KERN SFE-A03 User manual

KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
E-Mail: [e-mail]
Tel: +49-[0]7433- 9933-0
Fax: +49-[0]7433-9933-149
Internet: www.kern-sohn.com
Assembly instructions Tripods
KERN SFE-A01 / A02 / A03
Version 2.0
04/2014
GB
Example SFE-A02
SFE-A01/A02/A03-IA-e-1420

GB
KERN SFE-A01 /A02 / A03
Version 2.0 04/2014
Assembly instructions Tripod
Contents
1Technical data..........................................................................................................2
2Scope of delivery .....................................................................................................3
3Assembly..................................................................................................................3
3.1 Assemble the tripod to the balance..................................................................................3
3.2 Assemble the display unit to the tripod............................................................................4
1 Technical data
KERN SFE-A01 SFE-A02 SFE-A03
Tripod height 20 cm 40 cm 60 cm
Net weight 800 g 1600 g 2400 g
For SFE models with
weighing plate (mm) all sizes 400 x 300 x 118
500 x 400 x 137
650 x 500 x 142
500 x 400 x 137
650 x 500 x 142
SFE-A01/A02/A03-IA-e-1420 2

2 Scope of delivery
1. Tripod
2. Support screw
3. 4 screws (large) with securing
disks and washers for assembly
to a balance
4. 4 screws (small) with nuts for
assembly of the display unit
3 Assembly
3.1 Assemble the tripod to the balance
Attach the tripod to the platform acc. to
illustration using the 4 large screws, the
securing disks and the washers.
Screw-out support screw till it is safely
fixed.
3 SFE-A01/A02/A03-IA-e-1420

3.2 Assemble the display unit to the tripod
Screw tight the display unit to the tripod
using the 4 small screws and the nuts
according to the illustration.
Fix the cable using cable ties in a way
that it does not disturb the weighing
process.
SFE-A01/A02/A03-IA-e-1420 4
