KERN ABP User manual

KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
E-Mail: [e-mail]
Phone: +49-[0]7433- 9933-0
Fax: +49-[0]7433-9933-149
Internet: www.kern-sohn.com
Operating manual
Analytical balance
KERN ABP
Version 1.0
2018-08
GB
ABP-BA-e-1810

2 ABP-BA-e-1810
GB
KERN ABP
Version 1.0 2018-08
Operating manual
Analytical balance
Contents
1Technical data................................................................................................ 5
2Declaration of conformity ............................................................................. 7
3Appliance overview ....................................................................................... 8
3.1 Components.............................................................................................................................. 8
3.2 Keyboard................................................................................................................................. 10
3.2.1 Numeric entry ........................................................................................................................... 11
3.3 Display..................................................................................................................................... 12
4Basic Information (General)........................................................................ 15
4.1 Proper use............................................................................................................................... 15
4.2 Improper Use .......................................................................................................................... 15
4.3 Warranty.................................................................................................................................. 15
4.4 Monitoring of Test Resources............................................................................................... 16
5Basic Safety Precautions............................................................................ 16
5.1 Pay attention to the instructions in the Operation Manual................................................ 16
5.2 Personnel training.................................................................................................................. 16
6Transport and storage................................................................................. 16
6.1 Testing upon acceptance ...................................................................................................... 16
6.2 Packaging / return transport................................................................................................. 17
7Unpacking, Setup and Commissioning ..................................................... 19
7.1 Installation Site, Location of Use.......................................................................................... 19
7.2 Unpacking and checking....................................................................................................... 19
7.2.1 Placing ...................................................................................................................................... 21
7.3 Mains connection................................................................................................................... 24
7.3.1 Turning On the Power .............................................................................................................. 25
7.4 Initial Commissioning ............................................................................................................ 25
7.5 Connection of peripheral devices......................................................................................... 26
8Adjustment................................................................................................... 26
8.1 Automatic adjustment via PSC function.............................................................................. 26
8.2 Time-controlled automatic adjustment................................................................................ 28
8.3 Manual adjustment via key [CAL-key].................................................................................. 29
8.3.1 Setting adjustment function for CAL-key .................................................................................. 29
8.3.2 Adjustment with internal weight ................................................................................................ 29
8.3.3 Adjustment test with internal weight ......................................................................................... 30
8.3.4 Adjustment with external weight ............................................................................................... 30
8.3.5 Adjustment test with external weight ........................................................................................ 31
8.4 Adjustment log ....................................................................................................................... 32
8.5 Regular inspections............................................................................................................... 33
9Verification................................................................................................... 35

ABP-BA-e-1810 3
10 Basic Operation ........................................................................................... 36
10.1 Activate standard weighing mode........................................................................................ 36
10.2 Simple weighing ..................................................................................................................... 36
10.3 Taring....................................................................................................................................... 37
10.4 Underfloor weighing............................................................................................................... 38
10.5 Switch off the balance............................................................................................................ 39
10.6 Switch-over weighing unit..................................................................................................... 39
10.7 Change readability (1D/10D) (not available for verified models)....................................... 39
10.8 Display Tare / Net / Gross...................................................................................................... 40
10.9 Display decimal dot as point or comma............................................................................... 41
11 Menu ............................................................................................................. 42
11.1 Navigation in the menu.......................................................................................................... 42
11.1.1 Standard weighing mode ..................................................................................................... 43
11.1.2 Weighing settings ................................................................................................................. 44
11.1.3 System Settings ................................................................................................................... 46
11.1.4 Application settings .............................................................................................................. 48
11.2 Menu overview........................................................................................................................ 48
11.3 Resetting the menu................................................................................................................ 49
11.4 Menu Lock............................................................................................................................... 50
11.5 Log menu settings.................................................................................................................. 51
11.6 Menu history........................................................................................................................... 52
12 Description of individual functions............................................................ 53
12.1 Zero setting and tare function............................................................................................... 53
12.2 Zero tracking function............................................................................................................ 53
12.3 Auto Tare function.................................................................................................................. 54
12.4 Settings for Stability and Response..................................................................................... 55
12.4.1 Stability and reaction settings via „Smart Setting display“ (without invoking menu) ............ 55
12.5 Dosing...................................................................................................................................... 56
12.5.1 Standstill width ..................................................................................................................... 57
12.6 Weighing Units ....................................................................................................................... 58
12.7 User administration log-in function...................................................................................... 58
13 Balance settings .......................................................................................... 65
13.1 Screen saver ........................................................................................................................... 65
13.2 Display settings in operating mode...................................................................................... 65
13.3 Balance identification no....................................................................................................... 66
13.4 Entering date and time........................................................................................................... 66
13.5 Date format.............................................................................................................................. 66
13.6 Brightness of display............................................................................................................. 67
13.7 Audio signal on pressing key or display of stability.......................................................... 67
13.8 User language......................................................................................................................... 67
14 Application Functions ................................................................................. 68
14.1 Parts counting ........................................................................................................................ 69
14.1.1 Settings ................................................................................................................................ 69
14.1.2 Setting the display ................................................................................................................ 71
14.1.3 Part counting ........................................................................................................................ 71
14.1.4 Change settings ................................................................................................................... 72
14.1.5 Switching between counting and weighing mode ................................................................ 72
14.2 Percent determination............................................................................................................ 73
14.2.1 Settings ................................................................................................................................ 73
14.2.2 Setting the display ................................................................................................................ 75
14.2.3 Performing calculation of percentage .................................................................................. 76
14.2.4 Change settings ................................................................................................................... 76
14.2.5 Switching between percentage and weighing mode ............................................................ 77

4 ABP-BA-e-1810
14.3 Determining the density of solid matter and fluids ............................................................ 77
14.4 Totalization.............................................................................................................................. 78
14.5 Formulation............................................................................................................................. 81
14.5.1 Free formulating ................................................................................................................... 81
14.5.2 Define and process formulations ......................................................................................... 84
14.5.3 Change recipe ...................................................................................................................... 88
14.5.4 Sample log (KERN YKB-01N): ............................................................................................. 89
14.6 Preparing buffer solutions..................................................................................................... 90
14.7 Sample preparation................................................................................................................ 93
14.7.1 Changing saved samples ..................................................................................................... 95
14.8 Statistics.................................................................................................................................. 96
14.9 Control weighing and target weighing................................................................................. 98
14.9.1 Target weighing .................................................................................................................... 98
14.10 Control weighing (Pass / Fail evaluation)...................................................................... 100
14.11 Minimum sample weight.................................................................................................. 102
15 Interfaces.................................................................................................... 103
15.1 Connect printer..................................................................................................................... 103
15.2 Connect PC ........................................................................................................................... 103
15.3 Connect serial devices / connect programmable controller (SPS / PLC)....................... 104
15.4 Interface cable (RS232)........................................................................................................ 104
15.5 Data transmission format .................................................................................................... 105
15.6 Interface commands............................................................................................................. 106
15.7 Communication parameters................................................................................................ 110
15.7.1 Select standard setting ....................................................................................................... 110
15.7.2 User defined settings (display example for KERN YKB-01N ............................................. 111
15.8 Issue functions ..................................................................................................................... 113
15.8.1 Automatic data output / Auto Print function ........................................................................ 113
15.8.2 Continuous data output ...................................................................................................... 114
15.8.3 GLP Output Function ......................................................................................................... 116
15.8.4 Defining output details ........................................................................................................ 117
15.10 USB connection ............................................................................................................... 118
15.10.1 Edit weighing data, adjustment logs and screenshots to USB medium ............................ 119
15.10.2 Data transfer by means of barcode reader ........................................................................ 122
16 Servicing, maintenance, disposal ............................................................ 123
16.1 Cleaning ................................................................................................................................ 123
16.2 Servicing, maintenance ....................................................................................................... 124
16.3 Disposal................................................................................................................................. 125
17 Instant help................................................................................................. 125
18 Ionizer (factory option).............................................................................. 126
18.1 General .................................................................................................................................. 126
18.2 Basic Safety Precautions .................................................................................................... 126
18.3 Technical Data ...................................................................................................................... 128
18.4 Commissioning..................................................................................................................... 128
18.5 Maintenance and cleaning................................................................................................... 130

ABP-BA-e-1810 5
1 Technical data
KERN ABP 100-4M ABP 100-5DM
Item no./ Type TABP 100-4M-A TABP 100-5DM-A
Readability (d) 0.0001 g 0.00001 g / 0.0001 g
Weighing range (max) 120 g 52 g / 120 g
Minimum load (Min) 0.01 g 0.001 g
Verification value (e) 0.001 g 0.001 g
Verification class I I
Reproducibility 0.0001 g 0.00002 g / 0.0001 g
Linearity ± 0.0002 g ± 0.00005 g / 0.0002 g
Stabilization time 2 s 2 s / 8 s
Adjustment weight internal
Warm-up time 8 h
Weighing Units mg, g, ct (unverified)
g, ct (verified)
Smallest component weight
for part counting
1mg (under lab conditions*)
10 mg (under normal conditions**)
Reference quantities at
piece counting 1 - 100
Weighing plate, stainless steel ø 91mm
Dimensions caisse
(l x L x h) [mm] 212 x 367 x 345 212 x 411 x 345
Dimensions
Glass wind screen [mm] 170 x 165 x 220 mm (weighing space)
Net weight (kg) 7 8
Permissible
ambient condition +5° C to +40° C
Humidity of air 20 ~ 85 % relative (not condensing)
Power pack
Input voltage
AC 100 -240 V, 300 mA 50/60Hz
or
AC 100 -240 V, 320 – 190 mA 50/60Hz
Weighing scales
Input voltage DC 12 V, 1,0 A
Degree of pollution 2
Overvoltage category Category II
Metres in height Up to 2000 m
Place of installation In sealed rooms only
Interfaces RS-232, USB (type B, PC connection), USB host (type A)

6 ABP-BA-e-1810
KERN ABP 200-4M ABP 200-5DM ABP 300-4M
Item no./ Type TABP 200-4M-A TABP 200-5DM-A TABP 300-4M-A
Readability (d) 0.0001 g 0.00001 g / 0.0001 g 0.0001 g
Weighing range (max) 220 g 102 g / 220 g 320 g
Minimum load (Min) 0.01 g 0.001 g 0.01 g
Verification value (e) 0.001 g 0.001 g 0.001 g
Verification class I I I
Reproducibility 0.0001 g 0.00005 g / 0.0001 g 0.00015 g
Linearity ± 0.0002 g ± 0.0001 g / 0.0002 g ± 0.0003 g
Stabilization time 2 s 2 s / 8 s 2 s
Adjustment weight internal
Warm-up time 8 h
Weighing Units mg, g, ct (unverified)
g, ct (verified)
Smallest component weight
for part counting
1mg (under lab conditions*)
10 mg (under normal conditions**)
Reference quantities at
piece counting 1 - 100
Weighing plate, stainless steel ø 91mm
Dimensions caisse
(l x L x h) [mm] 212 x 367 x 345 212 x 411 x 345 212 x 367 x 345
Dimensions
Glass wind screen [mm] 170 x 165 x 220 mm (weighing space)
Net weight (kg) 7 8 7
Permissible
ambient condition +5° C to +40° C
Humidity of air 20 ~ 85 % relative (not condensing)
Power pack
Input voltage
AC 100 -240 V, 300 mA 50/60Hz
or
AC 100 -240 V, 320 – 190 mA 50/60Hz
Weighing scales
Input voltage DC 12 V, 1,0 A
Degree of pollution 2
Overvoltage category Category II
Metres in height Up to 2000 m
Place of installation In sealed rooms only
Interfaces RS-232, USB (type B, PC connection), USB host (type A)

ABP-BA-e-1810 7
* Smallest component weight for part counting - under lab conditions:
 There are ideal ambient conditions for high-resolution counting
 The parts to be counted are not scattered
** Smallest component part for part counting – under normal conditions:
 There are unsteady ambient conditions (draft, vibrations)
 The parts to be counted are being scattered
2 Declaration of conformity
The current EC/EU Conformity declaration can be found online in:
www.kern-sohn.com/ce
For verified weighing scales (= weighing scales assessed for
conformity) a declaration of
conformity is included in the scope of
delivery.

8 ABP-BA-e-1810
3 Appliance overview
3.1 Components
Models d = 0.0001 g Mode. d = 0.00001 g/0.0001 g
Pos. Description
1 Keyboard
2 Bubble level
3 Display
4 Windshield
5 Weighing pan
6 Fastening point ionizer (optional)
7 Glass wind screen
8 USB host port
9 Levelling screw

ABP-BA-e-1810 9
Rear view:
Models d = 0.0001 g Models d = 0.00001 g/0.0001 g
Pos. Description
10 Serial interface (RS232)
11 USB device
12 Port for ionizer
13 Connector for AC adapter
14 Fastening point for anti-theft device
16 Fastening lug for anti-theft chain or wire
17 Port for power pack
18 External electronics box

10 ABP-BA-e-1810
3.2 Keyboard
Button Description Function
Short key pressing
Long key pressing
In menu
[ON/OFF] Switching between
operating and
standby mode
- Return to
weighing mode
[1d/10d] Readability
change
[CAL] Start adjustment Call setup menu
"Adjustment" -
[PRINT] Data output to
external device
(weighing mode)
Call setup menu
"Print"
[TARE] Taring
Zeroing
Call setup "Zero
Setting / Taring"
[MENU]
• Call up menu
• Call application
specific settings
• Call Statistics
[Ionizer] Ionizer on/off
(Factory option)
Call Setup Menu
Ionizer
(Factory option)
[OK] - - Confirm
input

ABP-BA-e-1810 11
[R] Change reaction
setting for display
Select menu
item.
Navigation button 
[UNIT] Weighing mode:
Switch-over weighing
unit.
Counting mode:
Display single weight
Calculate
percentage:
Display reference
weight
Call setup menu
"Units"
Scroll forward in
menu
Navigation button 
[F] Switch over
weighing mode /
application mode
Scroll
backwards in
menu
Navigation button 
[S] Change stability
setting of display Select menu
item.
Navigation button 
3.2.1 Numeric entry
Button
Description
Function
Navigation button
Flashing digit (0 – 9) or
increase character (, [blank], -, A – Z)
Navigation button  Flashing digit (0 – 9) or
reduce character (, [blank], -, A – Z)
Navigation button Digit selection to the right
Navigation button
 Digit selection to the left
Navigation button Confirm entry
ESC Cancel input

12 ABP-BA-e-1810
3.3 Display
Apart from the display of the weighing result, all functions of the menu may be
accessed from here. The display will vary, depending on the weighing scale being
either in operating or setting mode.
Special keys (e.g. CAL-, TARE-, PRINT-key) provide fast and purposeful access to
the individual setup menu. The navigation keys allow intuitive control.
Display example operating mode:
The display is sub-divided into four areas.
No.
Status Description
1 Operating
mode
Current application
2 User field Display of logged-in user and current time
Data output to external devices
USB-storage medium is connected
Menu Lock
3 Measuring
Value
Display of weighing result in current weighing unit
Stability display
Net weight
Tare weight
Gross weight
Hold function enabled
Zero indicator
Negative weighed value
Net weight during formulating
Tolerance marker
Capacity display
The non-verified value is given in
brackets in verified scales.

ABP-BA-e-1810 13
4
Status display
Current settings
Minimum initial weight
Settings for Stability and Response
Printer settings
Auto Print function active
Flashing during automatic Output
continuous output enabled
Flashing during continuous Output
Weighing settings
Dispensing mode
Zero tracking (Autom. zero point
correction)
Statistics
Error reports
Adjustment required (PSC-function)
Inadequate power supply
Defective USB-connection
Display example setting mode:
After pressing the MENU-key in weighing mode the display will change to setting
mode.
Example of illustration: For calling system settings see chap. 11.1.3

14 ABP-BA-e-1810
Symbol Description Application icons
Level 1
Selecting an
application
Weighing mode
Parts counting
Percent determination
Density determination <Solid matter>
Density determination <Fluids>
Totalization
Formulation
Autom. Processing a recipe
Produce a buffer solution
Produce an analysis sample
Symbol Description Application icons
Level 2
Icon of selected
application Available settings will be shown on level 1.
Level 1
Weighing settings
Dosing
Zero tracking
Level 1
System Settings System Settings
Settings <Print>
Settings <Save data>
Settings <Communication>
Settings <Adjustment>
Settings <User>
Level 1
History
The last 10 menu steps will be displayed.
For further information about the operation of the display, see chap. 11.1
The icon for the
application selected
will be shown

ABP-BA-e-1810 15
4 Basic Information (General)
4.1 Proper use
The balance you purchased is intended to determine the weighing value of material
to be weighed. It is intended to be used as a “non-automatic balance”, i.e. the
material to be weighed is manually and carefully placed in the centre of the weighing
pan. As soon as a stable weighing value is reached the weighing value can be read.
4.2 Improper Use
Do not use balance for dynamic add-on weighing procedures, if small amounts of
goods to be weighed are removed or added. The “stability compensation“ installed in
the balance may result in displaying an incorrect measuring value! (Example: Slowly
draining fluids from a container on the balance.)
Do not leave permanent load on the weighing pan. This may damage the measuring
system.
Impacts and overloading exceeding the stated maximum load (max) of the balance,
minus a possibly existing tare load, must be strictly avoided. Balance may be
damage by this.
Never operate balance in explosive environment. The serial version is not explosion
protected.
The structure of the balance may not be modified. This may lead to incorrect
weighing results, safety-related faults and destruction of the balance.
The balance may only be used according to the described conditions. Other areas of
use must be released by KERN in writing.
4.3 Warranty
Warranty claims shall be voided in case
• Our conditions in the operation manual are ignored
• The appliance is used outside the described uses
• The appliance is modified or opened
• Mechanical damage or damage by media, liquids, natural wear and tear
• The appliance is improperly set up or incorrectly electrically connected
• The measuring system is overloaded

16 ABP-BA-e-1810
4.4 Monitoring of Test Resources
In the framework of quality assurance the measuring-related properties of the
balance and, if applicable, the testing weight, must be checked regularly. The
responsible user must define a suitable interval as well as type and scope of this test.
Information is available on KERN’s home page (www.kern-sohn.com with regard to
the monitoring of balance test substances and the test weights required for this. In
KERN's accredited DKD calibration laboratory test weights and balances may be
calibrated (return to the national standard) fast and at moderate cost.
5 Basic Safety Precautions
5.1 Pay attention to the instructions in the Operation Manual
 Carefully read this operation manual before setup and
commissioning, even if you are already familiar with KERN balances.
 All language versions contain a non-binding translation.
The original German is binding.
5.2 Personnel training
The appliance may only be operated and maintained by trained personnel.
6 Transport and storage
6.1 Testing upon acceptance
When receiving the appliance, please check packaging immediately, and the
appliance itself when unpacking for possible visible damage.

ABP-BA-e-1810 17
6.2 Packaging / return transport
 Keep all parts of the original packaging for a possibly
required return.
 Only use original packaging for returning.
 Prior to dispatch disconnect all cables and remove
loose/mobile parts.
Illustration example models d = 0.0001 g
 Reattach possibly supplied transport securing devices.
 Secure all parts such as the glass wind screen, the
weighing platform, power unit etc. against shifting and
damage.
 Put network adapter and accessories in the small box
 Lift scale with both hands

18 ABP-BA-e-1810

ABP-BA-e-1810 19
7 Unpacking, Setup and Commissioning
7.1 Installation Site, Location of Use
The balances are designed in a way that reliable weighing results are achieved in
common conditions of use.
You will work accurately and fast, if you select the right location for your balance.
Therefore, observe the following for the installation site:
• Place the balance on a firm, level surface;
• Avoid extreme heat as well as temperature fluctuation caused by installing
next to a radiator or in the direct sunlight;
• Protect the balance against direct draughts due to open windows and doors;
• Avoid jarring during weighing;
• Protect the balance against high humidity, vapours and dust;
• Do not expose the device to extreme dampness for longer periods of time.
Non-permitted condensation (condensation of air humidity on the appliance)
may occur if a cold appliance is taken to a considerably warmer environment.
In this case, acclimatize the disconnected appliance for ca. 2 hours at room
temperature.
• Avoid static charge of weighed items or weighing container.
If electro-magnetic fields or static charge occur, or if the power supply is unstable
major deviations on the display (incorrect weighing results) are possible. In that case,
the location must be changed.
7.2 Unpacking and checking
Remove device and accessories carefully from packaging, remove packaging
material and place device at the planned work place. Check if that there has been no
damage and that all packing items are present.

20 ABP-BA-e-1810
Scope of delivery / serial accessories
Pos. Description
1 Balance
2 Weighing pan
3 Carrier weighing pan
4 Centring ring (Models d = 0.0001 g only)
5 Protective cover
6 Mains adapter
7 Holder for adapter cable (Models d = 0.0001 g only)
8 Operating manual
9 External electronics box
10 Guard plate
11 Windshield
12 Multi-function weighing platform
13 Support multi-function weighing platform
Models d = 0.00001 g/0.0001 g only:
