Kenwood DDX371 User manual

Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best performance from your new DVD-receiver.
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below. Refer to the model and serial
numbers whenever you call upon your Kenwood dealer for information or service on the product.
Model DDX771/DDX491HD/DDX471HD/DDX371/DDX310BT/DDX3071BT/DDX271/DDX2071 Serial number
US Residents Only
Register Online
Register your Kenwood product at www.Kenwoodusa.com
LVT2506-001A (KN/RN)© 2013 JVC KENWOOD Corporation
DDX771
DDX491HD
DDX471HD
DDX371
MONITOR WITH DVD RECEIVER
INSTRUCTION MANUAL
This HD Radio receiver enables:
DDX310BT
DDX3071BT
DDX271
DDX2071
DDXEntryK.indb1 2013/11/0116:10

2
CONTENTS
BEFORE USE...................................................2
How to reset your unit.................................................... 3
INITIALSE TTINGS .........................................4
BASICS ...........................................................6
Component names and functions............................. 6
Common operations....................................................... 7
Common screen operations......................................... 8
Selecting the playback source..................................... 9
DISCS ...........................................................10
USB...............................................................14
iPod/iPhone ................................................15
Pandora® (Only for DDX771/DDX491HD/
DDX471HD/DDX371/DDX310BT/DDX271) ......19
TUNER (Only for DDX771/DDX371/DDX310BT/
DDX3071BT/DDX271/DDX2071).....................21
HD Radio™ tuner
(Only for DDX491HD/DDX471HD)...................23
SiriusXM® RADIO
(Only for DDX771/DDX491HD/DDX471HD/
DDX371/DDX310BT/DDX271).........................26
OTHER EXTERNAL COMPONENTS .............31
Using external audio/video players—AV-IN ........31
Using a rear view camera ............................................31
BLUETOOTH
(Only for DDX771/DDX491HD/DDX471HD/
DDX371/DDX310BT/DDX3071BT)...................32
SETTINGS.....................................................40
Sound adjustment .........................................................40
Adjustment for video playback.................................41
Changing display design.............................................43
Customizing the <Top Menu> screen....................44
Customizing the system settings .............................44
Setting menu items.......................................................46
REMOTE CONTROLLER ...............................49
CONNECTION/INSTALLATION ...................53
REFERENCES................................................58
Maintenance....................................................................58
More information...........................................................58
Error message list...........................................................62
Troubleshooting.............................................................63
Notice/Caution on using Bluetooth device..........65
Specifications...................................................................65
How to read this manual:
• Illustrations of DDX771 are mainly used for explanation. The displays and panels shown in this manual
are examples used to provide clear explanations of the operations. For this reason, they may be different
from the actual displays or panels.
• This manual mainly explains operations using the buttons on the monitor panel and touch panel. For
operations using the remote controller (RC-DV340: supplied only for DDX3071BT/DDX2071), see page
49.
• < > indicates the various screens/menus/operations/settings that appear on the touch panel.
• [ ] indicates the buttons on the touch panel.
• Indication language: English indications are used for the purpose of explanation. You can select the
indication language from the <Setup> menu. (Page48)
BEFORE USE
WARNINGS: (To prevent accidents and
damage)
• DO NOT install any unit or wire any cable in a
location where;
– it may obstruct the steering wheel and gearshift
lever operations.
– it may obstruct the operation of safety devices
such as air bags.
– it may obstruct visibility.
• DO NOT operate the unit while driving.
If you need to operate the unit while driving, be
sure to look around carefully.
• The driver must not watch the monitor while
driving.
ForDDX 3071BT/DDX2071:
The marking of products using lasers
The label is attached to the chassis/case and says
that the component uses laser beams that have
been classified as Class 1. It means that the unit is
utilizing laser beams that are of a weaker class. There
is no danger of hazardous radiation outside the unit.
DDXEntryK.indb2 2013/11/0116:10

ENGLISH 3
For DDX771/DDX491HD/DDX471HD/DDX371/
DDX310BT/DDX271:
CAUTION
Use of controls or adjustments or performance
of procedures other than those specified herein
may result in hazardous radiation exposure. In
compliance with Federal Regulations, the following
are reproductions of labels on, or inside the product
relating to laser product safety.
JVCKENWOOD Corporation
2967-3, ISHIKAWA-MACHI, HACHIOJI-SHI, TOKYO,
JAPAN
THIS PRODUCT COMPLIES WITH DHHS RULES
21CFR SUBCHAPTER J IN EFFECT AT DATE OF
MANUFACTURE.
Location : Top plate
For DDX771/DDX491HD/DDX471HD/DDX371/
DDX310BT/DDX271:
FCC WARNING
This equipment may generate or use radio
frequency energy. Changes or modifications to this
equipment may cause harmful interference unless
the modifications are expressly approved in the
instruction manual. The user could lose the authority
to operate this equipment if an unauthorized
change or modification is made.
FCC NOTE
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment may cause harmful interference to
radio communications, if it is not installed and used
in accordance with the instructions. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Cautions on the monitor:
• The monitor built into this unit has been
produced with high precision, but it may have
some ineffective dots. This is inevitable and is not
considered defective.
• Do not expose the monitor to direct sunlight.
• Do not operate the touch panel using a ball-point
pen or similar tool with a sharp tip.
Touch the buttons on the touch panel with your
finger directly (if you are wearing a glove, take it
off).
• When the temperature is very cold or very hot...
– Chemical changes occur inside, causing
malfunction.
– Pictures may not appear clearly or may move
slowly. Pictures may not be synchronized with
the sound or picture quality may decline in such
environments.
For safety...
• Do not raise the volume level too much, as this
will make driving dangerous by blocking outside
sounds, and may cause hearing loss.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or
cold weather, wait until the temperature in the car
becomes normal before operating the unit.
How to reset your unit
DDX771
DDX491HD/DDX471HD/DDX371/DDX310BT/
DDX3071BT/DDX271/DDX2071
If the unit fails to operate properly, press the Reset
button. The unit returns to factory settings when
the Reset button is pressed (except the registered
Bluetooth devices).
BEFORE USE
DDXEntryK.indb3 2013/11/0116:10

4
INITIAL SETTINGS
Initials etup
When you power on the unit for the first time or
reset the unit, the initial setting screen appears.
• You can also change the settings on the <Setup>
screen. (Page46)
1
DDX271
DDX771
DDX491HD/DDX471HD/DDX371/
DDX310BT/DDX3071BT/DDX2071
<Language>
(Page48)
Select the text language used for
on-screen information.
• Set <GUI Language> to
display the operation buttons
and menu items in the
selected language ([Local]:
initially selected) or English
([English]).
<Angle>*1
(Page7)
Adjust the panel angle.
<AV Input>
(Page47)
Select an external component
connected to the iPod/AV-IN2
input terminal to play.
<External
BUS>*2
(Page47)
Select the component
connected to EXT I/F input
terminal—[OEM] for ADS
adapter or [SXi] for SiriusXM
Connect Vehicle Tuner.
<R-CAM
Interrupt>
(Page47)
Select [On] when connecting
the rear view camera.
<Panel
Color>
(Page43)
Select the color of the buttons
on the monitor panel.
2 Finish the procedure.
The <Top Menu> screen is displayed.
*1Only for DDX771.
*2Only for DDX271.
Activating the security function
You can activate the security function to protect
your receiver system against theft.
1 Display the <Top Menu> screen.
On the source control screen:
2Display the <System> setting screen.
DDXEntryK.indb4 2013/11/0116:10

ENGLISH 5
INITIAL SETTINGS
3
The security indicator on the monitor panel
flashes when the vehicle ignition is off.
To deactivate the security function: Select [OFF]
for <SI>.
Clock settings
1Display the <Top Menu> screen.
On the source control screen:
2Display the <Setup> screen.
3Display the <Clock> screen.
4Set the clock time.
<Radio Data
System>
Synchronizes the clock time with
FM RBDS.
<OFF> Sets the clock manually. (See
below.)
When selecting <OFF>:
Adjust the hour (1), then adjust the minute (2).
• Press [Reset] to set the minute to “00”.
5Finish the procedure.
DDXEntryK.indb5 2013/11/0116:10

6
BASICS
Component names and functions
DDX771
1Monitor panel*
2Screen (touch panel)
3Reset button/Power indicator/Security indicator
•Resets the unit. (Page 3)
•Lights up while the unit is turned on.
•Flashes when the security function is activated.
(Page 4)
4Volume K/Jbutton
Adjusts the audio volume. (Page 7)
5AV/AV OUT button
•Displays the current source screen. (Press)
•Selects the AV source for external monitor or
amplier. (Hold)
6AUD/R-CAM button
•Displays the <Tone> screen. (Press)
(Page 40)
•The function of the button when held varies
depending on the <AUD Key Long Press>
setting. (Page 48)
7MENU button
•Displays the <Top Menu> screen. (Press)
(Page 8)
•Turns o the power. (Hold) (Page 7)
•Turns on the power. (Press) (Page 7)
8TEL/VOICE button
•Displays the <Handsfree> screen. (Press)
(Page 35)
•Activates voice dialing. (Hold) (Page 37)
9M(Eject) button
•Ejects the disc (Tilts the monitor panel fully).
•Opens/closes the monitor panel.
DDX491HD/DDX471HD/DDX371/DDX310BT/
DDX3071BT/DDX271/DDX2071
DDX491HD/DDX471HD/
DDX371/DDX310BT/
DDX3071BT
DDX271/DDX2071
1Remote sensor
2Reset button/Power indicator/Security indicator
•Resets the unit. (Page 3)
•Lights up while the unit is turned on.
•Flashes when the security function is activated.
(Page 4)
3M(Eject) button
Ejects the disc.
4Loading slot
5MENU button
•Displays the <Top Menu> screen. (Press)
(Page 8)
•Turns o the power. (Hold) (Page 7)
•Turns on the power. (Press) (Page 7)
6AV/AV OUT button
•Displays the current source screen. (Press)
•Selects the AV source for external monitor or
amplier. (Hold)
7For DDX491HD/DDX471HD/DDX371/
:TB1703XDD/TB013XDD Volume/ATT/AUD
knob
•Attenuates the sound. (Press) (Page 7)
•Adjusts the audio volume. (Turn) (Page 7)
•Displays the <Tone> screen. (Hold)
(Page 40)
For DDX271/DDX2071 Volume/ATT knob
•Attenuates the sound. (Press) (Page 7)
•Adjusts the audio volume. (Turn) (Page 7)
8For DDX491HD/DDX471HD/DDX371/
:TB1703XDD/TB013XDD TEL/VOICE button
•Displays the <Handsfree> screen. (Press)
(Page 35)
•The function of the button when held varies
depending on the <TEL Key Long Press>
setting. (Page 48)
:1702XDD/172XDDroF AUD/V.OFF button
•Displays the <Tone> screen. (Press)
(Page 40)
•The function of the button when held varies
depending on the <AUD Key Long Press>
setting. (Page 48)
9Monitor panel*
pScreen (touch panel)
* You can change the color of the buttons on the monitor panel.
(Page 43)
Caution on the volume setting:
Digital devices produce very little noise
compared with other sources. Lower the
volume before playing these digital sources
to avoid damaging the speakers by sudden
increase of the output level.
DDXEntryK.indb6 2013/11/0116:10

ENGLISH 7
BASICS
Common operations
Turning on the power
DDX491HD/DDX471HD/
DDX371/DDX310BT/
DDX3071BT/DDX271/DDX2071
DDX771
Turning off the power
DDX491HD/DDX471HD/
DDX371/DDX310BT/
DDX3071BT/DDX271/DDX2071
DDX771
(Hold) (Hold)
Adjustingt hevo lume
To adjust the volume (00 to 35)
DDX771
Press to increase, and press to decrease.
• Holding the button increases/decreases the
volume continuously.
DDX491HD/DDX471HD/
DDX371/DDX310BT/
DDX3071BT/DDX271/DDX2071
Turn to the right to increase, and turn to the left to
decrease.
To attenuate the sound (only for DDX491HD/
DDX471HD/DDX371/DDX310BT/DDX3071BT/
DDX271/DDX2071)
The ATT indicator lights up.
To cancel the attenuation: Press the same button
again.
Adjusting the panel angle (only for
DDX771)
1Display the <Angle Adjust> screen.
On the <Top Menu> screen:
2Select an angle (0 – 6).
• To set the current position as the power off
position, select [Memory].
Putting the unit in standby
1Display all <Top Menu> items.
On the <Top Menu> screen:
2
DDXEntryK.indb7 2013/11/0116:10

8
BASICS
Turning off the screen
DDX491HD/DDX471HD/
DDX371/DDX310BT/
DDX3071BT*2
DDX771*1
(Hold)
(Hold)
(Hold)
DDX271/DDX2071*1
To turn on the screen: Press MENU on the
monitor panel, or touch the display.
*1 This operation works only when <AUD Key Long Press> is
set to [V-OFF]. (Page48)
*2This operation works only when <TEL Key Long Press> is
set to [V-OFF]. (Page48)
Common screen operations
Common screen descriptions
You can display other screens any time to change
the source, show the information, or change the
settings, etc.
Source control screen
Performs source playback operations.
• The operation buttons vary depending on the
selected source.
Common operation buttons:
[MENU]: Displays the <Top Menu> screen. (See
below.)
• Pressing MENU on the monitor panel also
displays the <Top Menu> screen.
<Top Menu> screen
Displays the source control screen and settings
screen.
1
3
2
Common operating buttons:
1Changes the playback source. (Page 9)
• Press [ALL SRC] to display all <Top Menu>
items. (Page 9)
• You can arrange the items to display on the
<Top Menu> screen (Page 44)
2Displays the <Handsfree> screen. (Page 35)
3Displays the <Setup> screen. (See below.)
<Setup> screen
Changes the detailed settings. (Page 46)
3
1
24
Common operating buttons:
1Selects the menu category.
2Displays the <Top Menu> screen.
3Changes the page.
4Returns to the previous screen.
DDXEntryK.indb8 2013/11/0116:10

ENGLISH 9
BASICS
Touch screen operations
1
3
2
4
1Displays the video control menu while playing a
video.
2Displays the source control screen while playing
a video.
• The operation buttons disappear when the
screen is touched or when no operation is
done for about 5 seconds.
3Goes to the previous chapter/track.*
4Goes to the next chapter/track.*
* Not available for video from an external component.
Selecting the playback source
• You can change the items (other than [SETUP]) to
display on the <Top Menu> screen. (Page44)
[DISC] Plays a disc. (Page 10)
[HD Radio]*1Switches to the HD Radio
broadcast. (Page 23)
[TUNER]*2Switches to the conventional radio
broadcast. (Page 21)
[iPod] Plays an iPod/iPhone. (Page 15)
[USB] Plays files on a USB device.
(Page 14)
[PANDORA]*3
Switches to the Pandora broadcast.
(Page 19)
[SiriusXM]*3Switches to the SiriusXM® radio
broadcast. (Page 26)
[TEL]*4
Displays the <Handsfree> screen.
(Page 35)
[Bluetooth]*4
Plays a Bluetooth audio player.
(Page 39)
[AV-IN1][AV-IN2]*5
Switches to an external component
connected to the AV-IN1 and iPod/
AV-IN2 input terminal. (Page 31)
[OEM Features]*
6
Switches to the sources via
connected ADS adapter.
(Page 56)
*1 Only for DDX491HD/DDX471HD.
*2Only for DDX771/DDX371/DDX310BT/DDX3071BT/DDX271/
DDX2071BT.
*3
Only for DDX771/DDX491HD/DDX471HD/DDX371/DDX310BT/
DDX271.
*4
Only for DDX771/DDX491HD/DDX471HD/DDX371/DDX310BT/
DDX3071BT.
*5
Select an appropriate input setting in <AV Input>. (Page 47)
*6Only for DDX271: select an appropriate input setting in
<External BUS>. (Page 47)
To display all sources and items on the
<Top Menu> screen
DDXEntryK.indb9 2013/11/0116:10

10
DISCS
Playing a disc
• If a disc does not have a disc menu, all tracks on
it will be played repeatedly until you change the
source or eject the disc.
• For playable disc types/file types, see page 59.
Inserting a disc
Insert a disc with the label side facing up.
DDX771
DDX491HD/DDX471HD/DDX371/DDX310BT/
DDX3071BT/DDX271/DDX2071
The source changes to “DISC” and playback starts.
• The IN indicator lights up while a disc is inserted.
• If “ ” appears on the screen, the unit cannot
accept the operation you have tried to do.
– In some cases, without showing “ ,”
operations will not be accepted.
• When playing back a multi-channel
encoded disc, the multi-channel signals are
downmixed to stereo.
Ejecting a disc
DDX771 DDX491HD/DDX471HD/
DDX371/DDX310BT/
DDX3071BT/DDX271/DDX2071
• When removing a disc, pull it horizontally.
• You can eject a disc when playing another AV
source.
• If the ejected disc is not removed within
15 seconds, the disc is automatically inserted
again into the loading slot to protect it from dust.
Closing the monitor panel (only for DDX771)
After removing the disc, press on the monitor
panel. The monitor panel closes.
Playback operations
• When the operation buttons
are not displayed on the screen,
touch the area shown on the
illustration.
– To change settings for video
playback, see page 41.
Indications and buttons on the source
control screen
ForDV D/VCD/DivX/MPEG1/MPEG2/JPEG
1
54 6
32
Playback information
1Media type
2Current playback item information
• DVD Video: Title no./Chapter no.
• DivX/MPEG1/MPEG2: Folder no./Track no.
• JPEG: Folder no./File no.
• VCD: Track no.
3Playing time
4Playback mode (Page13)
5File type (for DivX/MPEG1/MPEG2/JPEG)
6IN indicator
DDXEntryK.indb10 2013/11/0116:10
