JWA CONWAY 74371 User manual

Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please refer to your receipt
ASSEMBLY INSTRUCTION
74371
DAYBED WITH TRUNDLE
CONWAY
1
2140mm 1120mm
1020mm

PRE-ASSEMBLY PREPARATION
Before you start:
1.Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the
product
2.Take care when lifting. Product should be assembled as near as possible to the point of
use
3.Ensure that you have all required contents for complete assembly
4.Always read the assembly instructions carefully before beginning assembly.
5.Keep all hardware parts and packaging out of reach of small children.
6.Do not over tighten the screws and bolts as this may damage the threads
7.Assembly is to be carried out by a competent adult(s) ONLY
8.During assembly, children should be kept away from the product due to possible risk to
injury.
9.Do not use this item if any components are missing or damaged.
10.Please keep the instructions for future reference.
Allow 30 min For 2 person Additional tools
required
2

3
PARTS LIST

STEP 1:
•Prepare a protected surface with a blanket or cardboard.
•Attach the 4x Threaded rod(D) to the armrest left(2) and armrest
right(3), as shown below. And tighten halfway.
•Attach the 4x feet(11) to the armrest left(2) and armrest right(3).
Secure with wood screw(I).
STEP 2:
•Connect the headboard(1) to the armrest left(2) and armrest
right(3). Insert washer(E) per corner. Fasten with hex nut(F).
•Connect the side rail(4) to the armrest left(2) and armrest
right(3).Secure with 2x bolt(B),spring washer(J) and washer(E)
per corner. Fasten with allen key(G).
•Attach the centre cross rail(5) to the side rail and headboard as
shown below. Thread 1x bolt(C),2x washer(E) per side from the
top and below, and lock with Hex nut(F),Repeat for the other
side rail.
4

STEP 3:
•Attach 2x end cap(7) onto every slat(6).
•Attach the slat to the bed as shown below. Push the caps into
the holes.
STEP 4:
•Attach trundle cross rail (10) with 3x bolt (A),washer(E) tighten
with allen key(G) to trundle front side rail (8) and with 2x bolt to
trundle side rail back (9) as shown below.
•Attach centre cross rail(5) to trundle side rail front (8) and
trundle side rail back (9) as shown below. Thread 1x bolt(C),2x
washer(E) per side from the top and below, and lock with Hex
nut(F),Repeat for the other side rail.
5

STEP 5:
•Attach 2x end cap(7) onto every slat(6).
•Attach the slat to the bed as shown below. Push the caps into
the holes.
STEP 6:
•Slot in the trundle bed and fixing is complete.
6Assembly Is Complete

PRODUCT CARE:
FURNITURE / BED
1. When assembling your furniture / bed please ensure that you have
checked the contents for all relevant parts.
2. When tightening bolts make sure that they are fully tightened but not
forced.
3. When moving your fully assembled bed you must first remove the
mattress and lift the frame into position, take care when lifting and
always have two people handling the bed. PLEASE DO NOT DRAG THE
BED as this will cause damage to the rail.
4. It is advisable to use approved cleaning products when cleaning the
furniture and bed frame as certain chemical based cleaners could have
an adverse effect on the bed finish.
