Kalorik FT 46688 User manual

1
www.KALORIK.com
FT 46688 –210430
SMART FRYER
FREIDORA DE AIRE SMART FRYER
FRITEUSE À AIR CHAUD SMART FRYER
EN……....2
ES……...18
FR…......35

2
www.KALORIK.com
FT 46688 –210430
PARTS DESCRIPTION
1
2
3
4
5
6
7
8
9

3
www.KALORIK.com
FT 46688 –210430
PARTS DESCRIPTION
1. Air inlet
2. Timer (0-30 min.)/power-on knob
3. Power-on light
4. Temperature control knob (190-410°F)
5. Handle
6. Base
7. Trivet
8. Basket
9. Housing
TECHNICAL SPECIFICATIONS
Model
Voltage
Wattage
Capacity
FT 46688 BK
120V, 60Hz
1500W
3.2 Qt / 3L

4
www.KALORIK.com
FT 46688 –210430
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
1. READ ALL INSTRUCTIONS BEFORE USE!
2. Check that the voltage in your home corresponds to that stated on the
appliance.
3. Do not touch hot surfaces. Use handles or knobs.
4. To protect against electrical shock, fire or personal injury, do not immerse
cord, plugs, or the appliance in water or other liquid.
5. Close supervision is necessary when any appliance is used by or near
children. As a rule, this appliance is not intended to be used by children.
6. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts.
7. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions or has been damaged in any manner. Return the
appliance to the nearest authorized service facility for examination, repair,
or adjustment.
8. The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
9. Do not use outdoors.
10. Do not let the cord hang over the edge of a table or counter or touch hot
surfaces.
11. Do not place on or near a hot gas or electric burner, or in a heated oven.
12. Extreme caution must be used when moving an appliance containing hot
oil or other hot liquids.
13. To disconnect, turn any control to “off” (or 0), then remove the plug from
wall outlet.
14. Do not use the appliance for anything other than intended use.
15. Oversize foods or metal utensils must not be inserted in the Smart Fryer as
they may create a fire or risk of electric shock.
16. A fire may occur if the appliance is covered or touching flammable
material, including curtains, draperies, walls, and the like, when in
operation. Do not store any item on top of the appliance when in
operation.
17. Do not clean with metal scouring pads. Pieces can break off the pad and
touch electrical parts involving a risk of electric shock.
18. Extreme caution should be exercised when using containers constructed of
other than metal or glass.

5
www.KALORIK.com
FT 46688 –210430
19. Do not store any materials, other than manufacturers recommended
accessories, in this appliance when not in use.
20. Do not place any of the following materials in the appliance: paper,
cardboard, or plastic.
21. Do not cover the cooking basket or any part of the Smart Fryer with metal
foil. This causes overheating of the Smart Fryer.
22. Do not leave unit unattended when in use.
23. Use extreme caution when removing the trivet or basket and disposing of
hot grease.
24. The Smart Fryer can be turned off while using any of the functions by
turning the timer knob to the 0 or Off position.
25. During hot air frying, hot steam is released through the air outlet openings.
Keep your hands and face at a safe distance from the steam and from the
air outlet openings. Also be careful of hot steam and air when you remove
the pan from the appliance.
26. Immediately unplug the appliance if you see dark smoke coming out of the
appliance. Wait for the smoke emission to stop before you remove the pan
from the appliance.
27. Do not place the appliance against a wall or against other appliances.
28. Leave at least 6 inches (15 cm) of free space on the back, sides and above
the appliance.
Caution!!
•Always place the appliance on a horizontal, level, heat resistant and
stable surface.
•This appliance is intended for normal household use only.
•Always unplug the appliance after use.
•Let the appliance cool down for approximately 30 minutes before
handling or cleaning it.
•The appliance is equipped with a safety micro switch inside that will
shut the appliance off automatically if the basket is removed during
cooking.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY

6
www.KALORIK.com
FT 46688 –210430
POLARIZED PLUG INSTRUCTIONS
This appliance is equipped with a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, this plug will fit into the
polarized outlet only one way. If the plug does not properly fit into the
outlet at first, reverse it. If it still does not fit, contact a competent qualified
electrician. Do not attempt to modify the plug in any way.
SHORT CORD INSTRUCTIONS
A short power supply cord is provided to reduce the hazards resulting
from becoming entangled in, or tripping over a longer cord. Extension
cords may be used if care is exercised in their use.
•The electrical rating of the extension cord should be at least that of
the appliance. If the electrical rating of the extension cord is too
low, it could overheat and burn.
•The resulting extended cord should be arranged so that it will not
drape over the countertop or tabletop where it can be pulled on by
children or tripped over.
KNOW YOUR SMART FRYER
Prepare your favorite foods and snacks in a quick, healthy, and easy
way with your new Smart Fryer. This Smart Fryer combines heat with
high-speed air circulation and a top grill to cook your ingredients from
all sides, simultaneously! It also allows you to prepare a variety of tasty
dishes without the addition of excess oils or fats to most ingredients. This
Smart Fryer features:
•A temperature control range of 190°F –410°F (85°C –210°C)
•A timer range from 0 to 30 minutes, which is equipped with an auto
shut-off feature. Once the timer goes off, the unit will turn itself off.
Other great advantages provided by your Kalorik Smart Fryer include:
•Fast cooking, with little to no preheating required.
•Quick and easy clean-up: the non-stick coated parts are
conveniently sized to fit in the dishwasher.

7
www.KALORIK.com
FT 46688 –210430
•Hassle-free frying—no spatters, no mess, and no oil smell!
•Versatility—with its frying, baking, grilling, and roasting capacities,
this unit serves as a great cooking tool for a busy kitchen.
•No assembly required—very easy and safe to use!
BEFORE THE FIRST USE
•Unpack the appliance and its accessories (trivet, basket). Wash the
accessories in hot, soapy water and then wipe them dry. Wipe the
interior of the frying cavity with a damp cloth or sponge, and then
dry with a paper towel. Make sure the cavity is dry before operating
the unit.
•Position the Smart Fryer on a flat, level and heat-resistant surface,
making sure that it is also positioned at least 6 inches (15 cm) away
from any surrounding objects.
•It is recommended to let the Smart Fryer heat on the highest setting
for about 20 minutes without any food in it. This helps to eliminate
grease that may have adhered during manufacturing, and to
eliminate the "new" appliance smell.
•Ventilate the room during this period. When your Smart Fryer is
heated for the first time, it may emit slight smoke or odor. This is
normal with many heating appliances. This does not affect the
safety of your appliance.
Caution: When moving the Smart Fryer, make sure that you hold it
securely and support the base—do not rely solely on the basket handle
when moving the Smart Fryer!

8
www.KALORIK.com
FT 46688 –210430
OPERATING INSTRUCTIONS
1. Preparing for use
•Place the appliance on a stable, horizontal, and level surface.
Make sure that the surface is heat resistant and that the Smart Fryer
is also positioned at least 6 inches (15 cm) away from any
surrounding objects.
•Make sure that the trivet is securely placed inside the basket. Use
the trivet handle located in the center of the trivet to easily insert or
remove it from the basket.
•Insert the power plug into a wall socket. Your Smart Fryer is now
ready for use!
Caution!
• Do not fill the basket with oil or any other liquid, as this may cause a
fire hazard.
• Never use the Smart Fryer without the basket and trivet in place.
• Keep all ingredients in the basket to prevent any contact with the
appliance’s heating elements. Do not overfill the basket.
• Do not cover the air inlet on the top or the air outlet on the back of the
unit while the appliance is in use.
• Do not touch the inside of the appliance while it is operating.
• Never immerse the unit’s housing in water or rinse it under the tap.
2. Using the appliance
The Smart Fryer can be used to prepare a large variety of foods. Please
refer to the table in the “Settings” section for basic cooking times or
refer to the included recipe book.
•Pull the handle to carefully remove the basket from the Smart Fryer.
•Put the ingredients that you will be air-frying into the basket, on top
of the trivet.
Note: Never fill the basket to capacity or exceed the recommended
amounts (see section ‘Settings’ in this chapter), as this could affect the
quality of cooking.
•Slide the basket back into the Smart Fryer.

9
www.KALORIK.com
FT 46688 –210430
Caution! Never use the Smart Fryer without the basket and trivet in it!
Caution! Do not touch the trivet, basket, or the inside of the Smart Fryer
during or immediately after use, as they get very hot. Only hold the
basket by its handle. Always use oven mitts. Unit is hot!
•Turn the temperature control dial to the required cooking
temperature (See section’ Settings’ in this chapter to help
determine the right temperature).
•Determine the required preparation time for the ingredients (see
section ‘Settings’ after this chapter).
•To switch the appliance on, turn the timer knob to the required
cooking time.
•Add 3 minutes to the preparation time when the appliance is cold
or let the appliance preheat for 3 minutes without any ingredients
inside.
•The orange power-on light will illuminate, and the fryer will quickly
start generating hot air. The timer will start counting down the set
time.
•During cooking, some excess oil and cooking juices from the
ingredients will collect in the basket. This is to be expected.
•Some recipes require shaking the food in the basket halfway
through the set time (see section ’Settings’ in this chapter). To shake
the ingredients, pull the basket out of the appliance using the
handle and gently, but firmly, shake it. Slide the basket back into
the Smart Fryer and continue to cook.
Note: Because the rapid hot air technology instantly reheats the air
inside of the appliance, pulling the basket briefly out of the appliance
during hot air frying will not disturb the cooking process.
Tip: Sometimes, it is easier to divide cooking times into 2 phases for
recipes that require the basket to be shaken mid-cooking. If you set the
timer to half the required cooking time, you will hear the timer bell go
off when you must shake the ingredients. Please note that after shaking,
you must set the timer again to the remaining preparation time.
Tip: If you set the timer to the full cooking time, the timer bell will not go
off until cooking is completed. You can pull the basket out at any time
to check the cooking condition of the ingredients.

10
www.KALORIK.com
FT 46688 –210430
The power will shut down automatically and resume after you slide the
basket back into the appliance. Note that the timer does not stop
counting down in this situation.
•When you hear the timer bell, the set preparation time has elapsed.
Using oven mitts and the handle, pull the basket out of the
appliance and place it on a heat-resistant surface.
Note: You can also switch the appliance off at any time. To do this,
simply set the timer to “0” or pull out the pan directly.
•Check to see if the ingredients are ready. If they are not ready,
simply slide the basket back into the appliance and set the timer for
a few extra minutes.
Caution! After Smart frying, the trivet, the basket and the ingredients will
be hot! Depending on the type of the ingredients in the Smart Fryer,
steam may escape out of the unit. Be mindful of scalding and wear
kitchen gloves for safety.
•Holding the basket by the handle, empty the food into a bowl or
onto a plate.
Tip: To remove large or fragile ingredients, you may use a pair of tongs
to lift the ingredients out of the basket. Use tongs or utensils with heat-
resistant plastic tips, as metallic tips or utensils may scratch the coating
of the basket.
•When a batch of food is ready, the Smart Fryer is instantly ready for
preparing another batch.
IMPORTANT: If you notice the fan is not operating once the product
starts cooking (no noise or airflow), please discontinue usage
immediately and contact Customer Service.
MAKING HOME-MADE FRIES
To make home-made fries, follow the steps below:

11
www.KALORIK.com
FT 46688 –210430
•Peel the potatoes and cut them into sticks.
•Wash the potato sticks thoroughly and dry them with paper towels.
•Pour 1/2 tablespoon of canola oil in a bowl, put the sticks on top
and mix until they are coated with oil.
•Remove the sticks from the bowl with your hands or a kitchen utensil
so that excess oil stays behind in the bowl. Put the sticks in the
basket.
Note: Do not tilt the bowl to pour the potato sticks into the basket.
Transfer them with your hands or a kitchen utensil in smaller batches to
prevent excess oil from collecting on the bottom of the pan.
Air fry the potato sticks for 15 minutes at 400 °F or until golden. For best
results, do not fry more than 1 lb. of fries per batch.
SETTINGS
The table below will help you select the basic settings for the
ingredients you want to prepare.
Note: Keep in mind that these settings are suggestions.
Tips:
•Any food that can be prepared in a traditional oven can also be
prepared in the Smart Fryer.
•Shaking smaller ingredients halfway through the preparation time
optimizes the result and can help prevent unevenly air-fried food.
•A larger amount of ingredients only requires a slightly longer
preparation time; a smaller amount of ingredients only requires a
slightly shorter preparation time.
•If food tends to stick to the trivet or sides of the basket, add cooking
oil spray in the basket and on the trivet prior to adding the
ingredients to cook.
•Do not prepare very greasy food, such as sausages, in the Smart
Fryer as the grease could catch fire.
•Add some oil to fresh potatoes for a crispy result. Wait a few minutes
after you add the oil before placing your food in the Smart Fryer.
•The optimal amount for preparing crispy fries is 500 grams / 1.2 lb.
•Use pre-made dough to prepare filled snacks quickly and easily.

12
www.KALORIK.com
FT 46688 –210430
Pre-made dough also requires a shorter preparation time than
home-made dough.
•Place a baking tin or oven dish on top of the trivet to bake a cake,
quiche or to fry fragile or filled ingredients.
•You can also use the Smart Fryer to reheat food, by setting the
temperature to 290°F for up to 10 minutes.
Min-max
Amount
(lb)
Time
(min.)
Temp.
(F)
Shake
Extra
information
Potatoes & fries
Thin frozen fries
0.75-1
13-20
400
shake
Thick frozen fries
0.75-1
20-25
400
shake
Home-made fries
(8×8mm)
0.75-1
18-22
400
shake
Add 1/2 tbsp.
of oil
Home-made potato
wedges
0.75-1
21-26
400
shake
Add 1/2 tbsp.
oil
Home-made potato
cubes
0.75-1
13-15
400
shake
Add 1/2 tbsp.
of oil
Hash brown
0.5
15-18
360
shake
Potato gratin
1.1
15-18
400
Meat & Poultry
Steak
0.2-1.1
12-18
345
Pork chops
0.2-1.1
10-14
360
Hamburger
0.2-1.1
7-14
360
Sausage roll
0.2-1.1
13-15
400
Drumsticks
0.2-1.1
18-22
360
Chicken breast
0.2-1.1
15-20
360
Snacks
Spring rolls
0.2-1.0
8-10
400
shake
Use oven-
ready type
Frozen chicken
nuggets
0.2-1.1
6-10
400
shake
Use oven-
ready type
Frozen fish fingers
0.2-1.0
6-10
400
Use oven-
ready type
Frozen bread-
crumbed
cheese snacks
0.2-1.0
8-10
360
Use oven-
ready type

13
www.KALORIK.com
FT 46688 –210430
Frozen vegetables
0.2-1.0
10-12
400
shake
Use oven-
ready type
Baking
Cake
0.7
20-25
365
Quiche
0.9
20-22
360
Muffins
0.7
15-18
400
Sweet snacks
0.9
20
320
* All data is indicative.
*Recommended steak doneness guide:
400°F/10 mins for Rare, 400°F/10.5 mins for Medium-Rare, 400°F/ 11 mins for Medium, and
400°F/12+ Mins for Well-done. These recommendations are for a 11 oz / 310 g steak at
room temperature before starting the cooking process.
CLEANING AND MAINTENANCE
•Make sure to clean the appliance after each use!
•Switch the appliance off by turning the knobs of the control panel
into the OFF position (timer knob to “0”). Before cleaning, unplug
the appliance from the outlet and allow it to cool down
completely.
•The basket and trivet can be cleaned in hot water with mild
detergent / dish soap, or in the dishwasher. Do not use metal
kitchen utensils or abrasive cleaning materials to clean them as this
may damage the double non-stick coating. Rinse and dry
thoroughly after cleaning.
•To remove baked-on food, fill the basket with hot, soapy water. Let
the basket soak for about 10 minutes before cleaning in the sink.
•To remove trivet use handle on the center to pull out from the
basket.
Cleaning inside the cavity:
•Wipe the cavity with a damp cloth or sponge. Dry with a paper
towel.
•Never use abrasive products in the cavity!

14
www.KALORIK.com
FT 46688 –210430
•Never immerse the appliance in water and make sure that no
water or moisture penetrates the upper part of the Smart Fryer.
•Clean the heating element inside the Smart Fryer with a cleaning
brush to remove any food residue.
Cleaning the Smart Fryer’s exterior:
•Wipe clean with a damp sponge or cloth. Wipe dry.
•NEVER use steel wool, metal scouring pads or abrasive cleaners, as
they may damage the finish.
Any other servicing should be performed by an authorized service
representative.
DO NOT IMMERSE THE FRYER IN WATER OR ANY OTHER LIQUID!
TROUBLESHOOTING
Problem
Possible cause
Solution
The Smart Fryer
does not work
The appliance is not
plugged in.
Put the main plug in an earthed
wall socket.
You have not set the
timer.
Turn the timer knob to the
required preparation time to
switch on the appliance.
The basket is not
properly locked.
Push the basket back in the
Smart Fryer properly.
The ingredients
fried with the
Smart Fryer are not
done.
There is too much
food in the basket.
Put smaller batches of
ingredients in the basket.
Smaller batches are fried more
evenly.
The set temperature is
too low.
Turn the temperature control
knob to the required
temperature setting (see section
‘Settings’)
The cooking time is
too short.
Turn the timer knob to the
required preparation time (see
section ‘Settings’)

15
www.KALORIK.com
FT 46688 –210430
Fried snacks are
not crispy when
they come out of
the Smart Fryer.
You used a type of
snack meant to be
prepared in a
traditional deep fryer.
Use snacks made to be
prepared in the oven, or lightly
brush some oil onto the snacks
for a crispier result.
I cannot slide the
basket into the
appliance
properly
There is too much
food in the basket.
Do not fill the basket to
capacity; refer to the “Setting”
table above for maximum
quantities.
White smoke
comes out of the
appliance.
The basket or trivet still
contains grease
residues from previous
use.
White smoke is caused by
grease heating up in the basket;
make sure you clean the basket
and trivet thoroughly after each
use.
Fresh fries are fried
unevenly in the
Smart Fryer.
You did not use the
right type of potato.
Use fresh potatoes and make
sure they stay firm during frying.
You did not rinse the
potato sticks properly
before you fried
them.
Rinse the potato sticks
thoroughly to remove starch
from the outside of the sticks.
Fresh fries are not
crispy when they
come out of the
Smart Fryer.
You did not rinse the
potato sticks properly
before you fried
them.
Make sure you dry the potato
sticks properly before you add
oil.
The crispiness of the
fries depends on the
amount of oil and
water in the fries.
Cut the potatoes into thinner
sticks for a crispier result. Add
slightly more oil for a crispier
result.

16
www.KALORIK.com
FT 46688 –210430
WARRANTY
We suggest that you complete and return the enclosed Product
Registration Card promptly to facilitate verification of the date of
original purchase. However, return of the Product Registration Card is
not a condition of these warranties. You can also fill out this warranty
card online, at the following address: www.KALORIK.com
This KALORIK product is warranted in the U.S.A. and in Canada for 1
year from the date of purchase against defects in material and
workmanship. This warranty is not transferable. Keep the original sales
receipt. Proof of purchase is required to obtain warranty performance.
During this period, if the KALORIK product, upon inspection by KALORIK,
is proven defective, it will be repaired or replaced, at Kalorik’s option,
without charge to the customer. If a replacement product is sent, it will
carry the remaining warranty of the original product.
This warranty does not apply to any defect arising from a buyer's or
user's misuse of the product, negligence, failure to follow KALORIK
instructions noted in the user’s manual, use on current or voltage other
than that stamped on the product, wear and tear, alteration or repair
not authorized by KALORIK, or use for commercial purposes. There is no
warranty for glass parts, glass containers, filter basket, blades and
agitators. There is also no warranty for parts lost by the user.
ANY WARRANTY OF MERCHANTABILITY OR FITNESS WITH RESPECT TO THIS
PRODUCT IS ALSO LIMITED TO THE ONE YEAR LIMITED WARRANTY
PERIOD.
Some states do not allow limitation on how long an implied warranty
lasts or do not allow the exclusion of incidental or consequential
damages, so the above limitations may not apply to you. This warranty
gives you specific legal rights, and you may also have other rights
which vary from state to state.
If the appliance should become defective within the warranty period
and more than 30 days after date of purchase, do not return the
appliance to the store: often, our Customer Service Representatives
can help solve the problem without having the product serviced.

17
www.KALORIK.com
FT 46688 –210430
If servicing is needed, a Representative can confirm whether the
product is under warranty and direct you to the nearest service
location.
If this is the case, send the product via your pre-paid postage back to
Kalorik, along with proof of purchase and a return authorization number
indicated on the outer package, given by our Customer Service
Representatives. Send to the authorized KALORIK Service Center
(please visit our website at www.KALORIK.com or call our Customer
Service Department for the address of our authorized KALORIK Service
Center).
When sending the product, please include a letter explaining the
nature of the claimed defect.
If you have additional questions, please call our Customer Service
Department (please see below for complete contact information),
Monday through Thursday from 9:00am - 5:00pm (EST) and Friday from
9:00am - 4:00pm (EST). Please note hours are subject to change.
If you would like to write, please send your letter to:
KALORIK Customer Service Department
Team International Group of America Inc.
16175 NW 49th Avenue
Miami Gardens, FL 33014 USA
Or call:
Toll Free: +1 888-521-TEAM / +1 888-KALORIK
Only letters can be accepted at this address above. Shipments and
packages that do not have a return authorization number will be
refused.

18
www.KALORIK.com
FT 46688 –210430
DESCRIPCIÓN DE LAS PARTES
1
2
3
4
5
6
7
8
9

19
www.KALORIK.com
FT 46688 –210430
DESCRIPCIÓN DE LAS PARTES
1. Entrada de aire
2. Medidor de tiempo (0-30 min.) /mando de encendido
3. Luz de encendido
4. Mando para control de temperatura (190-410°F)
5. Manija
6. Base
7. Trébede
8. Cesta
9. Carcaza
ESPECIFICACIONES TÉCNICAS
Modelo
Voltaje
Potencia
Capacidad
FT 46688 BK
120V, 60Hz
1500 W
3.2 Qt / 3L

20
www.KALORIK.com
FT 46688 –210430
MEDIDAS IMPORTANTES DE
PRECAUCIÓN
Al utilizar aparatos eléctricos se deben tener siempre en cuenta las siguientes
medidas básicas de precaución:
¡LEER LAS INSTRUCCIONES ANTES DE USAR!
1. Verifique que el voltaje de su hogar corresponda al que está indicado en
el aparato.
2. No toque las superficies calientes. Utilice asas o perillas.
3. Para protegerse de choques eléctricos, incendio o lesiones personales, no
sumerja el cable, los enchufes, o el aparato, dentro del agua ni cualquier
otro líquido.
4. Siempre preste atención al aparato cuando el mismo sea utilizado por niño
o cerca de ellos. Como norma, este aparato no ha sido fabricado para
que ser utilizado por niños.
5. Desconéctelo del tomacorriente cuando no esté en uso, y antes de
limpiarlo. Déjelo enfriar antes de colocar o retirar de él las partes.
6. No poner en funcionamiento ningún aparato cuando su cable o enchufe
esté dañado, o luego de detector alguna falla en el funcionamiento o si el
aparato no funciona correctamente. Devuelva el aparato al servicio
autorizado más cercano para su chequeo, reparación, o ajuste.
7. El uso de accesorios no recomendados por el fabricante del aparato
puede causar lesiones.
8. No utilizarlo en el exterior.
9. No deje que el cable cuelgue fuera del borde de una mesa o de una
mesada, o que entre en contacto con superficies calientes.
10. No coloque el aparato encima o cerca de una cocina a gas caliente, o
de una hornalla caliente, o en un horno caliente.
11. Se debe tener sumo cuidado al mover un aparato que contiene aceite u
otros líquidos calientes.
12. Para desconectar, mueva el control a la posición “Off” [o 0 -cero-), y luego
desconecte el cable del tomacorriente.
13. No utilice el aparato para nada que no sea lo indicado.
14. No se deben colocar en el aparato alimentos/ trozos demasiado grandes,
o utensilios de metal en la freidora de aire, ya que esto podría causar un
incendio o el riesgo de choque eléctrico.
