KAPUCI BGX-D1-25MAZ User manual

Product Manual
Applicable Model:BGX-D1-25MAZ

Packing Accessories
After open the package, please first check whether the accessories
are consistent with the following table.If you have any questions,
please contact:[e-mail]
Safe Box 1
Emergency Keys 2
Key Box 1
Expension Screw 2
Product Manual 1
External Batter y Pack 1
Tips
1.Please keep the emergency key in a safe place.Don‘t put the emergency key or
external battery pack in the safe box.
2.Please follow the instructions in the product manual strictly
Product Parameters
Product
Size
G.W/N.T
250mm x 350mm x 250mm(HxWxD)
KAPUCI SAFE BOX
11/10KG Model BGX-D1-25MAZ
Display LCD
Material thickness Door:5mm
Open Method Password+Keys
Internal Internal Light+Shelf

CONTENTS
Product Description
Panel Introduction
First Way to Open-External Battery Pack
Add Password
Second Way to Open-Emerency Keys
Normally Open
Close The Door
Undervolta
Hidden Code Setting
Three Times Wrong Code Lock
System Initialization
Remove The Alarm
Delect Function 6
6
6
6
5
5
5
5
4
3
2
1
1
Installation Notes 7

Product Description
Box
Control Panel
Feet
Door
Panel Introduction
Fingerprint Collection Area
Password Keypad
Emergency Keyhole Cover
Emergency Keyhole
External Battery Pack Hole
Tips:
In order to prevent the emergency Keyhole Cover from being lost during transportion
we put the cover in the key box.
1

【First Way to Open-External Battery Pack】
In the factory state,you can use factory password “168” .After enter the correct
password,you must end with “#”to let the System know that your password has
been entered. The management password is “88888888”
Step 1:
Insert 4-AA batteries into the external battery
pack in the correct direction(Because of
transportation,the battery is not included
in the accessorise)
Step 2:
Press the left or right end of the emergency keyhole
cover to expose the emergency keyhold.
(If the emergency keyhold cover is in the key box,this
step can be omitted )
Step 3:
Plug the battery plug into the external battery
pack hole.And press the“#”to wake up screen,
when the display shows the cursor states,enter
168 and press the “#”key to confirm.The display
shows “OPEN” and the door can be opend
automatically.
Step 3: Step 4:
Unplug the battery pack,replace the battery into the
battery compartment above the back cover of the
box door.
When the battery is dead,or external battery pack cannot be found,or the password is forgotten,or
the fingerprint is not recognized,etc.You can use the emergency key to open the safe.
Once again,the emergency key and the external battery pack are very important,do not put them
int the safe box .
2

Add Password
Modify users password(168):
Modify management password(88888888)
3
We provide two sets of initial factory password,one is user password(168) and
one is management password(88888888).Since the password Set button is inside
you must do it with the door open.
【Set button i s un der the black protective co ver,remove the protecti ve
cover,you can see the set button in side,when you finish the setting,restore
the protective cover to its original position,which can protect the set
button from being operated by mistake】
1.When the door is open and the display light is
off(Standby State),short press(About1 Second)
the set button on the inside of the back of the door.
2.The cursor is flashing.Enter3-8 digits new passwords.End with “#”key after entering the password.
(Pressing the # key means to tell the system that your password has been entered)
3.If the input is successful,the dispaly shows”IN” and a beep sounds.
eg:If you set the new password is “123456”,it means that you replaced the user password with 123456,
you can use 123456 to open the door,168 can not open the door.
1.When the door is open and the display light is off(Standby State).First press the “#”key to wake up
the display,then enter”00”,and press the set button on the inside of the back of the door.
2.The cursor is flashing.Enter3-8 digits new passwords.End with “#”key after entering the password.
(Pressing the # key means to tell the system that your password has been entered)
3.If the input is successful,the dispaly shows”IN” and a beep sounds.

Second Way to Open-Emerency Keys Open
When the electronic system is abnormal or the password is forgotten or the battery is dead.
You can use the emergency to open the safe, ensure that belongs can be taken out
Setp 1:
Press the left or right end of the emergency
keyhold cover and expose the emergency
keyhold.(If the emergency keyhold cover is
in the key box,this stepcan be omitted )
Step 2:
Insert the emergency key in the correct direction
(The key’s notch direction is to the left or right
but not up and down),then turn it clockwise to
the limit to open the safes.
Step 3: Step 4:
4
After the emergency is restored to its original
position,pull it out,and put 4-AAbattery into the
battery box above the back cover of the door.
When installing the battery,pay attention to the
positive and negative sides.
At this point,you can notice that the door bolt
is in an extended state.When the door bolt is
extended,you cannot close the door,which will
damage the paint.
After installing the battery,restore the emergency
lock cover,the emergency lock cover may be in the
key box.
Next,you can refer to:
Normal Open
Add Password
Close The Door
Prompt
If the emergency key is not pulled out ,the door of the box can not be locked,
otherwise it will cause the code lock failure.
This emergency lock can only be used when the electronic system is abnormal
when it is opened for the first time
Long-term use of the emergency key will affect the service life of the electronic system
Please do not put emergency keys in the safe box

5
【Normally Open】
【Close The Door】
Just close the box door ,while pressing the door with one hand,press the “#”key with the other hand.
The door can be automatically locked.
【Hidden Code Setting】
After waking up the system,press the”*”button again when no password is entered,the hidden code
setting is released,the display interface returns to the normal state,and the entered number is display
when the password is entered.
Enter the set password(Factory Password:168)in the keypad area,press”#” to confirm,the password is
correct,the screen display”OPEN”,and the buzzer”Di-Di”sounds,and the door automatically pops open.
At this time,if an incorrect password is entered,the unlocking fails,and the buzzer sounds three times
“Di-DI-Di”, and the dispaly shows”Error”
【Undervolta】
When the battery is running low,each time the system wakes up,the display will show “LOW-BAR”,
reminding you to replace the battery as soon as possible
1.If you want to restore,press the “*”button again when no password is entered,the hidden code
setting is released;The display interface returns to the normal state,and the entered number is
displayed when the password is entered.
2.The hidden code setting automatically released after each password is entered.

【Three Times Wrong Code Lock】
1.When the wrong password is entered ,the buzzer continuously alarms and the screen display “Error”
【System Initialization(Restore Factory Settings)】
Make sure the door is open ,then press the set button(about 10 seconds) until the screen light up
and the display shows”DEL ALL”,system initialization is successful.
【Remove The Alarm】
The three wrong password alarm can only be released after removing the battery.The alarm can
be cleared by entering the correct password in the alarm state,or the alarm will be automatically
released after 20 seconds.
Before the password is entered incorrectly and is not confirmed,press the “*”button to delete
the entered incorrect password one by one.
6
2.If you enter the wrong password 3 times in succession the system will automatically lock for 3 minutes,
and the alarm will start to count down 180 seconds after 20 seconds .During this process ,pressing any
key will have no effect.
【Delect Function】

Installation Notes
Choose a suitable place to place the box,remove the sticker on the back of the
box ,open the door,and mark the punching positions according to the installation
holes.
Remove the safe and drill holes with a percussion drill(Drill diameter 13.5mm)
Then align the mounting holes in the safe with the punched holes,insert and tighten
the mounting screws,and fix the box to the solid wall.
7
