INSTALLATION INSTRUCTIONS
LTD14_F-5197_091118
Luminaires for transportation Applications
LUXTRAN™
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions
should always be followed, including the following:
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE
APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH
THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND
THE HAZARDS INVOLVED. DISCONNECT POWER TO ALL CIRCUITS
BEFORE WIRING FIXTURE. INSTALL IN ACCORDANCE WITH
ALL NATIONAL, STATE, AND LOCAL CODES. DO NOT CONNECT
TO AN UNGROUNDED SUPPLY. READ ALL FIXTURE MARKINGS
AND LABELS TO ENSURE CORRECT INSTALLATION OF FIXTURE.
SUPPLEMENTAL INSTRUCTIONS MAY BE LOCATED ON THE
FIXTURE, IN ADDITION TO THIS INSTRUCTION SHEET, REGARDING
ORIENTATION, OR MOUNTING RESTRICTIONS.
SAVE THESE INSTRUCTIONS
INSTALLATION INSTRUCTIONS
Read all xture markings and labels to insure correct installation of the xture. Additional information may be
located on the xture, separate from this instruction sheet, regarding orientation and mounting restrictions.
Disconnect power to main circuits before wiring xture. Remove door/housing to gain access to the inside of the
xture.
LTD14 - FLUORESCENT SERIES
1. Attach luminaire to mounting brackets using 3/8” -
316 SS bolts, lock nuts and lock washers.
3. Remove four (4) 1/4 turn screws and remove
electrical tray.
2. Unlatch and remove door.

www.kenall.com |P: 800-4-Kenall |F: 262-891-9701 |10200 55th Street Kenosha, Wisconsin 53144, USA
This product complies with the Buy American Act: manufactured in the United States with more than 50% of the component cost of US origin. It may be covered by patents
found at www.kenall.com/patents.Content of specication sheets is subject to change; please consult www.kenall.com for current product details. ©2019 Kenall Mfg.Co.
2
INSTALLATION INSTRUCTIONS
LTD14_F-5197_091118
Care should be exercised when these xtures will not be installed immediately upon delivery, and if they will
not be put into service immediately after installation. Proper xture performance and a “like new” appearance
can only be assured if precautions are taken after xtures arrive. If xtures will be on site but uninstalled for any
length of time please follow these precautions to prevent damage to the xtures:
Fixtures should be left palletized in the cardboard gaylord, in an indoor area. If gaylord is opened, xtures should
be indoors and left in their plastic bags to protect from dirt and moisture.
CAUTION
For technical assistance, call 1-800-4KENALL (1-800-453-6255).
CUSTOMER SERVICE
4. Bring main power and make electrical connection
to terminal block.
5. Close and secure electrical tray with 1/4 turn
screws (reverse step 3).
6. Close and secure door with latches (reverse step 2).
For warranty information visit www.kenall.com/Resources/Certied-Performance-Warranties
WARRANTY
