KEBCO F5 COMBICOM ModBus User manual

12/2003
CM.F5.010-K000
BETRIEBSANLEITUNG
INSTRUCTION MANUAL
KEB COMBICOM ModBus

Seite GB - 3 ......... GB - 12
GB

GB - 3
Table of Contents
1. ModBus Interface ........................................................................4
1.1 Ordering Information....................................................................................... 4
Hardware Description ...................................................................................... 5
1.2 ModBusTransmission Speed ......................................................................... 5
1.3 Diagnosis Interface .......................................................................................... 5
2. Functions ....................................................................................5
2.1 Slave Addressing............................................................................................. 5
2.2 Parameter Addressing ..................................................................................... 5
2.3 ModBus Functions .......................................................................................... 6
2.4 User Defined Functions Defined By KEB ....................................................... 7
2.4.1 Function 100: Read Registers32 ........................................................................ 7
2.4.2 Function 101:Write Registers32 ........................................................................ 7
2.5 FieldbusWatchdog .......................................................................................... 7
3. Operator Parameters ..................................................................8
4 Annex.........................................................................................12
4.1 Table of Operator Parameters ....................................................................... 12
4.2 Error Codes of Exception Response ............................................................ 12
5. References ................................................................................12

GB - 4
F5 ModBus Operator: 00.F5.060-A000
Utilities for the diagnosis interface
HSP5 cable between PC and adapter: 00.F5.0C0-0001
Adapter DSUB / Western: 00.F5.0C0-0002
1. ModBus
Interface
1.1 Ordering Information
Hardware Description
SUBD9 (Female) connector is supplied for connecting to the ModBus. This connector
supports the RS232 or alternatively the RS485 transmission standard.The assignment
of the connector is as follows :
Pin Name Description
1 NC Not used
2 RS232_TxD RS232-Tx-Signal
3 RS232_RxD RS232-Rx-Signal
4 RS485_RxD(A) RS485-Rx-Signal-A
5 RS485_RxD(B) RS485-Rx-Signal-B
6 VCC Power supply of the serial interface
7 GND Reference potential of the serial interface
8 RS485_TxD(A) RS485-Tx-Signal-A
9 RS485_TxD(B) RS485-Tx-Signal-B
ModBus Interface
MDB: This green LED shines if
a ModBus service is
running.
ERROR: This red LED blinks if the
frequency inverter control
is in error state.
It shines constantly if the
frequency inverter is rea-
dy for operation.
If this LED is constantly
off then there is no power
supply.
X6B: Diagnosis interface
X6C: ModBus interface
connector (SUBD9
female).
ANTRIEBSTECHNIK
START
STOP
FUNC.
SPEED
ENTER
F/R
E
SDO
PDOUT
PDIN
X6B
X6C
COMBIVERT

GB - 5
Value Meaning
0 1200 Bit/s
1 2400 Bit/s
2 4800 Bit/s
3 9600 Bit/s
4 19200 Bit/s
5 38400 Bit/s
6 55500 Bit/s1
1.2 ModBus Transmission
Speed
The ModBus transmission speed is adjusted through parameter SY.07 in the frequency
inverter control. During initialisation this value is read out by the ModBus operator
together with the inverter address and the value is taken as ModBus bitrate.
1: No Default value of serial interfaces on Perso-
nal Computers
The KEB-ModBus operator is a slave interface. The required ModBus address for
addressing is determined by the operator parameter MDB_SlaveAddr_OP. If the value
of the operator parameter is equal to 255(decimal), the ModBus address is taken from
the inverter address (SY.06).If SY.06 shall have the value zero which was reserved for
broadcast at ModBus, the ModBus operator disable all ModBus activities. If the values
are unequal 255(decimal) the ModBus address is directly taken from this value.
1.3 Diagnosis Interface Attention !!! To prevent the damage of the serial interface on your Personal Compu-
ter be sure that you use the special HSP5 cable from KEB for connecting
your PC to the diagnosis interface of the ModBus operator.
With an adapter the HSP5 cable is connected to the diagnosis interface (see ordering
informations). When connected correctly access to all parameters of the frequency
inverter is possible using the PC-software KEB Combivis. Also the operator internal
parameters can be read out and partly adjusted or parameterized with Download.
2. Functions
2.1 Slave Addressing
The addresses of the parameters (register) are devided into different groups. Each of
this group has its own accessing method:
•0000(hex).....1FFF(hex):This group is build up by those parameters that are accessed
through the mapping list. For a possible adaption of existing applications, the real
start of the mapping parameters in this range can be adjusted by parameters
MDB_MapStartAddr_Rd/Wr ‘. (see below).
•2000(hex).....5EFF(hex): In this address area the parameters of the inverter control
board are mapped by a fixed algorithm. Access is always made on:
FI-Parameter Address = ModBus Register Address – 2000(hex). Please keep in
mind that in this address area access is done with indirect set addressing (with
FR.09).This means when writing/reading one parameter in different sets you have to
set the set indicator (FR.09) previously before access.
•5F00(hex)....5FFF(hex): This block consists of the operator parameters.
2.2 Parameter Addressing
Functions

GB - 6
The following predefined ModBus functions are supported by the KEB ModBus interface:
• 3 : ‚Read Holding Registers‘
• 4 : ‚Read Input Registers‘
• 6 : ‚Preset Single Register‘
• 16 : ‚Preset Multiple Registers‘
At KEB functions 3 and 4 are completely identical.
The predefined ModBus functions are designed for word (16 Bit) data access. Addressing
of parameters is also done by 16 bit register address.Therefore this services can only
operate to the inverter with indirect set addressing (FR.09).
As some parameters of the KEB frequency inverter have 32 bit data length, additional
definitions had to be made for accessing those parameters. This problem has been
solved in two ways:
• First is that parameter access through functions 3, 4, 6, 16 in a certain register
address area is controlled by two mapping lists. One list for reading and another for
writing.With these lists it is possible to access as well as 16 bit or 32 bit parameters
with the functions 3, 4, 16. Also the direct set addressing is supported here. The
beginning of the register addresses of the mapping lists is programmable with
parameters MDB_MapStartAddr_Rd/Wr in the operator.The real length of the mapping
list is programmable with parameters MDB_MapNr_Rd/Wr in the operator. The
maximum length is limited to 100 (dec) words (16-Bit).
• Second is that two additional ModBus functions have been defined by KEB. The
ModBus specification [2] releases function codes for so called 'user defined function
codes‘. In this function area the following functions have been created:
• 100: Read Registers32: Reading several 32 bit registers (indirect set addressing
through FR.09))
• 101:Write Registers32:Writing several 32 bit registers (indirect set addressing through
FR.09)
2.3 ModBus Functions
ModBus Reg-
Addr
Para-
Addr
Access controlled
by the mapping lists
0000h 0000h
1FFFh
2000h
5EFFh
5F00h
5FFFh 3EFFh
Parameter of the
frequency inverter
control
direct access
with Para-Addr =
Reg-Addr - 2000h
Operator Parameter
Read Mapping List
Write Mapping List
ModBus Functions

GB - 7
By this function a number of 32 bit registers/parameters can be read.
Function 100 – Request:
FUNC
100(dez)
Start-Addr
SL-Addr
HiByte LoByte
Nu ber
HiByte LoByte
CRC
LoByte HiByte
with Number: Number of registers/parameters to read
with Start-Addr: First read register address
Function 100 – Response:
FUNC
100(dez)
SL-Addr
MSByte LSByte
Byte_Cnt 1. Para eter-Wert
MSByte LSByte
n. Para eter-Wert CRC
LoByte HiByte
2.4 ModBus Functions
Defined By KEB
2.4.1 Function 100:
Read Registers32
By this function a number of 32 bit registers can be written.
Function 101 – Request:
FUNC
101(dez)
SL-Addr
HiByte
Byte_Cnt
Start-Addr
MSByte LSByte
1. Para eter-Wert CRC
LoByte HiByte
LoByte HiByte
Nu ber
LoByte MSByte LSByte
n. Para eter-Wert
with Number: Number of registers/parameters to read
with Start-Addr: First read register address
Function 101 – Response:
FUNC
101(dez)
Start-Addr
SL-Addr
HiByte LoByte
Nu ber
HiByte LoByte
CRC
LoByte HiByte
2.4.2 Function 101:
Write Registers32
The ModBus operator supports fieldbus supervising.Two operator parameters configure
this function. Watchdog_Inhibit defines several events that reset the fieldbus watchdog.
Watchdog_Activation serves for activating the watchdog functions with the first
occurence of certain events.The effect of the timeout of the Watchdog timer is adjusted
via parameter Pn.05.Parameter Pn.6 determines the Watchdog time.For more information
see parameter description below and in the application manual of the used inverter
control.
2.5 FieldbusWatchdog
ModBus Functions

GB - 8
This parameters are localized in the ModBus interface and determine their behaviour.
All operator parameters can be accessed as operator parameters via ModBus (mapping
lists only for 32 bit services) as well as via diagnosis interface (HSP5).
3. Operator Parame-
ters
MDB_ProtCfg 0280h (FB.00) 5F00h
Meaning: Configures the ModBus interface protocol configuration.
Data Length: 1 Byte
Coding:
B7 B6 B5 B4 B3 B2 B1 B0
RTU
/
ASCII PARITY
Bit7: = 1: ModBus RTU(binary) protocol
= 0: ModBus Ascii protocol (not yet adjustable)
Bit6, 5: = 00: 8 data bits, no parity bit, 2 stop bit
= 01: 8 data bits, odd parity bit, 1 stop bit
= 10: 8 data bits, even parity bit, 1 stop bit
Bit4, 3, 2, 1, 0 = reserved for further use
Default Setting: C0h: ModBus RTU, 8 data bits, even parity bit, 1 stop bit
Remarks: A changed value will immediately be active and non-volatile saved.
MDB_SlavAddr_OP 0281h (FB.01) 5F01h
Meaning: Defines the source for the ModBus slave address.
Data Length: 1 Byte
Coding: 255(dec): ModBus slave address = SY.06. No ModBus activity if SY.06 = 0!
1...247: ModBus slave address = MDB_SlaveAddr_OP
Default Setting: 255(dec): ModBus slave address = SY.06.
Remarks: A changed value will immediately be active and non-volatile saved.
MDB_MapStartAddr_Rd 0282h (FB.02) 5F02h
Meaning: Configures the first parameter address whose read access is controlled by the read
mapping list.
Data Length: 2 Byte
Coding: 1
Default Setting: 0
Remarks: A changed value will immediately be active and non-volatile saved.
MDB_MapStartAddr_Wr 0283h (FB.03) 5F03h
Meaning: Configures the first parameter address whose write access is controlled by the write
mapping list.
Data Length: 2 Byte
Coding: 1
Default Setting: 0
Remarks: A changed value will immediately be active and non-volatile saved.
Operator Parameters
Parameter name Combivis Parameter address ModBus-Register address
Legend

GB - 9
MDB_MapNr_Rd 0284h (FB.04) 5F04h
Meaning: Configures the number of parameters in the read mapping list.
Data Length: 1 Byte
Coding: 1
Default Setting: 2
Remarks: Maximum 100 words(16 bit) can be mapped. A changed value will immediately be
active and non-volatile saved.
MDB_MapNr_Wr 0285h (FB.05) 5F05h
Meaning: Configures the real number of parameters in the write mapping list.
Data Length: 1 Byte
Coding: 1
Default Setting: 2
Remarks: Maximum 100 words(16 bit) can be mapped. A changed value will immediately be
active and non-volatile saved.
Watchdog_Inhibit 0286h (FB.06) 5F06h
Meaning: Configures which events will reset the fieldbus watchdog.
Data Length: 1 Byte
Coding: Bit coded:
Bit0 = 1: Reset fieldbus watchdog by receive of each correct ModBus telegram
Bit1 = 1: Reset fieldbus watchdog by receive of each correct ModBus telegram to this
slave (broadcast included)
Default Setting: 01h
Remarks: A changed value will immediately be active and non-volatile saved.
Watchdog_Activation 0287h (FB.07) 5F07h
Meaning: Configures which events will activate the fieldbus watchdog.
Data Length: 1 Byte
Coding: Bit coded:
Bit0 = 1: Activate fieldbus watchdog by first receive of any ModBus telegram.
Bit1 = 1: Activate fieldbus watchdog by first receive of a correct ModBus telegram to
this slave (broadcast included)
Default Setting: 01h
Remarks: A changed value will immediately be active and non-volatile saved.
MDB_Command 0288h (FB.08) 5F31h
Meaning: Through writing to this parameter certain commands can be requested in the ModBus
operator.
Data Length: 2 Byte
Coding: 0: No command
1: Set operator parameter to default values
Remarks: After completion of the requested command bit 15 of this value will be set by the
ModBus operator.
Operator Parameters

GB - 10
MDB_Mapping_Rd_N see below 5F32h+N
COMBIVIS Para. Addr.: COMBIVIS access through two parameters:
MDB_Read_MapIndex (0289h (FB.09)): = N
MDB_Read_Mapping (028Ah (FB.10)):The mapping itself
Meaning: Configures the nte mapping for read access mapping. N = 0 referes to the first mapping.
Data Length: 4 Byte
Coding:
B0 B1 B2 B3
Para-Addr
HiByte LoByte
Para-Set Wlen
Para.Address: Parameter address (see application manual of the FI control).
Para. Set: Parameter set bit coded
Bit0 = 1 --> Set 0 addressed
Bit7 = 1 --> Set 7 addressed.
Wlen: Data length = 16 bit words
Wlen = 1 --> Data length = 16 bit
Wlen = 2 --> Data length = 32 bit: In this case the first mapping for this parameter
contains the used mapping. In the following mapping the values of Para. Addr., Para.
Set and Wlen has to be set to zero.That means that a 32 bit mapping takes two entries
in the mapping list.
Remarks: It is possible to address more than one set in one mapping.That means that the value
of Para. Set can have more then one bit set. Please keep in mind that in this case the
ModBus operator returns error code 3 (illegal value) if the values of the read parameter
are not the same in all mapped sets.
MDB_Mapping_Wr_N see below 5F96h+N
COMBIVIS Para. Addr.: COMBIVIS access through two parameters:
MDB_Write_MapIndex (028Bh (FB.11)): = N
MDB_Write_Mapping (028Ch (FB.12)):The mapping itself
Meaning: Configures the nte mapping for write access mapping. N = 0 referes to the first mapping.
Data Length: 4 Byte
Coding: Para.Addr.: Parameter address (see application manual of the FI control).
Para. Set: Parameter set bit coded
Bit0 = 1 --> Set 0 addressed
Bit7 = 1 --> Set 7 addressed.
Wlen: Data length = 16 bit words
Wlen = 1 --> Data length = 16 bit
Wlen = 2 --> Data length = 32 bit: In this case the first mapping for this parameter
contains the used mapping. In the following mapping the values of Para. Addr., Para.
Set and Wlen has to be set to zero.That means that a 32 bit mapping takes two entries
in the mapping list.
Remarks: It is possible to address more than one set in write mapping.That means that the value
of Para. Set can have more then one bit set.
OperatorType 0180h (OS.00) not available
Meaning: Returns an identifier for the operator type.
Data Length: 2 Byte
Coding: Internal KEB Coding:
10310(dec) = ModBus operator and diagnosis interface
Remarks: Only for information
Operator Parameters

GB - 11
Diag Error Counter 0183h (OS.03) not available
Meaning: Counts errors on the diagnosis interface.
Data Length: 2 Byte
Coding: 1
Remarks: Only for information
DiagRsp.DelayTime 0184h (OS.04) not available
Meaning: Response delay time on the diagnosis interface.
Data Length: 1 Byte
Coding: 1 ms
Remarks: A changed value will immediately be active and non-volatile saved.
Diag Baudrate 0185h (OS.05) not available
Meaning: Configures the transmission speed on the diagnosis interface.
Data Length: 1 Byte
Coding: 0: 1200 Bit/s
1: 2400 Bit/s
2: 4800 Bit/s
3: 9600 Bit/s
4: 19200 Bit/s
5: 38400 Bit/s
Remarks: This Parameter can only read by the diagnosis interface.
HSP5_Max_InvBusy_Retries 0186h (OS.06) not available
Meaning: Configures how often the ModBus operator repeats a request to the frequency inverter
control if this answers with error code ‚inverter busy‘.
Data Length: 1 Byte
Coding: 1
Remarks: A changed value will immediately be active and non-volatile saved.
HSP5 Tout Cnt 0187h (OS.07) not available
Meaning: Counts the occurrences of timeout on the interface between ModBus operator and
frequency inverter control.
Data Length: 2 Byte
Coding: 1
Remarks: Only for information
Operator Parameters
Software date 0182h (OS.02) not available
Meaning: Configures the software date.
Data Length: 2 Byte
Coding: The lowest decimal digit configures the year 2000.
The next two decimal digits configure the month.
The next two decimal digits configure the day.
Remarks: The representation is as follows: ddmm, year-2000

GB - 12
ModBus COMBIVIS Name Data length
Address Para. Address in Byte
——— 0180h Operator Type 2
——— 0182h Software date 2
——— 0183h Diag Error Counter 2
——— 0184h DiagRsp.DelayTime 1
——— 0185h Diag Baudrate 1
——— 0186h HSP5_Max_InvBusy_Retries 1
——— 0187h HSP5 Tout Cnt 2
5F00h 0280h MDB_ProtCfg 1
5F01h 0281h MDB_SlaveAddr_OP 1
5F02h 0282h MDB_MapStartAddr_Rd 2
5F03h 0283h MDB_MapStartAddr_Wr 2
5F04h 0284h MDB_MapNr_Rd 1
5F05h 0285h MDB_MapNr_Wr 1
5F06h 0286h Watchdog_Inhibit 1
5F07h 0287h Watchdog_Activation 1
5F31h 0288h MDB_Command 2
5F32h 0289h + 028Ah MDB_Mapping_Rd_0 4
: : : :
5F95h 0289h + 028Ah MDB_Mapping_Rd_99 4
5F96h 028Bh + 028Ch MDB_Mapping_Wr_0 4
: : : :
5FF9h 028Bh + 028Ch MDB_Mapping_Wr_99 4
4 Annex
4.1 Table of Operator
Parameters
Error Code Meaning
1 Illegal function
2 Illegal data address
3 Illegal data value
4 Slave device failure
5 Function accepted but not yet finished
6 Slave device busy
64 Internal buffer overflow
65 Timeout at transfer to frequency inverter control
66 Parameter is write protected
67 Invalid password
4.2 Error Codes of
Exception Response
[1]: Modicon ModBus Protocol Reference Guide, PI-MBUS-300 Rev.J v. 06/1996
[2]: ModBus Application Protocol Specification V1.1 v. 12/06/02
[3]: ModBus over Serial Line Specification & Implementation Guide V1.0 v. 12/02/02
5. References
Annex

© KEB CM.F5.010-K000 12/2003
Karl E. Brinkmann GmbH
Försterweg 36-38 • D-32683 Barntrup
fon: [phone] • fax: [phone]
net: www.keb.de • mail: in[email protected]e
KEB Antriebstechnik GmbH & Co. KG
Wildbacher Str. 5 • D–08289 Schneeberg
fon: [phone] • fax: [phone]
mail: [e-mail]
KEB Antriebstechnik Austria GmbH
Ritzstraße 8 • A-4614 Marchtrenk
fon: [phone] • fax: [phone]
Kostelni 32/1226 • CZ-370 04 Ceské Budejovice
fon: [phone] • fax: [phone]
mail: [e-mail]
KEB Antriebstechnik
Herenveld 2 • B-9500 Geraadsbergen
fon: [phone] • fax: [phone]
mail: [e-mail]
KEB China
Xianxia Road 299 • CHN-200051 Shanghai
fon: [phone] • fax: [phone]
net: www.keb-cn.com • mail: [email protected]
Société Française KEB
Z.I. de la Croix St. Nicolas • 14, rue Gustave Eiffel
F-94510 LA QUEUE EN BRIE
fon: [phone] • fax: [phone]
mail: sfkeb.[email protected]
KEB (UK) Ltd.
6 Chieftain Buisiness Park, Morris Close
Park Farm, Wellingborough GB-Northants, NN8 6 XF
fon: [phone] • fax: [phone]
net: www.keb-uk.co.uk • mail: i[email protected].uk
KEB Italia S.r.l.
Via Newton, 2 • I-20019 Settimo Milanese (Milano)
fon: [phone] • fax: [phone]
net: www.keb.it • mail: [e-mail]
KEB - YAMAKYU Ltd.
15–16, 2–Chome, Takanawa Minato-ku
J–Tokyo 108-0074
fon: [phone] • fax: [phone]
mail: [e-mail]
KEB Antriebstechnik
Leidsevaart 126 • NL–2013 HD Haarlem
fon: [phone] • fax: [phone]
mobil: [phone]
mail: [e-mail]
KEB Portugal
Lugar de Salgueiros – Pavilhao A, Mouquim
P-4760 V. N. de Famalicao
fon: [phone] • fax: [phone]
mail: keb.port[email protected]
KEB Taiwan Ltd.
1F, No.19-5, Shi Chou Rd., Tounan Town
R.O.C.-Yin-Lin Hsian / Taiwan
fon: [phone] • fax: [phone]
mail: [e-mail]
KEB Sverige
Box 265, Bergavägen 19
S-430 93 Hälsö
fon: [phone] • fax: [phone]
mail: thomas.c[email protected]
KEBCO Inc.
1335 Mendota Heights Road
USA-Mendota Heights, MN 55120
fon: [phone] • fax: [phone]
net: www.kebco.com • mail: i[email protected]
