Operating manual
Counting balance/counting system
KERN CFS/CCS
Version 2.5
2018-03
GB
CFS/CCS-BA-e-1825

2 CFS/CCS-BA-e-1825
GB
KERN CFS/CCS
Version 2.5 2018-03
Operating instructions Counting
balance/counting system
Contents
1Technical data .......................................................................................... 4
1.1 KERN CFS .......................................................................................................................... 4
1.2 Counting systems KERN CCS.......................................................................................... 7
2Appliance overview.................................................................................. 8
2.1 Counting scales KERN CFS ............................................................................................. 8
2.2 Counting systems KERN CCS........................................................................................ 10
2.3 Counting systems with your selected bulk scales ...................................................... 10
2.4 Overview of display......................................................................................................... 12
2.4.1 Display weight.................................................................................................................... 13
2.4.2 Display average piece weight............................................................................................ 13
2.4.3 Display quantity ................................................................................................................. 13
2.5 Keyboard overview.......................................................................................................... 14
3Basic instructions...................................................................................17
3.1 Proper use........................................................................................................................ 17
3.2 Improper Use.................................................................................................................... 17
3.3 Warranty ........................................................................................................................... 17
3.4 Monitoring of Test Resources........................................................................................ 18
4Basic Safety Precautions .......................................................................18
4.1 Pay attention to the instructions in the Operation Manual......................................... 18
4.2 Personnel training........................................................................................................... 18
5Transport and storage............................................................................18
5.1 Testing upon acceptance ............................................................................................... 18
5.2 Packaging / return transport .......................................................................................... 18
6Unpacking, Setup and Commissioning.................................................19
6.1 Installation Site, Location of Use................................................................................... 19
6.2 Unpacking, Scope of delivery ........................................................................................ 19
6.2.1 Scope of delivery / serial accessories ............................................................................... 19
6.3 Installing / removing transport fittings.......................................................................... 20
6.4 Mains connection ............................................................................................................ 21
6.5 Rechargeable battery operation (optional)................................................................... 21
6.6 Connection of peripheral devices.................................................................................. 22
6.7 Initial Commissioning ..................................................................................................... 22
6.8 Adjustment....................................................................................................................... 22
7Basic Operation.......................................................................................23
7.1 Switching on/off............................................................................................................... 23
7.2 Zeroing.............................................................................................................................. 23
7.3 Switching over reference scale bulk scales if used as counting system ............. 23
7.4 Weighing with tare........................................................................................................... 25
7.4.1 Taring................................................................................................................................. 25
7.4.2 Numeric entering of tare weight......................................................................................... 25
7.4.3 Switch-over weighing unit.................................................................................................. 25

CFS/CCS-BA-e-1825 3
8Parts counting........................................................................................ 26
8.1 Determination of the average piece weight by weighing.............................................27
8.2 Numeric input of the average piece weight...................................................................30
8.3 Automatic reference optimization..................................................................................32
8.4 Counting with counting system .....................................................................................33
9Fill-to-target function ............................................................................. 35
9.1 Tolerance check for target weight..................................................................................36
9.2 Tolerance check for target quantity...............................................................................38
10 Totalization ............................................................................................. 40
10.1 Manual totalizing..............................................................................................................40
10.2 Automatic adding-up.......................................................................................................42
11 Store article information........................................................................ 43
11.1 Store article ......................................................................................................................43
11.2 Call article.........................................................................................................................46
11.3 Article direct keys ~ (only model CFS 50K-3).....................................47
12 Menu........................................................................................................ 49
12.1 Navigation in the menu....................................................................................................49
12.2 Menu overview .................................................................................................................50
12.2.1 Models 6K0.1, 15K0.2, 30K0.5, 50K-3...............................................................................50
12.2.2 Models CFS 3K-5, CFS 300-3 ...........................................................................................52
13 Configuration of bulk scale................................................................... 54
14 Adjustment ............................................................................................. 60
14.1 Models CFS 300-3, CFS 3K-5 ..........................................................................................60
14.2 Models CFS 6K0.1, CFS 15K0.2, CFS 30K0.5 ................................................................61
14.3 Model KERN CFS 50K-3...................................................................................................63
15 Linearization........................................................................................... 64
15.1 Models CFS 300-3, CFS 3K-5 ..........................................................................................66
15.2 Model KERN CFS 50K-3...................................................................................................67
16 Second balance interface...................................................................... 69
17 RS 232C interface................................................................................... 70
17.1 Technical data ..................................................................................................................70
17.2 Printer operation ..............................................................................................................71
17.2.1 Printout example KERN YKB-01N / model CFS 300-3......................................................71
17.2.2 Printout examples KERN YKB-01N / model CFS 3K-5 .....................................................71
17.2.3 Printout examples KERN YKB-01N / CFS 6K0.1, CFS 15K0.2, CFS 30K0.5..................73
17.2.4 Printout examples KERN YKB-01N / model CFS 50K-3 ...................................................77
17.3 Remote control instructions...........................................................................................78
17.3.1 All Models...........................................................................................................................78
17.3.2 Models CFS 6K0.1 / CFS 15K0.2 / CFS 30K0.5................................................................79
17.4 User identification, scale identification, store article name ........................................80
17.5 Register / call article via RS232......................................................................................80
17.6 I/O-function.......................................................................................................................81
18 Servicing, maintenance, disposal......................................................... 82
18.1 Cleaning ............................................................................................................................82
18.2 Servicing, maintenance...................................................................................................82
18.3 Disposal ............................................................................................................................82
19 Instant help............................................................................................. 83
19.1 Error messages................................................................................................................84
20 Declaration of conformity...................................................................... 85

4 CFS/CCS-BA-e-1825
1 Technical data
1.1 KERN CFS
KERN CFS 300-3 CFS 3K-5 CFS 6K0.1
Readability (d) 0.001 g 0.01 g 0.1 g
Weighing range (max) 300 g 3 kg 6 kg
Reproducibility 0.002 g 0.02 g 0.1 g
Linearity ± 0.004 g ± 0.04 g ± 0.2 g
Stabilization time 2 s
Weighing Units g, lb kg, lb
Recommended adjusting
weight (not supplied) 200 g(F1) + 100 g(F1) 2 kg(F1) + 1 kg(F1) 6 kg (F2)
Warm-up time 2 h
Minimum unit weight at
piece counting under
laboratory conditions* 5 mg 50 mg 100 mg
Minimum unit weight at
piece counting under
normal conditions** 50 mg 500 mg 1 g
Reference unit weights at
piece counting freely selectable
Net weight (kg) 2.5 kg 3.8 kg
Permissible ambient
condition 0° C to 40° C
Humidity of air max. 80 % relative (not condensing)
Weighing plate, stainless
steel ᴓ 80 mm 294 x 225 mm
Dimensions wind screen
[mm]
inside
158 x 143 x 61 -
outside
167 x 154 x 80
Dimensions housing
(l x L x h) [mm] 320 x 350 x 125 mm
Mains connection Mains adapter 230 V AC, 50 Hz; 12 V DC balance, 500 mA
Rechargeable battery
(optional)
Operating duration approx. 70 h / loading time approx. 12
hours

CFS/CCS-BA-e-1825 5
KERN CFS 15K0.2 CFS 30K0.5 CFS 50K-3
Readability (d) 0.2 g 0.5 g 1 g
Weighing range (max) 15 kg 30 kg 50 kg
Reproducibility 0.2 g 0.5 g 1 g
Linearity ± 0.4 g ± 1 g ± 2 g
Stabilization time 2 s
Weighing Units kg, lb
Recommended adjusting
weight (not supplied) 15 kg (F2) 30 kg (F2) 50 kg (F2)
Warm-up time 2 h
Minimum unit weight at
piece counting under
laboratory conditions* 200 mg 500 mg 1 g
Minimum unit weight at
piece counting under
normal conditions** 2 g 5 g 10 g
Reference unit weights at
piece counting freely selectable
Net weight (kg) 3.8 kg 5.5 kg
Permissible ambient
condition 0° C to 40° C
Humidity of air max. 80 % relative (not condensing)
Weighing plate, stainless
steel 294 x 225 370 x 240
Dimensions housing
(l x L x h) [mm] 320 x 350 x 125 370 x 360 x 125
Mains connection Mains adapter 230 V AC, 50 Hz; 12 V DC balance, 500 mA
Rechargeable battery
(optional)
Operating duration approx. 70 h / loading time approx. 12
hours
* Minimum unit weight at piece counting under laboratory conditions:
Perfect ambient conditions to perform high resolution counting
No dispersion of counted parts weight
**Minimum unit weight at piece counting under normal conditions:
Unstable ambient conditions (wind gusts, vibrations)
Dispersion of counted parts weight

6 CFS/CCS-BA-e-1825
Dimensions:
Models
•CFS 300-3
•CFS 3K-5
•CFS 6K0.1
•CFS 15K0.2
•CFS 30K0.5
Model
•CFS 50K-3

CFS/CCS-BA-e-1523 7
1.2 Counting systems KERN CCS
Article no. /
Type
Weighing
pan
[mm]
Reference
balance
Article no.
Reference
balance
Weighing
range
Reference
balance
Readability
Bulk material balance
Article no.
Bulk material
balance
Weighing
range
Bulk material
balance
Readability
Minimum unit weight
at piece counting
under laboratory
conditions
Minimum unit
weight at piece
counting under
normal conditions
CCS 6K-6
230x230
CFS 300-3
0,3 kg
0,000001 kg
KFP 6V20M
6 kg
0,0002 kg
5 mg
50 mg
CCS 10K-6
300x240
CFS 300-3
0,3 kg
0,000001 kg
KFP 15V20M
15 kg
0,0005 kg
5 mg
50 mg
CCS 30K0.01.
400x300
CFS 3K-5
3 kg
10 mg
KFP 30V20M
30 kg
1 g
50 mg
500 mg
CCS 30K0.1.
400x300
CFS 6K0.1
6 kg
0,0001 kg
KFP 30V20M
30 kg
0,001 kg
100 mg
1 g
CCS 60K0.01.
225x295
CFS 3K-5
3 kg
0,00001 kg
KFP 60V20M
60 kg
0,002 kg
50 mg
500 mg
CCS 60K0.01L.
500x400
CFS 3K-5
3 kg
0,00001 kg
KFP 60V20LM
60 kg
0,002 kg
50 mg
500 mg
CCS 60K0.1.
400x300
CFS 6K0.1
6 kg
0,0001 kg
KFP 60V20M
60 kg
0,002 kg
100 mg
1 g
CCS 60K0.1L.
500x400
CFS 6K0.1
6 kg
0,0001 kg
KFP 60V20LM
60 kg
0,002 kg
100 mg
1 g
CCS 150K0.01
500x400
CFS 3K-5
3 kg
0,00001 kg
KFP 150V20M
150 kg
0,005 kg
50 mg
500 mg
CCS 150K0.01L
650x500
CFS 3K-5
3 kg
0,00001 kg
KFP 150V20LM
150 kg
0,005 kg
50 mg
500 mg
CCS 150K0.1.
500x400
CFS 6K0.1
6 kg
0,0001 kg
KFP 150V20M
150 kg
0,005 kg
100 mg
1 g
CCS 150K0.1L
650x500
CFS 6K0.1
6 kg
0,0001 kg
KFP 150V20LM
150 kg
0,005 kg
100 mg
1 g
CCS 300K0.01
650x500
CFS 3K-5
3 kg
0,00001 kg
KFP 300V20M
300 kg
0,01 kg
50 mg
500 mg
CCS 300K0.1
650x500
CFS 6K0.1
6 kg
0,0001 kg
KFP 300V20M
300 kg
0,01 kg
100 mg
1 g
CCS 600K-2
1000x1000
CFS 3K-5
3 kg
0,00001 kg
KFP 600V20SM
600 kg
0,2 kg
50 mg
500 mg
CCS 600K-2L
1500x1250
CFS 3K-5
3 kg
0,00001 kg
KFP 600V20NM
600 kg
0,2 kg
50 mg
500 mg
CCS 600K-2U
840x1190
CFS 3K-5
3 kg
0,00001 kg
KFU 600V20M
600 kg
0,2 kg
50 mg
500 mg
CCS 1T-1
1000x1000
CFS 6K0.1
6 kg
0,0001 kg
KFP 1500V20SM
1500 kg
0,5 kg
100 mg
1 g
CCS 1T-1L
1500x1250
CFS 6K0.1
6 kg
0,0001 kg
KFP 1500V20M
1500 kg
0,5 kg
100 mg
1 g
CCS 1T-1U
840x1190
CFS 6K0.1
6 kg
0,0001 kg
KFU 1500V20M
1500 kg
0,5 kg
100 mg
1 g
CCS 3T-1
1500x1250
CFS 6K0.1
6 kg
0,0001 kg
KFP 3000V20LM
3000 kg
1 kg
100 mg
1 g
CCS 3T-1L
1500x1500
CFS 6K0.1
6 kg
0,0001 kg
KFP 3000V20LM
3000 kg
1 kg
100 mg
1 g

CFS/CCS-BA-e-1523 8
2 Appliance overview
2.1 Counting scales KERN CFS
Model:
CFS 300-3 Models: CFS 3K-5, CFS 6K0.1, CFS 15K0.2, CFS 30K0.5
1. Weighing plate / rechargeable battery compartment (under
weighing plate)
2. Windshield
3. Bubble level
4. RS 232 interface
5. Second balance interface
6. Footscrews
7. ON/OFF switch
8. Mains adapter connection

CFS/CCS-BA-e-1825 9
Model CFS 50K-3
1. Weighing pan
2. Bubble level
3. RS 232 interface
4. Second balance interface
5. Footscrews
6. Connection of mains adapter
7. ON/OFF switch

10 CFS/CCS-BA-e-1825
2.2 Counting systems KERN CCS
In factory the counting system KERN CCS is preconfigured in a way that no
more changes will be necessary.


Bulk material balance KERN KFP
Reference balance KERN CFS
2.3 Counting systems with your selected bulk scales
When attaching a bulk scales (not pre-adjusted by KERN), the following must
be complied with:

Connect bulk scales with a suitable cable via the second-balance interface.
Interface connection allocation cf. chapter 16

Adjustment of bulk scales, cf. chapter 13
Adjustment / linearisation of bulk scales, cf. chapter 14 / 15
Example 1: High-load bulk scales
Reference balance KERN CFS

CFS/CCS-BA-e-1825 11
Example 2: High-load reference scale
Image similar


Bulk material balance KERN KFP
Reference scale KERN CFS 50K-3

12 CFS/CCS-BA-e-1825
2.4 Overview of display
Model CFS 300-3:
Weight
Average piece weight
Quantity
Accumulator’s loading state, cf. chapter 6.5
Models CFS 3K-5, CFS 6K0.1, CFS 15K0.2, CFS 30K0.5:
Weight
Average piece weight
Quantity
Accumulator’s loading state, cf. chapter 6.5
Model CFS 50K-3:
Weight
Average piece weight
Accumulator’s loading state, cf. chapter 6.5
Quantity

CFS/CCS-BA-e-1825 13
2.4.1 Display weight
Here the weight of your goods is displayed in [kg].
Indicator [

] atop the symbol shows:
Storage battery status display
NET Net weight
Stability state indication
Model CFS 50K-3
aZeroing display
lb/kg Current weighing unit

1 Weighing unit bulk scale

2 Weighing unit reference balance
2.4.2 Display average piece weight
Here the average reference weight of a sample is displayed in [g]. This value is
either numerically entered by user or calculated by weighing on balance.
Indicator [

] atop the symbol shows:
Number of parts placed on balance too
small
Piece below minimum weight of piece
M+ Data in summation memory
Active balance:
1. Reference balance KERN CFS
2. Bulk scales e.g. KERN KFP
2.4.3 Display quantity
Here the current piece quantity (PCS = pieces) or in totalizing mode the sum
Sum of the placed parts is displayed, see chapter 10
Indicator [

] atop the symbol shows:
Tolerance control in counting mode
Tolerance control in weighing mode
+ Goods to be weighed above tolerance limit
TOL Goods to be weighed within tolerance
range
- Goods to be weighed below tolerance limit
12

14 CFS/CCS-BA-e-1825
2.5 Keyboard overview
Models CFS 300-3, CFS 3K-5, CFS 6K0.1, CFS 15K0.2, CFS 30K0.5
Selection
Function in Weighing mode
….. •Numeric keys
•Decimal point
•At numeric input digit selection to the left
•Delete
•Totalization
•Display total weight /number of weighings / total quantity
•At numeric input digit selection to the right
•Data output (menu setting , see chapter 12.2)
•Store/call article, cf. chapters 11.1 / 11.2
•Fill-to-target function (cf. chapter 9)
•Switch-over balance,
see chap. 7.3
•Input of the average piece weight by weighing, see chap.
8.1
•Numeric input of the average piece weight see chapter 8.2
•Leafing through the menu
•Switch-over weighing unit
•Taring
•Confirm
•Zeroing
•Back to menu/weighing mode

CFS/CCS-BA-e-1825 15
Model CFS 50K-3:
Selection
Function in Weighing mode
….. •Article direct keys,
cf. chapter 11.3
….. •Numeric keys
•Decimal point
•Delete
•Summing up / printing (menu adjustment ,
cf. chapter 12.2
•Display total weight /number of weighings / total quantity
•Data output (menu setting , see chapter 12.2)
•Fill-to-target function (cf. chapter 9)

16 CFS/CCS-BA-e-1825
•Store/call article, cf. chapters 11.1 / 11.2
•Switching over the scale, cf. chapter 7.3
•At numeric input digit selection to the left
•Input of the average piece weight by weighing, see chap. 8.1
•Leafing through the menu
•Numeric input of the average piece weight see chapter 8.2
•Switch-over weighing unit
•Taring
•Confirm
•Zeroing
•At numeric input digit selection to the right.
•Back to menu/weighing mode

CFS/CCS-BA-e-1825 17
3 Basic instructions
3.1 Proper use
The balance / counting system you purchased is intended to determine the
weighing value of material to be weighed. It is intended to be used as a “non-
automatic balance”, i.e. the material to be weighed is manually and carefully placed
in the centre of the weighing pan.. As soon as a stable weighing value is reached
the weighing value can be read.
3.2 Improper Use
Do not use balance / counting system for dynamic weighing. In the event that small
quantities are removed or added to the material to be weighed, incorrect weighing
results can be displayed due to the “stability compensation“. (Example: Slowly
draining fluids from a container on the balance.)
Do not leave permanent load on the weighing pan. This may damage the measuring
system.
Impacts and overloading exceeding the stated maximum load (max) of the balance /
counting system, minus a possibly existing tare load, must be strictly avoided.
Balance may be damage by this.
Never operate balance / counting system in explosive environment. The serial
version is not explosion protected.
The structure of the balance may not be modified. This may lead to incorrect
weighing results, safety-related faults and destruction of the balance.
The scale / the counting system may only be used according to the described
preconditions. Other areas of use must be released by KERN in writing.
3.3 Warranty
Warranty claims shall be voided in case
•Our conditions in the operation manual are ignored
•The appliance is used outside the described uses
•The appliance is modified or opened
•Mechanical damage or damage by media, liquids, natural wear and tear
•The appliance is improperly set up or incorrectly electrically connected
•The measuring system is overloaded

18 CFS/CCS-BA-e-1825
3.4 Monitoring of Test Resources
In the framework of quality assurance the measuring-related properties of the
balance and, if applicable, the testing weight, must be checked regularly. The
responsible user must define a suitable interval as well as type and scope of this
test. Information is available on KERN’s home page (www.kern-sohn.com with
regard to the monitoring of balance test substances and the test weights required
for this. In KERN's accredited DKD calibration laboratory test weights and balances
may be calibrated (return to the national standard) fast and at moderate cost.
4 Basic Safety Precautions
4.1 Pay attention to the instructions in the Operation Manual
Carefully read this operation manual before setup and
commissioning, even if you are already familiar with KERN balances.
All language versions contain a non-binding translation.
The original German is binding.
4.2 Personnel training
The appliance may only be operated and maintained by trained personnel.
5 Transport and storage
5.1 Testing upon acceptance
When receiving the appliance, please check packaging immediately, and the
appliance itself when unpacking for possible visible damage.
5.2 Packaging / return transport
Keep all parts of the original packaging for a possibly required return.
Only use original packaging for returning.
Prior to dispatch disconnect all cables and remove loose/mobile parts.
Reattach possibly supplied transport securing devices.
Secure all parts such as the glass wind screen, the weighing platform,
power unit etc. against shifting and damage.

CFS/CCS-BA-e-1825 19
6 Unpacking, Setup and Commissioning
6.1 Installation Site, Location of Use
The balances / counting systems are designed in a way that reliable weighing
results are achieved in common conditions of use.
You will work accurately and fast, if you select the right location for your balance /
counting system.
On the installation site observe the following:
•Place the balance / counting system on a firm, level surface;
•Avoid extreme heat as well as temperature fluctuation caused by installing
next to a radiator or in the direct sunlight;
•Protect the balance against direct draughts due to open windows and doors;
•Avoid jarring during weighing;
•Protect the balance / counting system against high humidity, vapours and
dust;
•Do not expose the device to extreme dampness for longer periods of time.
Non-permitted condensation (condensation of air humidity on the appliance)
may occur if a cold appliance is taken to a considerably warmer environment.
In this case, acclimatize the disconnected appliance for ca. 2 hours at room
temperature.
•Avoid static charge of goods to be weighed or weighing container.
Major display deviations (incorrect weighing results) may be experienced should
electromagnetic fields (e.g. due to mobile phones or radio equipment), static
electricity accumulations or instable power supply occur. Change location or remove
source of interference.
6.2 Unpacking, Scope of delivery
Remove device and accessories carefully from packaging, remove packaging
material and place device at the planned work place. Verify that there has been no
damage and that all packing items are present.
6.2.1 Scope of delivery / serial accessories
KERN CFS KERN CCS
•Balance (see chap. 2.1)
•Reference balance KERN CFS, see chap. 2.2
•Power cable
•Bulk material balance KERN KFP (see chap. 2.2)
•Protective cover
•Operating instructions KERN CFS/CCS
•
Operating manual
•
Operating instructions KERN KFP

20 CFS/CCS-BA-e-1825
6.3 Installing / removing transport fittings
Remove transport lock, if applicable.
KERN CFS 3K0.5, CFS 6K0.1:
KERN CFS 300-3:
Bulk scales KERN KFP (illustration example):
KERN KFP 6V20M, KFP 6V20LM, KFP 15V20M.
Please take further details from the installation manual, added to the platform.
