Keating Of Chicago Instant Recovery 004341 User manual

5/98
HiLmtCntrl
MOUNTING INSTRUCTIONS FOR REPLACING
HI-LIMIT CONTROL #004341 (BACK MOUNT)
WITH #034357 (BOTTOM MOUNT)
FOR IFM & GAS FRYERS & PASTA COOKERS
1. Line up template with reset button clearance hole in bottom of control panel back. Hold in
place & mark hole centers.
2. Drill (2) Ø0.201 (#7) holes.
3. Drill (1) 0.413 hole.
4. Install new hi-limit control using (2) #8-32 x 1/4”screws (part #017744).
HI-LIMIT RESET BUTTON
If the Hi-limit has been activated, press the red button
to reset after the oil cools.
The red button is located under the control panel.
PART #031112 REV 2 DATE: 12/13/06
0.201
DRILL (2) #7
0.413 "Z"SIZE
LINE UP TEMPLATE ON EXISTING HOLE AS SHOWN.
DRILL (2) .201 #7 HOLES AND (1) .413 "Z"
VIEW A-A
(BOTTOM VIEW)
LINE UP WITH
EXISTING HOLE
FRONT VIEW OF FRYER OR PASTA COOKER
WITH CONTROL PANEL REMOVED
CONTROL PANEL
BACK REF.
www.keatingofchicago.com 1-800-KEATING
SERVICE INSTRUCTIONS
PART
#004341
R e wires as shown
a place on 034357
as shown
Remove wires as shown
and replace on 034357
as shown
WWHEN REPLACING 004341
WITH 034357
PART
#034357
P
TEMPLATE
Align the center hole of the template below with
the existing reset button hole in the control panel
back. Drill the 3 needed holes. See View A-A.

5/98
HiLmtCntrl
MOUNTING INSTRUCTIONS FOR REPLACING
HI-LIMIT CONTROL #025584 (BACK MOUNT)
WITH #034357 (BOTTOM MOUNT)
FOR IFM & GAS FRYERS & PASTA COOKERS
1. Line up template with reset button clearance hole in bottom of control panel back. Hold in
place & mark hole centers.
2. Drill (2) Ø0.201 (#7) holes.
3. Drill (1) 0.413 hole.
4. Install new hi-limit control using (2) #8-32 x 1/4”screws (part #017744).
HI-LIMIT RESET BUTTON
If the Hi-limit has been activated, press the red button
to reset after the oil cools.
The red button is located under the control panel.
PART #031112 REV 2 DATE: 12/13/06
0.201
DRILL (2) #7
0.413 "Z"SIZE
LINE UP TEMPLATE ON EXISTING HOLE AS SHOWN.
DRILL (2) .201 #7 HOLES AND (1) .413 "Z"
VIEW A-A
(BOTTOM VIEW)
LINE UP WITH
EXISTING HOLE
FRONT VIEW OF FRYER OR PASTA COOKER
WITH CONTROL PANEL REMOVED
CONTROL PANEL
BACK REF.
www.keatingofchicago.com 1-800-KEATING
SERVICE INSTRUCTIONS
PART
#004341
Remove wires as shown
and replace on 034357
as shown
Remove wires as shown
and replace on 034357
as shown
WHEN REPLACING 025584
WITH 034357
WHEN REPLACING 004341
WITH 034357
PART
#034357
PART
#034357
PART
#025584
TEMPLATE
Align the center hole of the template below with
the existing reset button hole in the control panel
back. Drill the 3 needed holes. See View A-A.
