König Electronic HAV-TR20 User manual

ENGLIS
H
HAV-TR20
HAV-TR21
FM/AM RADIO CONTROLS
ENGLISH
INSTRUCTIONS

CONTROLS
1) Innovative circular LCD Display
2) Snooze button
3) Mode button
4) C/F degree + Backlight button
5) Set button
6) Speaker
7) On/Off switch & Volume control
8) Tuning knob
9) Battery compartment
10) AC/DC Jack
11) AM/FM band switch
12) Wired antenna
Radio Operation
1. Insert 3 x AA batteries into battery compartment.
2. Turn on the radio by using On/Off switch.
3. Use Volume control to adjust the volume.
4. Use AM/FM band switch to select station as desired.
5. Use Tuning knob to select station as desired.
6. If the reception is still unsatisfactory, also pull the wired
antenna as long as possible.
7. Turn off the radio by using On/Off switch.
Setting the clock
-Press ‘Set’ button to select Hour, Minute, Year, Month and Date.
-Press ‘Snooze’ or ‘Backlight’ button to adjust the desired setting.
-Press ‘Mode’ button to confirm the Time setting (12H/24H mode)
-Press ‘Snooze’ button to switch 12H/24H mode. (C/F degree
temperature mode)
-Press ‘Backlight’ button to switch C/F degree temperature mode &
activate the backlight. The backlight is ON for 4 seconds
automatically.

-1-
Setting the Alarm time
-Press ‘Mode’ button to Alarm time setting mode.
-Press ‘Set’ button to select Hour, Minute, Snooze time and Alarm
sounds (8 different music).
-Press ‘Snooze’ or ‘Backlight’ button to adjust the desired alarm
setting.
-Press ‘Mode’ button to confirm the alarm time setting.
Alarm Operation
-In alarm time setting mode, press ‘Snooze’ button to activate the
alarm or snooze function. (The display shows Alarm On and
SNOOZE when the alarm and snooze function are on.)
-When the alarm goes off s the backlight is on for 4 seconds, press
any button to stop.
-If the snooze function is ON, press any button to stop the alarm for
preset snooze time. And when the alarm goes off again, press any
button to stop.
Specification
Frequency Range: AM530 – 1600 KHz, FM88 –108 MHz
Power Supply: 3 x AA batteries (DC 4.5V) or 4.5V DC 200mA
adaptor
WARNING:
To reduce risk of electric shock, this product should ONLY be
opened by an authorized technician if service is required.
Disconnect the product from mains and other equipment if a
problem should occur. Do not expose the product to water or
moisture.

WARRANTY:
No guarantee or liability can be accepted for any changes and
modifications of the product or damage caused due to incorrect use
of this product.
GENERAL:
Designs and specifications are subject to change without notice.
-2-
