SERVICE INSTRUCTIONS
FLAME SWITCH REPLACEMENT KIT
Part # 037406
1.) Remove old flame switch and bracket located inside control panel. (Retain hardware). Assemble
flame switch item A to bracket item D with items E and F. Slide bulb end of flame switch through
center hold in item D flame switch bracket and through hole located in control panel. If needed, use
a letter “n” drill to open hole. Reassemble to control panel with retained hardware.
2.) Remove old flame switch and clip (bulb end) and replace with new flame switch item A (as
shown in view “A”.)
3.) Insert flame switch clip item B as shown in view “A.” Secure with screw item C.
FlameSwitchRplcKit
8/08
www.keatingofchicago.com 1-800-KEATING
Part No. 037407
ITEM
D
Your kit includes:
ITEM
NO.
ITEMS
E, F
SEE NOTE #1
ITEM
A
ITEM
C
ITEM
B
CORRECT POSITION FOR
FLAME SWITCH BULB
PILOT RUNNER TUBE
VIEW “A”
SEE NOTES 2 AND 3
