Kalorik Digital kitchen scale withvolume measuring... User manual


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International USA. The pages must e reproduced and folded
in order to o tain a ooklet A5 (+/- 148.5 mm width x 210 mm
height). When folding, make sure you keep the good
num ering when you turn the pages of the I/B. Don’t change
the page num ering. Keep the language integrity. Print only
what is inside the frame,

Front cover page (first page)
Assem ly page 1/28
Fax [phone]
Digital kitchen scale with
volume measuring function
Bascula de cocina digital con
función de cálculo de volumen
Balance de cuisine digitale
avec fonction de mesure des
volumes
USK EKS 9724
2 x 1.5V (AAA batteries)
www.KALORIK.com


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International USA. The pages must e reproduced and folded
in order to o tain a ooklet A5 (+/- 148.5 mm width x 210 mm
height). When folding, make sure you keep the good
num ering when you turn the pages of the I/B. Don’t change
the page num ering. Keep the language integrity. Print only
what is inside the frame,
2 EKS 39724 - 120501
Assem ly page 2/28
Fax [phone]
IMPORTANT SAFEGUARDS
Please read these instructions carefully before using the appliance.
Important: People (including children) who are not a le to use the
appliance in a safe way, due to their physical, sensorial or mental capacity
or their lack of experience or knowledge, must never use the appliance
except if they are supervised y a person responsi le for their safety or if
they previously received instructions concerning the safe use of the
appliance.
Close supervision is necessary to prevent children from using the appliance
as a toy.
• Never leave the appliance unsupervised when in use.
• From time to time check the appliance for damages. Never use the
appliance if it shows any signs of damage. All repairs should e
made y a qualified electrician.
• Only use the appliance for domestic purposes and in the way
indicated in these instructions.
• Never immerse the appliance in water or any other liquid for any
reason whatsoever.
• Before cleaning, always remove the atteries.
• If the atteries leak, remove them, clean the contacts of the
appliance and wash your hands.
• If you do not use the appliance for a long time, remove the atteries
so that they do not leak.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
NOT SUITABLE FOR TRADE


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International USA. The pages must e reproduced and folded
in order to o tain a ooklet A5 (+/- 148.5 mm width x 210 mm
height). When folding, make sure you keep the good
num ering when you turn the pages of the I/B. Don’t change
the page num ering. Keep the language integrity. Print only
what is inside the frame,
3 EKS 39724 - 120501
Assem ly page 3/28
Fax [phone]
CHARACTERISTICS OF YOUR SCALE
• Remova le Stainless steel measuring owl, hygienic and easy to
clean
• Automatic switch-off
• Backlit LCD display
• Two weight unit systems: converti le g / l . + oz. (1 ounce = 28.35 g)
• Maximum weight (for normal weighing) = 5000 g / 11 l .
• Precision of the measurement = 1 g / 0.1 oz
• Automatic conversion of the weights into volumes (ml or US cups / Fl.
Oz.; for common ingredients like flour, water, milk or Oil).
• Low attery indicator and overloading indicator
BEFORE THE FIRST USE
This appliance works with 2 atteries (1.5V, type AAA,
not included). To install, remove the lid of the attery
housing on the ottom part of the scale. Place the
atteries, making sure to respect the polarity indicated
in the attery compartment, and then put the lid ack
in place. You can now use your scale.
HOW TO INSTALL OR REMOVE THE BOWL
To remove:
• Using your thum , slide the sliding
closure towards the handle to
release the owl.
• Remove the stainless steel owl with
your other hand
• Release the sliding closure
To install:
• Align the plate on the owl with the
handle
• Insert the plate on the owl into the
groove elow the sliding closure.
• Press the owl in place until you hear
a click sound indicating the sliding
closure is in place and the owl is
locked
LCD Display
Buttons Scale
Body
Groove
Sliding closure
Plate
Bowl


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International USA. The pages must e reproduced and folded
in order to o tain a ooklet A5 (+/- 148.5 mm width x 210 mm
height). When folding, make sure you keep the good
num ering when you turn the pages of the I/B. Don’t change
the page num ering. Keep the language integrity. Print only
what is inside the frame,
4 EKS 39724 - 120501
Assem ly page 4/28
Fax [phone]
FUNCTION BUTTONS
1. The On/Off-zero utton is used to switch the scale on or off, and to
reset the scale to 0.00 (Tare function).
2. The mode conversion utton is used to switch mode: press in
sequence to set the scale to Weighing mode / Water mode / Milk
mode / Oil Mode / Flour mode and then again: Weighing mode ….
3. The Unit utton is made to switch from
• g to l :oz in weighing mode
Flour Volume mode
Oil Volume mode
Milk Volume mode Water Volume mode
Weight
mode
Press MODE Press MODE
Press
MODE Press
MODE
Press
MODE
Press UNIT
Press MODE for
mode conversion
Press UNIT for unit
conversion
ON/OFF/ZERO


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International USA. The pages must e reproduced and folded
in order to o tain a ooklet A5 (+/- 148.5 mm width x 210 mm
height). When folding, make sure you keep the good
num ering when you turn the pages of the I/B. Don’t change
the page num ering. Keep the language integrity. Print only
what is inside the frame,
5 EKS 39724 - 120501
Assem ly page 5/28
Fax [phone]
• Fl. Oz. or ml to US cups in the Water, Milk and Oil mode
LCD DISPLAY
WEIGHT UNIT
Your scale allows you to use the metric measurement system (grams) OR
the imperial system (l .; ounce). Choose the measurement system at any
time y pressing the “Unit” utton (l :oz … g), depending on the
measurement system you wish to use. This utton is situated a ove the LCD
display.
USE
Put the scale on an even and hard surface, for instance a ta le or
countertop. Avoid soft surfaces.
Volume Unit (ml)
Weight unit (g)
Tare function symbol
Weight Unit (lb:Oz)
Arrow indicators in
“Mode” settings
Volume Unit (Fl. Oz.)
Volume Unit (US Cups)
Press UNIT


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International USA. The pages must e reproduced and folded
in order to o tain a ooklet A5 (+/- 148.5 mm width x 210 mm
height). When folding, make sure you keep the good
num ering when you turn the pages of the I/B. Don’t change
the page num ering. Keep the language integrity. Print only
what is inside the frame,
6 EKS 39724 - 120501
Assem ly page 6/28
Fax [phone]
WEIGHING
1) Place the stainless steel owl (if used) in place on the scale, efore
turning on the scale.
2) Switch the scale on using the on/off switch situated on the top of the
control panel. LCD screen will initialize.
3) The scale will turn on and the LCD display will show “0 g” or “0:0.0
l :oz.”.
4) Put the o ject you want to weigh on the scale. The sta ilized weight
is displayed. In the imperial weighing mode, the weight is indicated
in US pounds (l .), US ounces (oz.) and tenth of ounces. (for example
the weight display 2:3.2 means 2 l ., 3Oz. and 2/10 oz.).
5) Remove the o ject from the platform.
6) The scale turns off automatically after 30 seconds. You can also
switch the scale off anytime y keeping the on/off switch pressed.
7) If the scale goes off automatically, press on the ON/ZERO utton to
switch on again.
THE TARE FUNCTION
The tare function is extremely useful to calculate the weight of ingredients
that cannot e put directly on the platform. For
example flour, or liquids, which require a
container efore weighing, or for weighing
ingredients that are added after the first
weighing, without having to remove the initial
product.
In order to use this function, proceed with the first
weighing, let the weight sta ilize, and then press
the “On/Zero” utton a ove the LCD display.
The scale will reset, display a “T” at the lower left
corner, and indicate now 0g or 0:00.0 l :oz. Add
the new ingredient to weigh. The weight
indicated on the display is the weight of the
ingredient added after the reset to zero!
Note: When you remove the container from the platform, the LCD display
will show the weight as negative (“-” will appear on the left-hand side). To
reset, press “On/Zero” again.
Press
“On/Zero”


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International USA. The pages must e reproduced and folded
in order to o tain a ooklet A5 (+/- 148.5 mm width x 210 mm
height). When folding, make sure you keep the good
num ering when you turn the pages of the I/B. Don’t change
the page num ering. Keep the language integrity. Print only
what is inside the frame,
7 EKS 39724 - 120501
Assem ly page 7/28
Fax [phone]
VOLUME MODE
This measuring cup scale can convert the weight of the
most common ingredients automatically into volume
measurements (ml; Fl. Oz. or US cups).
For example, to measure milk in US cups, proceed as
follows:
• Place the scale on a flat surface, with a
container such as the stainless steel owl
supplied.
• Press On/Zero utton to turn on the scale.
• Wait until “0” is displayed.
• Set the weighing system to metric or imperial
using the UNIT utton (if needed).
• Press the MODE utton to select Water, Milk, Oil
or Flour – an indication arrow shall appear in in
front of the ingredient selected.
• Press the UNIT utton to display the volume in US
Cups.
• The display shows now the volume of the
ingredient selected, in US cups.
• Add the ingredient to measure.
• By pressing UNIT again, you can switch ack to
ml or Fl. Oz., depending on the weighing system
initially selected.
ERROR INDICATION
If the display shows sym ols randomly or if the scale doesn’t turn off
automatically, it means that your scale has a pro lem (wrong initialization
or weighing error). Remove any o ject from the scale and wait for it to turn
off. Make sure the steel owl is well in place (if used). Then start again.
If the pro lem goes on, remove the atteries for 10 seconds, and then put
them ack in place.
Press
“On/Zero”
Press
MODE
Press UNIT
Add Liquid


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International USA. The pages must e reproduced and folded
in order to o tain a ooklet A5 (+/- 148.5 mm width x 210 mm
height). When folding, make sure you keep the good
num ering when you turn the pages of the I/B. Don’t change
the page num ering. Keep the language integrity. Print only
what is inside the frame,
8 EKS 39724 - 120501
Assem ly page 8/28
Fax [phone]
WARNING INDICATORS
1. If the “Lo” sym ol is displayed on the LCD screen, it means that the
atteries of your scale are low and should e replaced soon. Please
dispose of the old atteries in an environmentally friendly way.
2. If the ”Err” sym ol appears on the LCD screen, it means
that the maximum weight accepted y your scale is
exceeded, please remove the o ject from the scale in
order not to damage your scale.
BATTERY
If your appliance does not work properly, it is pro a ly ecause the
atteries are dead. In that case, replace them with new ones of the same
type (see paragraph “Before the first use”).
Please dispose of the old atteries in an environmentally friendly way.
TIPS FOR USE AND MAINTENANCE
• Be careful when manipulating the scale ecause it is a precision
device.
• Clean the outside parts only with a lightly damp cloth.
• All plastics parts shall e cleaned immediately after contact with fat,
vinegar, spices or strongly flavored foods. Avoid contact with acid
juices
• Never use a rasive products to clean your scale.
• Remove the owl for cleaning. Ensure it is empty efore removing.
Clean the owl in warm soapy water.
• NEVER USE THIS APPLIANCE NEAR WATER; NEVER IMMERSE THE SCALE
ITSELF IN WATER OR ANY LIQUID WHATSOEVER.
• Keep the scale in a cool and dry place.
• Treat with care. Do not strike, shake or drop the scale
PROTECTION OF THE ENVIRONMENT
In order to preserve our environment and protect human health, the waste
of electrical and electronic equipment should e disposed of in
accordance with specific rules with the implication of oth suppliers and
users. For this reason, as indicated y the sym ol on the rating la el or on
the packaging, your appliance should not e disposed of as unsorted
municipal waste. The user should ring it to a municipal collection point
performing waste recovery y means of reuse, recycling or use for other
applications in accordance with the directive.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International USA. The pages must e reproduced and folded
in order to o tain a ooklet A5 (+/- 148.5 mm width x 210 mm
height). When folding, make sure you keep the good
num ering when you turn the pages of the I/B. Don’t change
the page num ering. Keep the language integrity. Print only
what is inside the frame,
9 EKS 39724 - 120501
Assem ly page 9/28
Fax [phone]
WARRANTY
We suggest that you complete and return the enclosed Product
Registration Card promptly to facilitate verification of the date of
original purchase. However, return of the Product Registration Card is
not a condition of these warranties. You can also fill out this warranty
card online, at the following address: www.KALORIK.com
This KALORIK product is warranted in the U.S.A. for 1 year from the
date of purchase against defects in material and workmanship. This
warranty is not transfera le. Keep the original sales receipt. Proof of
purchase is required to o tain warranty performance.
During this period, if the KALORIK product, upon inspection y
KALORIK, is proven defective, it will e repaired or replaced, at
Kalorik’s option, without charge to the customer. If a replacement
product is sent, it will carry the remaining warranty of the original
product.
This warranty does not apply to any defect arising from a uyer's or
user's misuse of the product, negligence, failure to follow KALORIK
instructions noted in the user’s manual, use on current or voltage
other than that stamped on the product, wear and tear, alteration
or repair not authorized y KALORIK, or use for commercial purposes.
There is no warranty for glass parts, glass containers, filter asket,
lades and agitators, and accessories in general. There is also no
warranty for parts lost y the user.
ANY WARRANTY OF MERCHANTABILITY OR FITNESS WITH RESPECT TO
THIS PRODUCT IS ALSO LIMITED TO THE ONE YEAR LIMITED WARRANTY
PERIOD.
Some states do not allow limitation on how long an implied warranty
lasts or do not allow the exclusion of incidental or consequential
damages, so the a ove limitations may not apply to you. This
warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International USA. The pages must e reproduced and folded
in order to o tain a ooklet A5 (+/- 148.5 mm width x 210 mm
height). When folding, make sure you keep the good
num ering when you turn the pages of the I/B. Don’t change
the page num ering. Keep the language integrity. Print only
what is inside the frame,
10 EKS 39724 - 120501
Assem ly page 10/28
Fax [phone]
If the appliance should ecome defective within the warranty
period and more than 30 days after date of purchase, do not return
the appliance to the store: often, our Customer Service
Representatives can help solve the pro lem without having the
product serviced. If servicing is needed, a Representative can
confirm whether the product is under warranty and direct you to the
nearest service location.
If this is the case, ring the product, or send it, postage prepaid y
the user (all Kalorik customers are responsi le for the initial shipment
ack to the warranty center), along with proof of purchase and a
return authorization number indicated on the outer package, given
y our Customer Service Representatives. Send to the authorized
KALORIK Service Center (please visit our we site at
www.KALORIK.com or call our Customer Service Department for the
address of our authorized KALORIK Service Center).
When sending the product, please include a letter explaining the
nature of the claimed defect.
If you have additional questions, please call our Customer Service
Department (please see elow for complete contact information),
Monday through Thursday from 9:00am - 5:00pm (EST) and Friday
from 9:00am - 4:00pm (EST). Please note hours are su ject to change.
If you would like to write, please send your letter to:
KALORIK Customer Service Department
Team International Group of America Inc.
1400 N.W 159th Street, Suite 102
Miami Gardens, FL 33169 USA
Or call:
Toll Free: +1 888-521-TEAM / +1 888-KALORIK
Only letters can be accepted at this address above. Shipments and
packages that do not have a return authorization number will be
refused.
