KEPCO ml-PI8 User manual

mL-PI8
Universal Input Process Indicator
PROCESS INDICATOR
mL-PI8 (Rev A)
PANEL MOUNTING
Weight:
260 gr.
Dimensions: (96 x 48mm, Depth:86.5 mm)
Panel Cut-Out: (92 x 46mm)
Minimum Distance Between Panel Cut-Out Centers:
X=129mm, Y=65mm
SPECIFICATIONS
PROCESS INPUT
Universal Input: TC, RTD, ZVoltage/Current
Thermocouple (TC): L(DIN 43710) ,J , K , R , S , T , B , E and N
(IEC584.1)(ITS90) ,C (ITS90)
Thermoresistance (RTD): PT-100 (IEC751)(ITS90)
ZInput: mV, V, mA
Measurement Range : Please refer to Table-1 for selection of input
type and scale
Accuracy:± 0.25% of full scale for thermocouple, thermoresistance,
mV, V and mA input.
Cold Junction Compensation:Automatically ±0.1°C/1°C
Line Compensation: Maximum 10 Ohm
Sensor break protection:Upscale
Sampling Cycle:3 samples per second
Input Filter: 0.0 to 900.0 seconds
OUTPUT
Standard Relay Output: Form C Relay 5A@250V (on resistive load)
Secondary Relay Output: Form A Relay (3A@250V on resistive load)
Analog Output :
-0/4...20 mAZCurrent Output Module
POWER SUPPLY
Power Supply Voltage :
100-240V V50/60 Hz (-%15;+%10) -6VA
DISPLAY
Process Display :
20.3 mm Red 4 digit LED Display
LED Indicators :°C /°F / V, OP1/2/3 (Output Status) LED.
ENVIRONMENTAL RATINGS and PHYSICAL SPECIFICATIONS
Operating Temperature: 0...50°C
Humidity: 0-90%RH (non condensing)
Protection Class: IP65 at front, IP20 at rear
Mounting: Type-1 Enclosure Mounting
Installation: Fixed installation Category II
Over Voltage Category: II
Pollution Degree: II, office or workplace, none conductive pollution
Maximum 15mm / 0.59 inch
48mm/ 1.89 inch
96mm / 3.78 inch
76mm / 2.99 inch
10.5 ± 1 mm /0.41 inch
°C
°F
O1
O2
O3
VV
PSET
a
c
i
This symbol is used for safety warnings. User must pay
attention to these warnings.
This symbol is used to determine the dangerous
situations as a result of an electric shock. User must
pay attention to these warnings definitely.
This symbol is used to determine the important notes
about functions and usage of the device
Electrical WiringsElectrical Wirings
Dimensions
mLINE
991035 04/05/22
TC
0 to 20mA
0 to 50mV
0 to 10V
24 V
Max 50mA
Pt-100
Universal
Process Input
(TC, RTD, DC Voltage/Current)
Sensor or Transmitter
Supply Voltage
Output-3
Relay Output
Communication
Socket
Secondary Relay
(3A@250VAC)
Analog Output
0/4 - 20mA
1 2 3456 7 8 9 10 11 12
13 14 15 16 17 18 19 20 21 22 23 24
MODULE - 1 MODULE - 2
5A@250 VAC
RELAY OUTPUT
CNONC
N(–) L(+)
NOTE: REV A. As of March, 2022:
MODULE-1 Provides 3A Relay
MODULE-2 Provides Analog Output
*
*
Supply Voltage Input
100-240VAC(-15%;+10%) 50/60Hz - 6VA
[optional 24VDC (-15%; +10%)]
External Fuse is recommended (1A T)
- 4
(TC, RTD, mVZ, VZ, mAZ)
digits Process Display (High brightness LED)
- Universal Process Input
-Two relay outputs
- Dual or Multi Point Calibration for DC voltage & DC current
Inputs
- Smart Output Module System
- Programmable Alarm Functions
-Process control or re-transmission with 0/4...20 mA Current
output
- RS-485 Serial Communication With Modbus RTU Protocol
NOTE
REV A. As of March, 2022: The mL-PI8 Revision A has been upgraded
to include the following options as standard features:
• Two Relays (Additional 3A Relay now STD)
• Gasket for NEMA4X Installation
• High Bright LED Display

Press SET
Button
Press
Increment
button to
enter Alarm-1
set value.
Press SET
button to
save the
Alarm-1 Set
value.
Main Screen Alarm-1 Set Screen
B(44°C;1800°C) or (111°F;3272°F)
B(44.0°C;999.9°C) or (111.0°F ; 999.9°F)
E (-150°C;700°C) or (-238°F;1292°F)
E (-150.0°C;700.0°C) or (-199.9°F;999.9°F)
N (-200°C;1300°C) or (-328°F;2372°F)
N (-199.9°C;999.9°C) or (-199.9°F;999.9°F)
C (0°C;2300°C) or (32°F;3261°F)
C (0.0°C;999.9°C) or (32.0°F;999.9°F)
Note: For detailed information look PASS ConF
section.
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
°C
°F
VV
OP1
OP2
OP3
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
°C
°F
VV
OP1
OP2
OP3
SET
SET
SET
°C
°F
VV
OP1
OP2
OP3
°C
°F
VV
OP1
OP2
OP3
SET
SET
SET
SET
SET
°C
°F
VV
OP1
OP2
OP3
°C
°F
VV
OP1
OP2
OP3
SET
SET
SET
°C
°F
VV
OP1
OP2
OP3
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
°C
°F
VV
OP1
OP2
OP3
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
SET
Alarm-2 Set Screen
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
SET
Alarm-3 Set Screen
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
SET
Main Screen
MODULE-2 analog output module configuration
0...20mAZoutput 4...20mAZoutput
Scale
0 20
mA
UPL
LOL
Re-transmission
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
°C
°F
VV
OP1
OP2
OP3
°C
°F
VV
OP1
OP2
OP3
SET
Main Screen
°C
°F
VV
OP1
OP2
OP3
SET
Technician menu
entering screen
Technician password
entering screen
Press Menu
Button.
Press Set/OK Button
to enter password
entering screen.
Press Increment button
to access password
entering screen
Enter password with
using Increment or
decrement buttons.
Press Set/OK Button
to approve password.
Not Used
Press increment
or decrement
button to change
the Alarm-1 Set
Value.
Press
Increment
button to
enter Alarm-2
set value.
Press
Increment
button to
enter Alarm-3
set value.
Note: User can exit from Set Value section without saving the values by pressing button.
If no operation for 120 seconds, device automatically exits from Set Value section .
P
Technician password
entering screen
Process Input Type
TC input type selection
RTD input type selection
ZVoltage / Current input type selection.
TC Input Selection
This parameter is active if TC input type is selected.
L (-100°C;850°C) or (-148°F;1562°F)
L (-100.0°C;850.0°C) or (-148.0°F;999.9°F)
J (-200°C;900°C) or (-328°F;1652°F)
J (-199.9°C;900.0°C) or (-199.9°F;999.9°F)
K (-200°C;1300°C) or (-328°F;2372°F)
K (-199.9°C;999.9°C) or (-199.9°F;999.9°F)
R (0°C;1700°C) or (32°F;3092°F)
R (0.0°C;999.9°C) or (32.0°F;999.9°F)
S(0°C;1700°C) or (32°F;3092°F)
S(0.0°C;999.9°C) or (32.0°F;999.9°F)
T(-200°C;400°C) or (-328°F;752°F)
T (-199.9°C;400.0°C) or (-199.9°F;752.0°F)
RTD Input Selection
This parameter is active if RTD input is selected.
PT-100 ( -200°C ; 650°C ) or ( -328°F ; 1202°F)
PT-100 ( -199.9°C ; 650.0°C ) or ( -199.9°F ;999.9°F)
Zvoltage / Current Input Selection
This parameter is active if ZVoltage / Current is selected.
0...50mV Z( -1999 ; 9999 )
0...5V Z( -1999 ; 9999 )
0...10V Z( -1999 ; 9999 )
0...20mA Z( -1999 ; 9999 )
4...20mA Z( -1999 ; 9999 )
No point
Fixed dual point display adjustment. Display adjustment low
point value is fixed to -1999, display adjustment high point
value is fixed to 9999.
Between second and third digits “0.00”
User can do defined 16 display adjustment points.
Between third and fourth digits “0.000”
Between first and second digits “0.0”
User can do dual point display adjustment with tPoL and tPoH.
Display Point Position
This parameter is active if oltage/Current input is selected.ZV
Display Value Adjustment Type
This parameter is active if oltage/Current input is selected.ZV
Low Point Display adjustment (-1999, 9999)Unit
This parameter is active if oltage/Current input is selected.ZV
High Point Display adjustment (-1999, 9999)Unit
This parameter is active if oltage/Current input is selected.ZV
Display adjustment points (-1999, 9999)Unit
This parameter is active if oltage/Current input is selected.
In multi point display adjustment operation, defined scale is
divided into 16 adjustment points.
For example : is (0-50 mV ) .
ZV
Z
Unit selection
Unit is °C
Unit is °F
Operating Scale Minimum Value
(Scale Low Point, Scale High Point)Unit
Used for Proportional band calculation and display blink.
Unit is Voltage. This selection is active if ZVoltage/Current
input is selected
No unit. This selection is active if oltage / current input is
selected
ZV
Coefficient value (1.000, 9.999)
Process value is multiplied with this value.
ZVThis parameter is active if oltage/Current input is selected.
mV Z
50
Po00 = 0
Po01
Po02
Po03
Po04
Po05
Po16
Po06
Po15
Po07
Po08
Po09
Po10
3.125 3.125 3.125 3.125 3.125 3.125 3.125 3.125 3.125 3.125 3.125 3.125 3.125 3.125 3.125 3.125
3.125 6.25 9.375 12.5 15.625 18.75 21.825 25 28.125 31.25 34.375 37.5 40.625 43.75 46.875
Po14
Po13
Po12
Po11
Process
Set value
0-50 mVZ range are divided into 16 egual parts. Every “Poxx” SET value is defined
50 / 16 = 3.125 mVZ range.
Operating Scale Maximum Value
(Scale Low Point, Scale High Point)Unit
Used for Proportional band calculation and display blink.
Display offset for process value (Scale -10%, Scale
+10%)Unit
This parameter value is added to the process value.
Filter Time (0.0, 900.0)Second
Defines filter time for display value.
Cold Junction Compensation
This parameter is active if process input is selected TC input.
Cold junction compensation is active.
Cold junction compensation is not active.
Scale: The difference, between high point and low point of the process
input type. Example: If tCSL = 2 (low point is -200, high point is 900),
then scale is 1100. If input type is Voltage/Current, then the scale is
difference between tPoH and tPoLparameters.
Press SET
button to
save the
Alarm-2 Set
value.
Press increment
or decrement
button to change
the Alarm-2 Set
Value.
Press SET
button to
save the
Alarm-3 Set
value.
Press increment
or decrement
button to change
the Alarm-3 Set
Value.
Scale
0 20
mA
UPL
LOL
Re-transmission
4
out2 ConF: MODULE-2 0/4 - 20mA
Access and change Set values
Easy Access diagram of Program Parameters
PýnP ConF: Process Input Type and Relevant Parameters
*
*
*
*
*
*
*
*
* NOTES
is analog input zero process variable
is analog input full scale process variable
is analog output zero process variable and below which
the blinking warning display uuuu appears
is analog output full scale process variable and above
which the blinking warning display nnnn appears
defines the operators minimum permitted setpoint
value for the process variable
defines the operators maximum permitted setpoint
value for the process variable
and maximum value of operating scale
Alarm-1 Type
MODULE-1 alarm type. This parameter is active, if the Logic-
1 output function is Alarm output.
Process high alarm
Process low alarm
Alarm-1 hysteresis value (0% of scale, 50% of scale)Unit
This parameter is active, if the Logic-1 output function is
Alarm output.
Alarm-1 On delay time (0, 9999)Second
This parameter is active, if the Logic-1 output function is
Alarm output.
Alarm output
Sensor break alarm output
Output is active when the process value is out of the band
which is defined with minimum value of operating scale
Alarm-1 Off Delay Time (0, 9998)Second
When the value is greater than 9998, is seen on the
screen. It means alarm latching output is selected.
parameter is active if logic-1 output function of Alarm-1
Output is alarm output.
This
out1 ConF: MODULE-1 Relay Output parameters

Alarm Set value Low limit ( , )Unit
Alarm Set value High limit ( , )Unit
Alarm output
Sensor break alarm output
Output-3 Logic output function
Process High Alarm
HYS
ON
OFF
Alarm
Set
Alarm
Output
Process Value
Process Low Alarm
HYS
ON
OFF
Alarm
Set
Alarm
Output
Process Value
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
SET
Process high alarm
Process low alarm
This parameter is active, if the Logic-3 output function is
Alarm output.
Alarm-3 On delay time (0, 9999)Second
This parameter is active, if the Logic-3 output function is
Alarm output.
Alarm-3 Type
Alarm-3 hysteresis value (0% of scale, 50% of scale)Unit
Output is active when the process value is out of the band
which is defined with minimum value of operating scale
and maximum value of operating scale
Alarm-3 Off Delay Time (0, 9998)
When the value is greater than 9998, is seen on the
screen. It means alarm latching output is selected. This
parameter is active if logic-3 output function of Alarm-3
Output is alarm output.
Second
Communication Accessing Address (1,247)
Communication accessing address of device.
Communication accessing address can be adjusted from 1
to 247.
Communication Baud Rate
1200 Baud Rate.
2400 Baud Rate .
4800 Baud Rate
9600 Baud Rate
19200 Baud Rate
Parity Selection for Communication
No parity.
Odd parity.
Even parity.
Stop Bit Selection for Communication
1 stop bit
2 stop bit
It is used for accessing to the technician parameters.
If it is no password protection while entering to the
technician Parameters.
If it is different from “ 0” and user wants to access to
the technician parameters;
f user does not enter password correctly It turns
to operation screen without accessing to parameters.
When in top display and in bottom display
are seen, if user presses SET button without entering
Password (For observing the parameters):
Operator can see operator menus and parameters but
operator can not change the parameters
1- I :
:
TPasswords(0, 9999)
1 - Sensor failure in analog inputs.
Sensor connection is wrong or there is no
sensor connection.
2- If top display blinks : If analog input
value is less than minimum value of
operating scale top display starts to
blink.
3- If top display blinks : If analog input
value is greater than maximum value of
operating scale top display starts to
blink.
4- If technician password is different from “0” and user accesses
to the parameter by Set button without entering the technician
password and wants to change a parameter, the warning
message is shown on the display as shown on the right.
Device does not allow to do any changes without entering the
password correctly.
Company Information:
Kessler-Ellis Products
10 Industrial Way East
Eatontown, NJ 07724
Phone: [phone] or 732-649-7100
Fax:
Email:
Web:
732-649-7099
[email protected]
www.kep.com
SET
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
SET
°C
°F
VV
OP1
OP2
OP3
mL-PI8 Process Indicator Error Messages
c
If there is danger of serious accident resulting from a failure or defect in
this unit, power off the system and separate the electrical connection
of the device from the system.
The unit is normally supplied without a power switch or a fuse. Use
power switch and fuse as required.
Be sure to use the rated power supply voltage to protect the unit
against damage and to prevent failure.
Keep the power off until all of the wiring is completed so that electric
shock and trouble with the unit can be prevented.
Never attempt to disassemble, modify or repair this unit. Tampering
with the unit may results in malfunction, electric shock or fire.
Do not use the unit in combustible or explosive gaseous atmospheres.
During the equipment is putted in hole on the metal panel while
mechanical installation some metal burrs can cause injury on hands,
you must be careful.
Montage of the product on a system must be done with it’s mounting
clamp. Do not do the montage of the device with inappropriate
mounting clamp. Be sure that device will not fall while doing the
montage.
It is your responsibility if this equipment is used in a manner not
specified in this instruction manual.
Before beginning installation of this product, please
read the instruction manual and warnings below
carefully.
In package ,
- One piece unit
- Two pieces mounting clamp
- One piece instruction manual
A visual inspection of this product for possible damage occured during
shipment is recommended before installation. It is your responsibility
to ensure that qualified mechanical and electrical technicians install
this product.
Kessler-Ellis Products warrants that the equipment delivered is free
from defects in material and workmanship. This warranty is
provided for a period of two years. The warranty period starts from
the delivery date. This warranty is in force if duty and
responsibilities which are determined in warranty document and
instruction manual performs by the customer completely.
Repairs should only be performed by trained and specialized
personnel. Cut power to the device before accessing internal parts.
Do not clean the case with hydrocarbon-based solvents (Petrol,
Trichlorethylene etc.). Use of these solvents can reduce the
mechanical reliability of the device. Use a cloth dampened in ethyl
alcohol or water to clean the external plastic case.
Ordering Information
PASS ConF: Password Parameter
Warranty
out3 ConF: 5A Relay Output
Alarm Types
Gen ConF: General Parameters
Com ConF: Serial Communication Configuration Parameters Maintenance
Other Informations
Installation
Warranty
Warranty
Maintenance
Maintenance
Warranty
Other Informations
mLINE
Model Number Description
mL-PI8
(Rev-A)
Process Indicator
1/8 DIN Case
Universal Input. Selectable: TC, RTD, mV, VDC, or mA
100 to 240VAC (-15%; +10%) 50/60Hz
2 Relay Outputs
1- (5A @ 250VAC with Resistive Load) (Form C)
1- (3A @ 250VAC with Resistive Load) (Form A)
RS-485 Serial Communication with Modbus RTU Protocol
Analog Output 0/4 - 20mA
Gasket to provide NEMA4X seal
Options (add to end of model number)
24VDC 24VDC (-15%; +10%) Power Input
Accessories
mL-cable-485 RS485 Serial Cable
