Kenwood DDX9018S User manual

B5A-2486-00 (M/M2/X/A9)© 2018 JVC KENWOOD Corporation
MONITOR WITH DVD RECEIVER
DDX9018S
DDX9018SM
DDX9018DABS
DDX918WS
DDX918WSM
INSTRUCTION MANUAL
• Updated information (the latest Instruction Manual, system updates, new
functions, etc.) is available from
<http://www.kenwood.com/cs/ce/>.
!B5A-2486-00_18DDX_M_En.indb 1 2018/02/20 9:37

2
Contents
Before Use 4
Precautions................................................................... 4
How to read this manual ......................................... 5
Basic Operations 6
Functions of the Buttons on the Front Panel ... 6
Turning on the Unit ................................................... 8
Initial Settings.............................................................. 8
Adjusting the volume.............................................10
Monitor Angle Control ...........................................10
Touch screen operations .......................................11
Gesture Control.........................................................11
HOME screen descriptions....................................11
Popup menu ..............................................................12
Source selection screen description..................12
Source control screen descriptions ...................14
List screen ...................................................................15
Widget 16
Widget..........................................................................16
Photo Frame Widget ...............................................16
Widget Setup.............................................................17
Disc 18
Playing a disc .............................................................18
DVD/ VCD Basic Operation....................................18
Music CD/ Disc media Basic Operation ............20
File search Operation..............................................21
DVD Disc Menu Operation....................................22
DVD Setup...................................................................23
APPS—Android Auto™/
Apple CarPlay 24
Air Mirroring Operation .........................................24
Apple CarPlay Operation .......................................25
Android Auto™ Operation.....................................26
Spotify Operation.....................................................27
USB 29
Connecting a USB device ......................................29
USB Basic Operation................................................29
Search Operation......................................................31
iPod/iPhone 32
Preparation.................................................................32
iPod/iPhone Basic Operation ...............................33
Search Operation......................................................34
Radio 35
Radio Basic Operation ............................................35
Memory Operation ..................................................36
Selecting Operation ................................................36
Traffic Information ...................................................37
Radio Setup ................................................................37
Digital Radio 38
Digital Radio Basic Operation..............................38
Storing Service in Preset Memory......................39
Selecting Operation ................................................39
Traffic Information ...................................................40
Replay...........................................................................40
Digital Radio Setup..................................................41
!B5A-2486-00_18DDX_M_En.indb 2 2018/02/20 9:37

3English
Bluetooth Control 42
Information for using Bluetooth® devices.......42
Register the Bluetooth device .............................43
Bluetooth Setup........................................................43
Playing the Bluetooth Audio Device .................45
Using the Hands-Free Unit....................................47
Hands-Free Setup.....................................................52
Other External Components 53
View Camera ..............................................................53
Use Dashboard Camera..........................................55
External audio/video players (AV-IN).................55
HDMI source...............................................................55
TV tuner .......................................................................56
Using the external navigation unit....................56
Setup 57
Monitor Screen Setup.............................................57
System Setup.............................................................57
User Interface Setup................................................58
Special Setup .............................................................60
Display Setup.............................................................60
AV Setup ......................................................................62
Controlling Audio 63
3 way speaker system setup.................................63
Speaker/ X’over setup.............................................64
Controlling General Audio....................................66
Equalizer Control ......................................................66
Volume Offset............................................................67
Zone Control ..............................................................68
Sound Effect...............................................................69
Listening Position/ DTA..........................................69
Audio Setup memory .............................................71
Remote control 72
Battery Installation...................................................72
Functions of the Remote control Buttons.......72
Connection/Installation 74
Before Installation....................................................74
Installing the unit .....................................................76
Troubleshooting 85
Problems and Solutions.........................................85
Error Messages ..........................................................85
Appendix 87
Playable Media and Files........................................87
Region Codes in the World ...................................89
DVD Language Codes.............................................90
Specifications.............................................................91
About this Unit..........................................................94
!B5A-2486-00_18DDX_M_En.indb 3 2018/02/20 9:37

Before Use
4
Before Use
Precautions
#WARNINGS
Ñ To prevent injury or fire, take
the following precautions:
• To prevent a short circuit, never put or leave
any metallic objects (such as coins or metallic
tools) inside the unit.
• Do not watch or fix your eyes on the unit’s
display when you are driving for any extended
period.
• If you experience problems during installation,
consult your KENWOOD dealer.
Ñ Precautions on using this unit
• When you purchase optional accessories,
check with your KENWOOD dealer to make
sure that they work with your model and in
your area.
• You can select a language to display menus,
audio file tags, etc. See User Interface Setup
(P.58).
• The Radio Data System or Radio Broadcast
Data System feature won’t work in areas
where the service is not supported by any
broadcasting station.
Ñ Protecting the monitor
• To protect the monitor from damage, do not
operate the monitor using a ball point pen or
similar tool with a sharp tip.
Ñ Cleaning the unit
• If the faceplate of this unit is stained, wipe it
with a dry soft cloth such as a silicon cloth.
If the faceplate is stained badly, wipe it with
a cloth moistened with neutral cleaner, then
wipe it again with a clean soft dry cloth.
NOTE
• Applying spray cleaner directly to the unit
may damage its mechanical parts. Wiping the
faceplate with a hard cloth or using a volatile
liquid such as thinner or alcohol may scratch the
surface or erase the screened print.
Ñ Lens fogging
When you turn on the car heater in cold
weather, dew may form on the lens in the
disc player of the unit due to condensation.
This condensation on the lens (also called lens
fogging) may not allow discs to play. In such a
situation, remove the disc and wait for the dew
to evaporate. If the unit still does not operate
normally after a while, consult your KENWOOD
dealer.
Ñ Precautions on handling discs
• Do not touch the recording surface of the disc.
• Do not stick tape etc. on the disc, or use a disc
with tape stuck on it.
• Do not use disc type accessories.
• Clean the disc from the center toward the
outside rim.
• When removing a disc from this unit, pull it out
horizontally.
• If the disc center hole or outside rim has burrs,
use the disc only after removing the burrs with
a ballpoint pen etc.
• Discs that are not round cannot be used.
• 8-cm (3 inch) discs cannot be used.
• Discs with coloring on the recording surface or
discs that are dirty cannot be used.
!B5A-2486-00_18DDX_M_En.indb 4 2018/02/20 9:37

Before Use
5English
• This unit can only play the following tyeps of
CDs.
• This unit may not correctly play discs which do
not have the mark.
• You cannot play a disc that has not been
finalized. (For the finalization process, see
your writing software and your recorder's
instruction manual.)
Ñ Acquiring GPS signal
The first time you turn on this unit, you must
wait while the system acquires satellite signals
for the first time. This process could take up
to several minutes. Make sure your vehicle
is outdoors in an open area away from tall
buildings and trees for fastest acquisition.
After the system acquires satellites for the first
time, it will acquire satellites quickly each time
thereafter.
How to read this manual
• The screens and panels shown in this manual are
examples used to provide a clear explanation of
operations.
For this reason, they may be different from the actual
screens or panels, or some display patterns may be
different from the actual ones.
• Display language: English is used for the purpose
of explanation. You can select a display language
from the [SETUP]menu. See User Interface Setup
(P.58).
!B5A-2486-00_18DDX_M_En.indb 5 2018/02/20 9:37

Basic Operations
6
Basic Operations
Functions of the Buttons on the Front Panel
DDX9018S/ DDX9018SM/ DDX9018DABS
8
1 2 3 4 5 6 7
NOTE
• The panels shown in this guide are examples used to provide a clear explanation of operations. For this reason,
they may be different from the actual panels.
• In this manual, each model name is abbreviated as follows.
– DDX9018S/ DDX9018SM/ DDX9018DABS:
If above icon is showed, read the article applicable to the unit you use.
Number Name Motion
1
Remote
Sensor
• Receives the remote control signal.
2
S, R
(Volume)
• Adjusts the volume.
The volume will go up to 15 when you keep pressing R.
3
CAM • Switches view camera display on/off. (P.53)
– The camera whose view is displayed first changes according to the "Camera
Setup" setting and the shift lever position in the shift gate.
4
HOME • Displays the HOME screen (P.11).
• Pressing for 1 second turns the power off.
• When the power is off, turns the power on.
5
MENU • Displays the popup menu screen.
• Pressing for 1 second switches attenuation of the volume on/off.
6
• Displays the APP (CarPlay/ Android Auto/ Air Mirroring) screen.
• Pressing for 1 second displays the Voice Recognition screen (P.49).
7
G• Displays the Angle Adjust screen.
– [DISC EJECT]: Ejects the disc.
• When the panel is opened, pressing closes the panel.
• To forcibly eject the disc, press it for 2 seconds and then touch [DISC EJECT]after the
message is displayed.
8
Disc insert
slot
• A slot to insert a disc media.
!B5A-2486-00_18DDX_M_En.indb 6 2018/02/20 9:37

Basic Operations
7English
DDX918WS/ DDX918WSM
1
2
4
5
6
7
3
8
NOTE
• The panels shown in this guide are examples used to provide clear explanations of the operations. For this reason,
they may be different from the actual panels.
• In this manual, each model name is abbreviated as follows.
– DDX918WS/ DDX918WSM:
If above icon is showed, read the article applicable to the unit you use.
Number Name Motion
1
Gesture
control
sensor
• A sensor which detects motions of your hand. (P.11)
2
• Switch the APP (CarPlay/ Android Auto/ Air Mirroring) source.
• Pressing for 1 second displays the Voice Recognition screen (P.49).
3
S, R
(Volume)
• Adjusts volume.
The volume will go up until 15 when you keep pressing R.
4
HOME • Displays the HOME screen (P.11).
• Pressing for 1 second turns the AV off.* (Touch the display to turn on the screen.)
* Turns off the screen and audio. Interrupts from incoming hands-free calls, rear camera
views and so on are functional, though.
5
MENU • Displays the popup menu screen.
6
G• Displays the Angle Adjust screen.
– DISC EJECT: Ejects the disc.
• When the panel is opened, pressing closes the panel.
• To forcibly eject the disc, press it for 2 seconds and touch [DISC EJECT]after the
message is displayed.
7
Remote
Sensor
• Receives the remote control signal.
8
Disc insert
slot
• A slot to insert a disc media.
!B5A-2486-00_18DDX_M_En.indb 7 2018/02/20 9:37

Basic Operations
8
Turning on the Unit
The method of turning on is different
depending on the model.
1
Press the [HOME]button.
 The unit is turned on.
●To turn off the unit:
1
Press the [HOME]button for 1 second.
NOTE
• If it is your first time to turn the unit on after
installation, it will be necessary to perform Initial
setup (P.8).
1
Touch the display.
 The unit is turned on.
Initial Settings
Initial setup
Perform this setup when you use this unit first
time.
1
Set each item as follows.
■[Language]
Select the language used for the control
screen and setting items. Default is“British
English (en)”.
1Touch [Language].
2Touch [Language Select].
3Select the desired language.
4Touch [
].
For details of operation, see User Interface
Setup (P.58).
■[Clock]
Sets the synchronization of the clock and
adjusts it.
For detailed operation, see Calendar/clock
settings (P.10).
■[Display]
Set the button illumination color.
If it is hard to see the image on the screen
even, adjust the viewing angle.
1Touch [Display].
2Touch [Key Colour].
3Select the desired color.
4Touch [
].
5Touch [Viewing Angle].
6Select an angle
7Touch [
].
For details of, see Display Setup (P.60).
!B5A-2486-00_18DDX_M_En.indb 8 2018/02/20 9:37

Basic Operations
9English
■[Camera]
Set the parameters for the camera.
1Touch [Camera].
2Set each item and touch [
].
For details of, see Camera Setup (P.53).
■[DEMO]
Set the demonstration mode. Default is “ON”.
1Touch [DEMO]and select ON or OFF.
■[3way X'over]
Displays the message screen.
For detailed operation, see 3 way speaker
system setup (P.63).
2
Touch [Finish].
NOTE
• These settings can be made from the SETUP
menu. See Setup (P.57).
Security Code Setup
You can set up a security code to protect your
receiver system against theft.
When the Security Code function is activated,
the code cannot be changed and the function
cannot be deactivated. Note that the Security
Code can be set with a 4 to 8 digit number of
your choice.
1
Press the [MENU]button.
 Popup menu appears.
2
Touch [SETUP].
 SETUP Menu screen appears.
3
Touch [Security].
 Security screen appears.
4
Touch [Security Code Set]on the Security
screen.
 Security Code Set screen appears.
5
Enter a security code with 4 to 8 digits
and touch [Enter].
6
Enter the same code again and touch
[Enter].
Now, your security code is registered.
NOTE
• Touch [BS]to delete the last entry.
• If you enter a different security code, the
procedure returns to step 5 (for first code entry).
• If you have disconnected the Receiver from the
battery, enter the correct security code as that
you have entered in step 5 and touch [Enter]. You
can use your receiver.
To change the security code:
1
Touch [Security Code Change]on the
Security screen, then repeat step 5 and 6.
To clear the security code:
1
Touch [Security Code Cancellation]on
the Security screen, then repeat step 5.
!B5A-2486-00_18DDX_M_En.indb 9 2018/02/20 9:37

Basic Operations
10
Calendar/clock settings
1
Press the [MENU]button.
 Popup menu appears.
2
Touch [SETUP].
 SETUP Menu screen appears.
3
Touch [User Interface].
 User Interface screen appears.
4
Touch [Time Zone]in the User Interface
screen.
5
Select the time zone.
6
Set each item as follows.
Scroll the page to show hidden items.
■[Time Format]
Select the time display format.
[12-Hour ](Default)/ [24-Hour]
■[Clock]
[GPS-SYNC ](Default): Synchronizes the clock
time with the GPS.
[Manual]: Set the clock manually.
■[Time Zone]
Select the time zone.
■[Clock Adjust]
If you select [Manual]for Clock, adjust the
date and time manually. (P.58)
NOTE
• Please set the date and time. If they not set, some
functions may not work.
Adjusting the volume
To adjust the volume (0 to 40),
Press [R]to increase, and press [S]to decrease.
Holding [R]increases the volume continuously
to level 15.
Monitor Angle Control
You can adjust the position of the monitor.
1
Press the [G]button.
 Angle Adjust screen appears.
2
Select a number below that represents
your desired angle setting.
Default is “0”.
■[Off Position]
You can store the current monitor angle as
the angle during power off. Touch [Memory]
when the desired angle is selected.
!B5A-2486-00_18DDX_M_En.indb 10 2018/02/20 9:37

Basic Operations
11English
Touch screen operations
To perform operations on the screen, you need
to touch, touch and hold, flick or swipe to
select an item, display a setting menu screen
or change pages.
●Touch
Touch the screen gently to
select an item on the screen.
●Touch and hold
Touch the screen and keep
your finger in place until
the display changes or a
message is displayed.
●Flick
Slide your finger quickly
to the left or right on the
screen to change the page.
You can scroll a list screen
by flicking up/ down on the
screen.
●Swipe
Slide your finger up or down
on the screen to scroll the
screen.
Gesture Control ( )
You can also operate the unit by moving your
hand in front of the gesture control sensor.
1
7
12
• To control by hand motion, select [ON]for
[Gesture Control]on the "User Interface"
screen beforehand. (P.58)
• When shipped from the factory, you can
operate by moving your hand as follows:
– To the right: Displays the current source control
screen.
– To the left: Switches to Apple CarPlay/Android Auto
screen. (P.25)
– Up: Displays the Home screen.
– Down: When a call comes in, answers the call.
• You can assign the functions or sources/
screens to display on the "Gesture SETUP"
screen. (P.58)
HOME screen descriptions
Most functions can be performed from the
HOME screen.
5
4
3
6
2 1
1
• Widget (P.16)
– You can change the widget by flicking left
or right on the widget area.
– Touch the widget to display the detailed
screen.
2
• Current source information
3
• Displays the control screen of the current
source.
• The artwork is displayed if available from
current content.
4
• Current source information
5
• Displays the source selection screen. (P.12)
6
• Short-cut playback source icons (P.13)
Display the HOME screen
1
Press the [HOME]button.
 HOME screen appears.
!B5A-2486-00_18DDX_M_En.indb 11 2018/02/20 9:37

Basic Operations
12
Popup menu
1
Press the [MENU]button.
 Popup menu appears.
2
Touch to display the popup menu.
1
The contents of the menu are as follows.
• Displays the Screen Adjustment screen.
(P.57)
• Turns the display off. (P.12)
• Displays the view camera screen.
(P.53)
• Displays the SETUP Menu screen.
(P.57)
• Displays the Audio screen. (P.63)
• Displays the control screen of current
source. Icon feature differs depending on
the source.
• Close the popup menu.
1
• Short-cut buttons: The source changes to
the one you have set with a short-cut. For
the short-cut setting, refer to Customize
Short-cut buttons on HOME screen
(P.14).
Turn off the screen
1
Select [Display OFF]on the popup menu.
●To turn on the screen
1
Touch the display.
Source selection screen
description
You can display icons of all playback sources
and options on the source selection screen.
4 5
321
1
• Changes playback sources.
For playback sources, see P.12.
2
• Page indication
3
• Changes pages. (Touch []/[ ].)
You can also change pages by flicking left or
right on the screen.
4
• Returns to the previous screen.
5
• Displays the SETUP Menu screen. (P.57)
Select the playback source
1
Press the [HOME]button.
 HOME screen appears.
2
Touch [ ].
From the screen, you can select the
following sources and functions.
• Switches to the Android Auto/ Apple
CarPlay/ Air Mirroring screen from the
connected iPhone/Android device.*1
(P.24)
• Displays the Hands Free screen. (P.47)
When connecting as Apple CarPlay
or Android Auto, it works as a phone
provided in Apple CarPlay or Android
Auto.
• Switches to the Radio broadcast.
(P.35)
!B5A-2486-00_18DDX_M_En.indb 12 2018/02/20 9:37

Basic Operations
13English
• Switches to the Digital Radio broadcast.
*2(P.38)
• Plays a Bluetooth audio player. (P.42)
• Plays a disc. (P.18)
• Plays an iPod/iPhone. (P.32)
• Plays files on a USB device. (P.29)
• Switches to Spotify. (P.27)
• Plays a device connected to the HDMI
input terminal. (P.55)
• Switches to an external component
connected to the AV-IN input terminal.
(P.55)
• Displays the navigation screen when a
navigation unit is connected. (P.56)
• Displays the Audio screen. (P.63)
• Puts the unit in standby. (P.13)
*1When iPhone compatible with CarPlay is
connected, [Apple CarPlay]is displayed.
When an Android device compatible with
Android Auto is connected, [Android Auto]is
displayed.
*2DDX9018DABS only
To select the playback source on the
HOME screen
The 4 items displayed on the source selection
screen with large icons are shown on the
HOME screen.
You can change the items displayed on this
area by customizing the source selection
screen. (P.14)
To select the playback source on the
source control screen
Display source selection buttons by touching
[ ]/[ ] or flicking left or right on the source
control screen, then select a playback source.
Put the unit in standby
1
Press the [HOME]button.
 HOME screen appears.
2
Touch [ ].
3
Touch [STANDBY].
!B5A-2486-00_18DDX_M_En.indb 13 2018/02/20 9:37

Basic Operations
14
Customize Short-cut buttons on
HOME screen
You can arrange the positions of the source
icons as you like.
1
Press the [HOME]button.
 HOME screen appears.
2
Touch [ ].
3
Touch and hold the icon which you want
to move in the customizing mode.
4
Drag the icon to the desired position.
Changes the page
Source control screen
descriptions
There are some functions which can be
performed from most screens.
Indicators
5
6
1 2
3
4
Short-cut buttons
1
All sources icon
Displays all sources.
2
Secondary screen
• [
]/[ ] : The Secondary screen changes to
another one every time you touch it. You can
also change the Secondary screen by flicking
left or right on the screen.
• Indicators: Displays the current source
condition and so on.
– [ATT]: The attenuator is active.
– [DUAL]: The dual zone function is active.
– [MUTE]: The mute function is active.
– [LOUD]: The loudness control function is active.
• Short-cut buttons: The source changes to the
one you have set with a short-cut. For the
short-cut setting, refer to Customize Short-
cut buttons on HOME screen (P.14).
3
Content list
Displays the track/file/station/channel list.
!B5A-2486-00_18DDX_M_En.indb 14 2018/02/20 9:37

Basic Operations
15English
4
• Connected Bluetooth device information.
• : Lights up during quick charging of
the battery of the connected iPod/ iPhone/
Smartphone.
5
Artwork & information
You can select whether to display an artwork
and song information or only song information
in more detail.
6
Function panel
Touch the left side of the screen to display the
function panel. Touch again to close the panel.
List screen
There are some common function keys in the
list screens of most sources.
61 2
3 4 5
1
Displays the list type selection window.
2
Displays a music/movie file list.
3
Text scroll
Scrolls the displayed text.
4
etc.
Keys with various functions are displayed here.
• : Plays all tracks in the folder containing
the current track.
• : Jumps to the letter you entered
(alphabetical search).
• : Moves to the upper hierarchy
level.
5
[ ] / [ ] / [ ] / [ ] Page scroll
You can change pages to display more items by
pressing [
]/[ ].
• [
]/[ ] : Displays the top or bottom page.
6
Return
Returns to the previous screen.
NOTE
• Buttons which cannot be activated from the list
screen are not displayed.
!B5A-2486-00_18DDX_M_En.indb 15 2018/02/20 9:37

Widget
16
Widget
Widget
1 Press the [HOME]button.
2 You can change the widget by flicking left
or right on the widget area.
Widget list
• Clock Widget
• Spectrum analyzer Widget
• Multi Widget (Spectrum analyzer, Clock,
Current source information)
• Photo Frame Widget
Photo Frame Widget
You can display a slideshow of the image
files stored in the USB memory on the Home
screen.
Ñ Preparation
• Select “ON”for Photo Frame Widget. See
Widget Setup (P.17).
●Acceptable Picture files
Max. Picture size
JPEG (.jpg, .jpeg) *15,000 × 5,000
PNG (.png) 1,000 × 1,000
BMP (.bmp) 1,000 × 1,000
• This unit can only play back files which are less
than 50 MB.
• The maximum number of files per device is
500.
• Picture files may not be played depending on
their condition.
*1 A progressive format is not supported.
Ñ Photo Frame
1 Press the [HOME]button.
2 Flick the widget area to the left/right to
display the photo frame widget.
• Scroll the screen to display the hidden part.
!B5A-2486-00_18DDX_M_En.indb 16 2018/02/20 9:37

Widget
17English
Widget Setup
Set up the widgets on the Home screen.
1 Press the [MENU]button.
 Popup menu appears.
2 Touch [SETUP].
 SETUP screen appears.
3 Touch [User Interface].
 User Interface screen appears.
4 Touch [Widget SETUP]in the User
Interface screen.
5 Set each item as follows.
■[Photo Frame Widget]
Determine whether to use the photo frame
widget.
"ON" (Default)/ "OFF"
■[Photo Frame SETUP]
Make settings related to display of the photo
frame widget.
6 Touch [].
To Photo Frame Setup
Make settings related to display of the photo
frame widget.
1 Touch [Photo Frame SETUP]on the
Widget SETUP screen.
2 Set each item as follows.
■[Sort Order]
Specify a file sorting criterion.
"By Name(Ascending)"/ "By
Name(Descending)"/ "By Date(Newest First)"
(Default)/ "By Date(Oldest First)"
■[Slide Show Interval]
Specify the slideshow interval.
"5" (Default) to "30" seconds
■[Photo Frame is • • • • •]
Display help topics about the photo frame.
3 Touch [].
!B5A-2486-00_18DDX_M_En.indb 17 2018/02/20 9:37

Disc
18
Disc
Playing a disc
Ñ Insert a disc
1 Press the [G]button.
2 Touch [DISC EJECT].
 The panel opens.
3 Insert the disc into the slot.
 The panel closes automatically.
The unit loads the disc and playback
starts.
Ñ Eject a disc
1 Press the [G]button.
2 Touch [DISC EJECT].
When removing a disc, pull it horizontally.
3 Press the [G]button.
DVD/ VCD Basic Operation
Most functions can be controlled from the
source control screen and playback screen.
NOTE
• Set the remote control mode switch to DVD
mode before starting operation for DVD and VCD,
see Switch the operation mode (P.72).
• The screen shot below is for DVD. It may be
different from the one for VCD.
1 When the operation buttons are not
displayed on the screen, touch
7
area.
Control screen
1
2
34
5
DVD VCD
2
Video screen
7
6
8
6
1
Information display area
Displays the following information.
• Title #, Chapter #: DVD title and chapter
number
• Track #/Scene #: VCD track or scene number.
Scene # is displayed only when Playback
control (PBC) is on.
!B5A-2486-00_18DDX_M_En.indb 18 2018/02/20 9:37

Disc
19English
• Linear PCM, etc.: Audio format
• OFF/Zoom2 – 4 (DVD)/ Zoom2 (VCD):
Displays the zoom ratio.
• [Hide]: Hides the control screen.
• [
]: Repeats the current content. Each time
you touch the key, repeat modes are switched
in the following sequence;
DVD: Title repeat ( ), Chapter repeat
( ), Repeat off ( )
VCD (PBC On): Does not repeat
VCD (PBC Off ): Track repeat ( ), Repeat off
( )
2
Function panel
Touch the left side of the screen to display the
function panel. Touch again to close the panel.
• I]: Stops playback. Touching twice will play
the disc from the beginning when you play it
next time.
• [
][ ]: Fast-forwards or fast-backward the
disc. Each time you touch the key, the speed
changes. 2 times, 10 times.
• [
][ ] (DVD only): Plays in slow motion
forward or backward.
• [SETUP](DVD only): Touch to display the DVD
SETUP screen. See DVD Setup (P.23).
• [MENU CTRL](DVD only): Touch to display
the DVD-VIDEO disc menu control screen. See
DVD Disc Menu Operation (P.22).
• [PBC](VCD only): Touch to turn Playback
control (PBC) on or off.
• [Audio](VCD only): Touch to change audio
output channels.
3
Play mode indicator/ Playing time
• D, B, I, etc.: Current play mode indicator
Meanings of the icons are as follows: D(play),
B(fast forward), A(fast backward),
I(stop), R(resume stop), H(pause), (slow
playback), (slow reverse playback).
• For confirmation of current playing position.
You can drag the circle left or right to change
the playing position.
4
Operation keys
• [E][F]: Searches for the previous/next
content.
• Touch and hold to fast-forward or fast-
backward the disc. (It will be cancelled
automatically after about 50 seconds.)
• [DH]: Plays or pauses.
• [
]: Touch to mute or not to mute.
5
Indicator Items
• [IN]: Disc insertion status.
White: A Disc is inside the unit.
Orange: Disc player failure.
VCD
• [1chLL/2chLL]: Identifies the left audio output
of channel 1 or 2.
• [1chLR/2chLR]: Identifies the monaural audio
output of channel 1 or 2.
• [1chRR/2chRR]: Identifies the right audio
output of channel 1 or 2.
• [1chST/2chST]: Identifies the stereo audio
output of channel 1 or 2.
• [LL]: Identifies the left audio output.
• [LR]: Identifies the monaural audio output.
• [RR]: Identifies the right audio output.
• [ST]: Identifies the stereo audio output.
• [PBC]: The PBC function is on.
• [VER1]: The VCD version is 1.
• [VER2]: The VCD version is 2.
6
Searching area
Touch to search the for next/previous content.
7
Key display area
Touch to display the control screen.
8
[MENU CTRL](DVD only)
Touch to display the DVD-VIDEO disc menu
control screen. See DVD Disc Menu Operation
(P.22).
NOTE
• The control screen disappears when no operation
is done for 5 seconds.
• If you use a remote control, you can jump directly
to the desired image by entering the chapter
number, scene number, play time, etc. (P.72).
!B5A-2486-00_18DDX_M_En.indb 19 2018/02/20 9:37

Disc
20
Music CD/ Disc media Basic
Operation
Most functions can be controlled from the
source control screen and playback screen.
NOTE
• Set the remote controller mode switch to AUD
mode before starting operation for Music CD
and audio files, see Switch the operation mode
(P.72).
• In this manual,“Music CD”means a general CD
which includes music tracks.
“Disc media” means a CD/DVD disc which
includes audio or video files.
• The screen shot below is for disc media. It may be
different from the one for CD.
Control screen
7
3
4
5
2
1
6
Open the drawer
5
7
Close the drawer
5
7
6
8
1
CODEC / [ ] / [ ]
• When a high-resolution source is played, its
format information is displayed. (Disc media
only)
• [
]: Repeats the current track/folder. Each
time you touch the key, repeat mode switches
in the following sequence;
Track/ File repeat ( ), Folder repeat ( )
(Disc media only), Repeat all ( )
• [
]: Randomly plays all tracks in current
folder/disc. Each time you touch the key,
random mode switches in the following
sequence;
Track random ( ) (Music CD only), Folder
random ( ) (Disc media only), Random off
( )
2
Track information
Displays the information of the current track/ file.
Only a file name and a folder name are displayed
if there is no tag information. (Disc media only)
3
Play mode indicator/ Playing time
• D, B, etc.: Current play mode indicator
Meanings of the icons are as follows: D(play),
B(fast forward), A(fast backward),
H(pause).
• For confirmation of current playing position.
You can drag the circle left or right to change
the playing position. (Video file only)
4
Operation keys
• [1](Disc media only) : Searches files. For
details on search operation, see File search
Operation (P.21).
• [E][F]: Searches for the previous/next
content.
• Touch and hold to fast-forward or fast-
backward the disc. (It will be cancelled
automatically after about 50 seconds.)
• [DH]: Plays or pauses.
• [
]: Touch to mute or not to mute.
5
Content list
• Touch the right side of the screen to display
the Content list. Touch again to close the list.
• Displays the playing list. When you touch a
track/file name on the list, playback will start.
6
Artwork/ Analog meter
• Displays/hides artwork area.
• The jacket of the currently playing file is
displayed. (Disc media only)
• When touched, switches the artwork to the
analog meter.
!B5A-2486-00_18DDX_M_En.indb 20 2018/02/20 9:37
