  9. KERN EOB-A01 User manual

KERN EOB-A01 User manual

2 EOB-A01-A01N-IA-e-1310
GB
KERN EOB-A01-A01N
Version 1.0 03/2013
Assembly instructions Tripod
Contents
1Technical data.........................................................................................................2
2Scope of delivery ....................................................................................................3
3Assembly EOB-A01.................................................................................................3
3.1 Assemble the tripod to the balance .................................................................................3
3.2 Assemble the display unit to the tripod...........................................................................4
4Assembly EOB-A01N..............................................................................................4
4.1 Assemble the tripod to the balance .................................................................................4
4.2 Assemble the display unit to the tripod...........................................................................5
EOB-A01 EOB-A01N
Suitable only for medical balances
with platform size up to 310 x 300
mm.
Only suitable for non–medical
balances with platform size up to
310 x 300 mm.
1 Technical data
KERN EOB-A01 EOB-A01N
Net weight 1150 g 1645 g
Tripod height 450 mm 450 mm
EOB-A01-A01N-IA-e-1310 3
2 Scope of delivery
EOB-A01 EOB-A01N
1. Tripod
2. Fastening screws
3. Turning knobs for assembly display unit
4. Support screw
1. Tripod
2. Fastening screws
3. Turning knobs for assembly display unit
4. Support screw (already assembled)
5. Rubber cover
3 Assembly EOB-A01
3.1 Assemble the tripod to the balance
Example:
(Figure approximately)
Fasten the tripod acc. to illustration with
the 4 screws on the lower side of the
platform.
Observe that during screwing
down not too much pressure is performed
on the weighing pan.
