KEUCO Edition 400 11596 User manual

US ES
Instruction for use Manual de instrucciones de uso CA Instructions d'utilisation
Edition 400
311825_002/06.2020
11596 171050
11596 171550
11596 172050
11596 172550

2
US Read all instructions before using or installing this product.
IMPORTANT SAFETY
INSTRUCTIONS
DANGER - To reduce the risk of electric
shock:
–Always unplug this furnishing from the electrical
outlet before installation and cleaning.
WARNING - To reduce the risk of burns,
fire, electric shock, or injury to persons:
–Unplug from outlet before putting on or taking off
parts.
–Close supervision is necessary when this fur-
nishing is used by, or near children, invalids or
disabled persons.
–Use this furnishing only for its intended use as
described in these instructions. Do not use attach-
ments not recommended by the manufacturer.
–Never operate this furnishing if it has a damaged
cord or plug, if it is not working properly, if it has
been dropped or damaged, or dropped into water.
Return the furnishing to the service center for exa-
mination and repair.
–Never drop or insert any object into any opening.
–Do not use outdoors.
–Do not operate where aerosol (spray) products are
being used or where oxygen is being administe-
red.
–Before disconnect turn all controls to the off
position. Also turn the electricity offat the circuit
breaker or fuse box.
WARNING: Risk of Electric Shock -
Connect this furnishing to a properly grounded
outlet only. See Grounding Instructions.
–For loading always put heavier items at the bottom
and not near the top in order to help prevent the
possibility of the furnishing tipping over.
–Each surface intended to support a load shall have
a corresponding statement in the use instructions
specifying the maximum intended load for that
surface in pounds (kilograms).
WARNING - California Prop 65
–This product can expose you to chemicals inclu-
ding Di(2-ethylhexyl)phthalate (DEHP), which is
known to the State of California to cause cancer.
For more information, go to www.P65Warnings.
ca.gov .
SAVE THESE INSTRUCTIONS
–This product must be installed by a qualified
installer, in accordance with local codes
and regulations and according to the
instructions for use in the enclosed manual.
Correct installation reduces the risk of fire,
electric shock, burns and injury.
–Consult a qualified electrican to ensure cor-
rect branch circuit conductor.
– Connect the receptacle circuit to a branch circuit
protected with a Class A GFCI device.
– Do not start the appliance if it or the power
supply cable is damaged, but have it replaced
by the manufacturer, its customer service or by
an equally qualified person.
– It must be ensured that the wall can support the
weight of the mirror cabinet.
– Use only genuine replacement parts and
accessories. The use of other parts will result in
voiding of the warranty.
Approval and conformity
This mirror cabinet complies with
applicable requirements of the referenced
standard(s):Safety Household and
Commercial Furnishings.( UL962, 4rd ed.
portable Luminaires CSA C22.2 #250.4 )
Intended use
FOR RESIDENTIAL USE ONLY.
As a light mirror with dimmable lighting for use in
wet rooms such as bathrooms and toilets.
The product is suitable only for mounting indoors!
Caution! Only install in frost-free rooms.
CAUTION: Risk of personal injury: This prod-
uct is very heavy. Get assistance lifting the mirror
cabinet.
WARNING - GROUNDING
INSTRUCTIONS
This product must be connected to a grounded me-
tal, permanent wiring system, or an equiment-groun-
ding conductor must be run with the circuit con-
ductors and connected to the equipment-grounding
terminal or lead on the product.

3
Read all instructions before using or installing this product. US
Symbols and their meaning
Caution! Warning of personal injury or material
damage
Caution! Warning of electric shock.
Caution! Warning of water damage.
Note, tip or reference
Correct assembly/functional test
Incorrect assembly
Observe assembly details
Optional/accessories
Button on/off
Dimming the lighting
Light colour - daylight white (cool white)
Light colour warm white
Technical data
– Supply voltage: 120V AC 50Hz/60Hz
– Max. power consumption:
Prod. No.: Width Weight Light
11596 171050 21-1/16" 15.4 lb 10.7 W
11596 171550 27-15/16" 18.7 lb 14.3 W
11596 172050 41-3/4" 26.0 lb 20.7 W
11596 172550 55-1/2" 33.5 lb 27.0 W
– Degree of protection: NEMA 1
– Ambient conditions:
- Operating temperature 32° – 113° F
- Storage temperature -40° – 158° F
– Luminous color 2700 – 6500 Kelvin
Mounting dimensions, see page 11.
Operation
As with a multiway switch, the mirror cabinet
can be operated with the sensor button Aon
the mirror, or with an external light switch B
(installation type Ior III); refer to figure 3 on
page 12.
Depending on the type of connection, the
sockets are permanently supplied with voltage
(Ior II) or switch controlled (III).
KEUCO recommends connection type Iin
combination with a switch for switching on/off.
Before installation check whether the fastening materials
included are suitable for the anchoring base. The fas-
tening materials are suitable exclusively for stud walls
with timber constructions or for drywall constructions with
timber wood reinforcement.
Installation, see figure 1 onwards on page 12.
• Mark the wall bracket position, see figure 1.
• Mount the wall brackets and safety locking to the
wall, see figure 2.
• Connect the light mirror to the power supply ,
see figure 3.
L
L1
N
PE
= BLACK
= WHITE
= GREEN
= RED
• Mount the light mirror fixation, see figure 4 on
page 13.
• Remove the adhesive cover from the light mirror
fixation , see figure 5.
• Hang the light mirror on the wall from above ,
see figure 6.
• Press the light mirror to the light mirror fixation , see
figure 7.
A
B

4
US Read all instructions before using or installing this product.
Button functions
Button Function
Light on/off
• Pressing the button switches the mirror on
with the selected settings. The white LED
goes off.
• Pressing the button again switches the mirror
off. The white LED lights up.
• The white LED can be deactivated.
– Switch on the mirror.
– Press and hold the button for 15 seconds.
- The lighting gets lighter or darker.
- The lighting switches offbriefly and the
white LED is deactivated.
To switch the white LED back on, repeat the
described procedure.
Dimming the front, wall and washbasin
lighting
• Press the button when the light mirror is
switched on and hold until the desired bright-
ness or the end value has been reached.
The setting is stored and reproduced when
switched on again.
Setting the light colour cooler
• Press and hold daylight white button and the
light colour fades to cool white.
• Release when the desired light colour has
been reached.
The setting is stored and reproduced when
switched on again.
Adjusting light colour - daylight white (cool
white)
• Press button and the colour temperature sets
to 6500 Kelvin.
Setting the light colour warmer
• Press and hold warm white button and the
light colour fades to warm white.
• Release when the desired light colour has
been reached.
The setting is stored and reproduced when
switched on again.
Adjusting light colour - warm white
• Press button and the colour temperature sets
to 2700 Kelvin.
Replacement parts with order numbers, see page 15.
The light sources may only be replaced by the
manufacturer, its customer service or by an
equally qualified person.
For information about warranty and mainte-
nance, see the enclosed Care Instructions
and Warranty Card.
Disposal instructions
This category of device does not belong in
the domestic waste, but must be disposed of
separately in accordance with the relevant
local national regulations.

5
Lea todas las instrucciones antes de usar o instalar este producto. ES
INSTRUCCIONES IMPOR-
TANTES DE SEGURIDAD
PELIGRO - Para reducir el riesgo de
descarga eléctrica:
–Desenchufe siempre este mobiliario de la toma de
corriente antes de la instalación y limpieza.
ADVERTENCIA - Para reducir el
riesgo de quemaduras, incendios, descargas eléctri-
cas o lesiones para las personas:
–Desenchúfelo de la toma de corriente antes de
poner o quitar piezas.
–Es necesaria una supervisión estricta cuando este
mobiliario esté cerca o sea utilizado por niños,
inválidos o personas discapacitadas.
–Use este mobiliario exclusivamente para su uso
previsto tal y como se describe en estas instruc-
ciones. No utilice accesorios no recomendados
por el fabricante.
–Nunca utilice este mobiliario si tiene un cable o
un enchufe dañado, si no funciona correctamente,
si se ha caído o dañado o si se ha caído al agua.
Devuelva el mobiliario al centro de servicio para
su examen y reparación.
–Nunca deje caer ni introduzca ningún objeto en
ninguna abertura.
–No lo utilice en exteriores.
–No lo utilice allí donde se usen productos de aero-
sol (espray) o donde se esté administrando oxígeno.
–Antes de la desconexión, ponga todos los interrupto-
res en la posición de apagado. Desconecte también la
electricidad en el interruptor o en la caja de fusibles.
ADVERTENCIA: Riesgo de descarga
eléctrica: conecte este mobiliario solo a una
toma de corriente con conexión a tierra. Vea las
instrucciones de conexión a tierra.
–Coloque siempre los artículos más pesados en la
parte inferior del armario y no cerca de la parte
superior para evitar la posibilidad de que el mobi-
liario vuelque.
–Cada superficie destinada a soportar una carga
debe tener una declaración correspondiente en
las instrucciones de uso que especifique la car-
ga máxima prevista para esa superficie en libras
(kilogramos).
ADVERTENCIA - California Prop 65
–Este producto puede exponerte a productos quími-
cos como el Di(2-ethylhexyl)phthalate (DEHP), que
es conocidos por el Estado de California causar
cáncer. Para más información ve a www.P65War-
nings.ca.gov .
GUARDE ESTAS INSTRUCCIO-
NES
–Este producto debe ser instalado por un técnico
cualificado, de acuerdo con los códigos y regula-
ciones locales y conforme a las instrucciones de
uso en el manual adjunto.
La instalación correcta reduce el riesgo de incen-
dio, descarga eléctrica, quemaduras y lesiones.
–Consulte a un electricista cualificado para
asegurar la correcta instalación del conduc-
tor de circuito derivado.
– Conecte el circuito del receptáculo a un circuito
derivado protegido con un dispositivo GFCI
Clase A.
– No encienda el aparato si el mismo o si el
cable de la fuente de alimentación estuvieran
dañados. Contacte con el fabricante, el servicio
al técnico o con una persona con cualificación
equivalente y pida una sustitución.
– Se debe asegurar que la pared puede soportar
el peso del armario con espejos.
– Utilice exclusivamente repuestos y accesorios
originales. El uso de otras piezas provocará la
anulación de la garantía.
Aprobación y conformidad
Este armario con espejos cumple con los
requisitos aplicables de la(s) norma(s) a
la(s) que se hace referencia:Mobiliario
doméstico y comercial de seguridad
(UL962, 4ª ed. luminarias portátiles CSA
C22.2 #250.4)
Uso previsto
EXCLUSIVAMENTE PARA USO RESIDENCIAL.
Espejo con luz con iluminación atenuable para
uso en habitaciones húmedas, tales como cuartos
de baño y aseos.
¡El producto solo es adecuado para su montaje
en interiores!
¡Precaución! Instálelo exclusivamente en espa-
cios resguardados de heladas.
PRECAUCIÓN: Riesgo de lesiones personales:
Este producto es muy pesado. Obtenga ayuda
para levantar el armario con espejos.
ADVERTENCIA -
INSTRUCCIONES DE
CONEXIÓN A TIERRA
Este producto debe conectarse a un sistema de
cableado fijo, de metal con conexión a tierra o bien,
un conductor de puesta a tierra del equipo deberá
estar incorporado con los conductores del circuito
y conectado al terminal de conexión a tierra del
equipo o al cable del producto.
