the both side of the
Rear cabinet. (See Fig.2)
Fig.2
(3) Remove the four screws Cattaching the Rear cabinet.
(See Fig.3)
Fig.3
(4) Disengage two hooks aengaged Rear cabinet. (See Fig.4)
Fig.4
AA
B
C
C
hook a

(No.MB699<Rev.003>)1-9
3.1.2 Removing the SMPS board (See Fig.5)
(1) Disconnect the connector wires from MCU board connect-
ed to connectors CN2 and CN3 of the SMPS board.
(2) Remove the four screws Dattaching the SMPS board.
Fig.5
3.1.3 Removing the MCU board (See Fig.6, 7)
(1) Remove the two screws Eattaching the PCB bracket. (See
Fig.6)
Fig.6
(2) Remove the three screws Fattaching the MCU board. (See
Fig.7)
(3) Disconnect the card wire from Tuner pack connected to
connector CN201 of the MCU board. (See Fig.7)
(4) Disconnect the card wire from Display board Connected to
connector CN202 of the MCU board. (See Fig.7)
(5) Disconnect the connector wire from USB board connected
to connector CN210 of the MCU board. (See Fig.7)
(6) Disconnect the connector wire from CD board connected to
connector CN208 of the MCU board. (See Fig.7)
(7) Disconnect the card wire from CD board connected to con-
nector CN207 of the MCU board. (See Fig.7)
Fig.7
3.1.4 Removing the CD mechanism (See Fig.8 to 10)
(1) Disconnect the card wire from Pickup connected to con-
nector CN102 of the CD board. (See Fig.8)
Fig.8
(2) Remove the four screws Gattaching the CD mechanism.
(See Fig.9)
Fig.9
CN2CN3
D
D
E
F
F
CN201CN210CN208
CN202 CN207
CN102
G
G

1-10 (No.MB699<Rev.003>)
(3) Disconnect the connector wire from Loader board connect-
ed to connector CN103 of the CD board. (See Fig.10)
(4) Disconnect the connector wire from Traverse mechanism
connected to connector CN104 of the CD mechanism.
(See Fig.10)
Fig.10
3.1.5 Removing the CD board (See Fig.11)
(1) Disconnect the connector wire from USB board connected
to connector CN114 of the CD board.
(2) Remove the four screws Hattaching the CD board.
Fig.11
3.1.6 Removing the Front cabinet (See Fig.12, 13)
(1) Remove the two screws Jattaching the Front cabinet. (See
Fig.12)
Fig.12
(2) Disengage two hooks bengaged both side of the Front
cabinet. (See Fig.13)
Fig.13
3.1.7 Removing the LCD board (See Fig.14)
(1) Remove the Volume knob.
(2) Remove the eleven screws Kattaching the LCD board.
Fig.14
3.1.8 Removing the USB board (See Fig.15)
(1) Remove the six screws Lattaching the USB board.
Fig.15
CN103
CN104
CN114 H
H
J
hook b
KK
L
L

(No.MB699<Rev.003>)1-11
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.
SECTION 5
TROUBLESHOOTING
This service manual does not describe TROUBLESHOOTING.

(No.MB699<Rev.003>)
VSE
Printed in Japan
Victor Company of Japan, Limited
Audio/Video Systems Division 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan

3-1
PARTS LIST
* All printed circuit boards and its assemblies are not available as service parts.
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
Electrical parts list (Block No.01~04)
Packing materials and accessories parts list (Block No.M3)
UX-G357E,UX-G357EN,UX-G357EV
UX-G357UT,UX-G355B,UX-G355E
UX-G355EN,UX-G355EV,UX-G355A
UX-G355US,UX-G355UB,UX-G355UW
UX-G355UP, UX-G355UT
3- 2
3- 6
3-14
MODEL MARK MODEL MARK MODEL MARK
AUX-G357E BUX-G357EN CUX-G357EV
D E F
G H I
J K
UX-G355B UX-G355E
UX-G355EV UX-G355A
UX-G355UB UX-G355UW
UX-G355EN
UX-G355US
M NUX-G355UT
UX-G355UP
L
UX-G357UT
MB699PAR<Rev.003>

3-2
Exploded view of general assembly and parts list
Block No. M MM1
A
E
21
22
23
65
12
70
72
14
16
1
3
13
20 17
17
11
11
10
25
25
28
18
18
18
18
19
19
26
25 25
24
74
18
15
69
71
6
5
45
58
59
7
64
4
8
42
55
61
62
41
57
42
56
63
33
33
43
a
c
a
b
f
g
d
e
h
j
j
m
A
B
G
D
G
MCU board
USB board
Display board

3-3
The parts without symbol number are not service.
E
F
F
32
76
53
78
52
67
32
75
29
2
8
73
38
79
36
40
37
9
99
9
51
77
68
35
35
34
34
34
39
44
66
50
31
30
2
8
27
60
45
45
5
45
27
68
46
47
27
49
49
49
49
4
4
48
54
b
g
c
de
f
h
k
k
p
p
m
n
n
B
D
CD board
355B,UB
SMPS board
355US,UW
357/355UT

3-4
General Assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 CD5501081600100 DISPLAY LENS 5501-081600100 A,B,C,D
1 CD5501081000100 DISPLAY LENS 5501-081000100 E,F,G,H,I,J,K,L,M,N
2 CD6024230080200 SCREW 6024-230080200 (x2) A,B,C,D
2 CD6024230080100 SCREW 6024-230080100 (x2) E,F,G,H,I,J,K,L,M,N
3 CD5913081000100 COSMETIC FRAME 5913-081000100
4 CD6024230080200 SCREW 6024-230080200 (x2) A,B,C,D
4 CD6024230080100 SCREW 6024-230080100 (x2) E,F,G,H,I,J,K,L,M,N
5 CD5905081000100 RING 5905-081000100
6 CD5307081000100 VOLUME KNOB 5307-081000100
7 CD5201081600100 CD DOOR 5201-081600100 A,B,C,D
7 CD5201081000100 CD DOOR 5201-081000100 E,F,G,H,I,J,K,L,M,N
8 CD6014230100200 SCREW 6014-230100200 (x2) A,B,C,D
8 CD6014230100110 SCREW 6014-230100110 (x2) E,F,G,H,I,J,K,L,M,N
9 CD6014230100200 SCREW 6014-230100200 (x4) A,B,C,D
9 CD6014230100110 SCREW 6014-230100110 (x4) E,F,G,H,I,J,K,L,M,N
10 CD6211080700100 PANEL FIXING PLATE 6211-080700100
11 CD6211080700100 PANEL FIXING PLATE 6211-080700100 (x2)
12 CD5001081600100 FRONT CABINET 5001-081600100 A,B,C
12 CD5001081600200 FRONT CABINET 5001-081600200 D
12 CD5001081000100 FRONT CABINET 5001-081000100 E,F,G,H
12 CD5001081000200 FRONT CABINET 5001-081000200 I,J,K,L,M,N
13 CD6013217060100 SCREW 6013-217060100 (x5)
14 CD6303081000100 CONNECTOR BRACKET 6303-081000100
14 or CD6303081000200 CONNECTOR BRACKET 6303-081000200 J,L
15 CD5408081600100 POWER BUTTON 5408-081600100 A,B,C,D
15 CD5408081000100 POWER BUTTON 5408-081000100 E,F,G,H,I,J,K,L,M,N
16 CD6011226080100 SCREW 6011-226080100
17 CD6011226080100 SCREW 6011-226080100 (x6)
18 CD6011226080100 SCREW 6011-226080100 (x7)
19 CD6011226080100 SCREW 6011-226080100 (x4)
20 CD5618081000100 BUTTON BRACKET 5618-081000100
21 CD5413081600100 SOUND BUTTON 5413-081600100 A,B,C,D
21 CD5413081000100 SOUND BUTTON 5413-081000100 E,F,G,H,I,J,K,L,M,N
22 CD5401081600100 ECO BUTTON 5401-081600100 A,B,C,D
22 CD5401081000100 ECO BUTTON 5401-081000100 E,F,G,H,I,J,K,L,M,N
23 CD5403081600100 CONTROL BUTTON 5403-081600100 A,B,C,D
23 CD5403081000200 CONTROL BUTTON 5403-081000200 E,F,G,H,I,J,K,L,M,N
24 CD5601081000100 VFD BRACKET 5601-081000100
25 CD5601081000200 LED BRACKET 5601-081000200 (x4)
26 CD6011226060100 SCREW 6011-226060100 (x2)
27 CD6011226060100 SCREW 6011-226060100 (x4)
28 CD5607081000100 PCB BRACKET 5607-081000100 A,B,C,E,F,G,H
28 CD5607081000101 PCB BRACKET 5607-081000101 D,J,K,L,M,N
28 CD5607081000200 PCB BRACKET 5607-081000200 I
29 CD6210081200200 PC CUT SHEET 6210-081200200
30 CD6204081000100 SHIELDING TOP 6204-081000100 A,B,C,E,F,G,H
30 CD6204081000101 SHIELDING TOP 6204-081000101 D,I,J,K,L,M,N
31 CD6210081000200 PC CUT SHEET 6210-081000200
31 or CD6210081000300 PC CUT SHEET 6210-081000300 J,L
32 CD6013230100200 SCREW 6013-230100200 (x4) A,B,C,D
32 CD6013230100120 SCREW 6013-230100120 (x4) E,F,G,H,I,J,K,L,M,N
33 CD6013230100200 SCREW 6013-230100200 (x3) A,B,C,D
33 CD6013230100120 SCREW 6013-230100120 (x3) E,F,G,H,I,J,K,L,M,N
34 CD6013230100200 SCREW 6013-230100200 (x4) A,B,C,D
34 CD6013230100120 SCREW 6013-230100120 (x4) E,F,G,H,I,J,K,L,M,N
35 CD6013230100200 SCREW 6013-230100200 (x2) A,B,C,D
35 CD6013230100120 SCREW 6013-230100120 (x2) E,F,G,H,I,J,K,L,M,N
36 CD6600061000200 HEAT SINK A 6600-061000200
37 CD6600081000200 HEAT SINK 6600-081000200
38 CD6406081000100 EVA 6406-081000100
39 CD6013230060300 SCREW 6013-230060300
40 CD6013230060300 SCREW 6013-230060300
41 CD6600081000100 HEAT SINK 6600-081000100
42 CD5939081000100 PLASTIC WASHER 5939-081000100 (x2)
43 CD6023230100300 SCREW 6023-230100300 (x2)
44 CD6217081000100 GROUND PLATE 6217-081000100
45 CD6013230120100 SCREW 6013-230120100 (x4)
46 CD6012226100110 SCREW 6012-226100110
47 CD8024000000100 FIBRE WASHER 8024-000000100
48 CD5002081000200 BOTTOM CABINET 5002-081000200
49 CD6404081100200 SILICON FOOT 6404-081100200 (x4)
50 CD5624081000100 PCB BRACKET 5624-081000100 A,B,C,D,E,F,G,H,J,K,L,M,N
50 CD5624081000200 PCB BRACKET 5624-081000200 I
51 CD6034226060100 SCREW 6034-226060100 (x2)

3-5
52 CD3801000000350 FM TUNER MODULE 3801-000000350 A,B,C,F,G,H
52 CD3801000000360 AM/FM TUNER MODULE 3801-000000360 D,I,J,K,L,M,N
52 CD3801000000370 AM/FM TUNER MODULE 3801-000000370 E
53 CD5002081000400 REAR CABINET 5002-081000400 A,B,C,F,G,H
53 CD5002081600101 REAR CABINET 5002-081600101 D
53 CD5002081000300 REAR CABINET 5002-081000300 E,I,K,M
53 CD5002081000101 REAR CABINET 5002-081000101 J,L,N
54 CD4401120001120 CD MECHANISM 4401-120001120
55 CD3002160150900 FFC CABLE 3002-160150900
56 CD3505040252500 HOUSING 3505-040252500
57 CD3505030252000 SHIELD WIRE 3505-030252000
58 CD3502050152010 HOUSING 3502-050152010
59 CD3502060252000 HOUSING 3502-060252000
60 CD3002160105900 FFC CABLE 3002-160105900
61 CD3002200090910 FFC CABLE 3002-200090910
62 CD3505090252000 HOUSING 3505-090252000
63 CD3505030332000 HOUSING 3505-030332000
64 CD8949050900200 CD MECHANISM LOADER 8949-050900200
65 CD3505070362020 SHIELD WIRE 3505-070362020
66 CD3001000150130 WIRE 3001-000150130 A,B,C,E,F,G,H
66 CD3001000180130 WIRE 3001-000180130 D,I,J,K,L,M,N
67 CD3002100120920 FFC CABLE 3002-100120920
 68 CD2902223007000 AC CORD 2902-223007000 A,B,C,F,G,H,J,L
 68 or CD2902123007040 AC CORD 2902-123007040 A,B,C,F,G,H,J,L
 68 or CD2902225007040 AC CORD 2902-225007040 A,B,C,F,G,H,J,L
 68 or CD2902125007210 AC CORD 2902-125007210 A,B,C,F,G,H,J,L
 68 or CD2902225007060 AC CORD 2902-225007060 A,B,C,F,G,H,J,L
 68 CD2908212507000 AC CORD 2908-212507000 D,N
 68 CD2905123007000 AC CORD 2905-123007000 E,K
 68 or CD2905225007070 AC CORD 2905-225007070 E
 68 CD2904225007000 AC CORD 2904-225007000 I
68 CD2911225007010 AC CORD 2911-225007010 M
69 CD5416081600200 CD BUTTON 5416-081600200 A,B,C,D
69 CD5404081000100 CD BUTTON 5404-081000100 E,F,G,H,I,J,K,L,M,N
70 CD5416081600300 USB BUTTON 5416-081600300 A,B,C,D
70 CD5416081000100 USB BUTTON 5416-081000100 E,F,G,H,I,J,K,L,M,N
71 CD5416081600100 TUNER BUTTON 5416-081600100 A,B,C,D
71 CD5403081000100 TUNER BUTTON 5403-081000100 E,F,G,H,I,J,K,L,M,N
72 CD5424081600100 AUDIO BUTTON 5424-081600100 A,B,C,D
72 CD5424081000100 AUDIO BUTTON 5424-081000100 E,F,G,H,I,J,K,L,M,N
73 CD7111081000100 RATING LABEL 7111-081000100 A,B,C,E,F,G,H
73 CD7111081600500 RATING LABEL 7111-081600500 D
73 CD7111081001000 RATING LABEL 7111-081001000 I
73 CD7111081000700 RATING LABEL 7111-081000700 J,L
73 CD7111081001300 RATING LABEL 7111-081001300 K
73 CD7111081000900 RATING LABEL 7111-081000900 M
73 CD7111081000701 RATING LABEL 7111-081000701 N
74 CD2401000000070 VFD 2401-000000070
75 CD6304041500100 FUSE HOLDER 6304-041500100 (x2)
 76 CD2001250250120 FUSE 2001-250250120
 76 or CD2001250250100 FUSE 2001-250250100 A,B,C,E,F,G,H
77 CD6011226080100 SCREW 6011-226080100 (x2) D,I,J,K,L,M,N
78 CD3307020200010 VOLTAGE SELECTOR SWITCH 3307-020200010 D,J,L,N
79 CD3501020083900 HOUSING 3501-020083900 D,J,L,N
 Symbol No. Part No. Part Name Description Local

3-6
Electrical parts list
MCU board
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
IC201 CD1506780514000 IC 1506-780514000 A,B,C,E,F,G,H
IC201 CD1506780515000 IC 1506-780515000 D,I,J,K,L,M,N
IC202 CD1511002402050 IC 1511-002402050
IC202 or CD1511002402030 IC 1511-002402030 A,B,C,E,F,G,H
IC202 or CD1511002402020 IC 1511-002402020 A,B,C,E,F,G,H
IC202 or CD1511002402040 IC 1511-002402040 A,B,C,E,F,G,H
IC202 or CD1511002402060 IC 1511-002402060 A,B,C,E,F,G,H
IC204 CD1502002314010 IC 1502-002314010
IC205 CD1502004453000 IC 1502-004453000
IC212 CD1502007492010 IC 1502-007492010
IC212 or CD1502007492000 IC 1502-007492000 A,B,C,E,F,G,H
IC214 CD1507007404030 IC 1507-007404030 A,B,C,E,F,G,H
Q1 CD1421085500000 TRANSISTOR 1421-085500000
Q1 or CD1421385500000 TRANSISTOR 1421-385500000 A,B,C,E,F,G,H
Q1 or CD1421085500010 TRANSISTOR 1421-085500010 A,B,C,E,F,G,H
Q201 CD1422080500020 TRANSISTOR 1422-080500020
Q201 or CD1422080500030 TRANSISTOR 1422-080500030 A,B,C,E,F,G,H
Q201 or CD1422080500050 TRANSISTOR 1422-080500050 A,B,C,E,F,G,H
Q202 CD1411385500000 TRANSISTOR 1411-385500000
Q202 or CD1411085500000 TRANSISTOR 1411-085500000 A,B,C,E,F,G,H
Q203 CD1422080500020 TRANSISTOR 1422-080500020
Q203 or CD1422080500030 TRANSISTOR 1422-080500030 A,B,C,E,F,G,H
Q203 or CD1422080500050 TRANSISTOR 1422-080500050 A,B,C,E,F,G,H
Q204 CD1422080500020 TRANSISTOR 1422-080500020
Q204 or CD1422080500030 TRANSISTOR 1422-080500030 A,B,C,E,F,G,H
Q204 or CD1422080500050 TRANSISTOR 1422-080500050 A,B,C,E,F,G,H
Q205 CD1424023010020 MOS FET 1424-023010020
Q206 CD1422080500020 TRANSISTOR 1422-080500020
Q206 or CD1422080500030 TRANSISTOR 1422-080500030 A,B,C,E,F,G,H
Q206 or CD1422080500050 TRANSISTOR 1422-080500050 A,B,C,E,F,G,H
Q207 CD1412080500000 TRANSISTOR 1412-080500000
Q212 CD1412080500000 TRANSISTOR 1412-080500000
Q213 CD1422080500020 TRANSISTOR 1422-080500020 A,B,C,E,F,G,H
Q213 or CD1422080500030 TRANSISTOR 1422-080500030 A,B,C,E,F,G,H
Q213 or CD1422080500050 TRANSISTOR 1422-080500050 A,B,C,E,F,G,H
Q213 CD1424230180010 MOS FET 1424-230180010 D,I,J,K,L,M,N
Q214 CD1421085500000 TRANSISTOR 1421-085500000 A,B,C,E,F,G,H
Q214 or CD1421385500000 TRANSISTOR 1421-385500000 A,B,C,E,F,G,H
Q214 or CD1421085500010 TRANSISTOR 1421-085500010 A,B,C,E,F,G,H
Q217 CD1422080500020 TRANSISTOR 1422-080500020
Q217 or CD1422080500030 TRANSISTOR 1422-080500030 A,B,C,E,F,G,H
Q217 or CD1422080500050 TRANSISTOR 1422-080500050 A,B,C,E,F,G,H
Q218 CD1422080500020 TRANSISTOR 1422-080500020
Q218 or CD1422080500030 TRANSISTOR 1422-080500030 A,B,C,E,F,G,H
Q218 or CD1422080500050 TRANSISTOR 1422-080500050 A,B,C,E,F,G,H
Q219 CD1422080500020 TRANSISTOR 1422-080500020
Q219 or CD1422080500030 TRANSISTOR 1422-080500030 A,B,C,E,F,G,H
Q219 or CD1422080500050 TRANSISTOR 1422-080500050 A,B,C,E,F,G,H
D1 CD1321041480020 DIODE 1321-041480020 A,B,C,E,F,G,H
D1 or CD1321041480010 SWITCH DIODE 1321-041480010 A,B,C,E,F,G,H
D1 CD1321041480040 DIODE 1321-041480040 D,I,J,K,L,M,N
D2 CD1321041480020 DIODE 1321-041480020 A,B,C,E,F,G,H
D2 or CD1321041480010 SWITCH DIODE 1321-041480010 A,B,C,E,F,G,H
D2 CD1321041480040 DIODE 1321-041480040 D,I,J,K,L,M,N
D3 CD1321041480040 DIODE 1321-041480040 D,I,J,K,L,M,N
D6 CD1321041480020 DIODE 1321-041480020 A,B,C,E,F,G,H
D6 or CD1321041480010 SWITCH DIODE 1321-041480010 A,B,C,E,F,G,H
D6 CD1321041480040 DIODE 1321-041480040 D,I,J,K,L,M,N
D7 CD1321041480020 DIODE 1321-041480020 A,B,C,E,F,G,H
D7 or CD1321041480010 SWITCH DIODE 1321-041480010 A,B,C,E,F,G,H
D7 CD1321041480040 DIODE 1321-041480040 D,I,J,K,L,M,N
D201 CD1321041480020 DIODE 1321-041480020 A,B,C,E,F,G,H
D201 or CD1321041480010 SWITCH DIODE 1321-041480010 A,B,C,E,F,G,H
D201 CD1321041480040 DIODE 1321-041480040 D,I,J,K,L,M,N
D202 CD1321041480020 DIODE 1321-041480020 A,B,C,E,F,G,H
D202 or CD1321041480010 SWITCH DIODE 1321-041480010 A,B,C,E,F,G,H
D202 CD1321041480040 DIODE 1321-041480040 D,I,J,K,L,M,N
D203 CD1321041480020 DIODE 1321-041480020 A,B,C,E,F,G,H
D203 or CD1321041480010 SWITCH DIODE 1321-041480010 A,B,C,E,F,G,H
D203 CD1321041480040 DIODE 1321-041480040 D,I,J,K,L,M,N
D206 CD1321041480020 DIODE 1321-041480020 A,B,C,E,F,G,H
D206 or CD1321041480010 SWITCH DIODE 1321-041480010 A,B,C,E,F,G,H
D206 CD1321041480040 DIODE 1321-041480040 D,I,J,K,L,M,N
C1 CD1121103082020 C CAPACITOR 1121-103082020
C2 CD1132107043060 E CAPACITOR 1132-107043060 A,B,C,E,F,G,H
C2 CD1132225083060 E CAPACITOR 1132-225083060 D,I,J,K,L,M,N
C3 CD1121103082020 C CAPACITOR 1121-103082020
C4 CD1132107053060 E CAPACITOR 1132-107053060 A,B,C,E,F,G,H
C5 CD1121102082020 C CAPACITOR 1121-102082020
C6 CD1121102082020 C CAPACITOR 1121-102082020
C9 CD1138474091210 M CAPACITOR 1138-474091210
C10 CD1121105051020 C CAPACITOR 1121-105051020
C11 CD1121104082020 C CAPACITOR 1121-104082020
C16 CD1121103082020 C CAPACITOR 1121-103082020
C17 CD1121103082020 C CAPACITOR 1121-103082020
C18 CD1121103082020 C CAPACITOR 1121-103082020
C19 CD1121103082020 C CAPACITOR 1121-103082020
C20 CD1121224084020 C CAPACITOR 1121-224084020 D,I,J,K,L,M,N
C21 CD1121224084020 C CAPACITOR 1121-224084020 D,I,J,K,L,M,N
C22 CD1121224084020 C CAPACITOR 1121-224084020 D,I,J,K,L,M,N
C23 CD1121224084020 C CAPACITOR 1121-224084020 D,I,J,K,L,M,N
C7B CD1121104082020 C CAPACITOR 1121-104082020
C8B CD1121104082020 C CAPACITOR 1121-104082020
C201 CD1121102082020 C CAPACITOR 1121-102082020
C202 CD1121471081020 C CAPACITOR 1121-471081020 A,B,C,E,F,G,H
C202 CD1221000062020 C RESISTOR 1221-000062020 D,I,J,K,L,M,N
C203 CD1121330081020 C CAPACITOR 1121-330081020 A,B,C,E,F,G,H
C204 CD1121104082020 C CAPACITOR 1121-104082020 A,B,C,E,F,G,H
C206 CD1121101081020 C CAPACITOR 1121-101081020 A,B,C,E,F,G,H
C207 CD1121101081020 C CAPACITOR 1121-101081020 A,B,C,E,F,G,H
C207 CD1221304062020 C RESISTOR 1221-304062020 D,I,J,K,L,M,N
C208 CD1121101081020 C CAPACITOR 1121-101081020 A,B,C,E,F,G,H
C208 CD1221000062020 C RESISTOR 1221-000062020 D,I,J,K,L,M,N
C209 CD1121101081020 C CAPACITOR 1121-101081020 A,B,C,E,F,G,H
C210 CD1121104082020 C CAPACITOR 1121-104082020
C220 CD1121104082020 C CAPACITOR 1121-104082020
C221 CD1121104082020 C CAPACITOR 1121-104082020
C222 CD1121104082020 C CAPACITOR 1121-104082020
C223 CD1121105051020 C CAPACITOR 1121-105051020
C224 CD1121105051020 C CAPACITOR 1121-105051020
C225 CD1132225083060 E CAPACITOR 1132-225083060
C226 CD1121104082020 C CAPACITOR 1121-104082020
C227 CD1121104082020 C CAPACITOR 1121-104082020
C228 CD1121104082020 C CAPACITOR 1121-104082020
C229 CD1132228073271 E CAPACITOR 1132-228073271 A,B,C,E,F,G,H
C229 CD1132158073271 E CAPACITOR 1132-158073271 D,I,J,K,L,M,N
C230 CD1121331081020 C CAPACITOR 1121-331081020
C231 CD1138474091210 M CAPACITOR 1138-474091210
C232 CD1121104082020 C CAPACITOR 1121-104082020 A,B,C,E,F,G,H
C232 CD1121224084020 C CAPACITOR 1121-224084020 D,I,J,K,L,M,N
C233 CD1121104082020 C CAPACITOR 1121-104082020 A,B,C,E,F,G,H
C233 CD1121224084020 C CAPACITOR 1121-224084020 D,I,J,K,L,M,N
C234 CD1138474091210 M CAPACITOR 1138-474091210
C235 CD1121104082020 C CAPACITOR 1121-104082020 A,B,C,E,F,G,H
C235 CD1121224084020 C CAPACITOR 1121-224084020 D,I,J,K,L,M,N
C236 CD1121104082020 C CAPACITOR 1121-104082020 A,B,C,E,F,G,H
C236 CD1121224084020 C CAPACITOR 1121-224084020 D,I,J,K,L,M,N
C237 CD1121474084020 C CAPACITOR 1121-474084020
C238 CD1121474084020 C CAPACITOR 1121-474084020
C239 CD1121104082020 C CAPACITOR 1121-104082020
C240 CD1121474084020 C CAPACITOR 1121-474084020
C241 CD1121681081020 C CAPACITOR 1121-681081020
C242 CD1121681081020 C CAPACITOR 1121-681081020
C243 CD1121474084020 C CAPACITOR 1121-474084020
C244 CD1121104082020 C CAPACITOR 1121-104082020 D,I,J,K,L,M,N
C245 CD1121105051020 C CAPACITOR 1121-105051020
C246 CD1121105051020 C CAPACITOR 1121-105051020
C247 CD1121104082020 C CAPACITOR 1121-104082020
C256 CD1121104082020 C CAPACITOR 1121-104082020
C257 CD1132227053320 E CAPACITOR 1132-227053320
C258 CD1132227053320 E CAPACITOR 1132-227053320
C260 CD1121104082020 C CAPACITOR 1121-104082020
C262 CD1121105051020 C CAPACITOR 1121-105051020
C264 CD1121105051020 C CAPACITOR 1121-105051020
C265 CD1132476053050 E CAPACITOR 1132-476053050
 Symbol No. Part No. Part Name Description Local

3-7
C266 CD1132227053320 E CAPACITOR 1132-227053320
C267 CD1132476053050 E CAPACITOR 1132-476053050
C268 CD1121105051020 C CAPACITOR 1121-105051020
C269 CD1121105051020 C CAPACITOR 1121-105051020
C270 CD1121104082020 C CAPACITOR 1121-104082020
C271 CD1132107053060 E CAPACITOR 1132-107053060
C272 CD1132476053060 E CAPACITOR 1132-476053060
C273 CD1138272092230 M CAPACITOR 1138-272092230
C274 CD1138272092230 M CAPACITOR 1138-272092230
C275 CD1118104084370 M CAPACITOR 1118-104084370
C276 CD1132225083060 E CAPACITOR 1132-225083060
C277 CD1118104084370 M CAPACITOR 1118-104084370
C278 CD1121105051020 C CAPACITOR 1121-105051020
C279 CD1121105051020 C CAPACITOR 1121-105051020
C280 CD1121105051020 C CAPACITOR 1121-105051020
C281 CD1132106053060 E CAPACITOR 1132-106053060
C282 CD1132106053060 E CAPACITOR 1132-106053060
C283 CD1132226053060 E CAPACITOR 1132-226053060
C284 CD1121102082020 C CAPACITOR 1121-102082020
C285 CD1121102082020 C CAPACITOR 1121-102082020
C286 CD1121105051020 C CAPACITOR 1121-105051020
C291 CD1118104084370 M CAPACITOR 1118-104084370
C292 CD1118104084370 M CAPACITOR 1118-104084370
C293 CD1118104084370 M CAPACITOR 1118-104084370
C294 CD1118104084370 M CAPACITOR 1118-104084370
C295 CD1132225083060 E CAPACITOR 1132-225083060
C296 CD1121331081020 C CAPACITOR 1121-331081020
C301 CD1121104082020 C CAPACITOR 1121-104082020
C302 CD1132107053710 E CAPACITOR 1132-107053710
C303 CD1121104082020 C CAPACITOR 1121-104082020
C304 CD1132107053710 E CAPACITOR 1132-107053710
C306 CD1121104082020 C CAPACITOR 1121-104082020
C307 CD1121104082020 C CAPACITOR 1121-104082020
C308 CD1132107053710 E CAPACITOR 1132-107053710
C309 CD1132475053030 E CAPACITOR 1132-475053030
C310 CD1121104082020 C CAPACITOR 1121-104082020
C311 CD1121240081020 C CAPACITOR 1121-240081020
C312 CD1121240081020 C CAPACITOR 1121-240081020
C313 CD1121104082020 C CAPACITOR 1121-104082020
C314 CD1132107053060 E CAPACITOR 1132-107053060
C315 CD1132107053710 E CAPACITOR 1132-107053710
C316 CD1121104082020 C CAPACITOR 1121-104082020
C317 CD1121104082020 C CAPACITOR 1121-104082020
C318 CD1121101081020 C CAPACITOR 1121-101081020
C319 CD1121104082020 C CAPACITOR 1121-104082020
C320 CD1121104082020 C CAPACITOR 1121-104082020
C325 CD1121681081020 C CAPACITOR 1121-681081020
C326 CD1121681081020 C CAPACITOR 1121-681081020
C327 CD1132475083060 E CAPACITOR 1132-475083060
C328 CD1132475083060 E CAPACITOR 1132-475083060
C332 CD1121105051020 C CAPACITOR 1121-105051020
C336 CD1121105051020 C CAPACITOR 1121-105051020
C339 CD1121104082020 C CAPACITOR 1121-104082020
R1 CD1221000062020 C RESISTOR 1221-000062020
R2 CD1221000062020 C RESISTOR 1221-000062020
R4 CD1221472062020 C RESISTOR 1221-472062020
R5 CD1221103062020 C RESISTOR 1221-103062020
R9 CD1221563062020 C RESISTOR 1221-563062020 A,B,C,E,F,G,H
R10 CD1221563062020 C RESISTOR 1221-563062020 A,B,C,E,F,G,H
R11 CD1221333062020 C RESISTOR 1221-333062020 A,B,C,E,F,G,H
R12 CD1221333062020 C RESISTOR 1221-333062020 A,B,C,E,F,G,H
R13 CD1221102062020 C RESISTOR 1221-102062020
R14 CD1221102062020 C RESISTOR 1221-102062020
R15 CD1221102062020 C RESISTOR 1221-102062020
R26 CD1221101062020 C RESISTOR 1221-101062020
R27 CD1221224062020 C RESISTOR 1221-224062020 D,I,J,K,L,M,N
R28 CD1221000062020 C RESISTOR 1221-000062020 D,I,J,K,L,M,N
R29 CD1221000062020 C RESISTOR 1221-000062020 D,I,J,K,L,M,N
R30 CD1221000062020 C RESISTOR 1221-000062020 D,I,J,K,L,M,N
R200 CD1221101062020 C RESISTOR 1221-101062020
R201 CD1221562062020 C RESISTOR 1221-562062020
R202 CD1221562062020 C RESISTOR 1221-562062020
R203 CD1221562062020 C RESISTOR 1221-562062020
R210 CD1221242062020 C RESISTOR 1221-242062020
R212 CD1221242062020 C RESISTOR 1221-242062020
R213 CD1221242062020 C RESISTOR 1221-242062020
R214 CD1221242062020 C RESISTOR 1221-242062020
 Symbol No. Part No. Part Name Description Local
R215 CD1221242062020 C RESISTOR 1221-242062020
R216 CD1221242062020 C RESISTOR 1221-242062020
R217 CD1221242062020 C RESISTOR 1221-242062020
R218 CD1221242062020 C RESISTOR 1221-242062020
R223 CD1221392062020 C RESISTOR 1221-392062020
R227 CD1221562062020 C RESISTOR 1221-562062020
R228 CD1221562062020 C RESISTOR 1221-562062020
R229 CD1221562062020 C RESISTOR 1221-562062020
R230 CD1221561062020 C RESISTOR 1221-561062020
R231 CD1221561062020 C RESISTOR 1221-561062020
R232 CD1221473062020 C RESISTOR 1221-473062020
R233 CD1221104062020 C RESISTOR 1221-104062020
R234 CD1221103062020 C RESISTOR 1221-103062020
R235 CD1221103062020 C RESISTOR 1221-103062020
R236 CD1221103062020 C RESISTOR 1221-103062020
R238 CD1221473062020 C RESISTOR 1221-473062020
R240 CD1221473062020 C RESISTOR 1221-473062020
R241 CD1221821061020 C RESISTOR 1221-821061020
R242 CD1221473062020 C RESISTOR 1221-473062020
R243 CD1221103062020 C RESISTOR 1221-103062020
R244 CD1221222062020 C RESISTOR 1221-222062020
R245 CD1221222062020 C RESISTOR 1221-222062020
R246 CD1221103062020 C RESISTOR 1221-103062020
R247 CD1221182062020 C RESISTOR 1221-182062020
R248 CD1221182062020 C RESISTOR 1221-182062020
R250 CD1221562062020 C RESISTOR 1221-562062020
R251 CD1221562062020 C RESISTOR 1221-562062020
R255 CD1221332062020 C RESISTOR 1221-332062020
R256 CD1221102062020 C RESISTOR 1221-102062020
R257 CD1221392062020 C RESISTOR 1221-392062020
R286 CD1221105062020 C RESISTOR 1221-105062020
R300 CD1221102062020 C RESISTOR 1221-102062020
R301 CD1221152062020 C RESISTOR 1221-152062020
R302 CD1221152062020 C RESISTOR 1221-152062020
R303 CD1221000062020 C RESISTOR 1221-000062020
R304 CD1221000062020 C RESISTOR 1221-000062020
R305 CD1221101062020 C RESISTOR 1221-101062020
R306 CD1221472062020 C RESISTOR 1221-472062020
R307 CD1221472062020 C RESISTOR 1221-472062020
R308 CD1221472062020 C RESISTOR 1221-472062020
R309 CD1221472062020 C RESISTOR 1221-472062020
R310 CD1221101062020 C RESISTOR 1221-101062020
R311 CD1221101062020 C RESISTOR 1221-101062020
R312 CD1221102062020 C RESISTOR 1221-102062020
R313 CD1221102062020 C RESISTOR 1221-102062020
R314 CD1221102062020 C RESISTOR 1221-102062020
R315 CD1221102062020 C RESISTOR 1221-102062020
R316 CD1221102062020 C RESISTOR 1221-102062020
R317 CD1221102062020 C RESISTOR 1221-102062020
R318 CD1221102062020 C RESISTOR 1221-102062020
R320 CD1221223062020 C RESISTOR 1221-223062020
R321 CD1221472062020 C RESISTOR 1221-472062020
R322 CD1221223062020 C RESISTOR 1221-223062020
R323 CD1221102062020 C RESISTOR 1221-102062020
R324 CD1221103062020 C RESISTOR 1221-103062020
R325 CD1221473062020 C RESISTOR 1221-473062020
R326 CD1221103062020 C RESISTOR 1221-103062020
R327 CD1221472062020 C RESISTOR 1221-472062020
R328 CD1221473062020 C RESISTOR 1221-473062020
R329 CD1221105062020 C RESISTOR 1221-105062020
R330 CD1221102062020 C RESISTOR 1221-102062020
R331 CD1221220062020 C RESISTOR 1221-220062020
R332 CD1221220062020 C RESISTOR 1221-220062020
R333 CD1221220062020 C RESISTOR 1221-220062020
R334 CD1221220062020 C RESISTOR 1221-220062020
R335 CD1221220062020 C RESISTOR 1221-220062020
R336 CD1221102062020 C RESISTOR 1221-102062020
R337 CD1221102062020 C RESISTOR 1221-102062020
R338 CD1221000062020 C RESISTOR 1221-000062020
R339 CD1221000062020 C RESISTOR 1221-000062020
R355 CD1221000062020 C RESISTOR 1221-000062020
R356 CD1221000062020 C RESISTOR 1221-000062020
R358 CD1231121012000 RESISTOR 1231-121012000
R359 CD1221223062020 C RESISTOR 1221-223062020
R360 CD1221472062020 C RESISTOR 1221-472062020
R361 CD1221472062020 C RESISTOR 1221-472062020
R362 CD1221103062020 C RESISTOR 1221-103062020
R363 CD1221102062020 C RESISTOR 1221-102062020
 Symbol No. Part No. Part Name Description Local

3-8
CD board
Block No. [0][2]
R364 CD1221102062020 C RESISTOR 1221-102062020
R365 CD1221102062020 C RESISTOR 1221-102062020
R366 CD1221103062020 C RESISTOR 1221-103062020
R367 CD1221102062020 C RESISTOR 1221-102062020
R368 CD1221103062020 C RESISTOR 1221-103062020
R369 CD1221103062020 C RESISTOR 1221-103062020
R370 CD1221223062020 C RESISTOR 1221-223062020
R373 CD1221102062020 C RESISTOR 1221-102062020
R374 CD1221102062020 C RESISTOR 1221-102062020
R375 CD1221103062020 C RESISTOR 1221-103062020
R376 CD1221102062020 C RESISTOR 1221-102062020
R377 CD1221102062020 C RESISTOR 1221-102062020
R378 CD1221102062020 C RESISTOR 1221-102062020
R379 CD1221102062020 C RESISTOR 1221-102062020
R380 CD1221103062020 C RESISTOR 1221-103062020
R381 CD1221102062020 C RESISTOR 1221-102062020
R382 CD1221102062020 C RESISTOR 1221-102062020
R383 CD1221000062020 C RESISTOR 1221-000062020
R384 CD1221103062020 C RESISTOR 1221-103062020
R385 CD1221103062020 C RESISTOR 1221-103062020
R387 CD1221103062020 C RESISTOR 1221-103062020
R388 CD1221103062020 C RESISTOR 1221-103062020
R389 CD1221103062020 C RESISTOR 1221-103062020 A,B,C,E,F,G,H
R389 CD1221392062020 C RESISTOR 1221-392062020 D,I,J,K,L,M,N
R390 CD1221103062020 C RESISTOR 1221-103062020 A,B,C,E,F,G,H
R390 CD1221392062020 C RESISTOR 1221-392062020 D,I,J,K,L,M,N
R391 CD1221103062020 C RESISTOR 1221-103062020
R392 CD1221223062020 C RESISTOR 1221-223062020
R393 CD1221123062020 C RESISTOR 1221-123062020
R394 CD1221682062020 C RESISTOR 1221-682062020
R395 CD1221472062020 C RESISTOR 1221-472062020
R396 CD1221103062020 C RESISTOR 1221-103062020
R401 CD1221223062020 C RESISTOR 1221-223062020
R402 CD1221223062020 C RESISTOR 1221-223062020
R403 CD1221513062020 C RESISTOR 1221-513062020
R404 CD1221513062020 C RESISTOR 1221-513062020
R405 CD1221222062020 C RESISTOR 1221-222062020
R406 CD1221222062020 C RESISTOR 1221-222062020
R407 CD1221333062020 C RESISTOR 1221-333062020
R408 CD1221333062020 C RESISTOR 1221-333062020
R409 CD1221220062020 C RESISTOR 1221-220062020
R410 CD1221105062020 C RESISTOR 1221-105062020
R411 CD1221105062020 C RESISTOR 1221-105062020
R412 CD1221105062020 C RESISTOR 1221-105062020
R413 CD1221473062020 C RESISTOR 1221-473062020 D,I,J,K,L,M,N
R414 CD1221105062020 C RESISTOR 1221-105062020
R415 CD1221000062020 C RESISTOR 1221-000062020
R416 CD1221000062020 C RESISTOR 1221-000062020
R417 CD1221220062020 C RESISTOR 1221-220062020
R418 CD1221220062020 C RESISTOR 1221-220062020
R419 CD1221104062020 C RESISTOR 1221-104062020 A,B,C,E,F,G,H
R419 CD1221102062020 C RESISTOR 1221-102062020 D,I,J,K,L,M,N
R420 CD1221104062020 C RESISTOR 1221-104062020 A,B,C,E,F,G,H
R421 CD1221682062020 C RESISTOR 1221-682062020 A,B,C,E,F,G,H
R422 CD1221105062020 C RESISTOR 1221-105062020 A,B,C,E,F,G,H
R423 CD1221103062020 C RESISTOR 1221-103062020 A,B,C,E,F,G,H
R424 CD1221000062020 C RESISTOR 1221-000062020
R425 CD1221101062020 C RESISTOR 1221-101062020 A,B,C,E,F,G,H
R425 CD1221000062020 C RESISTOR 1221-000062020 D,I,J,K,L,M,N
R426 CD1221103062020 C RESISTOR 1221-103062020 A,B,C,E,F,G,H
R428 CD1221821061020 C RESISTOR 1221-821061020 A,B,C,E,F,G,H
R429 CD1221220062020 C RESISTOR 1221-220062020 A,B,C,E,F,G,H
R430 CD1221471062020 C RESISTOR 1221-471062020
R431 CD1221102062020 C RESISTOR 1221-102062020
R433 CD1221000062020 C RESISTOR 1221-000062020
R434 CD1221220062020 C RESISTOR 1221-220062020
R435 CD1221104062020 C RESISTOR 1221-104062020
R436 CD1221332062020 C RESISTOR 1221-332062020
R437 CD1221101062020 C RESISTOR 1221-101062020
R440 CD1221000062020 C RESISTOR 1221-000062020 A,B,C,E,F,G,H
R441 CD1221000062020 C RESISTOR 1221-000062020 A,B,C,E,F,G,H
R443 CD1221000062020 C RESISTOR 1221-000062020
R445 CD1221103062020 C RESISTOR 1221-103062020
R446 CD1221103062020 C RESISTOR 1221-103062020
L1 CD2105000000100 EMI FILTER BEAD 2105-000000100
L1 or CD2105000000050 EMI FILTER BEAD 2105-000000050 A,B,C,E,F,G,H
L2 CD1608300025000 TORODIDAL COIL 1608-300025000
 Symbol No. Part No. Part Name Description Local
L3 CD1608300025000 TORODIDAL COIL 1608-300025000
L205 CD1614330010000 COIL 1614-330010000
L206 CD1614330010000 COIL 1614-330010000
L207 CD1614330010000 COIL 1614-330010000
L208 CD1614330010000 COIL 1614-330010000
L209 CD3005000000000 JUMP WIRE 3005-000000000
L210 CD3005000000000 JUMP WIRE 3005-000000000
L211 CD1604101350000 COIL 1604-101350000
L212 CD1604101350000 COIL 1604-101350000
L213 CD1604101350000 COIL 1604-101350000
CN201 CD3106121021000 FFC CONNECTOR 3106-121021000
CN202 CD3106101621020 FFC CONNECTOR 3106-101621020
CN204 CD3101200821010 HEADER 3101-200821010
CN207 CD3106122021000 FFC CONNECTOR 3106-122021000
CN208 CD3101200321010 HEADER 3101-200321010
CN210 CD3101200721000 HEADER 3101-200721000
CN212 CD3401000000310 SP TERMINAL 3401-000000310
EC1 CD1132106053060 E CAPACITOR 1132-106053060
FB03 CD1221000062030 C RESISTOR 1221-000062030
FB04 CD1221000062030 C RESISTOR 1221-000062030
FB07 CD1221000062030 C RESISTOR 1221-000062030
FB09 CD1221000062030 C RESISTOR 1221-000062030
FB10 CD1221000062030 C RESISTOR 1221-000062030
X201 CD1002006027900 CER.RESONATOR 1002-006027900 A,B,C,E,F,G,H
X202 CD1002007000900 CER.RESONATOR 1002-007000900 A,B,C,E,F,G,H
X203 CD1001000327130 CRYSTAL 1001-000327130
Z201 CD1313000510000 Z DIODE 1313-000510000
Z214 CD1313000910010 Z DIODE 1313-000910010
Z215 CD1313079330020 Z DIODE 1313-079330020
Z216 CD1313079330020 Z DIODE 1313-079330020
Z217 CD1313000510000 Z DIODE 1313-000510000 A,B,C,E,F,G,H
Z218 CD1313079560020 Z DIODE 1313-079560020
ZD1 CD1323001110000 Z DIODE 1323-001110000
 Symbol No. Part No. Part Name Description Local
IC101 CD1512001117130 IC 1512-001117130
IC102 CD1512001117080 IC 1512-001117080
IC102 or CD1512001117010 IC 1512-001117010 A,B,C,E,F,G,H
IC103 CD1511981616030 IC 1511-981616030
IC103 or CD1511811616020 IC 1511-811616020 A,B,C,E,F,G,H
IC103 or CD1511981616000 IC 1511-981616000 A,B,C,E,F,G,H
IC103 or CD1511811616010 IC 1511-811616010 A,B,C,E,F,G,H
IC103 or CD1511164161020 IC 1511-164161020 A,B,C,E,F,G,H
IC104 CD1513005888020 IC 1513-005888020
IC104 or CD1513005888010 IC 1513-005888010 A,B,C,E,F,G,H
IC105 CD1511002540000 IC 1511-002540000
IC106 CD1509008104020 IC 1509-008104020
Q101 CD1422080500020 TRANSISTOR 1422-080500020
Q101 or CD1422080500030 TRANSISTOR 1422-080500030 A,B,C,E,F,G,H
Q102 CD1421211320010 TRANSISTOR 1421-211320010
Q103 CD1422080500020 TRANSISTOR 1422-080500020
Q103 or CD1422080500030 TRANSISTOR 1422-080500030 A,B,C,E,F,G,H
Q104 CD1422080500020 TRANSISTOR 1422-080500020
Q104 or CD1422080500030 TRANSISTOR 1422-080500030 A,B,C,E,F,G,H
Q105 CD1424023010020 MOS FET 1424-023010020
Q106 CD1412080500000 TRANSISTOR 1412-080500000
Q107 CD1412080500000 TRANSISTOR 1412-080500000
Q108 CD1411385500000 TRANSISTOR 1411-385500000
Q109 CD1411385500000 TRANSISTOR 1411-385500000
D101 CD1311140010020 DIODE 1311-140010020 A,B,C,E,F,G,H
D101 CD1311140010040 DIODE 1311-140010040 D,I,J,K,L,M,N
D102 CD1321041480020 DIODE 1321-041480020 A,B,C,E,F,G,H
D102 or CD1321041480010 SWITCH DIODE 1321-041480010 A,B,C,E,F,G,H
D102 CD1321041480040 DIODE 1321-041480040 D,I,J,K,L,M,N
D103 CD1321041480020 DIODE 1321-041480020 A,B,C,E,F,G,H
D103 or CD1321041480010 SWITCH DIODE 1321-041480010 A,B,C,E,F,G,H
D103 CD1321041480040 DIODE 1321-041480040 D,I,J,K,L,M,N
 Symbol No. Part No. Part Name Description Local
