KEBCO COMBICONTROL C5 User manual

COMBICONTROL
Mat.No. Rev.
00C5CEB-K140 1D
GB Instruction Manual C5 Compact

2
Preface
Karl E. Brinkmann GmbH reserves itself the right to change/adapt specications and
technical data without previous notication.
The safety and warning reference specied in this manual is not exhaustive. The manual
and the information contained in it is made with care. KEB don´t accept a guarantee for
misprint or other errors or resulting damages.
The marks and product names are trade marks or registered trade marks of the respective
title owners.
The information contained in the technical documentation, as well as any user-specic advice
in spoken and written and through tests, are made to best of our knowledge and information
about the application. However, they are considered for information only without responsibility.
This also applies to any violation of industrial property rights of a third-party.
Inspection of our units in view of their suitability for the intended use must be done generally
by the user. Inspections are particulary necessary, if changes are executed, which serve for
the further development or adaption of our products to the applications (hardware, software
or download lists). Inspections must be repeated completely, even if only parts of hardware,
software or download lists are modied.
Application and use of our units in the target products is outside of our control and
therefore lies exclusively in the area of responsibility of the user.

GB - 3
Inhalt
1. Description of the unit............................................................................. 4
1.1 Application .............................................................................................................4
1.2 Construction ..........................................................................................................4
1.3 CE-certications ....................................................................................................4
1.4 Unitidentication ..................................................................................................4
1.5 Technical data ........................................................................................................5
1.6 Accessories............................................................................................................6
2. Functional Description ............................................................................ 7
2.1 Real-time clock ......................................................................................................7
2.2 HSP5/485 interfaces to the inverter/servo axes..................................................7
2.2.1 View of the inverter interfaces X1A...X1D for the axes 1..4.....................................8
2.2.2 Assignment of the HSP5/485 interfaces ..................................................................8
2.2.3 HSP5 Operator with screw terminal (00F5060-9001)..............................................9
2.2.4 HSP5 Operator with RJ45 socket (00F5060-9002) .................................................9
2.2.5 Adapter cable HSP5 interface operator .................................................................10
2.2.6 Comparison of the standards.................................................................................10
2.3 Voltage supply and digital inputs and outputs .................................................11
2.3.1 Assembly of the wires............................................................................................11
2.3.2 Voltage supply of the control..................................................................................12
2.3.3 Voltage supply for the inputs and outputs..............................................................12
2.3.4 Digital inputs (X2.11…14) ......................................................................................13
2.3.5 Digital outputs (X2.15…18)....................................................................................13
2.4 The operating unit.................................................................................. 14
2.5 Serial interface (X6A)...........................................................................................14
2.6 Ethernet interface (X6B/X6C)..............................................................................15
2.7 Description of the LED’s .....................................................................................15
2.8 Multi-function switch/button S1 .........................................................................16
2.9 File system ...........................................................................................................16
3. Software.................................................................................................. 17
3.1 Programming system CoDeSys .........................................................................17
3.2 Parameterizing system COMBIVIS.....................................................................17
3.3 Parameter description.........................................................................................18
3.3.1 Runtime and error monitoring ................................................................................18
3.3.2 Ethernet parameter................................................................................................19
3.3.3 Real-time clock ......................................................................................................20
3.3.4 Process image .......................................................................................................21
3.3.5 Userdenition parameter .......................................................................................22
3.3.6 System parameter .................................................................................................23
3.3.7 Debugging .............................................................................................................24
3.4 System variables .................................................................................................25

GB - 4
COMBICONTROL
1. Description of the unit
1.1 Application
KEB COMBICONTROL C5 is a programmable control with direct connection upto four KEB
frequency inverters/servo axes of the series F5. The connection to the axes is created as
HSP5/485. All axes can be operated directly and synchronously with an inexpensive operator
with this fast, reliable connection. Cycle times down to one millisecond are realizable. This
manual describes the release of the rmware V1.4 and higher.
The axis control is programmed with the uniform IEC 61131-3 programming system CoDeSys
of the 3S-Software Company, Kempten (Germany) (www.3s-software.com).
1.2 Construction
The control consists of following modules:
• CPU and memory
• internal ash le system
• Switching power supply
• Real-time clock
• HSP5/485-interfaces to the inverter/servo axes
• Ethernet interfaces
• serial interface
• Control and error LED’s
• RUN/Reset switch
• Voltage supply connection
• four digital inputs
• four digital outputs
• Field bus interface (optional)
1.3 CE-certications
This unit was tested in accordance with the generic standard EN 61000-6-2 in the range of noise
immunity and corresponds to the EMC directive 89/336/EWG with changes/extensions.
1.4 Unitidentication
C5 Material number Description
Compact 14C5B00-1000 4DI/4DO

GB - 5
COMBICONTROL
1.5 Technical data
General
Dimensions (HxBxT) 125 x 44 x 144 mm
Weight approx. 260 g
Installation method 35 mm Mounting rail
Grounding via terminal strip or plug-in contact
Protective system (EN 60529) IP20
Operation temperature -10…45 °C (14…113 °F)
Storage temperature -25…70 °C (-13…158 °F)
Climatic category (EN 60721-3-3) 3K3
Environment (IEC 664-1) Pollution degree 2
Control
Operating voltage control (US) 18…30 VDC ±0 %
Power input control 3 W max.
Digital inputs/outputs
Wiring system cage-clamp terminals
Operating voltage inputs/outputs (UM) 18…30 VDC ±0 %
Output current max. 0,7 A per channel, short-circuit proof,
free-wheeling diode integrated
Input voltage/current according to IEC 61131-2 Type 1
Axis interface
Type HSP5/485
Connector RJ-45, 8-pole, screened
Cable Cat5, max. 100 m
Speed 38,4…250 kBaud
Use Connection to KEB F5 inverter/servo, process
data transmission, communication channel
Ethernet interfaces
Type IEEE802.3
10/100BaseTx
2-Port Switch
Connector RJ-45, 8-pole, screened
Speed 10/100 MBaud
autocrossover

GB - 6
COMBICONTROL
Use Connection to CoDeSys (programming sy-
stem, debugging, visualization).
Connection to COMBIVIS (control and axis
adjustment, Scope)
Connection to any devices (Socket-APi)
Serial interface
Type DIN66019II, RS232, RS485 full/half duplex
Connector D-Sub 9 female
Speed 9,6…115,2 kBaud
Use Connection to COMBIVIS (control and axis
adjustment, Scope)
Connection to any devices (Socket-APi)
Memory of the programming system
Code 8 MB, double for online change
Data 12 MB
Retain 31 KB
Flag area 32 KB
Input 2 KB
Output 2 KB
1.6 Accessories
Operators Material number
F5 HSP5/485, screw terminal 00F5060-9001
F5 HSP5/485, RJ45 00F5060-9002
Supply cable Material number
Cable RS232 for COMBIVIS 0058025-001D
Cable RJ45 open end (for operator -9001), 2,5 m 00F50C3-2025
Patch cable RJ45 (for operator -9002), 5 m 00F50C3-1050

GB - 7
COMBICONTROL
2. Functional Description
The C5 compact is mounted on a 35 mm mounting rail. The earthing occurs with a plug-in
contact or terminal connection X2.19/20.
2.1 Real-time clock
The integrated real-time clock is maintenance-free (no battery) and operates without power
supply for approx.30 days. After this time it must be adjusted again. A read out parameter
indicates the validity of the date and time. The control shall remain switched on min. 30 minutes
for complete loading. Leap years are recognized automatically up to the year 2099. Date and
time can be read and set via COMBIVIS or the control program.
2.2 HSP5/485 interfaces to the inverter/servo axes
Up to four KEB COMBIVERT F5 can be connected via the terminals X1A to X1D. The
connection occurs via reliability RS485 cables, which can be up to 100 m long. A shielded
standard cable with RJ-45 connector is used on the control side and appropriate operator
on the frequency inverter/servo. The process data of the required axes are exchanged by
the control in the cyclic or synchronous mode. Service 50 (1*32 + 2*16 Bit process data) is
used thereby. The parameter channel is free for the PLC program and COMBIVIS access
to the axes. Depending on the used axes the cycle time can be between 1 and 65 ms. The
process data assignment in the axes must be adjusted before starting the cyclic/synchronous
operation in parameters SY.16…31 (if not stored in the axes).
The process data are mapped-in as follows in the image of the control:
%IW8+9 %ID4 1. Word (32 Bit) of axis 1 %QD4 1. Word (32 Bit) to axis 1
%IW10 2. Word (16 Bit) of axis 1 %QW10 2. Word (16 Bit) to axis 1
%IW11 3. Word (16 Bit) of axis 1 %QW11 3. Word (16 Bit) to axis 1
%IW16+17 %ID8 1. Word (32 Bit) of axis 2 %QD8 1. Word (32 Bit) to axis 2
%IW18 2. Word (16 Bit) of axis 2 %QW18 2. Word (16 Bit) to axis 2
%IW19 3. Word (16 Bit) of axis 2 %QW19 3. Word (16 Bit) to axis 2
%IW24+25 %ID12 1. Word (32 Bit) of axis 3 %QD12 1. Word (32 Bit) to axis3
%IW26 2. Word (16 Bit) of axis 3 %QW26 2. Word (16 Bit) to axis3
%IW27 3. Word (16 Bit) of axis 3 %QW27 3. Word (16 Bit) to axis3
%IW32+33 %ID16 1. Word (32 Bit) of axis 4 %QD16 1. Word (32 Bit) to axis 4
%IW34 2. Word (16 Bit) of axis 4 %QW34 2. Word (16 Bit) to axis 4
%IW35 3. Word (16 Bit) of axis 4 %QW35 3. Word (16 Bit) to axis 4

GB - 8
COMBICONTROL
2.2.1 View of the inverter interfaces X1A...X1D for the axes 1..4
X1B (axis 2) —— —— X1A (axis 1)
X1D (axis 4) —— —— X1C (axis 3)
2.2.2 Assignment of the HSP5/485 interfaces
X1A…D Name Description Socket (top view)
1 TXD+ Transmission signal+
1 8
2 TXD- Transmission signal-
3 GND Reference potential
4 RXD+ Receive signal+
5 RXD- Receive signal-
6 GND Reference potential
7 EnTXD+ Handshake transmission
signal+
8 EnTXD- Handshake transmission
signal-
-Shielding Shielding

GB - 9
COMBICONTROL
2.2.3 HSP5 Operator with screw terminal (00F5060-9001)
X6E Name Description
No cables may be connected
to terminal VCC. High voltage
can destroy the interface in the
control.
1 TXD- Transmission signal-
2 TXD+ Transmission signal+
3 RXD- Receive signal-
4 RXD+ Receive signal+
5 EnTXD- Handshake transmission signal-
6 EnTXD+ Handshake transmission signal+
7EnRxD- Handshake receive signal-
8EnRxD+ Handshake receive signal+
9 GND Reference potential
10 VCC +24 V voltage output
-Shielding Shielding (see gure)
2.2.4 HSP5 Operator with RJ45 socket (00F5060-9002)
RJ45 Name Description
1 RXD+ Receive signal+
2 RXD- Receive signal-
3 GND Reference potential
4 TXD+ Transmission signal+
5 TXD- Transmission signal-
6 GND Reference potential
7EnRxD+ Handshake receive signal+
8EnRxD- Handshake receive signal-
- Shielding Shielding
The connection to the control is realized with a commercial CAT5 Patch cable for this ope-
rator.
X6E

GB - 10
COMBICONTROL
2.2.5 Adapter cable HSP5 interface operator
Screw terminal:
Color see below C5 PCC
X1A…H
Signal TXD+ TXD- GND RXD+ RXD- GND EnTXD+ EnTXD-
PIN 1 2 3 4 5 6 7 8
| | | | | | | |
PIN 4 3 9 2 1 9 8 7 Operator
X6E
Signal RXD+ RXD- GND TXD+ TXD- GND EnRxD+ EnRxD-
Color see below
RJ45 connection:
Color see below C5 PCC
X1A...H
Signal TXD+ TXD- GND RXD+ RXD- GND EnTXD+ EnTXD-
PIN 1 2 3 4 5 6 7 8
|||||| | |
PIN 1 2 3 4 5 6 7 8 Operator
RJ45
Signal RXD+ RXD- GND TXD+ TXD- GND EnRxD+ EnRxD-
Color see below
Inc a s e o f p r o d u c t I o n o f o w n c o n n e c t I n g c a b l e s p l e a s e p a y a t t e n t I o n t h a t t h e s I g n a l p a I r s (e.g.
txd+ a n d txd -) a r e a s s I g n e d t o t h e c o r r e s p o n d I n g t w I s t e d c a b l e s (e.g. g r e e n a n d g r e e n /
w h I t e ). co n n e c t u n -u s e d s c o r e s a l w a y s t o gnd.
2.2.6 Comparison of the standards
Pair PIN EIA/TIA568B EIA/TIA568A DIN 47100 IEC 189.2 USOC
3 1 orange/white green/white green red black
3 2 orange green yellow orange yellow
2 3 green/white orange/white grey black orange
1 4 blue blue brown blue red
1 5 blue/white blue/white white white green
2 6 green orange pink green brown
4 7 brown/white brown/white blue yellow grey
4 8 brown brown red brown blue

GB - 11
COMBICONTROL
2.3 Voltage supply and digital inputs and outputs
Figure 2.3 Socket X2
Voltage supply Digital inputs and outputs
+ Voltage input (UM)
(internally interconnected)
111 Digital input 0
2 12 Digital input 1
3 13 Digital input 2
4 14 Digital input 3
- Voltage input (UM)
(internally interconnected)
515 Digital output 0
616 Digital output 1
7 17 Digital output 2
818 Digital output 3
+ Voltage input (US) 919 PE
- Voltage input (US) 10 20
2.3.1 Assembly of the wires
Required tools:
Screw driver
SD 0,4 x 2,5 (DIN 5264)
1. Strip cable
Cable permissible cross-section
exible 0,2…1mm2
Wire-end ferrule 0,13…0,34mm2
7mm
2. Plug screw driver into the square slot to the midside

GB - 12
COMBICONTROL
3. Plug cable into the round slot, that no wires can be seen
from the outside.
4. Remove screw driver and check if cables are xed.
2.3.2 Voltage supply of the control
The voltage for supply of the control (US) occurs via terminals X2.9 and X2.10 in accordance
with picture 2.3.2 and is electrically insulated from UM. If the control is supplied with voltage,
the VCC-LED ashes (green).
Picture 2.3.2 Voltage supply of the control
U = 18…30 V DC ±0 %
F1 = 2A type gG
+
-
U
F1
X2.9
X2.10
2.3.3 Voltage supply for the inputs and outputs
The voltage for supply of the digital inputs and outputs (UM) occurs via the terminals X2.1 to
X2.8 in accordance with picture 2.3.3 and is electrically insulated from US.
%IW1
%IX1.0 Condition of the supply voltage in/outputs (UM)
%IX1.1 Is set in case of overload at one or several outputs. Additio-
nally the OL-LED (red) is set.
%IX1.2…%IX1.15 not assigned

GB - 13
COMBICONTROL
Picture 2.3.3 Voltage supply for the inputs and outputs
U = 18…30 V DC ±0 %
F2 = 6,3A type gG
+
-
U
F2
X2.1...4
X2.5...8
2.3.4 Digital inputs (X2.11…14)
The digital inputs are potential-free to the control voltage US.
4 digital inputs 0...3
%IW0 %IX0.0…%IX0.3 Condition of the digital inputs 0…3 not assigned
%IX0.4…%IX0.15
Picture 2.3.4 Connection of the digital inputs
Potential-free connection Connection e.g. via PLC
X 2.2 (+UM)
X 2.12 (I1)
+
-
X2.2 (+UM)
X2.5 (- UM)
X2.12 ( I1 )
П
2.3.5 Digital outputs (X2.15…18)
The digital outputs are potential-free to the control voltage US. A free-wheeling diode is inte-
grated in the unit, so that no external wiring is necessary at inductive load.
4 digital outputs 0...3
%QW0 %QX0.0…%QX0.3 Condition of the digital outputs 0…3 not assigned
%QX0.4…%QX0.15
Picture 2.3.5 Connection of the digital outputs
Ohmic load Inductive load
X 2.16 (O1)
X 2.6 (- UM)
X 2.17 (O2)
X 2.7 (- UM)

GB - 14
COMBICONTROL
2.4 The operating unit
View Front Name Function Addition View from the
bottom
S1 Multi function switch/button
RUN Run-LED green
ERROR ERROR-LED red
OL Overload red
VCC Voltage supply (US) green
X6A Serial interface COMBIVIS
X6B Ethernet interface COMBIVIS/
CoDeSys
X6C Ethernet interface
X1A…D Axis interfaces
2.5 Serial interface (X6A)
The socket X6A is a serial RS232/485 interface. It serves for the connection of the control
with a PC or other operating units via the protocol DIN66019II. Alternatively access to this
interface can occur by the control program.
X6A Name Description SUB-D9 socket
1 PGM No wiring ! (top view)
2TxD Transmission signal RS232
54321
9 8 76
54321
9876
3RxD Receive signal RS232
4RxD-A Receive signal RS485 A
5RxD-B Receive signal RS485 B
6 PGM+ No wiring !
7 DGND Data reference potential
8TxD-A Transmission signal RS485 A
9TxD-B Transmission signal RS485 B
9pol. SUB-D coupling 9 pol. SUB-D connector
Part.No.: 0058025-001D
RS 232 cable
2,8 m Housing (PE)
PC C5

GB - 15
COMBICONTROL
2.6 Ethernet interface (X6B/X6C)
The standardized 10/100 base-T interface supports the protocols TCP/IP and UDP/IP. The
two interfaces are internally connected as switch.
The following ports have these functions:
The CoDeSys port is adjusted to 1200 (as standard). The port can be changed with para-
meter Et.03. The control program is processed here by means of CoDeSys (only TCP/IP
possible).
The COMBIVIS port is adjusted to 8000 (as standard). It can be changed with parameter
Et.02. The access of COMBIVIS or other control/visualizations to parameters of the control,
the axes as well as if necessary by the control program dened parameter occurs here. TCP
or UDP is possible as protocol, at which encapsulated DIN66019II data telegrams will be
transferred.
The used IP address can be adjusted with parameter Et.01. In case that a cross-over cable
is used for the connection, make sure that the upper part of the IP address (network number)
is the same and the lower part of the IP address (Node number) is different from the PC IP
address. The IP address may not have been used in the entire connected Ethernet.
Protect C5 against unauthorized access
Each user within a network can take access to the control with knowledge of the IP address.
The C5 should be absolutely protected against unauthorized access. For the protection
• the write access on the COMBIVIS port can be limited with parameter et.09.
• CoDeSys can be protected with a login-password.
2.7 Description of the LED’s
Run-LED green
off PLC program stopped or not available
on PLC program in run mode
ERROR-LED red
off O.K.
on Program error, exact error cause can be determined via CoDeSys.
fast blinking Hardware error, control must be restarted
OL-LED red
off no error at the outputs
on Overload or short circuit at the outputs
VCC-LED green
off no voltage supply
on Voltage supply available

GB - 16
COMBICONTROL
2.8 Multi-function switch/button S1
The multi function switch/button is constructed as follows:
run (switch)
stop/reset
clear (button)
The button S1 is assigned with the following functions
Activity Function
Stop --> Run Program is started
Run --> Stop Programm is stopped, all variables are resetted
(reset warm)
Stop --> Clear and hold (> 3 s) until
ERROR LED lights
After releasing the switch all retain variables are
resetted (reset cold)
Stop --> Clear and hold (> 10 s) until
ERROR and RUN LED light
All variables and the boot project are cleared (re-
set origin) after releasing the button.
2.9 File system
The le system consists of an internal ash memory (drive C:). Access can occur via CoDeSys
or directly from the program of the control.
Internalashmemory
This memory is accessed as drive C: and the boot project can be stored, which is automatically
loaded and started when switching on. Any other les (documentation, download lists, prescrip-
tions, etc.) can be stored and read here. The following particularities must be observed:
• Access is possible only to les in the root directory.
• Only short le names (8.3 format) are possible.
• Reading takes place with high speed and can occur also at any time in the time-critical
cyclic operating modes of the control.
• Writing occurs at a slow rate, because the ash must be programmed here. Any data can
be written if the control is in stop condition, but only one le can be opened for writing. If
the control is in run condition, only blocks of max. 32KByte can be written into the opened
le. As soon as this block was completely stored in the background the next data can be
written.
• Data is not physically deleted. First they are internal marked as deleted. Thus the free availa-
ble memory space decreases. The command "leformat" can be used via the CoDeSys PLC
browser. Thus the complete memory is formatted again. All data is irrevocable deleted.
• The deleted memory space can be make available again with the command "lecleanup"
without reformatting.

GB - 17
COMBICONTROL
3. Software
3.1 Programming system CoDeSys
The axis control is programmed with the programming system CoDeSys of the company 3S-
Software (www.3s-software.com). This programming software is free-available in the Internet.
A KEB target information le (TNF) for the control is available as accessories, which contains
all required hardware specications. A library with rmware functional modules is further con-
tained for access to the periphery (axes, real-time clock, switch, LED, le system). The use
of these functional modules is explained in the provided example projects.
The connection to CoDeSys occurs via the Ethernet interface X6B or X6C via IP protocol. For
this the control is connected with a 1:1 cable to the distribution system of an existing rm net
or by means of a cross cable directly to the network interface of a PC. IP-address and port
number can be adjusted at rst via COMBIVIS. TCP/IP (Level2) is selected with the following
adjustments in the CoDeSys communication parameter:
Address (as adjusted)
Port 1200 (or as changed)
Block size 512
Motorola Byteorder Yes
3.2 Parameterizing system COMBIVIS
The axis control can be parameterized and monitored with COMBIVIS. COMBIVIS is free-
available in the Internet (www.keb.de). Access to all axes is possible via the control with
COMBIVIS. The control has the node address 0, the axes have the node addresses 1 to 4.
Connection with COMBIVIS occurs via Ethernet interface X6B or X6C via IP protocol or the
serial interface X6A. IP-address and port number can be adjusted rst via the serial interface
and COMBIVIS. Afterwards the protocol TCP or UDP as well as the correct IP-address of
the control is selected in the COMBIVIS IP protocol driver. The data port number is 8000, if
necessary it can be changed.
The following must be observed on access to axis:
• First the axes must be switched on, then the control, or the function block 'tSetModes' must
call-up in order to make the connection between control and axis. Thus the baud rate between
axis and control is adjusted to the highest possible value and the axis can be accessed via
COMBIVIS. (After power-on reset the inverter /servo starts always with 38,4 KBaud)
• If an axis is operated cyclically or synchronously, only the indirect set addressing can be
used in COMBIVIS. This applies also to download and scope

GB - 18
COMBICONTROL
3.3 Parameter description
3.3.1 Runtime and error monitoring
The ru-parameters serve for monitoring of the program ow.
ru.00 Status Address 0200h
Program status no prog no program loaded
prog OK program loaded
prog corrupt program checksum error
Control status run Program runs
Stop Program stopped
breakpoint Program is on break point
Error status err_cyctime The adjusted cycle time was exceeded
err_watchdog The length of the last PLC cycle exceeded the
maximum value, the PLC program was stopped.
ru.01 cycle time Address 0201h
This parameter indicates the cycle time adjusted by the PLC program in milliseconds.
This value is also used for the cycle time monitoring, a value of 0 ms means a free-run-
ning PLC program without cycle time monitoring.
ru.02 axis mode Address 0202h
The parameter indicates the axis conguration adjusted by the PLC program. There is a
differentiation between normal- and synchronous/cyclic operation.
ru.03 axis errors Address 0203h
The parameter indicates the axes which did not respond. This can have been released by
interruption of the cable to the axis or by switching off the axis. The value 0 means that all
monitored axes are connected correctly.
ru.04 min. process time Address 0204h
ru.05 max. process time Address 0205h
ru.06 response time Address 0206h
ru.07 process time Address 0207h
ru.08 idle time Address 0208h
The cycle time of a PLC program ow is composed of:
response time Time of recognizing the new program cycle up to the call of the PLC
program
process time Time, when the PLC program as well as all accesses by CoDeSys
and COMBIVIS are processed.
idle time Remaining time up to the next program cycle.
Parameter ru.04 / ru.05 displays the minimum/maximum process time and can be reset
by writing of any value.

GB - 19
COMBICONTROL
3.3.2 Ethernet parameter
The following parameters contain the values, which are needed for the communication via
the Ethernet interface.
et.00 MAC address Address 0300h
The MAC address (Media Access Control) is formed of 6 byte. The rst three bytes
contain the manufacturer's code (00-08-FA). Only the lowest 4 bytes are displayed here
„FAxxxxxx“. This address is assigned by the manufacturer and cannot be changed.
et.01 IP address Address 0301h
The IP address consists of 4 bytes and is the clear identication of one Internet partici-
pant (called node by such a way). In case of doubt the network administrator gives the
address to be adjusted.
When using a direct connection of control and PC with a cross cable, this IP address
should be adjusted in such a way that the difference is only in the lowest byte to the
address of the PC's (same network but different node).
et.02 COMBIVIS port number Address 0302h
The port number for the access via COMBIVIS is adjusted with this parameter. The stan-
dard value is 8000 and normally it is not changed.
et.03 CoDeSys port number Address 0303h
This parameter adjusts the port number, under which CoDeSys establishes the connec-
tion. The standard value is 1200 and normally it is not changed.
et.04 IP error count Address 0304h
Serves for the diagnosis of the IP protocol stack.
et.05 TCP connections Address 0305h
This parameter displays the number of active TCP/IP connections.
et.06 UDP connections Address 0306h
This parameter displays the number of active UDP connections.
et.07 PGM logged in Address 0307h
This parameter displays that there is an online connection to CoDeSys. A further login via
CoDeSys is not possible then.
et.08 TCP multicount Address 0308h
This parameter serves only for diagnostic purposes.

GB - 20
COMBICONTROL
et.09 data port password Address 0309h
This parameter denes the write protection password for the COMBIVIS data port. The
programming of the password occurs only via the serial interface. Then this password
must be entered here again for write access via the data port. Error message "operation
not possible" is displayed in case of locked data port write access. Value 0 switches off
the write protection password.
et.10 gateway address Address 030Ah
This parameter determines the IP address of the appropriate gateway. As soon as
a connection to IP slave address outside the own network shall be made by the control
program, this address is used. In case of doubt the gateway address to be adjusted can
be ask for by the network administrator.
et.11 subnet mask Address 030Bh
The decision whether an IP slave address is outside of the own network is determined
with this mask. If this mask is 0.0.0.0 the standard masks are used depending on network
class A, B or C. In case of doubt the subnet mask to be adjusted can be ask for by the
network administrator.
et.12 data port response delay Address 030Ch
This parameter adjusts the response delay for the Combivis-data port in ms. The network
utilization can be reduced by setting of higher values. A value of 0 enables the fastest
communication with the control, but a high network utilization is also generated.
et.14 Link state Address 030Eh
Displays state informations for the Ethernet link.
et.15 Link mode Address 030Fh
Determines the adjustments of the Ethernet interface. Fixed values or automatic recogni-
tion can be adjusted here. The additional clearlock value 32 activates a special behavior,
which corrects link problems automatically with automatic detection on both sides (control
and switch).
3.3.3 Real-time clock
The internal real-time clock is adjusted and/or read-out with the following parameters.
rc.00 time Address 0400h
This parameter displays the time in hours and minutes in a 24-hours format. Writing on
this parameter adjusts the time.
