Kask HP PLUS Owner's manual

COD:420306 - ED. 02/2022
EN 14052
USE AND CARE BOOKLET
HP PLUS
OCCUPATIONAL PROTECTIVE HELMET
HIGH PERFORMANCE HELMET FOR INDUSTRY
KASK S.p.A.
24060 Chiuduno, BG
Via Firenze, 5 - Italy
t. [phone]
[email protected]
www.kask.com
PRODUCT OF ITALY
FIG. 1
FIG. 2
FIG. 3
FIG. 5 FIG. 6
FIG. 4a 4b
NOOK NO
Size: HP PLUS 51/62cm ADJUSTABLE
DATE OF MANUFACTURE
AS/NZS 1801
HIGH PERFORMANCE HELMET FOR INDUSTRY
Wearing a helmet can not always prevent from death or long term invalidity.
This helmet:
- must be replaced after a signicant shock; damages can also be not
visible;
- t correctly to the wearer's head;
- must be equipped only with accessories and spare parts recommended
from the helmet manufacturer;
- must not be painted, must not have stickers (except from those applied
from the manufacturer) and must not be cleaned with a solvent not
approved; does not have to be modied in any part;
- must be worn with the chinpad correctly adjusted.
EXPLANATORY MARKING DIAGRAM
MANUFACTURER
MODEL NAME
SHELL MATERIAL
HELMET PROVIDED OF CHINPAD
MODEL DESIGNATION
REFERENCE TO LEGISLATION
SIZE IN CM
HELMET WEIGHT
CERTIFICATION MARKING
DATE OF MANUFACTURE
IDENTIFICATION NUMBER
8
9
10
11
1
2
3
4
5
6
7
FAC-SIMILE LABELLING
Size: HP 51 - 63cm ADJUSTABLE
1
2
5
6
7
KASK S.p.A.
HP
HIGH PERFORMANCE HELMET
FOR INDUSTRY
EN 14052:2012
Adjustable 51-63cm
8
9
10
11
500 g
IMPRESSED ON THE SHELL
18.0000.0001
0426
3
4
ABS
KS
HIGH PERFORMANCE HELMET FOR INDUSTRY
Wearing a helmet can not always prevent from death or long term invalidity.
This helmet:
- must be replaced after a signicant shock; damages can also be not
visible;
- t correctly to the wearer's head;
- must be equipped only with accessories and spare parts recommended
from the helmet manufacturer;
- must not be painted, must not have stickers (except from those applied
from the manufacturer) and must not be cleaned with a solvent not
approved; does not have to be modied in any part;
- must be worn with the chinpad correctly adjusted.
EXPLANATORY MARKING DIAGRAM
MANUFACTURER
MODEL NAME
SHELL MATERIAL
HELMET PROVIDED OF CHINPAD
MODEL DESIGNATION
REFERENCE TO LEGISLATION
SIZE IN CM
HELMET WEIGHT
CERTIFICATION MARKING
DATE OF MANUFACTURE
IDENTIFICATION NUMBER
8
9
10
11
1
2
3
4
5
6
7
FAC-SIMILE LABELLING
Size: HP 51 - 63cm ADJUSTABLE
1
2
5
6
7
KASK S.p.A.
HP
HIGH PERFORMANCE HELMET
FOR INDUSTRY
EN 14052:2012
Adjustable 51-63cm
8
9
10
11
500 g
IMPRESSED ON THE SHELL
18.0000.0001
0426
3
4
ABS
KS
5
0
0
g
5
1
-
6
3
A
B
S
K
S
H
P
E
N
1
4
0
5
2
:
2
0
1
2
FAC-SIMILE LABELLING
EXPLANATORY MARKING DIAGRAM
Class 0
1
2
3
4
5
6
KASK S.p.A.
ZENITH X
SAFETY HELMET
FOR INDUSTRIAL USE
EN 397 | 440V a.c. impressed
-30°C | LD | MM on the shell
EN50365
Adjustable 52-63cm PP
20.2000.0001
7
8
9
10
2008
Class 0
1
2
3
4
5
6
KASK S.p.A.
ZENITH X AIR
SAFETY HELMET
FOR INDUSTRIAL USE
EN 397 | impressed
-30°C | LD | MM on the shell
EN50365
Adjustable 52-63cm PP
20.2000.0001
7
8
9
10
2008
16
4
5
7
KASK S.p.A. -Via Firenze, 5
Chiuduno - BG - Italy
HP PLUS
480 g
Adjustable 51-62 cm
Impressed on the shell
8
3
2
Type 1 - General Industrial
Safety Helmet
AS/NZS
1801:1997
Complies with
16
4
5
7
KASK S.p.A. -Via Firenze, 5
Chiuduno - BG - Italy
HP PLUS
480 g
Adjustable 51-62cm
Impressed on the shell
8
3
2
Type 1 - General Industrial
Safety Helmet
AS/NZS
1801:1997
Complies with
MARCATURA - ZENITH X

DANGER!Intended use of this helmet involves activities that are extremely dangerous. FAILURE TO HEED AND
FOLLOW THESE INSTRUCTIONS AND ANY OF THESE WARNINGS MAY RESULT IN SERIOUS INJURY OR EVEN
DEATH.
WARNING: Carefully read and understand these instructions. Use this helmet exclusively for the activities for
which it is certied (see Labeling) and in strict accordance with AS/NZS 1801
WARNING: Improper use of this helmet can cause serious or fatal injury. lf the instructions are not followed
correctly, the level of protection offered by the helmet can be signicantly reduced. Inspect the helmet
before each use far any signs of visible damage. DO NOT USE HELMET IF THERE IS ANY SUSPICION OF ITS
CONDITION OR AFTER A MAJOR IMPACT.
WARNING: It is mandatory that the user becomes knowledgeable about all features of the helmet, its
capabilities and limitations, and gets specic instructions and/or training from a competent and responsible
person in the proper use of the helmet.
WARNING: USERS OF THE HELMET ARE FULLY RESPONSIBLE FOR THEIR ACTIONS AND ASSUME ALL RISKS
FOR THEIR DECISIONS. KASK S.p.A., its afliates, subsidiaries, importers, distributors and dealers will accept
no responsibility in the event of an accident leading to injury or even death and shall not be liable for any injury,
death, loss, or damage resulting from improper use of this helmet.
WARNING: SPECIFIC TRAINING IS ESSENTIAL BEFORE USE. Read this notice carefully and keep all
instructions and information on the proper use and application of the product(s). Many types of misuse exist
and it is impossible to enumerate or even imagine all of them. Contact KASK if you have any doubt or difculty
understanding these instructions. Activities at height are dangerous and may lead to severe injury or even death.
Gaining adequate training in appropriate techniques and methods of protection is your own responsibility.
You personally assume all risks and responsibilities tor all damage, injury or death which may occur during or
following incorrect use of our products in any manner whatsoever. If you are not able, or not in a position to
assume this responsibility or to take this risk, do not use this equipment.
USE: This product must only be used by competent and responsible persons; or those placed under the direct
and visual supervision of a competent a responsible person. Personal protective equipment (PPE) is to be used
only on or with energy absorbing systems (tor example dynamic ropes, energy absorbers etc.). Check that
this product is compatible with the other components of your equipment, see the instructions specic to the
products. To prolong the life of this product, take care when transporting and using it. Avoid impacts, or contact
with abrasive surfaces or sharp edges.
NOTE: You are responsible for your own actions and decisions. Before using this helmet, you must:
• read and understand all instructions for use;
• get specic training in its proper use;
• become acquainted with its capabilities and limitations;
• understand and accept the risks involved.
Failure to heed any of these warnings may result in severe injury or death. The manufacturer and/or distributor
will accept no responsibility in the event of accidents leading to injury or even death due to improper use of
the helmet. This helmet is constructed to absorb impact by partially distributing the shock or by damaging its
essential components. Activities at height present a risk of serious head injury. Wearing a helmet can signicantly
reduce this risk, but cannot entirely eliminate it. This helmet should be used exclusively for the activities for which
it is certied (see labeling). This helmet has been approved for industrial head protection.
WARNING: This helmet cannot always protect the user from injury. Specically, keep in mind that no helmet can
protect the head from the shock generated by violent impact. Following violent impact, even if no damage is
visible, the helmet should be replaced, in that its capacity to absorb further impact could be impaired.
WARNING: Your helmet can be damaged from improper care: do not sit on it, pack it too tightly, drop it, allow
it to contact sharp or pointed objects, etc. Do not expose your helmet to high temperatures, for example by
leaving it inside a vehicle in direct sunlight.
INSTRUCTIONS: As a protective measure, this helmet must be worn at all times during work activity. For
adequate protection, it is important that the helmet be sized correctly and t the head properly to offer optimum
comfort and safety. The helmet should be adjusted to t the user, ex., the straps should be positioned so that
they do not cover the ears, the buckle should be kept away from the jawbone, and the straps and buckle should
both be adjusted so that they are comfortable and secure. After properly buckling and adjusting the strap, always
check that the helmet is not excessively tight; nor should it move freely back and forth. Verify that the helmet is
well seated and centered on the head (see Fig. 1). The better a helmet is adjusted (minimal movement front to
back or side-to-side), the better protection it can provide.
HP PLUS NOMENCLATURE: 1. Shell; 2. Headband (not removable); 3. Size adjustment system; 4. Chinstrap;
5. Lateral retractor; 6. Buckle; 7. Lamp clip; 8. Side slot for hearing protection adapter; 9. Side slot to insert visor
adapter; 10. Marking Label.
ADJUSTMENTS: Wear the helmet and adapt the size by turning the rear wheel (clockwise to tighten the size and
counter-clockwise to enlarge it) or simply (only for models equipped) by drawing the two quick-closing elements
to obtain the desired tension (Fig. 2). Position the size adjustment system in the nuchal area as shown (Fig. 3),
tilting it and adjusting it in height. For versions equipped with a chin strap, fasten it by inserting one buckle strap
into the other until it clicks into place (Fig. 4a). Pull the chin strap to check that the buckle is locked (Fig. 5). Adjust
the length of the chin-strap to rmly secure the helmet on your head. The rubber ring must be positioned on end
of the tape to prevent it dangling. Adjust the lateral retractor of the chin strap by sliding it along the straps until
you nd the desired position below the ear (Fig. 6). To remove the helmet from the head, open the chin-strap by
simultaneously pressing the buttons on each side of the buckle (Fig. 4b). Use of the rear sliders (only for versions
provided): it is possible to use the rear adjuster to prevent the lateral retractor from being in uncomfortable
positions, such as interference with the ear or during the use of hearing protectors.
SPARE PARTS: Changes, replacements and/or removals of one or any of the original components of the helmet
are prohibited unless authorized by the manufacturer. Only use original KASK spare parts. The helmet should
not be modied to accommodate other accessories other than those described below. If necessary, contact your
retailer or the manufacturer directly.
ACCESSORIES: Check with your retailer or manufacturer the actual availability of the accessories. Follow the
user manual supplied with them. Only use accessories approved by the manufacturer.
CLEANING: Clean the helmet (and accessories) using only water, mild soap and a soft, clean cloth, and let it
air dry at room temperature. The internal padding can be removed and washed by hand in cold water or in the
washing machine (max. 30°C / 86° F). Never use chemical cleaning products or solvents.
WARNING: Certain chemical products, especially solvents, can damage your helmet. Protect your helmet from
exposure to chemicals.
STORAGE: When not in use, it is preferable to store the helmet at a temperature between 5°C and 35°C (41°F
to 95°F), protected from direct sunlight and away from sources of hear. KASK recommends to store the helmet
in its original packaging.
MODIFICATIONS AND REPAIRS: Do not apply adhesives, solvents, stickers, or paint that does not comply
with the manufacturer’s specications. Do not modify the helmet in any way without authorization from KASK. An
unauthorized modication can reduce the product’s effectiveness and invalidate its certication. Repairs made
outside of KASK facilities are prohibited.
TRANSPORT: Given the type of device (helmet), no particular instructions are necessary for its transport. During
transport do not pack the helmet too tightly.
CHECK: Before using the helmet check its integrity in all its parts. Following a violent impact even if the damage
is not visible replace the helmet, as it may have exhausted its ability to absorb further shocks and provide the
expected protection.
REVISION: In addition to the normal visual check before each use, a competent person must perform a thorough
examination at least annually. The registration of the controls must be made on a control sheet downloadable
from the manufacturer’s website www.kask-safety.com. Do not remove labels or markings and check their
legibility. If you nd cuts, abrasions or any other damage, before reusing the helmet contact the manufacturer
to have it examined.
LIFE: The life span of the helmet depends on the occurrence of various degenerative factors, including sudden
changes in temperature, exposure to sunlight, intense use. The helmet must be checked periodically, and in any
case before each use, to ascertain the presence of damage such as cracks, detachments, deformations, peeling,
which are elements that reveal the deterioration of the helmet. The helmets which have suffered signicant
impacts must be replaced even if they do not show evident signs of damage. The maximum shelf life of this
product is 10 years from the date of manufacture. After this period, the helmet must be discarded because the
protection decreases due to the aging. The production date is shown inside the helmet.
ATTENTION: In extreme cases, the lifetime can be reduced to one single use through exposure to any of
the following: chemicals, extreme temperatures, sharp edges, major fall or load, etc. Cracks, detached parts,
warping, aking, and changes in color are signicant elements for verifying the helmet’s state of deterioration; in
any case, we advise replacing it after 5 years of use, because over time its protection decreases.
WHEN TO RETIRE YOUR EQUIPMENT: Iimmediately retire any equipment if:
• it fails to pass inspection (inspection before and during use and the periodic in-depth inspection);
• it has been subjected to a major fall or load;
• you do not know its full usage history;
• it is at least 10 years old;
• you have any doubt as to its integrity.
Destroy retired equipment to prevent further use.
PRODUCT OBSOLESCENCE: There are many reasons why a product may be judged obsolete and retired
before the end of its lifetime. Examples include changes in applicable standards, regulations, or legislation;
development of new techniques, incompatibility with other equipment, etc.
EN
GUARANTEE: This product is guaranteed for 3 years against any defects in materials or manufacturing.
Exclusions from the guarantee: normal wear and tear, oxidation, modications or alterations, incorrect storage,
poor maintenance, damage due to accidents and/or negligence, or to improper and incorrect usage. KASK is
not responsible for the consequences, direct, indirect or accidental, or any other type of damage befalling or
resulting from the use of its products.
LABELING: Information contained on the inside of the helmet, printed on a label, should not be removed for
any reason.
ADDITIONAL REQUIREMENTS ACCORDING TO EN STANDARDS
PURPOSE OF THIS PPE: This device has been designed to offer protection of the user’s head against the risk of
objects falling from above and consequent brain injuries and skull fractures. This helmet is constructed in such a
way as to absorb the energy of an impact through the partial distribution or damage of the essential components.
This helmet must be used only and exclusively for the activity for which it was certied (see marking). This high
performance helmet for industry has been CE approved following to the European Regulation EN 14052:2012.
This helmet complies with the retention standards of the European Regulation EN 14052:2012 when the chin
strap is worn and adjusted as per our instruction manual. The helmet also meets the additional EN 12492:2012: §
4.2.1.2-4.2.1.3-4.2.1.4 front/back/side shock protection and EN397:2012 § 5.2.4 Side deformation - § 5.1.1 – 5.1.2
impact and penetrations standard requirements. The Certication procedure was carried out by the notied
body no.0426, Italcert Viale Sarca, 336 20126 Milan - Italy.
WARNING: This helmet cannot always protect the user from injury. Specically, one should keep in mind that no
helmet can protect the head from the shock generated by violent impact. Following a violent impact even if the
damage is not visible, the helmet should be replaced, as it may have exhausted its ability to absorb further shocks
and provide the expected protection. The helmet object of this manual is a type III Personal Protection Device
and as such was subjected to EU-type Certication procedure with application of the requirements laid down
in Annex V of the EU Regulation 2016/425. The device is subject to the control procedure in accordance with
Annex VII of the aforementioned Regulation. The verication activities are assigned to the Notied Body 0426.
DECLARATION OF CONFORMITY: To get a copy of the EU Declaration of Conformity for this device, visit the
website www.kask.com.
HP PLUS NOMENCLATURE
7
10
7
2
91
3
4
5
8
6
