Keating Of Chicago Bumper Guard 14 IFM SE Operating instructions

14 IFM SE BUMPER GUARD
Installation Instructions
www.keatingofchicago.com 1-800-KEATING
SERVICE INSTRUCTIONS
BEFBumperGuard 6/04
Kit Includes: Tools Needed:
Bumper Guard 7/16” socket & driver
7/16” open end wrench
part # 037532
CAUTION: During
assembly of Item B,
sides of cabinet should
be parallel. Clearance in
mounting holes on
cabinet sides, leg
channels and bumper
guard will allow
adjustment when
attaching hardware.
Tighten bolts and nuts
at the end of installation.
View A-A
B
C
(Qty 4)
A (Qty 4)
View A-A
Rear view of
fryer
Instructions:
1. Remove bolts (A) and nuts (C) in rear of fryer using socket and wrench.
2. Remove bar currently in place (1/4”x1” bar stock).
3. Install bumper guard (B) in place of bar stock as shown above.
4. Reinstall bolts, nuts and spacers (A and C). NOTE: Keep loose until all four are in place.
5. Tighten bolts and nuts using socket and wrench.
Qty. Description
A 4 Bolt 1/4-20
B 1 Bumper Guard
C 4 Nut 1/4-20
A and C
(Qty 4)
Spacers
Cabinet Side
Leg Channel
Enlarged View
