Kasco RGB4C5 Manual

RGB4C5
WaterGlow Composite Lighting – Universal
Operation & Maintenance Manual
Document number 884103

RGB4C5 UNIVERSAL LIGHTING MANUAL
884103 / 2021.1.1
2
Contents
Caution ���������������������������������������������������������������������������������������2
Parts Included�����������������������������������������������������������������������������3
Universal Mounting Instructions ������������������������������������������������� 4
RGB Control Panel Installation & Operation�������������������������������6
Control Input Features����������������������������������������������������������������7
Remote Control Features �����������������������������������������������������������7
Maintenance Recommendations������������������������������������������������8
Warranty �������������������������������������������������������������������������������������8
Repair�����������������������������������������������������������������������������������������9
Non-Warranty Repairs����������������������������������������������������������������9
Repair Contact Form �����������������������������������������������������������������11
CAUTIONCAUTION
Please read and follow these important instructions to help ensure your safety and the quality performance of your Kasco equipment�
• RGBC5 kit is 120Vac and MUST be plugged into a GFCI protected receptacle or GFCI protected eld terminal connections.
• RGBC5 xtures MUST be properly submerged (approximately halfway) to avoid overheating; insufcient submersion or opera-
tion out of water will damage xtures and void warranty.
• Use caution when dealing with any electrical and/or moving equipment�
• Under NO CIRCUMSTANCES should anyone enter the water with the electrical equipment plugged in and/or in operation.
• Kasco WaterGlow lighting kits are intended for use with a Listed control panel having a GFCI protected receptacle, or eld wiring
terminals and disconnect switch, or a timer with a disconnect for use with a GFCI receptacle� They are intended to be mounted on
a oating fountain or aerator for use in a natural or man-made body of water to comply with NEC Article 682.
• Kasco WaterGlow lighting kits have not been evaluated for use in swimming pools, spas or stationary fountains�
• Use extreme caution around water, especially cold water, as in spring, fall, and winter, which poses a hazard in and of itself.
• NEVER lift or drag the equipment by the power cords. If you need to pull the unit to the side of the pond, use the anchoring ropes.
• Do not use boats that tip easily for lighting kit installation and follow all boating safety rules and regulations, including wearing a
PFD (Personal Flotation Device). Do not use waders in deep ponds/lakes or ponds/lakes with drop-offs, drastic slopes, or soft
bottom material�
• For more information regarding your control panel instructions, refer to your equipment owner’s manual. A control panel must be
installed a minimum of 5 feet (3m in Canada) from the body of water unless separated from the body of water by a fence, wall, or
other permanent barrier that will make the unit inaccessible to persons in the water. A complete list of control panels can be found
in the Accessories section of kascomarine�com�
• Warning: When using the universal mounting bracket assembly, ensure the WaterGlow xtures are mounted properly to provide
cooling of the xture. Typically, the bottom half of the xture should be submerged. Recheck the xture elevation with the fountain/
aerator in operation. Assembly to your fountain/aerator oat will be as illustrated on the next page. Make adjustment to the xture
elevation to ensure the xture is properly submerged when the fountain/aerator is in operation.
• Many fountain/aerator oats will drop lower in the water when running.

RGB4C5 UNIVERSAL LIGHTING MANUAL
884103 / 2021.1.1
3
PARTS INCLUDED
ID Description Qty Part Number
A RGBC5 Fixture 4347000
B Cord connector O-ring 4 345035
C10-32 thumb nut 8 345043
D #10 split lock washer 8 771037
EBracket O-ring 8 345008
F Composite light bracket 4 345007
G10-32 x 1/2” hex screw 8 345042
H1/4”-20 x 1-3/8” hex screw 4584692
I1/4”, 5/8 O.D. at washer 4258476
J1/4”-20 split lock washer 12 840537
K1/4”-20 nut 8 840536
LCable tie (not shown) 8 415038
MRGB Control panel (not shown) 1130030
Universal Mounting Hardware
N Universal mounting bracket 4 345060
O1/4”-20 x 3/4” hex screw 4840539
P1/4” fender washer 4 144114
Q1/4”-20 x 2-1/2” hex screw 4345048
Fig. 1
Universal Mounting Hardware
Back to Contents

RGB4C5 UNIVERSAL LIGHTING MANUAL
884103 / 2021.1.1
4
UNIVERSAL MOUNTING INSTRUCTIONS
1� Attach the bracket (F) to the light xture (A) by tting the head
of the 10-32 x 1/2’’ hex screw (G) into the tabs on each side of
the xture. Place one bracket O-ring (E), one #10 lock washer
(D), and one thumb nut (C) on each #10 screw outside the
bracket� Tighten the thumb screws on each side hand tight
only. Repeat this step for all xtures.
Fig. 2
Fig. 3
2� Assemble parts H, I, J, and K as shown in Figure 4 to secure
the xture to the oat and tighten until secure.
• 7/16’’ socket and wrench required.
Fig. 4
Note: Determine whether the Universal mount
bracket works better in a horizontal or vertical
conguration for your application (see next
page) before attaching the composite light
bracket to the xture. Some congurations
require the composite light bracket to be ipped
from what is pictured here�
Back to Contents

RGB4C5 UNIVERSAL LIGHTING MANUAL
884103 / 2021.1.1
5
Hardware is provided for basic installation. Check your installation to ensure you have the correct hardware. Additional hardware may
be included, or you may need to purchase it if your installation varies from the diagrams below�
For vertical bracket mounting, use the hard-
ware shown in Figure 6 to fasten the two
brackets together. Then use your existing oat
screws through the slot in the Universal brack-
et to secure it�
3. Use 1/4”-20 x 3/4” hex screws (O), at washers (I), lock
washers (J), and hex nut (K) as shown in Figure 5 to se-
cure each Composite light brackets (F) to the Universal
mounting brackets (M).
Use 1/4”-20 x 3/4” hex screws (Q), fender washers (P),
lock washers (J), and hex nut (K) to secure the Univer-
sal bracket to the oat.
• Note: Composite light bracket (H) needs to be
ipped upside down for horizontal mounting.
Fig. 5
Fig. 6
4� Repeat for remaining xtures, spacing evenly around the oat. Adjust the angle of the lights using thumb nuts if desired, being
sure to use the same angle for all xtures. Cable ties can be used to attach the xture cords to oat, decrease play, and ensure
protection. Cable-tie the light kit power cord to the oat opposite the fountain power cord for balance and to prevent damage from
the fountain. Remember: RGBC5 xtures MUST be properly submerged (approximately halfway) to avoid overheating.
Back to Contents

RGB4C5 UNIVERSAL LIGHTING MANUAL
884103 / 2021.1.1
6
RGB CONTROL PANEL INSTALLATION & OPERATION
1� Open the control box and remove the operating instruction sheet, remote control, and battery. Insert the battery into the remote
control� If the battery is already inserted, remove the plastic battery guard from the remote to active the battery connection�
2� The RGB control box is ready to mount next to your Kasco fountain control box (mount a minimum of 5ft from water) using two
exterior-grade wood screws; one for the top and one for the bottom hanger. Tighten the top screw to prevent the box from lifting off
the screws. Mount close enough for the power cord to reach the receptacle or terminals labeled “Lights” in the fountain control box.
Note: Do NOT power on RGB control box at this time.
3. Once mounted, connect the RGB light kit power cord to the eld terminal connections in the RGB control box. Connect: White to
White, Green to Green, Red to Red, and Black to Black�
4� For 120V fountain control box: Plug the RGB control box into the “Lights” receptacle in the fountain control box. This will allow
the C-25 control panel to control the lights and the fountain through the timer. To energize the C-25 light receptacle, the photo-eye
of the C-25 will need to be covered (to simulate nighttime conditions). Refer to your C-25 instructions.
For 240V or 3phase fountain control box: If you have a Kasco C-85, C-95 or 3phase control panel, you will need to hardwire the
RGB controller power cord to the light terminals in your fountain control panel� Refer to your fountain owner’s manual for connec-
tion information. The Kasco C-85, C-95, and 3phase control panels use a timer for controlling the light output. Ensure the light
timer is set as required� Refer to your fountain owner’s manual for timer setting instructions�
5� With the RGB controller door open, a red LED “Power” indicator on the RGB control module will be seen. If this indicator is not on,
then power is not being sent to the RGB control box.
6. The RGB controller is operated with the included remote control� The controller will operate in the last mode set until it is changed
with the remote. Before use, remove the clear plastic tab at the base of the remote. The gure on the next page details the remote
control’s functions. The green signal indicator (on the RGB controller) will ash while the remote is communicating to the controller.
3.5mm audio jack Mic input level adjustment
Connect light kit power cord wires
to this terminal block�
Signal indicator
Fig. 7
Back to Contents

RGB4C5 UNIVERSAL LIGHTING MANUAL
884103 / 2021.1.1
7
3 automatic music modes:
• FT – Fast track, color change is fast change;
• MT – My track, color change is medium
changing speed;
• CT – Cool track, color change is slower and
smoother than FT and MT�
9 static color modes:
White, Red, Green, Blue, Warm White,
Amber, Yellow, Cyan, Magenta.
• Repeatedly press the color to cycle the
intensity from 100%, 50%, 25%, 12%, 6%
and back to 100%�
Automatic color sequencing modes:
• Flash – jump to next color;
• Bloom – transition from color to color;
• Smooth – smooth transition from color to color
S+, S- button:
• Slow down or speed up the
color transitions of the 3
automatic modes
RF Remote Control
FLASH BLOOM SMOOTH S+
S-
F. T M.T C.T
REMOTE CONTROL FEATURES
The audio input jack is compatible with the headphone jack on a smartphone, MP3 player, or a pre-amp type output via an “aux” style
3.5mm connection. Do not connect to a line level (amplied speaker) output. Kasco recommends a 3.5mm “Y” adapter to allow for
connection of the audio source to the RGB controller and a stereo amplier simultaneously if desired.
Music input control: The RGB controller is capable of changing colors based on sound input. The controller has a 3.5mm audio jack
and a microphone built into the controller. The microphone input is adjustable with a level sensitivity dial.
CONTROL INPUT FEATURES
Mic input level adjustment3.5mm audio jack
Fig. 8
Fig. 9
Power on/off
Back to Contents

RGB4C5 UNIVERSAL LIGHTING MANUAL
884103 / 2021.1.1
8
WARRANTYWARRANTY
Warranty Policy
Warranty period: RGB4C5 = 2 year Limited Warranty: Kasco®
Marine, Inc� warrants this Light Kit to be free from defects in ma-
terial or workmanship under normal use and service� The Kasco
Marine, Inc� obligation under this warranty is limited to replacing
or repairing free of charge any defective part within the warranty
period from the date of shipment� Customer shall pay shipping
charges for returning the unit to Kasco�
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES,
EXPRESSED OR IMPLIED, AND ANY OTHER OBLIGATION
OR LIABILITY WHATEVER ON THE PART OF KASCO MA-
RINE, INC. AND IN NO EVENT SHALL KASCO MARINE, INC.
BE LIABLE FOR ANY SPECIAL OR CONSEQUENTIAL DAM-
AGES.
Warranty is void if:
• The Light Kit is not maintained properly according to the
Maintenance Recommendations supplied in this Manual�
• The lights, control box, or power cord are altered in any
way from original shipment� Cuts in the power cord are not
covered under warranty�
• The Light Kit is damaged by unauthorized tampering.
Warranty Claim Procedure:
The best method for establishing warranty period is by keeping
your original receipt and registering the equipment online at
kascomarine�com under the Warranty Information section�
Once warranty coverage has been established, the light kit may
be sent to Kasco Marine or any Kasco Authorized Repair Center
for evaluation and repair�
MAINTENANCE RECOMMENDATIONSMAINTENANCE RECOMMENDATIONS
Under NO CIRCUMSTANCE should anyone enter the water
while a fountain is operating�
The following maintenance procedures can be utilized to ensure
many years of quality performance from your Kasco light kit and
reduce the need for more costly repair work�
PROPER INSTALLATION: Proper installation of Kasco equip-
ment will include a power source with ground fault protection�
The control panel included with the equipment has built-in ground
fault protection for both the fountain and the lighting kit� Ground
fault interrupters are a safety feature that can also alert you to
electrical leaks in the equipment� If you have repeat, consistent
trips of the ground fault device, the equipment should be discon-
nected and removed from the water� The power cord should be
inspected for damage and you should contact your distributor or
contact Kasco Marine at 715-262-4488 or sales@kascomarine.
com for further instructions. A complete list of control panels can
be found in the Accessories section of kascomarine�com�
OBSERVATION: Operating equipment should be observed on a
regular basis (daily, if possible) for any reduction or variation in
performance� If a change in performance is observed, the equip-
ment should be disconnected from power and inspected�
WINTER STORAGE: In regions where there is signicant freez-
ing in the wintertime, the light kit should be removed from the
water to protect it from the expansion pressure of ice. Storage
over winter is best in a location that is out of the sun and cool, but
above 32° F.
CLEANING: Light kits should be removed from the water at least
once per year (at the end of the season in cold climates) to clean
the exterior of the system. The light xture surfaces dissipate
heat into the water, and any algae, calcium, or other build-up
will become an insulator that blocks heat transfer and may lead
to overheating and damage� Keeping the lenses clean will also
ensure the brightest light possible�
Back to Contents

RGB4C5 UNIVERSAL LIGHTING MANUAL
884103 / 2021.1.1
9
Kasco Marine
800 Deere Road
Prescott, WI 54021
Contact Us
Phone: 715-262-4488
Fax: 715-262-4487
www.kascomarine.com
REPAIR
Note: The LED light xtures are sealed and do not require any
physical maintenance other than cleaning. If a xture fails to op-
erate, it can be removed and the included sealing cap installed
onto the waterproof connector of the power cord� This will allow
you to continue to operate your light kit with two xtures while a
replacement xture is procured. Utilize caution when removing
the shrink tube from the connector� Only perform this removal/
replacement with all equipment disconnected from the power
source�
Any required repairs must be performed by Kasco Marine. Any
alterations or changes made to Kasco units by an unauthorized
source will void the warranty� This includes tampering with the
unit, power cord, and/or control box.
A physical Kasco Repair Form must be included with any equip-
ment sent to Kasco or an Authorized Repair Center. This form
can be found under the Product Support section of kascomarine�
com� If no Repair Form is available, include your name and
physical address for return delivery of the repaired Light Kit and
a daytime phone number and/or e-mail address for correspon-
dence regarding the warranty claim�
Note: Visually inspect the power cord for any cuts, rodent
chews, etc� to determine if it should be included in the repair
shipment� The cord may be needed by the shop to diagnose the
failure�
Once warranty coverage has been established, the equipment
may be sent to any Kasco Authorized Repair Center or to Kasco
at:
NON-WARRANTY REPAIRS
Most failed equipment can be repaired at substantially lower
costs than replacement with new� If your light kit requires repair
and is no longer covered under warranty, please contact Kasco
Marine or your local distributor for available options� Please ship
according to the instructions above�
• Kasco Marine does estimates on repairs at the request of
the customer� The request for estimate should be included
in the letter that accompanies the returned unit and must
include a daytime phone number and/or e-mail address� We
will contact the customer with a total after the unit has been
evaluated, but before the work is performed�
• All estimates that are rejected for repair will be destroyed
unless otherwise directed by the customer. Rejected
equipment can be returned at the customer’s expense for
shipping and handling charges�
Billing:
All non-warranty repairs will be returned and billed to the cus-
tomer unless otherwise directed� Kasco Marine accepts Visa
and MasterCard credit card payments� Kasco Marine will call for
credit card information upon completion of the estimate at the
customer’s request�
Please see the Product Support section of kascomarine�com
for more information about warranty and repairs� Contact Kasco
Marine at the number above or [email protected] for ad-
ditional information and your closest Authorized Repair Center.
Back to Contents

RGB4C5 UNIVERSAL LIGHTING MANUAL
884103 / 2021.1.1
10
Back to Contents

RGB4C5 UNIVERSAL LIGHTING MANUAL
884103 / 2021.1.1
11
REPAIR CONTACT FORM
• Kasco requires that all equipment sent for repair MUST be accompanied by this form and marked to Repairs attention�
• Kasco is NOT responsible for shipping damage accrued in return shipment�
• It is the responsibility of the customer to ship and pay freight to Kasco�
Note: Contact Information should be that of the person or company to contact for repair information�
Company name
Contact name
First name Last name
Address
Street
City
State
ZIP code
Phone number
Primary Alternate
Email address
Preferred method of contact
(circle) Phone Email
Purchase order number
Additional product information
Serial Number Cord Length
Additional notes
for repair technician:
Kasco Marine
800 Deere Road
Prescott, WI 54021
Back to Contents
This manual suits for next models
8
Table of contents
Other Kasco Lighting Equipment manuals

Kasco
Kasco WaterGlow LED3S19 Manual

Kasco
Kasco WaterGlow LED4S19 Manual

Kasco
Kasco WaterGlow LED6S19 User manual

Kasco
Kasco RGB3C5 User manual

Kasco
Kasco LED3C11 Manual

Kasco
Kasco RGB3C5 Manual

Kasco
Kasco LEDS19 Manual

Kasco
Kasco WaterGlow RGBC5 Manual

Kasco
Kasco WaterGlow LEDC11 Manual

Kasco
Kasco WaterGlow LED4C11 Manual
