Kaba Access Manager 200 Specification sheet

Kaba Access & Data Systems Americas
Tel: [phone] | 336-725-1331
www.kaba-adsamericas.com
LIT1067 0613 © Copyright 2013 Kaba ADS Americas. All rights reserved.
QUICK SETUP: ACCESS MANAGER 200 & FINGERPRINT KEY • RS485 | Electric Strike
2. WIRING
A. Connect Access Manager 200 and Door Unit
RS485 between Access Manager 200 and Door Unit
12 to 24V DC Power Source (24V recommended)
B. Connect FPK (TLR401B or AR402) RS485 reader to Door Unit
12V DC (red)
GND (black)
RS485A (pink)
RS485B (gray)
C. Connect door locking hardware
Locking device (electric strike shown)
Door contact (monitors door status)
Request for exit / PIR (exit button shown)
Locking hardware power (DC Power Source)
3. NETWORK
A. Ethernet connection
Using CAT5 patch cable connect the Access Manager 200 to an Ethernet router or directly to a PC using a
CAT5 crossed cable
B. Setting the IP address
Set the IP address of the connected PC to allow connection to the Access Manager 200 default IP
address 192.168.50.120
(See Software Configuration Manual for details.)
4. POWER ON
A. Plug in DC power source
B. Verify the Access Manager 200 LED indicators
V2 (On = RS485 Data Transmission)
V3 (Blinking = Application Software Running)
V5 (On = Power On)
V14 (On = 100MHz Ethernet Connection)
V15 (On = Ethernet Connected)
V19 (On = Ethernet Data Transmission)
5. LOG IN AND CONFIGURE
A. Connecting to the Access Manager 200
Open the Web browser of the connected PC
Enter the default IP address of 192.168.50.120 at the address line
The “User Login and Status” screen is displayed
B. Log in to the system
Enter the name “user1”
Enter the password “pw”
Click Logon
C. Modify the system for your unique application
Modify the pre-loaded configuration to your needs
Enroll Cards and add Persons as required
(See Software Configuration Manual for details.)
1. MOUNTING

Kaba Access & Data Systems Americas
Tel: [phone] | 336-725-1331
www.kaba-adsamericas.com
LIT1067 0613 © Copyright 2013 Kaba ADS Americas. All rights reserved.
QUICK SETUP: ACCESS MANAGER 200 & FINGERPRINT KEY • RS485 | Electric Strike

Kaba Access & Data Systems Americas
Tel: [phone] | 336-725-1331
www.kaba-adsamericas.com
LIT1067 0613 © Copyright 2013 Kaba ADS Americas. All rights reserved.
QUICK SETUP: ACCESS MANAGER 200 & FINGERPRINT KEY • Wiegand | Electric Strike
2. WIRING
A. Connect Access Manager 200 and Door Unit
RS485 between Access Manager 200 and Door Unit
12 to 24V DC Power Source (24V recommended)
B. Connect proximity reader to Door Unit
12V DC (red)
GND (black)
Data 0 (green)
Data 1 (white)
Shield (must be connected)
Beeper (yellow)
Green LED (orange)
C. Connect door locking hardware
Locking device (electric strike shown)
Door contact (monitors door status)
Request for exit / PIR (exit button shown)
Locking hardware power (DC Power Source)
3. NETWORK
A. Ethernet connection
Using CAT5 patch cable connect the Access Manager 200 to an Ethernet router or directly to a PC using a
CAT5 crossed cable
B. Setting the IP address
Set the IP address of the connected PC to allow connection to the Access Manager 200 default IP
address 192.168.50.120
(See Software Configuration Manual for details.)
4. POWER ON
A. Plug in DC power source
B. Verify the Access Manager 200 LED indicators
V2 (On = RS485 Data Transmission)
V3 (Blinking = Application Software Running)
V5 (On = Power On)
V14 (On = 100MHz Ethernet Connection)
V15 (On = Ethernet Connected)
V19 (On = Ethernet Data Transmission)
5. LOG IN AND CONFIGURE
A. Connecting to the Access Manager 200
Open the Web browser of the connected PC
Enter the default IP address of 192.168.50.120 at the address line
The “User Login and Status” screen is displayed
B. Log in to the system
Enter the name “user1”
Enter the password “pw”
Click Logon
C. Modify the system for your unique application
Modify the pre-loaded configuration to your needs
Enroll Cards and add Persons as required
(See Software Configuration Manual for details.)
1. MOUNTING

Kaba Access & Data Systems Americas
Tel: [phone] | 336-725-1331
www.kaba-adsamericas.com
LIT1067 0613 © Copyright 2013 Kaba ADS Americas. All rights reserved.
QUICK SETUP: ACCESS MANAGER 200 & FINGERPRINT KEY • Wiegand | Electric Strike

Kaba Access & Data Systems Americas
Tel: [phone] | 336-725-1331
www.kaba-adsamericas.com
LIT1067 0613 © Copyright 2013 Kaba ADS Americas. All rights reserved.
2. WIRING
A. Connect Access Manager 200 and Door Unit
RS485 between Access Manager 200 and Door Unit
12 to 24V DC Power Source (24V recommended)
B. Connect FPK (TLR401B or AR402) RS485 reader to Door Unit
12V DC (red)
GND (black)
Data 0 (green)
Data 1 (white)
Shield (must be connected)
Beeper (yellow)
Green LED (orange)
C. Connect door locking hardware
Locking device (electric strike shown)
Door contact (monitors door status)
Request for exit / PIR (exit button shown)
Locking hardware power (DC Power Source)
3. NETWORK
A. Ethernet connection
Using CAT5 patch cable connect the Access Manager 200 to an Ethernet router or directly to a PC using a
CAT5 crossed cable
B. Setting the IP address
Set the IP address of the connected PC to allow connection to the Access Manager 200 default IP
address 192.168.50.120
(See Software Configuration Manual for details.)
4. POWER ON
A. Plug in DC power source
B. Verify the Access Manager 200 LED indicators
V2 (On = RS485 Data Transmission)
V3 (Blinking = Application Software Running)
V5 (On = Power On)
V14 (On = 100MHz Ethernet Connection)
V15 (On = Ethernet Connected)
V19 (On = Ethernet Data Transmission)
5. LOG IN AND CONFIGURE
A. Connecting to the Access Manager 200
Open the Web browser of the connected PC
Enter the default IP address of 192.168.50.120 at the address line
The “User Login and Status” screen is displayed
B. Log in to the system
Enter the name “user1”
Enter the password “pw”
Click Logon
C. Modify the system for your unique application
Modify the pre-loaded configuration to your needs
Enroll Cards and add Persons as required
(See Software Configuration Manual for details.)
1. MOUNTING
QUICK SETUP: ACCESS MANAGER 200 & PROXIMITY • Wiegand | Electric Strike

Kaba Access & Data Systems Americas
Tel: [phone] | 336-725-1331
www.kaba-adsamericas.com
LIT1067 0613 © Copyright 2013 Kaba ADS Americas. All rights reserved.
QUICK SETUP: ACCESS MANAGER 200 & PROXIMITY • Wiegand | Electric Strike
