JWA Acorn 70818 User manual

ASSEMBLY INSTRUCTION
Acorn
5 tier Bookcase
ITEM CODE 70818
1

PRE-ASSEMBLY PREPARATION
Before you start:
1.Choose a clean, level, spacious assembly area. Avoid hard surfaces that
may damage the product
2.Take care when lifting. Product should be assembled as near as possible
to the point of use
3.Ensure that you have all required contents for complete assembly
4.Always read the assembly instructions carefully before beginning assembly.
5.Keep all hardware parts and packaging out of reach of small children.
6.Do not over tighten the screws and bolts as this may damage the threads
Allow 45min For 2 person Additional tools required
Serious or fatal injuries may occur from furniture toppling over.
To help avoid this please follow the below recommendations;
· Install the provided"Tipping Kit" as per the instructions
· Never allow children to climb on or hang off of any part of this
product
· Unless specifically designed to accommodate,do not set Tvs or
other heavy objects on top of this product
IF this product has drawers:
· Place the heaviest items in lowest drawers
· Do not open more than 1 drawer at a time as this may cause
the product to become unbalanced
· Do not tamper with or remove any drawer
interlocking/running system
Note:The use of the provided"Tipping Kit" may reduce but not
necessarily eliminate the risk of furniture toppling over.
Please use this product with caution.
This is a permanent label.Do not attempt to remove!
TIPPING WARNING
2

PARTS LIST
ABC D E
FG
M6X30 mm
20pcs
M6X20 mm
20pcs
M8
4pcs
2pcs
ST3.5X14mm
4pcs
2pcs
3
M4X25 mm
2pcs
P2
P1
P1
2
1
P2
P2
P2
P2
2
2
2
1 Layer Panel 1
2 Layer Panel 2
P1 Metal Frame
P2 Back net

4
P1
E
90%
1
E
90%
P1
D
D
C
CCC
Screw fitting C into the bottom of metal frame P1.
Fix the fitting D to the Panel 1 with fitting E align the
corresponding position holes at the bottom of Panel 1.

5
P1
P2
B
AAA
AA
AA
AA
A
A
A
A
A
A
A
A
A
A
A
1
2
2
2
2
B
B
B
BB
B
B
B
B
B
B
B
B
B
B
B
B
P1
P2
P2
P2
P2
P1
P1
Assemble the back net to the metal frame with fitting A.
Assemble Panel 1 and 2 to the metal frame with fitting
B.

6
Assembly complete!
G
F
D

7
