1/3" CCD COLOR VIDEO CAMERA
TK-C9200UA
600 TV Lines
Easy Day/Night
■High-Resolution of 600 TV Lines
Newly developed 14bit DSP enables industry-leading high
quality pictures
■Super LoLuxTM Sensitivity
0.05 lx at color mode (50% video level, F1.2, AGC HIGH)
0.03 lx at B&W mode (50% video level, F1.2, AGC HIGH)
■Industry-leading S/N Ratio of 52dB
■3D Noise Reduction
Powerful system to reduce noise in dark environments
■Up to 128x of Slow Shutter
Increases visibility even in low light situations
■Area White Balance
New function that can apply Auto White Balance to a specific area
■Black Level Adjustment
Intelligent adjustment for dark areas to provide images without
black out
■Easy Installation with Well-Conceived Menu
Combination of DIP switch and built-in Menu makes detailed
settings simple and easy
■Variety of Functions for Precise Monitoring
• Automatic Gain Control (AGC)
• Automatic Electronic Shutter (AES)
• 4 Area Patterns for Backlight Compensation (BLC)
• Manual and Auto Tracking White Balance
• 1.4x/2.0x Digital Zoom
• Privacy Mask for protecting against intrusive monitoring
• Display Mode Selection for CRT and LCD
• CCD White Spot Compensation
• Focus Adjustment Mode for accurate focusing
• 24VAC/12VDC Dual Voltage
■Eco-Friendly Super Low Power Consumption
Approx. 40% lower than conventional models
Lens not included
TK-C9200U.qxd 09.10.7 11:33 Page 1

This camera has been designed to assure precise color
reproduction in low light situations. It is possible to identify
image colors in much darker places.
Full-Fledged Surveillance Camera with High-Resolution Images
and Clear Colors in Any Situation
■Super LoLuxTM “COLOR IN VIRTUAL ZERO LUX”
Normal camera JVC Super LoLuxTM
3DNR is the powerful method to improve image quality even
though it’s shot in the dark. Noise data is detected by
comparing some continuous frames and reduced by blending
it into other frames over time.
■3D Noise Reduction (3DNR)
Normal 3DNR
Specifications TK-C9200UA
Signal system NTSC
Image device 1/3 type IT CCD
Number of effective pixels 380,000 (768H x 494V)
Sync system Internal
Scanning system 2:1 interlace, 525 lines
Scanning frequency 15.734kHz (H), 59.94Hz (V)
Video output Composite video signal: 1.0V (p-p), 75 ohms (BNC)
Video S/N ratio 52 dB (AGC off)
Horizontal resolution 600 TV lines *
Minimum illumination (typical) 0.05 lx (50%, F1.2, AGC HIGH)
0.025 lx (25%, F1.2, AGC HIGH)
B&W mode 0.03 lx (50%, F1.2, AGC HIGH)
0.015 lx (25%, F1.2, AGC HIGH)
Iris control DC iris
White balance ATW (wide/narrow) / AWC / Manual
(ATW color temp. range 2300K to 10,000K)
Day/Night Easy D/N
3DNR NORMAL / HIGH
Display mode (Monitor type) LCD1/LCD2/CRT
BLC off/on (4 patterns)
AGC OFF/MID/HIGH
AES off/on (1/60s to 1/100,000s)
Sens-up off / x2 to x128
Digital zoom x1, x1.4, x2
Privacy mask 4 areas
Focus adjustment mode Yes
Lens mount CS
Power supply 24VAC (60Hz) / 12VDC UL listed
Power consumption 2.3 W
Operating temperature range 14°F to 122°F (-10°C to 50°C)
(32°F to 104°F (0°C to 40°C) recommended)
Dimensions (WxHxD) 2-3/16" x 2-7/16" x 5" (55mm x 61mm x 126mm)
Weight (approx.) 0.6lbs (270g)
Auto White Balance can be applied to a designated area.
With this, color casting can be prevented by setting the white
balance within an area while avoiding strong color zones.
■Area White Balance
Avoid the area with
strong blue when setting
the white balance.
Focus Adjustment mode opens the iris fully for 30 seconds to
make it easier to adjust focus by temporarily reducing the
depth of field.
■Focus Adjustment Mode
Printed in Japan
KCN-1858C TK-C9200U 2011/3
“JVC” is the trademark or registered trademark of Victor Company of Japan, Limited.
JQA-0288
Design and specifications subject to change without notice.
Note: Screen images are explanatory purpose and not actual images attained using this product.
All brand or product names may be trademarks and/or registered trademarks of their respective owners.
Copyright © 2011, Victor Company of Japan, Limited. All Rights Reserved.
DISTRIBUTED BY
1-1/2 (36.8)1/4 20 UNC
MOUNTING HOLE
4-1/2 (114.3)
5 (126)
2-3/16 (55)
5/16 (7.8)
2-1/8 (53)
1-3/8
(34.3)
4-R7
Unit: inch (mm)
Dimensions
TK-C9200U.qxd 09.10.7 11:34 Page 2
* Tamron M13VM246 at wide angle
