Kampmann Venkon XL Assembly instructions

Venkon XL
► Assembly, installation and operating instructions
Keep these instructions in a safe place for future use!
Issue11/20EN
SAP No.1374732

3
Table of contents
1 General ................................................................................................................................. 5
1.1 About these instructions ......................................................................................................................... 5
1.2 Explanation of Symbols........................................................................................................................... 5
2 Safety.................................................................................................................................... 6
2.1 Correct use.............................................................................................................................................. 6
2.2 Limits of operation and use .................................................................................................................... 7
2.3 Risk from electrocution!.......................................................................................................................... 8
2.4 Personnel requirements - Qualifications ................................................................................................. 9
2.5 Personal Protective Equipment ............................................................................................................... 9
3 Transport, storage and packaging........................................................................................ 10
3.1 General transport instructions ................................................................................................................ 10
3.2 Scope of delivery..................................................................................................................................... 10
3.3 Storage ................................................................................................................................................... 11
3.4 Packaging ............................................................................................................................................... 11
4 Technical data....................................................................................................................... 12
5 Construction and function .................................................................................................... 13
5.1 Overview................................................................................................................................................. 13
5.2 Brief description...................................................................................................................................... 13
5.3 Wear parts list......................................................................................................................................... 13
6 Installation and wiring.......................................................................................................... 14
6.1 Definition of the connection side ............................................................................................................ 14
6.2 Requirements governing the installation site.......................................................................................... 15
6.3 Minimum clearances............................................................................................................................... 15
6.4 Installation.............................................................................................................................................. 15
6.4.1 Installation of basic unit............................................................................................................................ 16
6.4.2 Installation of sheet steel accessories ....................................................................................................... 18
6.5 Installation.............................................................................................................................................. 21
6.5.1 Connection to the pipe network................................................................................................................ 22
6.5.2 Overview of valve kits ............................................................................................................................... 23
6.5.3 Connection of 2-way valve kit................................................................................................................... 24
6.5.4 Condensation connection.......................................................................................................................... 25
7 Electrical connection............................................................................................................. 32
7.1 Maximum electrical rating values ........................................................................................................... 32
7.2 Electromechanical control, Venkon XL.................................................................................................... 33

4
7.2.1 Connection (*00 or 00D), Venkon XL ........................................................................................................ 33
7.2.2 Cabling, Venkon XL (*00), control by Climate Controller 30155 ............................................................... 34
7.2.3 Cabling, Venkon XL (*00), control by Climate Controller 30155, with condensate pump......................... 35
7.2.4 Cabling, Venkon XL (*00), control by Climate Controller 30256 ............................................................... 36
7.2.5 Cabling, Venkon XL (*00), control by Climate Controller 30256, with condensate pump......................... 37
7.2.6 Cabling, Venkon XL (*00), control by Climate Controller type 148941/148942 ........................................ 38
7.2.7 Cabling, Venkon XL (*00), control by Climate Controller type 148941/148942, with condensate pump .. 39
7.2.8 Cabling, Venkon XL (* 00), control by DDC/BMS ...................................................................................... 40
7.3 KaControl (*C1) ...................................................................................................................................... 41
7.3.1 KaController installation............................................................................................................................ 41
7.3.2 Connection (*C1) ...................................................................................................................................... 42
7.3.3 Cabling, Venkon XL, KaControl (*C1), control by in situ 0-10 V DC signal................................................ 44
7.3.4 Cabling, Venkon XL, KaControl (*C1), control by KaController ................................................................. 45
8 Pre-commissioning checks.................................................................................................... 46
9 Operation.............................................................................................................................. 48
9.1 Operation of electromechanical control.................................................................................................. 48
9.2 Operation of the KaController................................................................................................................. 52
9.2.1 Function keys, display elements ................................................................................................................ 52
10 Maintenance ......................................................................................................................... 54
10.1 Securing against reconnection ................................................................................................................ 54
10.2 Maintenance Schedule:........................................................................................................................... 54
10.3 Maintenance work.................................................................................................................................. 55
10.3.1 Opening the inspection flap ...................................................................................................................... 55
10.3.2 Replacing the filter.................................................................................................................................... 56
10.3.3 Cleaning the condensate tray.................................................................................................................... 57
10.3.4 Clean the inside of the unit ....................................................................................................................... 59
11 Faults .................................................................................................................................... 60
11.1 Fault table............................................................................................................................................... 60
11.2 KaControl faults...................................................................................................................................... 61
11.3 Start-up after rectification of fault .......................................................................................................... 61
12 List of KaControl parameters................................................................................................ 62
12.1 Venkon XL parameter list........................................................................................................................ 62
12.2 KaController parameter list..................................................................................................................... 65
13 Certificates............................................................................................................................ 67
13.1 348_EU_Konformitätserklärung_Venkon_XL_INT.................................................................................. 68
13.2 ERP Datenblatt Venkon XL...................................................................................................................... 70

Venkon XL
Assembly, installation and operating instructions
5
1 General
1.1 About these instructions
These instructions ensure the safe and efficient handling of this equipment. These instructions form an integral part of the
equipment and have to be kept in the direct vicinity of the equipment and available to personnel at all times.
All personnel must have carefully read through these instructions prior to commencing all work on the equipment. A funda-
mental prerequisite for safe working is compliance with all the stated safety instructions and other instructions contained in
this manual.
In addition all local occupational health and safety at work regulations apply, as do general safety provisions governing the
use of the equipment.
Illustrations in this guide are intended to provide a basic understanding and may differ from the actual model.
Ongoing tests and further developments may result in small variations between the unit supplied and the instructions.
1.2 Explanation of Symbols
DANGER!
This combination of symbol and signal word indicates an immediately dangerous situation caused by elec-
trical power, which will cause death or serious injury if not avoided.
WARNING!
This combination of symbol and signal word indicates a possible hazardous situation.
IMPORTANT NOTE!
It represents a potentially hazardous situation, which could lead to damage to property or for a measure to
optimise workflows.
IMPORTANT NOTE!
This symbol highlights useful hints, recommendations and information for efficient and trouble-free opera-
tion.

Venkon XL
Assembly, installation and operating instructions
6
2 Safety
This section provides an overview of all important safety aspects to ensure optimum protection of personnel as well as safe
and trouble-free operation. In addition to the safety instructions in these operating instructions, the valid safety, accident pre-
vention and environmental protection regulations must be observed for the area of use of the unit. It is the duty of the oper-
ator to ensure that instructions relating to maintenance (e.g. relating to hygiene) are complied with.
2.1 Correct use
The units are only intended to be used for heating and cooling air in frost-free and dry rooms. Within the room, the unit
needs to be connected to the building's heating/cooling/ventilation system and to the building's waste water and power net-
work. The operating limits and limits of use described in Chapter 2.2 [}7] must be observed.
IMPORTANT NOTE!
Only use the unique after completion of the complete building and system. Site heating is not deemed to be
correct and proper use.
Intended use of the unit also includes adherence to these instructions.
Information in accordance with EN60335-1
This unit can be used by children aged 8 years or more and also by people with reduced physical, sensory or mental cap-
abilities or a lack of experience and knowledge, if they are supervised or have been instructed in the safe use of the unit
and the resulting dangers. Do not allow children to play with the unit. Do not allow children to clean and maintain the
unit without supervision.
This unit is not intended for permanent connection to the drinking water supply system.
This unit is intended for being accessible to the general public.
Any use beyond or other than the stated intended use is considered as misuse.
Any change to the unit or use of non-original spare parts will cause the expiry of the warranty and the manufacturer’s liabil-
ity.

Venkon XL
Assembly, installation and operating instructions
7
2.2 Limits of operation and use
Limits of operation
Min./max. water temperature °C 4-90
Min./max. air intake temperature °C 6-40
Min./max. air humidity % 20-60
Min. operating pressure bar/kPa -
Max. operating pressure bar/kPa 10/1000
Min./max. glycol percentage % 0-50
Tab.1: Limits of operation
Operating voltage 230 V/ 50/60 Hz
Power/Current consumption On the type plate
Tab.2: Operating voltage
We would refer to VDI-2035 Sheets 1 & 2, DIN EN 14336 and DIN EN 14868 with regard to the properties of the medium
used to protect the equipment. The following values provide further guidance.
The water used should be free of contamination, such as suspended substances and reactive substances.
Water quality
pH value (at 20 °C) 8-9
Conductivity (at 20 °C) μS/cm < 700
Oxygen content (O2) mg/l < 0.1
Hardness °dH 4-8.5
Sulphur ions not measurable
Sodium ions (Na+) mg/l < 100
Iron ions (Fe2+) mg/l < 0.1
Manganese ions (Mn2+) mg/l <0.05
Ammonia ions (NH4+) mg/l < 0.1
Chlorine ions (CI) mg/l < 100
CO2< 50
Sulfate ions (SO4
2-) mg/l < 50
Nitrite ions (NO2+) mg/l < 50
Nitrate ions (NO3+) mg/l < 50
Tab.3: Water quality

Venkon XL
Assembly, installation and operating instructions
8
IMPORTANT NOTE!
Danger of frost in cooling mode!
There is a risk of the heat exchanger freezing when used in unheated rooms.
Make sure that the unit is equipped with a frost protection sensor and/or thermostat in this case.
IMPORTANT NOTE!
Warning of misuse!
In the event of misuse, as itemised below, there is a danger of limited or failing operation of the unit. En-
sure that the airflow can circulate freely.
Never operate the unit in humid areas, such as swimming pools, wet areas etc.
Never operate the unit in rooms with an explosive atmosphere.
Never operate the unit in aggressive or corrosive atmospheres (e.g. sea air).
Never operate the unit above electrical equipment (such as switch cabinets, computers or other electrical
units, or contacts that are not drip-proof).
IMPORTANT NOTE!
Energy losses due to misuse!
Operating the unit with open windows (or other room openings) can result in significant energy losses.
Heating and cooling modes (particularly when operating different units) need to be coordinated with
each other.
2.3 Risk from electrocution!
DANGER!
Risk of fatal injury from electrocution!
Contact with live parts will lead to fatal injury from electrocution. Damage to the insulation or individual
components can lead to a fatal injury.
Only permit qualified electricians to work on the electrical system.
Immediately disconnect the system from the power supply and repair it in the event of damage to the in-
sulation.
Keep live parts away from moisture. This can cause a short circuit.
Properly earth the unit.
DANGER!
Risk of fatal injury from electrocution!
Where multiple EC fans are connected in parallel, an electrical charge (>50 C) is present between line
conductor and protective earth conductor when the power is switched off. Before working on the elec-
trical connection, short-circuit the network connections and PE!
The terminals and connectors are still energised even when the unit is switched off. Use a two-pole
voltage tester to establish that the unit has been de-energised. Only open the unit 5 minutes after all
poles of the voltage have been switched off.
The protective earth carries high leakage currents (depending on the frequency, intermediate voltage and
motor capacity). Therefore, check EN-compliant earthing under test conditions (EN 50178, art. 5.2.11).
Without earthing, hazardous voltages can occur on the motor housing. In case of a fault, electrical
voltage will be present on the rotor and impeller. Rotor and impeller are base-insulated. Do not touch!

Venkon XL
Assembly, installation and operating instructions
9
2.4 Personnel requirements - Qualifications
Specialist knowledge
The installation of this product requires specialist knowledge of heating, cooling, ventilation, installation and electrical engin-
eering. This knowledge, generally learned in vocational training in one of the fields mentioned above, is not described separ-
ately.
Damage caused by improper installation is the responsibility of the operator or installer. The installer of these units should
have adequate knowledge of the following gained from specialist vocational training
safety and accident prevention regulations
Guidelines and recognised technical regulations, i.e. Association of German Electricians (VDE) regulations, DIN and EN
standards.
VDI 6022; maintenance personnel must be trained to Category B (possibly Category C) to comply with hygiene require-
ments (as required).
The installation, operation and maintenance of this unit must comply with the applicable laws, standards, provisions and reg-
ulations in the respective country and the current state of the art!
2.5 Personal Protective Equipment
Personal protective equipment is used to protect people from impaired safety and health when working with the unit. The ap-
plicable accident prevention regulations at the place of use apply in all cases.
Personnel have to wear personal protective equipment during maintenance and troubleshooting on and with the unit.

Venkon XL
Assembly, installation and operating instructions
10
3 Transport, storage and packaging
3.1 General transport instructions
Check on delivery for completeness and transport damage.
Proceed as follows in the event of visible damage:
Do not accept delivery or only accept with reservations.
Record any transport damage on the transportation documents or on the transport company's delivery note.
Submit a complaint to the freight forwarder.
IMPORTANT NOTE!
Warranty claims can only be made within the applicable period for complaints. (More information is avail-
able in the T&Cs on the Kampmann website)
IMPORTANT NOTE!
2 people are needed to transport the unit. Wear personal protective clothing when transporting the unit.
Only lift the unit on both sides and not by the pipes / valves.
IMPORTANT NOTE!
Material damage caused by incorrect transport!
Units being transported can drop or topple over if transported wrongly. This can cause serious material
damage.
Proceed carefully when unloading the equipment on delivery and when transporting it on site and note
the symbols and instructions on the packaging.
Only use the holding points provided.
Only remove packaging shortly before assembling the unit.
3.2 Scope of delivery
IMPORTANT NOTE!
Check the scope of delivery!
Check the delivery for damage.
Check that the articles and type numbers are correct.
Is the delivery and number of items delivered correct?

Venkon XL
Assembly, installation and operating instructions
11
3.3 Storage
Store packaging under the following conditions:
Do not store outdoors.
Store in a dry and dust-free place.
Store in a frost-free place.
Do not expose to aggressive media.
Protect from direct sunlight.
Avoid mechanical vibrations and shocks.
IMPORTANT NOTE!
Under certain circumstances, packages can carry storage instructions that exceed the requirements listed
here. Comply with these instructions accordingly.
3.4 Packaging
Handling packaging materials
IMPORTANT NOTE!
Dispose of packaging materials in line with the applicable statutory requirements and local regulations.
IMPORTANT NOTE!
The packaging is also use to protect the product from site dust and dirt. Only remove packaging shortly be-
fore assembling the unit.

Venkon XL
Assembly, installation and operating instructions
12
4 Technical data
Unit Venkon XL
Model 1 2 3 4
Width of basic unit [mm] 500 900 1300 1700
Width of basic unit includ-
ing condensate tray over-
hang [mm]
694 1094 1494 1894
Weight of basic unit [kg] 33 51 71 88
Weight of basic unit with
connection unit for circular
pipe [kg]
40 64 86 104
Air volume [m³/h] 3110 - 680 395 - 1465 405 - 2200 845 - 2975
Internal volume of 2-pipe
system [l] 1,4 2,8 4,2 5,7
Internal volume of 4-pipe
system heating [l] 0,2 0,4 0,6 0,9
Internal volume of 4-pipe
system cooling [l] 1,4 2,8 4,2 5,7
Connection size 2-pipe Rp 3/4" Rp 3/4" Rp 3/4" Rp 3/4"
Connection size 4-pipe
heating Rp 1/2" Rp 1/2" Rp 1/2" Rp 1/2"
Connection size 4-pipe
cooling Rp 3/4" Rp 3/4" Rp 3/4" Rp 3/4"
Heat output [kW] 11,5 - 10,6 4,0 - 22,8 4,5 - 34,4 8,4 - 46,9
Flow rate, heating [kg/h] 1125 - 580 474 - 1359 471 - 1916 718 - 4033
Cooling output [kW] 20,7 - 3,4 2,8 - 7,9 2,7 - 11,2 5,6 - 16,9
Flow rate, cooling [kg/h] 2125 - 580 474 - 1359 471 - 1916 969 - 2899
Sound power level, suction-
side [dB(A)] 43 - 62 46 - 65 48 - 67 49 - 68
Sound power level, pres-
sure-side [dB(A)] 39 - 63 44 - 67 45 - 68 47 - 70
3at 30 Pa external pressure, ISO Coarse filter, continuously variable control
1at LPHW 75 / 65°C, tL1 = 20°C
2at CHW 7/12°C, tL1 = 27 °C, 48% relative humidity

Venkon XL
Assembly, installation and operating instructions
13
5 Construction and function
5.1 Overview
12 3 467
589
Fig.1: Venkon XL at a glance (connection shown on left)
1Service hatch 6Filter
2EC radial fan 7Electrical connection
3Condensation tray 8Connection unit for circular pipe
4Heat exchanger 9Suspension and connecting bracket
5Water connections
5.2 Brief description
Venkon XL are decentralised units for the heating, cooling and filtering of air, for use in hotels, offices and business premises,
among others. Secondary air is drawn in filtered by the fan and passed through the copper/aluminium heat exchanger. Here
the air is either heated or cooling depending on the temperature of the water in the heat exchanger. The heated or cooled air
is discharged into the room through the optional connection unit for circular pipes.
5.3 Wear parts list
Figure Article Properties Suitable for Art. no.
ISO Coarse spare filter
1 set = 1 mat Model 1 348016000000
BG 2 348026000000
1 set = 2 mats
Model 3 348036000000
BG 4 348046000000
ISO spare filter
ePM10>50% (M5)
1 set = 1 mat Model 1 348016005000
BG 2 348026005000
1 set = 2 mats
Model 3 348036005000
BG 4 348046005000

Venkon XL
Assembly, installation and operating instructions
14
6 Installation and wiring
6.1 Definition of the connection side
Venkon XL, connection on left
Venkon XL, connection on right
Venkon XL, with flexible connection unit, connection on left
Venkon XL, with flexible connection unit, connection on right
Side view, connection side Side view, connection side
Side view, connection side Side view, connection side
Connection on left
Connection on right
View of air inlet side
View of air inlet side
Connections
1 Cooling flow 3/4"
2 Cooling return 3/4"
5 Condensate drain Ø15 mm
6 Vent
Air direction/
air inlet
Fig.2: Definition of left/right connection

Venkon XL
Assembly, installation and operating instructions
15
6.2 Requirements governing the installation site
Only install and assemble the unit if the following conditions are met:
Make sure that the wall/ceiling is sufficiently load-bearing to take the weight of the unit (Technical data [}12]).
Make sure that the ceiling is sufficiently load-bearing to take the weight of the unit (Technical data [}12]).
Make sure that the unit is securely suspended/standing.
Ensure that the airflow can circulate freely.
Provide adequate space for appropriately sized flow and return water connections on site (Connection to the pipe
network [}22]).
There is a power supply on site (Maximum electrical rating values [}32]).
If need be, provide a condensation connection with a sufficient gradient on site.
6.3 Minimum clearances
Fig.3: Minimum clearances (top view, connection on left)
With suspended ceiling units, provide the following service hatches for installation, maintenance and inspection beside the
unit (see hatched area) and below the unit:
Model Unit width A [mm]
1 500
2 900
3 1300
4 1700
Tab.4: Minimum clearances

Venkon XL
Assembly, installation and operating instructions
16
6.4 Installation
2 people are needed to install the unit.
CAUTION!
Risk of injury from sharp metal housing!
The inner metal of the casing can have sharp edges.
Wear suitable protective gloves.
IMPORTANT NOTE!
Horizontal installation of units!
When installing the units, ensure that they are completely horizontal to ensure proper operation.
IMPORTANT NOTE!
Avoid draughts!
Consider the occupied zone when installing/suspending the units. Do not expose people to the direct air
flow. Position the unit accordingly and adjust the air outlet if required.
6.4.1 Installation of basic unit
Each Venkon XL unit is fixed to the ceiling or an on-site structure at 4 points. The units are suspended on mounting brackets,
for instance on threaded rods (M8).
Fig.4: Suspension points (top view, connection on left)
Model Distance A (suspension)
1 530
2 930
3 1330
4 1730
Tab.5: Spacing of suspension points

Venkon XL
Assembly, installation and operating instructions
17
Fig.5: Suspending the unit
Suspend the unit using the suspension and connecting brack-
ets to on-site suspensions (recommended: M8 threaded rod
with washer and nut).
Fig.6: Adjusting the suspension
Level the unit and, if need be, adjust it by adjusting the nuts.
Fig.7: Checking alignment
Use an appropriate tool to check the alignment of the unit.

Venkon XL
Assembly, installation and operating instructions
18
6.4.2 Installation of sheet steel accessories
Overview of air-side sheet steel accessories
1
2
Fig.8: Basic unit with connection unit for circular pipe
1Basic unit 2Connection unit for circular pipe
Figure Description Dimensions [mm]
500 / 900 /1300 / 1700
275
275
Connecting unit for circular pipe with spigot DN 200
Model 1: 500
Model 2: 900
Model 3: 1300
Model 4: 1700
Tab.6: Air-side sheet steel accessories
Venkon XL are available in the following models ex works:
Basic unit
Basic unit with connection unit for circular pipe fitted
Proceed as follows should it be necessary to retrofit a connection unit for circular pipe to a basic unit on site (assembly re-
quires 2 people):

Venkon XL
Assembly, installation and operating instructions
19
Fig.9: Screwing on the connecting bracket
Use 4.8x13.0 metal screws to fix the connecting brackets (2
no. with model 2, 4 no. with model 3 and model 4) to the top
and bottom of the air outlet side.
Fig.10: Positioning the connecting unit
Position the connecting unit in front of the air outlet and
hand-tighten the M6x10 self-locking screws at the 4 corners.
Fig.11: Tightening the screws externally
Use an appropriate tool to tighten the screws on the suspen-
sion and connecting brackets.

Venkon XL
Assembly, installation and operating instructions
20
Fig.12: Turning the screws internally
Hand-tighten the M6x10 self-locking screws on the inner con-
necting brackets (accessible through one of the spigots).
Fig.13: Tightening the screws internally
Use an appropriate tool to tighten the screws on the internal
connecting brackets.
Frame connection dimensions
The air inlet side of Venkon XL units can be connected to a ductwork system (by others).
Front view (air inlet grille)
Fig.14: Frame connection dimensions
Model A [mm] B [mm]
1 500 482
2 900 441
3 1300 416 – 450 - 416
4 1700 561
