Kathrein 80010735V01 User manual

2-Port Antenna
Frequency Range
Dual Polarization
Half-power Beam Width
Integrated replaceable Remote Control Unit
Adjustable Electrical Downtilt
R1
R1
2-Port Antenna iRCU 698–894 65° 16dBi 0°–10°T
Type No. 80010735V01
A) Antenna specifications
R1, connector 1–2
R1, connector 1–2
698–894
Frequency range MHz 698 – 806 824 – 894
Polarization ° +45, –45 +45, –45
Gain dBd
dBi
13.35
15.5
13.85
16
Horizontal Pattern:
Half-power beam width ° 67 65
Front-to-back ratio dB Copolar: > 30
Average: 35
Copolar: > 30
Average: 35
Cross polar ratio
Maindirection 0°
Sector ±60°
dB Typically: > 25
> 11, Avg. 15
Typically: > 25
> 11, Avg. 15
Vertical Pattern:
Half-power beam width ° 11.3 10
Electrical tilt ° 0–10, continuously adjustable
Min. sidelobe suppression for
rst sidelobe above main beam:
Average:
° T
dB
dB
0 ... 5 ... 10
16 ... 17 ... 17
16 ... 19 ... 20
0 ... 5 ... 10
18 ... 17 ... 16
20 ... 20 ... 20
Impedance Ω 50
VSWR < 1.5
Isolation, between ports dB > 30
Intermodulation IM3 dBc < –150 (2 x 43 dBm carrier)
Max. power per input W 500 (at 50 °C ambient temperature)
698–894
X
65°
iRCU
0°–10°
B) iRCU specifications (86010149)*
Field replaceable without dismantling the antenna
Logical interface ex factory1) 3GPP/AISG 2.0
Protocols Compliant to AISG 1.1 and 3GPP/AISG 2.0
Hardware interface2) 2 x 8pin connector acc. IEC 60130-9;
according to AISG:
– iRCU in (male): Control / Daisy chain in
– iRCU out (female): Daisy chain out
Power supply 10 ... 30 V
Power consumption < 1 W (stand by)
< 8.5 W (motor activated)
Adjustment time (full range) 40 sec.
Adjustement cycles > 50,000
Certication CE, 3)
* See mounting instructions and warnings.
1) The protocol of the logical interface can be switched from 3GPP/AISG 2.0 to AISG
1.1 and vice versa with a vendor specic command. Start-up operation of the iRCU
86010149 is possible in a RET system supporting AISG 1.1 or supporting 3GPP/AISG
2.0 after performing a layer 2 reset before address assignment. The protocol can also
be changed as follows: AISG 1.1 to 3GPP: Enter „3GPP“ into the additional data led
„Installer’s ID“ and perform a layer 7 reset or a power reset. 3GPP to AISG 1.1: Enter
„AISG 1“ into the additional data eld „Installer’s ID“ and perform a layer 2 reset or a
power reset. After switching the protocol any other information can be entered into the
„Installer’s ID“ eld.
2) The tightning torque for xing the connector must be 0.5 – 1.0 Nm (‘hand-tightened’). The
connector should be tightened by hand only or using the torque screwdriver (85010080)
as described in the connecting cable data sheet (86010007, ...)!
3) Tested to comply with FCC Standards. This device complies with part 15 of the FCC
Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
698– 894
–45°
7-16
698– 894
+45°
7-16
iRCU
in out
8pin
male
8pin
female
80010735V01 Page 1 of 2
936.4273/b.1 Subject to alteration.
Kathrein USA Greenway Plaza II, 2400 Lakeside Blvd., Suite 650, Richardson TX 75082
Phone: [phone] Fax: [phone] Email: [email protected]
All specifications are subject to change without notice.
The latest specifications are available at www.kathreinusa.com
Downloaded from Arrow.com.

Accessories
General Information
Any previous data sheet issues have now become invalid.
Page 2 of 2 80010735V01
936.4273/b.1 Subject to alteration.
2)
3)
1934 | 76.1 1984 | 78.1 2024 | 79.7
1) 9 | 0.4
2) 72 | 2.8
3) 64 | 2.5
4) 99 | 3.9
5) 111 | 4.4
6) 70 |2.8
Bottom view
Dimensions refer to radome
All dimensions in mm | inches
1)
303 | 11.9
4)
5)
6)
Correlation Table
Frequency range Array Connector
698– 894 MHz R1 1–2
Accessories
Type No. Description Remarks
mm | inches
Weight approx. Units per antenna
kg lb
738546 1 clamp Mast diameter: 42 – 115 | 1.7 – 4.5 1.1 2.4 2 (included in the scope of supply)
86010149 1 iRCU 0.5 1.11 (included in the scope of supply)
85010002 1 clamp Mast diameter: 110 – 220 | 4.9 – 8.7 2.7 6.0 2 (order separately if required)
85010003 1 clamp Mast diameter: 210 – 380 | 8.3 – 15.0 4.8 10.6 2 (order separately if required)
85010008 1 downtilt kit Downtilt angle: 0° – 11° 4.3 9.5 1 (order separately if required)
Wall mounting: No additional mounting kit needed.
Mechanical specifications
Input 2 x 7-16 female
iRCU in: 1 x 8pin male
iRCU out: 1 x 8pin female
Connector position Bottom
Wind load N | lbf Frontal: 750 | 169 (at 150 km/h) 1935 | 436 (at 150 mph)
Maximal: 825 | 185 (at 150 km/h) 2130 | 479 (at 150 mph)
Max. wind velocity km/h
mph
241
150
Height/width/depth mm
inches
1934 / 303 / 99
76.1 / 11.9 / 3.9
Category of mounting hardware H (Heavy)
Weight kg
lb
14 / 16 (clamps incl.)
30.9 / 35.3 (clamps incl.)
Packing size mm
inches
2136 x 317 x 127
84.1 x 12.5 x 5
Scope of supply Panel, 1unit of iRCU and
2 units of clamps 42–115 mm | 1.7–4.5 inches diameter
R1
Material: Reflector screen: Weather-proof aluminum. Radiator: Tin-plated zinc.
iRCU housing: Coated aluminum.
Fiberglass radome: The grey berglass radomes of these antennas
are very stable and extraordinarily stiff. They are resistant to ultraviolet
radiation and can also be painted to match their surroundings.
All screws and nuts: Stainless steel.
Grounding: The metal parts of the antenna including the mounting kit and the inner
conductors are DC grounded.
Environmental tests: iRCU additionally full the standards:
EN 60950-1 (Safety), EN 55022 (Emission) and EN 55024 (Immunity)
Kathrein USA Greenway Plaza II, 2400 Lakeside Blvd., Suite 650, Richardson TX 75082
Phone: [phone] Fax: [phone] Email: [email protected]
All specifications are subject to change without notice.
The latest specifications are available at www.kathreinusa.com
Order Information
Model Description
80010735V01 Antenna with mounting bracket
80010735V01K Antenna with mounting bracket and
mechanical tilt bracket
Downloaded from Arrow.com.Downloaded from Arrow.com.

936.4054/b.1 Subject to alteration.
86010149 Page 1 of 2
Integrable Remote Control Unit (iRCU)
Type No. 86010149
Protocols Compliant to AISG 1.1 and 3GPP/AISG 2.0
Logical interface ex factory
1) AISG 2.0/3GPP
Input voltage range 10 ... 30 V (pin 1, pin 6)
Power consumption < 1 W (stand by); < 10 W (motor activated)
Connectors 2) 2 x 8 pin connector according to IEC 60130-9; according to AISG
Daisy chain in: male; Daisy chain out: female
Hardware interfaces RS 485A/B (pin 5, pin 3);
power supply (pin 1, pin 6); DC return (pin 7);
according to AISG / 3GPP
Adjustment time (full range) 40 sec (typically, depending on antenna type)
Adjustment cycles > 50,000
Temperature range –40 °C … +60 °C
Protection class IP 24
Lightning protection AISG interface (each pin);
2.5 kA (10/350µs); 8 kA (8/20µs)
Weight 480 g (1.1 lbs)
Packing size 245 x 93 x 102 mm, (9.6 x 3.6 x 4 inches)
Dimensions (H x W x D) 170 x 68.5 x 66 mm, (6.68 x 2.7 x 2.6 inches)
1)
The protocol of the logical interface can be switched from 3GPP/AISG 2.0 to AISG 1.1 and vice versa
with a vendor specific command.
Please note:
If the Primary of the RET system doesn’t support the standard of the ‘logical interface ex factory’, the
iRCU must be switched to the appropriate standard of the Primary before installation. Please contact
Kathrein for further information.
2) The tightning torque for fixing the connector must be 0.5 – 1.0 Nm (‘hand-tightened’). The connector
should be tightened by hand only!
Standards EN 60950-1 (Safety)
EN 55022 (Emission)
EN 55024 (Immunity)
ETS 300019-1-4 (Environmental)
Certification: CE, FCC15.107 class B
Scope of supply: Integrable Remote Control Unit
Kathrein’s 86010149 integrable Remote Control Unit (iRCU) allow operators to control the
electrical tilt of compatible antennas without direct access to the antenna.
•Compliant to AISG 1.1 and 3GPP/AISG 2.0
•Field replaceable without dismantling the antenna
•Daisy Chain feasibility
•Allow control of the antenna either locally through a laptop computer, on site desktop compu-
ter, the optional central control unit; remotely via an ethernet network or over the internet
Daisy chain in
(male)
Daisy chain out
(female)
Retaining Screw Torx 20
Bottom view of RCU
170 (6.68˝)
14.6 (0.57˝)
17.4 (0.68˝) 66 (2.6˝)
49.5 (1.45˝)
59.5 (2.34˝)
68.5 (2.7˝)
Kathrein USA Greenway Plaza II, 2400 Lakeside Blvd., Suite 650, Richardson TX 75082
Phone: [phone] Fax: [phone] Email: [email protected]
All specifications are subject to change without notice.
The latest specifications are available at www.kathreinusa.com
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Integrable Remote Control Unit (iRCU)
936.4054/b.1 Subject to alteration.
Page 2 of 2 86010149
Please note: Additional grounding of the iRCU is not required if the iRCU is fixed to an antenna with proper grounding.
Please assure that grounding of the antenna has been carried out according to all relevant local regulations.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Please note: As a result of more stringent legal regulations and judgements regarding product liability, we are obliged to point
out certain risks that may arise when products are used under extraordinary operating conditions.
The mechanical design is based on the environmental conditions as stipulated in ETS 300 019-1-4 and thereby respects
the static mechanical load imposed on an antenna by wind at maximum velocity. Wind loads are calculated according to
DIN 1055-4. Extraordinary operating conditions, such as heavy icing or exceptional dynamic stress (e.g. strain caused by
oscillating support structures), may result in the breakage of an antenna or even cause it to fall to the ground. These facts
must be considered during the site planning process.
The installation team must be properly qualified and also be familiar with the relevant national safety regulations.
The details given in our data sheets have to be followed carefully when installing the antennas and accessories.
The limits for the coupling torque of RF-connectors, recommended by the
connector manufacturers must be obeyed.
Any previous datasheet issues have now become invalid.
Kathrein USA Greenway Plaza II, 2400 Lakeside Blvd., Suite 650, Richardson TX 75082
Phone: [phone] Fax: [phone] Email: [email protected]
All specifications are subject to change without notice.
The latest specifications are available at www.kathreinusa.com
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Any previous data sheet issues have now become invalid.
738546 Page 1 of 1
Mounting Hardware
Clamp Included in the Scope of Supply
936.3920/c Subject to alteration.
Suitable for mast diameter (mm)
[inches]
42 – 115
[1.65 – 4.53]
Antenna – mast distance (mm)
[inches]
20 – 25
[0.79 – 0.98]
Material of clamp and screws Hot-dip galvanized steel / stainless steel
Weight (kg)
[lb]
1.1
[2.43]
Please note: Kathrein does not recommend to use counter nuts.
The additional nuts supplied are only meant as spares.
All dimensions in mm and [inches]
152 [5.98]
100 [3.94] 40 [1.57]
72 [2.83]
35 [1.38]
64 [2.52]
125 [4.92]
40 [1.57]
20–25 [0.79–0.98]
42–115
[1.65– 4.53]
M10 MA= 25 Nm
M8 MA= 20 Nm
20–25
[0.79–0.98]
Kathrein USA Greenway Plaza II, 2400 Lakeside Blvd., Suite 650, Richardson TX 75082
Phone: [phone] Fax: [phone] Email: [email protected]
All specifications are subject to change without notice.
The latest specifications are available at www.kathreinusa.com
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

936.4073/a Subject to alteration.
Page 1 of 2
Mounting Instructions and Warnings
Remove the AISG control
cables by following the above
Control Cable installation
instructions. Use a TORX T20
Screwdriver to loosen the
retaining screw.
When the retaining screw is
completely released the screw
will hang free but will not fall
from the iRCU housing.
Connect a control cable to the daisy chain input of the iRCU.
The tightening torque for fixing the connector must be 0.5 – 1.0 Nm
(“hand-tightened”).
The connector should be tightened by hand only!
Please note: If the daisy chain output is not used, do not
remove the protection cap.
Carefully slide the iRCU out of
the antenna housing.
Install the new iRCU by sliding
the iRCU into the empty cavity
with the correct orientation.
When the iRCU is inserted all
the way into the antenna hous-
ing use the TORX Screwdriver
to tighten the retaining screw.
Torque: MA= 2.5 …. 3.0 Nm.
Reattach the AISG control
cable using the Control Cable
Installation instructions.
Important:
Application of the correct
torque on the screw is
mandatory as earthing of the
iRCU to the reflector screen
is otherwise endangered.
Instructions for iRCU Replacement:
Connecting the control cables:
Warning!
Take care that the iRCU does not fall from the antenna
housing when the retaining screw is not tightened. The falling
iRCU can cause injury or death and may permanently
damage equipment.
For daisy chain operation, remove the protection cap and attach
a control cable to interconnect with the daisy chain input of the
next iRCU.
Please note: Do not remove the protection cap on the daisy
chain output of the last iRCU device.
Caution!
When installing or removing cables, turn only the threaded collar indicated and not the body of the
connector. Rotating the connector body can result in permanent damage to the connector and the
device being installed. Note that the connectors have keyways which must be carefully aligned
before insertion. Insert the connector fully until well seated before tightening.
Hand tighten connectors (0.5 – 1.0 Nm).
Avoid tightening connectors with wrenches or pliers.
Over tightening connectors may permanently damage the iRCU.
Kathrein USA Greenway Plaza II, 2400 Lakeside Blvd., Suite 650, Richardson TX 75082
Phone: [phone] Fax: [phone] Email: [email protected]
All specifications are subject to change without notice.
The latest specifications are available at www.kathreinusa.com
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Color coding:
Correlation of each RF input to:
– the corresponding iRCU
– the frequency range
– the polarization
936.4073/a Subject to alteration.
Page 2 of 2
General Instructions for Feederline Installation
for Single- and Dual-band Antennas with iRCU
Please note: To avoid any damage to the interfaces, please ensure that only the right tools are used.
Installation of the feederline connector:
Carefully place the connector and fix the nut using a torque-wrench (according to the manufacturers guidelines).
Ventilation hole
7-16 female
iRCU
Description of bottom end cap:
Single-band Antennas with iRCU
Dual-band Antennas with iRCU
Ventilation hole
7-16 female
iRCU
Kathrein USA Greenway Plaza II, 2400 Lakeside Blvd., Suite 650, Richardson TX 75082
Phone: [phone] Fax: [phone] Email: [email protected]
All specifications are subject to change without notice.
The latest specifications are available at www.kathreinusa.com
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.
