Keurig B3000 User manual

Please read and save these instructions.
Pour des directives en français, veuillez vous reporter à la page 18.
USE & CARE GUIDE
B3000 SINGLE-CUP BREWING SYSTEM
BREWING EXCELLENCE ONE CUP AT A TIME™
a

When using electrical appliances, basic safety
precaution should be followed, including the
following:
1. Read all instructions before using.
2. Do not touch hot surfaces. Use handles and
knobs when available.
3. This appliance must be properly installed
and located in accordance with these
instructions before it is used.
4. The use of an accessory not evaluated for
use with this appliance may cause injuries.
5. Do not place on or near a hot gas or electric
burner, or in a heated oven.
6. Do not use outdoors.
7. To protect against electric shock, do not
immerse cords, plugs, or the appliance in
water or any other liquid.
8. Unplug the coffee brewer before cleaning.
Allow to cool before putting on or taking off
parts and before cleaning the appliance.
9. For best operation, plug the appliance into
its own electrical outlet on a dedicated
circuit to prevent flickering of lights, blowing
of fuses or tripping a circuit breaker.
10. Do not operate any appliance with a dam-
aged cord or plug or after the appliance
malfunctions or is damaged in any manner.
Contact your Keurig Authorized Dealer
(KAD) to arrange for replacement or repair.
11. Do not let the cord hang over the edge of
the table or counter, or touch hot surfaces.
12. To disconnect, press the Power Button on
the right-rear of the Brewer to ‘OFF’ status
and then remove the plug from the wall
outlet.
13. Close supervision is necessary when any
appliance is used by or near children.
14. Do not lift the Handle to open the Lid of
the Brewer while brewing is in progress.
15. This appliance is equipped with a power
cord having a grounding wire with a
grounding plug. The appliance must be
grounded using a 3-hole properly grounded
outlet. In the event of an electrical short
circuit, grounding reduces the risk of
electrical shock.
16. If the outlet is a standard 2-prong wall
outlet, it is your personal responsibility and
obligation to have it replaced with a properly
grounded 3-prong wall outlet.
17. Do not, under any circumstances, cut or
remove the third (ground) prong from the
power cord or use an adapter.
18. Consult a qualified electrician if the
grounding instructions are not completely
understood, or if doubt exists as to whether
the appliance is properly grounded.
19. Do not use the appliance for other than its
intended use.
SAFE OPERATION & USE
IMPORTANT SAFEGUARDS
2
SAVE THESE INSTRUCTIONS
KEURIG®GOURMET SINGLE CUP
COMMERCIAL BREWING SYSTEM
Model B3000 Use & Care Guide

WARNING
WARNING:
TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT REMOVE THE
COVERS. NO USER SERVICEABLE PARTS
ARE INSIDE. REPAIR SHOULD BE DONE BY
AUTHORIZED SERVICE PERSONNEL ONLY.
UNPLUG BEFORE SERVICING.
RISK OF FIRE OR ELECTRIC SHOCK
DO NOT OPEN
3
KEURIG®GOURMET SINGLE CUP
BREWING SYSTEM
Model B3000 Use & Care Guide
TABLE OF CONTENTS
SECTION 1
SET-UP & OPERATION
Unpacking
. . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Plumbing Fitting Connections
. . . . . . . . . . 7
Set-Up & First Brew
. . . . . . . . . . . . . . . . . . 8-9
Helpful Hints
. . . . . . . . . . . . . . . . . . . . . . . . 9
Dispensing H
o
ot Water
. . . . . . . . . . . . . . . . . 10
Using a Travel Mug
. . . . . . . . . . . . . . . . . . . 10
Emptying K-CUP bin
. . . . . . . . . . . . . . . . . . 10
Draining
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Emptying the drip tray
. . . . . . . . . . . . . . . . . 11
SECTION 2
CLEANING & MAINTENANCE
Cleaning
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
De-Scaling
. . . . . . . . . . . . . . . . . . . . . . . . . . 13
SECTION 3
TROUBLESHOOTING
. . . . . . . . . . . . . . . . . 14
Storage
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Menu Mode
. . . . . . . . . . . . . . . . . . . . . . . . . 15
Error codes
. . . . . . . . . . . . . . . . . . . . . . . . . . 16
Warranty
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
CAUTION: There are two sharp needles that
puncture the K-Cup®portion pack, one
above the K-Cup®Holder and the other in
the bottom of the K-Cup®Holder
.
To avoid risk of injury, do not put your
fingers in the K-Cup Chamber.
CAUTION: There is extremely hot water in
the K-Cup®Holder during the brew process.
To avoid risk of injury, do not lift the Handle
or open the K-Cup®chamber during the
brew process.
THIS PRODUCT IS FOR COMMERCIAL USE ONLY
If an extension cord is used, (1) the marked
electrical rating of the cord set or extension
cord should be at least as great as the electrical
rating of the appliance. (2) The cord should be
arranged so that it will not drape over the
countertop or tabletop where it can be pulled
on by children or tripped over unintentionally
and (3) the extension cord must include a
3-prong grounding plug.
WARNING: The product should be connected
to branch circuit protected at maximum 20A.
Record your Brewer Serial Number here.
The Serial Number is located on the UL
label found inside the K-Cup storage bin
area, behind the storage bin
_________________________________
WARNING: This product contains chemicals,
including lead, known to the State of
California to cause c
a
ancer, birth defects or
other reproductive harm.

4
1. Place Brewer box on a large steady surface
(such as a table or countertop) or on the
floor. Open the box.
2. Remove the Quick Start Guide, Use & Care
Guide and other literature.
3. Reach into the box and grasp the polyfoam
that encases the Brewer.
4. Carefully pull the polyfoam toward you and
out of the box. The Brewer will still be
encased in the poly foam.
5. Remove the poly foam packaging material.
6. Place the brewer upright on a flat, steady
surface.
7. Remove the K-Cup storage bin from the
brewer and record on page 3 of this book
the Serial Number located on the UL label
behind it. The Serial Number is also
located on the Brewer box.
8. We recommend you save all packing
materials in case future shipping of the
product is necessary.
SET-UP & OPERATION
Unpacking Instructions
SECTION 1
WARNING:
Keep all plastic bags away
from children.

5
5
Front View
Model B3000 Commercial Brewer
Dimensions: 12”W x 18”D x 17.375”H
Weight: 35 Lbs /16 Kgs. (empty)
Electrical: 110-120 VAC, 1400W 60 H
z
z
Water Supply: 40 psig- 125 psig
Optional Accessories:
• #5025 OmniPure Filter Kit
• #5558 Platform for additional used K-Cup
storage (up to 70)
• #5557 Coin Changer (cabinet) accepts Coin
Acceptors, Inc. Model Quantum USQ-G701
or Model Quantum CAQ-G701 (not supplied)
or Model Guardian 6000
LCD Display, 5
lines Indicates
brewer status and
action needed
Control Panel
User Interface
Buttons (4) Use to
select brew size,
hot water or lan-
guage (English,
French or Spanish)
Brew head
top cover
Cup sensors
Upper Drip
Tray Plate
Door Handle,
pull to empty
K-Cup bin
Pull here to
remove drip tray Lower Drip Tray Plate
for travel mugs
Brew/Puncture
Handle, Lift to
open and
insert K-Cup
or Model Quantum CAQ-G701
or Model Guardian 6000 (not supplied)

6
Back View
Shown with optional filter kit
#5025 in place and connected
Filter Kit
#5025
includes the
mounting
head and
filter body
Omnipure
KQ8 filter
Water Inlet
valve 3/4”
Garden Hose
type,
Connector
not included
RJ11 Jack for
connecting
optional Coin
Changer #5557
Power
Cord
Power
Switch
Hot water
drain tube
Cold water
drain tube
Shown with optional filter kit
#5025 in place and connected
Back View
Drain Plugs

Plumbing Fitting Connections
CAUTION:
This brewer is designed to handle
local water pressures from 40 psig up to 125
psig. Consult a licensed plumber for water
pressures in your area. Use plumbing fittings
and tubing specified to withstand 125 psig.
WARNING:
Keurig requires the use of an
external water filter such as the Omnipure
KQ8A, available from Keurig Incorporated.
PN 5025. Failure to use a filter invalidates the
brewer warranty.
1. An external filter (KQ8A) can be mounted
on the rear surface of the brewer using the
mounting screws provided. See page 6.
2. Loosen the two mounting screws located
on the upper-rear of the brewer and hang
the KQ8A filter kit assembly.
3. Tighten the two mounting screws (be
careful not to over tighten).
NOTE:
The KQ8A Filter assembly comes
with 1/4FPT ports for both inlet and outlet
and the plumbed water inlet to the brewer
is 3/4Male Garden Hose Thread (Invensys
solenoid valve). 1/4OD LLDPE (Linear Low
Density Polyethylene) tubing is recom-
mended (NSF compliant) between the filter
assembly and the brewer. NSF compliant
fittings are recommended such as High
Density Polypropylene Type.
4. Connect the ‘INLET’ port of the filter
assembly to the local water supply.
5. Connect a long length of tubing to the
‘EXIT port of the filter assembly. DO NOT
CONNECT TO THE BREWER YET.
6. The filter needs an initial flush to clear any
carbon deposits. Bring the long length
tubing to a container or sink.
7. Turn on water supply and allow at least 4
gallons of water to flush through the filter.
8. Turn off water supply.
9. Cut the tubing to proper length and con-
nect to inlet plumbing port on the brewer.
10. Turn on water supply.
7

8
B3000 Set-Up & First Brew
IMPORTANT:
You cannot use your Keurig
brewer until it has been primed for its first use
as set forth below.
Priming your Brewer
1. Unwrap cord and plug the brewer into a
grounded outlet.
2. Place a cup or mug (10 oz Min) on the Drip
Tray Plate (if not done the brewer will
prompt for the cup or mug later in the
priming sequence).
3. Press power switch (see Page 6) to ON
position.
4. At power up and the brewer is new the
following is displayed:
(At this stage you can go into MENU MODE
to set the default language or input the
service phone number. To enter the MENU
MODE proceed to page 15. You can also do
this anytime the brewer is in IDLE MODE.
5. The Display will automatically change to:
6. If water is connected then press “CONT”
button which will be flashing.
7. The display will read:
8. Then automatically change to:
At this stage you may want to go into MENU MODE
to set the default language or input the service
pho
n
ne number. To enter MENU MODE proceed to
page 15.
BREWING THE FIRST CUP
1. Place a cup or mug on the Drip Tray Plate.
2. Brewer is now ready for normal operation.
And the display will show:
3. At this stage you do any of the following:
a. Change the language for the next brew
from the default to either of the other two
languages displayed, just press the button
below the language of your choice.
b. Dispense hot water, just press and hold the
button below HOT WATER.
c. Choose a K-Cup, lift handle and insert it in
the K-Cup holder.
4. Place a K-Cup®portion pack in the K-Cup®
Holder.
CAUTION: There are two sharp needles
that puncture the K-Cup®portion pack,
one above the K-Cup®Holder and the
other in the bottom of the K-Cup®
Holder.
To avoid risk of injury, do not put
your fingers in the K-Cup®Chamber.
KEURIG B3000
BREWING SYSTEM
CONNECT WATER AND THEN
PRESS FLASHING BUTTON
PRIMING
HEATING - PLEASE WAIT
INSERT NEW K-CUP
LOWER HANDLE
READY – CHOOSE K-CUP
LIFT HANDLE
Español Français HOT
WATER
READY – CHOOSE K-CUP
LIFT HANDLE
Español Français HOT
WATER

9
If no K-Cup is detected the display will show:
Either insert a K-Cup or press YES to continue.
Choosing option “c” the display will read:
If no mug is present or not detected on the
drip tray it will display:
Take the appropriate action.
Four brew size options are available, they are
from left to right 4 oz, 6 oz, 8 oz and 10 oz and
are indicated in the cup and mug icons. 8 oz is
the standard brew size, 4 oz and 6 oz are more
robust and 10 oz gives a milder brew.
5. Press your brew size selection.
The brewer display will indicate:
6. There may be a short pause before the
brewing process begins. The entire brew
process lasts for approximately 40 to 52
seconds (depending upon brew size select-
ed) and ends with a burst of air to remove
all liquid coffee or tea from the KCup®.
The button below your selected brew size
will remain lit until the brew is completed
and the following is displayed:
7. Enjoy your first cup of Keurig Brewed®
gourmet coffee or tea!
8. The Brewer will be ready again for use in
approximately 20 seconds.
The brewer will then revert to its idle state
and indicate:
Helpful Hints
1. Keep your Brewer turned ‘ON’ at all
times.
To brew a fresh cup of coffee or tea
anytime you want, we suggest you keep
your Brewer turned ‘ON’ all the time.
2. Keurig requires the use of filtered water
on thi
s
sbrewer.
We recommend the
OmniPure Filter Kit, Keurig PN 5025.
3. Plug Brewer into its own grounded outlet.
If the electric circuit is overloaded with
other appliances, your Brewer may not
function properly. If possible, The Brewer
should be operated on its own circuit,
separate from other appliances. A separate
circuit with a GFCI is recommended.
4. Brewing into a travel mug.
To brew into a
travel mug, simply lift and rotate back the
drip plate housing till it rests against the
drip plate back wall then place travel mug
on lower drip plate and commence brew.
CAUTION: There is extremely hot water in
the K-Cup Holder during the brew process.
To avoid risk of injury, do not lift the
Handle or open the K-Cup®Chamber
during the brew process.
PLACE YOUR CUP
OR SELECT CONT.
KEURIG BREWED
ENJOY!
Insert K-Cup
NOTE:
Do not remove the foil lid or
puncture the K-Cup®portion pack.
NO K-CUP DETECTED
CONTINUE ANYWAY?
READY
SELECT BREW SIZE
BREWING
NOTE:
Following the brew, your Brewer will fill
in preparation for the next brew. The pump will
make a vibrating sound. This is normal.
NO YES
READY – CHOOSE K-CUP
LIFT HANDLE
Español Français HOT
WATER

10
Stopping the Brew Process
If you need to stop the brewing after the process
has started, press the Power Button to turn the
Brewer ‘OFF’. The flow of coffee or tea will stop,
the heating element will shut off and the LCD
screen and brew buttons will extinguish.
NOTE:
You may get less coffee or tea in your
cup during your next brew. We recommend that
you perform a cleansing brew without a K-Cup®
after a terminated brew. Then your NEXT brew
will be the proper selected volume.
Dispensing Hot Water
The B3000 brewer is able to dispense hot
water for making hot chocolate, instant soups,
etc. The path of the water delivery is separate
from the coffee delivery path. When ready the
brewer will display:
The right hand button option is ‘Hot Water’.
Hot water will be dispensed as long as the
button is pressed up to 8 oz.
Using a travel mug.
Emptying the K-Cup Bin
The used K-Cup is automatically ejected into
the internal K-Cup bin. When the K-Cup bin
requires emptying the brewer will
display:
To empty the K-Cup bin open the brewer door
by grasping the door handle and swinging door
fully open to remove bin from brewer. Dispose
used K-Cups and replace bin.
Lift up the upper
drip tray Place travel mug on
lower drip plate
Open Door
Remove
K-Cup Bin
EMPTY K-CUP BIN
READY – CHOOSE K-CUP
LIFT HANDLE
Español Français HOT
WATER
