1 General
1.1 About these instructions
These instructions ensure the safe and efficient handling of this equipment. These instructions form an integral part of the
equipment and have to be kept in the direct vicinity of the equipment and available to personnel at all times.
All personnel must have carefully read through these instructions prior to commencing all work on the equipment. A funda-
mental prerequisite for safe working is compliance with all the stated safety instructions and other instructions contained in
this manual.
In addition all local occupational health and safety at work regulations apply, as do general safety provisions governing the
use of the equipment.
Illustrations in this guide are intended to provide a basic understanding and may differ from the actual model.
Ongoing tests and further developments may result in small variations between the unit supplied and the instructions.
1.2 Explanation of Symbols
WARNING!
This combination of symbol and signal word indicates a possible hazardous situation.
IMPORTANT NOTE!
It represents a potentially hazardous situation, which could lead to damage to property or for a measure to
optimise workflows.
IMPORTANT NOTE!
This symbol highlights useful hints, recommendations and information for efficient and trouble-free opera-
tion.

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
6
2 Safety
This section provides an overview of all important safety aspects to ensure optimum protection of personnel as well as safe
and trouble-free operation. In addition to the safety instructions in these operating instructions, the valid safety, accident pre-
vention and environmental protection regulations must be observed for the area of use of the unit. It is the duty of the oper-
ator to ensure that instructions relating to maintenance (e.g. relating to hygiene) are complied with.
2.1 Correct use
Intended use of the unit also includes adherence to these instructions.
Information in accordance with EN60335-1
This unit can be used by children aged 8 years or more and also by people with reduced physical, sensory or mental cap-
abilities or a lack of experience and knowledge, if they are supervised or have been instructed in the safe use of the unit
and the resulting dangers. Do not allow children to play with the unit. Do not allow children to clean and maintain the
unit without supervision.
This unit is not intended for permanent connection to the drinking water supply system.
This unit is intended for being accessible to the general public.
Any use beyond or other than the stated intended use is considered as misuse.
Any change to the unit or use of non-original spare parts will cause the expiry of the warranty and the manufacturer’s liabil-
ity.

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
7
2.2 Limits of operation and use
Limits of operation
Min./max. water temperature °C 15-90
Min./max. air intake temperature °C 15-40
Min./max. air humidity % 15-75
Min. operating pressure bar/kPa -
Max. operating pressure bar/kPa 10/1000
Min./max. glycol percentage % 25-50
Tab.1: Limits of operation
Operating voltage 230 V/ 50/60 Hz
Power/Current consumption On the type plate
Tab.2: Operating voltage
We would refer to VDI-2035 Sheets 1 & 2, DIN EN 14336 and DIN EN 14868 with regard to the properties of the medium
used to protect the equipment. The following values provide further guidance.
The water used should be free of contamination, such as suspended substances and reactive substances.
Water quality
pH value (at 20 °C) 8-9
Conductivity (at 20 °C) μS/cm < 700
Oxygen content (O2) mg/l < 0.1
Hardness °dH 4-8.5
Sulphur ions not measurable
Sodium ions (Na+) mg/l < 100
Iron ions (Fe2+) mg/l < 0.1
Manganese ions (Mn2+) mg/l <0.05
Ammonia ions (NH4+) mg/l < 0.1
Chlorine ions (CI) mg/l < 100
CO2< 50
Sulfate ions (SO4
2-) mg/l < 50
Nitrite ions (NO2+) mg/l < 50
Nitrate ions (NO3+) mg/l < 50
Tab.3: Water quality

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
8
IMPORTANT NOTE!
Warning of misuse!
In the event of misuse, as itemised below, there is a danger of limited or failing operation of the unit. En-
sure that the airflow can circulate freely.
Never operate the unit in humid areas, such as swimming pools, wet areas etc.
Never operate the unit in rooms with an explosive atmosphere.
Never operate the unit in aggressive or corrosive atmospheres (e.g. sea air).
Never operate the unit above electrical equipment (such as switch cabinets, computers or other electrical
units, or contacts that are not drip-proof).
2.3 Risk from electrocution!
DANGER!
Risk of fatal injury from electrocution!
Contact with live parts will lead to fatal injury from electrocution. Damage to the insulation or individual
components can lead to a fatal injury.
Only permit qualified electricians to work on the electrical system.
Immediately disconnect the system from the power supply and repair it in the event of damage to the in-
sulation.
Keep live parts away from moisture. This can cause a short circuit.
Properly earth the unit.

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
9
2.4 Personnel requirements - Qualifications
Specialist knowledge
The installation of this product requires specialist knowledge of heating, cooling, ventilation, installation and electrical engin-
eering. This knowledge, generally learned in vocational training in one of the fields mentioned above, is not described separ-
ately.
Damage caused by improper installation is the responsibility of the operator or installer. The installer of these units should
have adequate knowledge of the following gained from specialist vocational training
safety and accident prevention regulations
Guidelines and recognised technical regulations, i.e. Association of German Electricians (VDE) regulations, DIN and EN
standards.
The installation, operation and maintenance of this unit must comply with the applicable laws, standards, provisions and reg-
ulations in the respective country and the current state of the art!
2.5 Personal Protective Equipment
Personal protective equipment is used to protect people from impaired safety and health when working with the unit. The ap-
plicable accident prevention regulations at the place of use apply in all cases.
Personnel have to wear personal protective equipment during maintenance and troubleshooting on and with the unit.

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
10
3 Transport, storage and packaging
3.1 General transport instructions
Check on delivery for completeness and transport damage.
Proceed as follows in the event of visible damage:
Do not accept delivery or only accept with reservations.
Record any transport damage on the transportation documents or on the transport company's delivery note.
Submit a complaint to the freight forwarder.
IMPORTANT NOTE!
Warranty claims can only be made within the applicable period for complaints. (More information is avail-
able in the T&Cs on the Kampmann website)
3.2 Scope of delivery
IMPORTANT NOTE!
Check the scope of delivery!
Check the delivery for damage.
Check that the articles and type numbers are correct.
Is the delivery and number of items delivered correct?

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
11
3.3 Storage
Store packaging under the following conditions:
Do not store outdoors.
Store in a dry and dust-free place.
Store in a frost-free place.
Do not expose to aggressive media.
Protect from direct sunlight.
Avoid mechanical vibrations and shocks.
IMPORTANT NOTE!
Under certain circumstances, packages can carry storage instructions that exceed the requirements listed
here. Comply with these instructions accordingly.
3.4 Packaging
Handling packaging materials
IMPORTANT NOTE!
Dispose of packaging materials in line with the applicable statutory requirements and local regulations.

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
12
4 Technical data
Unit PowerKon nano
Length [mm] 950 1150 1400 1800 2150
Height [mm] 160 160 160 160 160
Depth [mm] 160 160 160 160 160
Weight [kg] 8,4 9,8 11,5 14,2 16,6
Air volume [m³/h] 25-75 40-120 50-155 75-230 95-290
Heat output [W] 1321-851 497-1317 646-1713 971-2574 1221-3237
Sound power level
[dB(A)] <28-42 <28-44 <28-45 <28-47 <28-48
1at LPHW 75 / 65°C, tL1 = 20°C

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
13
5 Construction and function
5.1 Overview
5.2 Brief description
PowerKon nano are free-standing decentralised units for room air heating, for use in hotels, offices and business premises,
among others. Secondary air is drawn in by the filter and passed through the copper/aluminium heat exchanger. The air is
warmed depending on the water temperature and fed back into the room.

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
14
6 Installation and wiring
6.1 Requirements governing the installation site
Only install and assemble the unit if the following conditions are met:
Make sure that the unit is securely suspended/standing.
Ensure that the airflow can circulate freely.
Provide adequate space for appropriately sized flow and return water connections on site (Connection to the pipe
network [}21]).
There is a power supply on site (Maximum electrical rating values [}22]).
6.2 Installation
2 people are needed to install the unit.

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
15
CAUTION!
Risk of injury from sharp metal housing!
The inner metal of the casing can have sharp edges.
Wear suitable protective gloves.
6.3 Installing the unit

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
16

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
17

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
18

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
19

PowerKon nano
PowerKon nano
Assembly, installation and operating instructions
20
