Key Digital KD-HD16x16ProK User manual

16 Inputs to 16 Outputs HDBaseT/HDMI via Single
CAT5e/6 Matrix Switcher, supports Ultra HD/4K,
includes 16 HDBaseT/HDMI Receiver Extenders
KD-HD16x16ProK
Operating Instructions
Key Digital®Systems :: 521 East 3rd Street :: Mount Vernon, NY 10553
Phone : [phone] Fax : [phone] Web : www.keydigital.com
The Experts in Digital Video Technology and Solutions™
Key Digital®, led by digital video pioneer Mike Tsinberg,
develops and manufactures high quality, cutting-edge
technology solutions for virtually all applications where
high quality video imaging is important. Key Digital®
is at the forefront of the video industry for Home Theater
Retailers, Custom Installers, System Integrators,
Broadcasters, Manufacturers, and Consumers.
Rev 0 – June 2014

4 1
Introduction
Key Digital®Champion Series™KD-HD16x16ProK Matrix Switcher is a 16 Inputs to 16
Outputs HDBaseT/HDMI via CAT5e/6 Matrix Switcher, supports Ultra HD/4K, and includes
16 Receiver (RX) Extenders KD-X16x16RX.
Key Features
›Digital Switching: 16 HDMI Inputs to 16 HDBaseT HDMI Outputs via RJ45
›HDBaseT HDMI Outputs: 16 HDBaseT (CAT5e/6 RJ45) outputs with fully-automatic CAT5e/6
cable equalization
›Control Signal Extension: Each output has individual RS-232, IR input and IR output ports,
enabling bi-directional control signal extension
›HDBaseT: Utilized on CAT5e/6 RJ45 outputs
›Extenders: Kit includes 16 KD-X16x16RX HDBaseT HDMI Extenders, with IR/RS-232
Control Signal Extension via Single CAT5e/6 Cabling
›Signal Extension:
» Regular Mode: Up to 400 ft. @ 4K/60/30/24, 1080p/60/24, 1080i, 720p using Key Digital
®
KD-CAT6STP1X CAT6/STP Cabling
»Up to 300 ft. @ 4K/60/30/24, 1080p/60/24, 1080i, 720p using third-party cabling
»Long Range Mode (1080p and lesser only): Up to 600 ft. @ 1080p/60, 1080p/24,
1080i, 720p using Key Digital KD-CAT6STP1X CAT6/STP Cabling
»Up to 500 feet @ 1080p/60/24, 1080i, 720p using third-party cabling
›3D Ready: Capability to pass 3D stereoscopic signal formats
›Ultra HD/4K: Ability to pass UHD/4K signal (4096x2160/30/25/24 or 3840x2160/30/25/24 at
4:4:4 color spacing and 4096x2160/60 or 3840x2160/60 at 4:2:0 color spacing)
›EDID: Internal library with 15 default EDID configurations for each input,
in addition to native EDID data for any Output/Display
›Full Buffer™Technology : Full buffering of HDCP and EDID, for best possible switching and
viewing of any source/input to any display/output, regardless of multiple output viewing relation
›TMDS re-clocking : Support for long HDBaseT/CAT5e/6 or HDMI connections
›IR Sensor Powering: +5V power on 3.5mm stereo IR ports power IR sensors
to collect line-of-sight IR from remote(s)
›Deep Color Support: Up to 12 bits/color (8bits/color @ 4K/60)
›Lossless Compressed Digital Audio: Dolby
®
TrueHD, Dolby
®
Digital Plus
and DTS-HD Master Audio
™
›Licensing: Fully licensed and compatible with all HDMI and HDCP technologies
›Memory Presets: 8 Memory presets for output to input selections
›Control: Front panel push buttons and LEDs, Optical IR, Serial IR, RS-232, and TCP/IP
with full bi-directional operation
›Major Control System Support: Compass Control
®
, AMX
®
, Control4
®
, Crestron
®
,
KNX
®
, RTI
®
, Savant, URC
®
, Honeywell
®
, HAI
®
, Leviton
®
, etc.
Always follow the instructions provided in this Operating Manual.
© 2014 Key Digital, Inc. All rights reserved.
Table of Contents
Introduction ................................................................ 1
Quick Setup Guide .......................................................... 2
Application Example ......................................................... 3
Connections, Buttons and LEDs ................................................ 4
Front Panel Operation ........................................................ 5
KD-X16x16Rx HDBaseT Extender............................................... 8
Extending Control Signals ..................................................... 9
RS-232 and TCP/IP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Firmware Update........................................................... 12
Specifications ............................................................. 14
Important Product Warnings & Safety Instructions .................................. 15
How to Contact Key Digital
®
.................................................. 16
Warranty Information ........................................................ 16
Accessories
›16 KD-X16x16Rx Receiver Extenders
›16 HDMI Cable Clips
›Remote Control, Serial IR Cable
›Rack Ears
›Manual
›Power cord

2 3
Quick Setup Guide
1. Begin with the KD-HD16x16ProK and all input/output devices turned off with power
cables removed.
2. Connect HDMI sources to the appropriate input ports on the KD-HD16x16ProK
3. Connect display devices via the RJ45 outputs and included KD-X16x16RX extenders.
4. Connect power to the KD-HD16x16ProK as well as to all other input and output devices
and turn them on.
5. Operate the KD-HD16X16ProK switcher via front panel buttons, IR Remote, Serial IR,
RS-232 or TCP/IP control.
Application Example
Operation:
After performing the setup above, the unit is ready for operation. There are several options for
controlling the unit. Commands can be issued via IR remote control, RS-232, TCP/IP or by using
the front panel buttons.
Note: Advanced commands are available only via the RS-232 and TCP/IP protocols.
Mounting:
Rack mount: Secure the rack ears to each side of the KD-HD16x16ProK with the supplied
hardware then fasten the unit to the rack rails with the included machine screws.
PCs (x4)
Satellite (x7)
Cable (x4)
RF Repeater
(Light/Shade Control)
RF
Ultra HD/4K
Digital Signage
Bar Area - Displays 1-4
Shades
Dining Area - Displays 5-8
Outdoor Area - Displays 9-12 Second Floor - Displays 13-16
Lights
Displays
Displays
Displays
Displays
Shades
Lights
CAT5e/6
Ethernet
KD-MC1000
KD-HD16x16ProK
HDMI
IR/RS232
CAT5e/6
KD-X16x16Rx x4
WiFi Router
Master Controllers
RJ45
RJ45
RJ45
RJ45
x3
x16
x16
x16
x4
x4
x7
HDMI
HDMI
HDMI
RJ45
HDMI
IR
RS-232
HDMI
IR/RS232
RJ45
iPad
WiFi
KD-CSLX1
KD-CSLX1
HDMI
IR/RS232
CAT5e/6
KD-X16x16Rx x4
KD-CSLX1
HDMI
IR/RS232
CAT5e/6
KD-X16x16Rx x4
KD-CSLX1
HDMI
IR/RS232
CAT5e/6
KD-X16x16Rx x4
KD-CSLX1

4 5
Connections, Buttons and LEDs
Rear Panel Connections:
All connections to the KD-HD16x16ProK are found on the rear panel of the unit. Refer to the
illustrations below for port assignments while making connections:
HDBaseT Outputs HDMI InputsIR/RS-232 Ports Mode Switches
Each Input/Output has following connections:
›HDMI Inputs: Via standard 19-pin HDMI connectors (x16)
›HDBaseT Outputs: Via shielded CAT5e/6 RJ45 ports (x16)
›IR In/Out via 3.5mm connection
›RS-232 bi-directional via 3.5mm connection
Main Ports
›RS-232, RS-485, Serial IR, TCP/IP and power ports
are located on the far right of the back panel. The
RS-232 port utilizes a straight-through connection
(see the RS-232 section of the manual for connection
protocol and commands).
Power
Serial IR
RS-232
RS-485
TCP/IP
Controls
Front Panel Connections:
OutputsLCD Screen
InputsOptical IRControl Buttons
›16 output buttons on the top-right of the front panel
›16 input buttons on the bottom-right of the front panel
›8 control buttons located to the left of the output/input buttons
›LCD indicator screen on the far left of the front panel
›Optical IR sensor located to the left of the output 1 & 9 buttons
Front Panel Operation
Switching
›To switch inputs: press the output button of the output you wish to switch ➔ press the desired
input button
›You can switch all outputs to a desired input by pressing “All Out” ➔ then pressing the desired
input button
Memory and Recall Functions
The KD-HD16x16ProK allows you to store up to 8 input/output configuration presets.
›Save:
»When you have your desired output-to-input relationships made, press “ Memory Store ” ➔
then press an input select number (1-8) to save this configuration.
›Recall:
»To recall a configuration, press “ Memory Recall ” ➔ then press the desired preset number
you wish to recall

6 7
EDID Control
The KD-HD16x16ProK has a built-in library of 15 EDID settings and the ability to copy EDID data
from the display connected to output 1.
›To copy EDID from output 1, press “ EDID ” ➔ Output 1 button
›To select a default EDID, press “ EDID ” ➔ input button (1-15) that corresponds to the default
EDID you want to set. See the chart below for a list of EDID library settings.
›Note: The default EDID is No. 4: 1080p, 2ch. Audio
11080i, 2CH AUDIO 10 4Kx2K, 2CH AUDIO
21080i, DOLBY/DTS 5.1 11 4Kx2K, DOLBY/DTS 5.1
31080i, HD AUDIO 12 4Kx2K, HD AUDIO
4
1080p, 2CH AUDIO (DEFAULT) 13 1280x1024 DVI
51080p, DOLBY/DTS 5.1 14 1920x1080 DVI
61080p, HD AUDIO 15 1920x1200 DVI
73D, 2CH AUDIO
*EDID (Extended display identification data) is a data
structure provided by a display to describe its capabilities
to a source device
83D, DOLBY/DTS 5.1
93D, HD AUDIO
Output Disable/Enable
The “ Output Disable ” button serves two purposes: disabling unused output(s) and shutting the
LCD screen.
›To toggle the LCD on/off, press the “Output Disable” button
›To disable an output, press the desired output button ➔ press “Output Disable”
»A disabled output is indicated by “00” on the LCD screen
›To disable all outputs, press “All Out” ➔ ”Output Disable”
›To enable an output, simply send it a switching command
IR Remote Operation
The IR remote control mimics the functions of the front panel buttons.
To use the IR remote control, follow the chart below for button
functions and execute functions the same way you would via
the front panel buttons.
Front Panel Function Remote Button
Exit POWER
Output Disable OFF
All Out ALL
Unit Info ID
Memory Store STO
Memory Recall RCL
»OSD, SCAN, UP Arrow, DOWN Arrow, AUDIO, VIDEO, and “+10” have no function
Example: To set output 16 to input 05, press OUT 1, OUT 6, IN 0, IN 5 or OUT 1, OUT 6, IN 5
(note: “OUT 0” and “IN 0” button presses may be omitted)
Serial IR Operation
The unit may also be controlled via the Serial IR
interface. You must use the supplied Serial IR
cable (pictured to the right). This cable connects
to the “Serial IR” input port on the back of the unit.
The other end of the cable contains an IR receiver,
to which you can send IR control signals.
8 Pin Dip Switch
There is an 8 pin dipswitch on the back right of the unit.
Flipping a pin down is “ON” and up is “OFF”.
›Pins 1-5: Configure the Device ID
»Single Unit: 00000 ( = Default ) (ON=0, Off=1)
»All other configurations are used for multi-unit control/configuration
›Pin 6: RS-485 Master/Slave Configuration
»Off: RS-485 master; RS-232 and TCP/IP disabled
»On: RS-485 slave; RS-232 and TCP/IP enabled ( =Default)
›Pin 7: RS-232 or TCP/IP port control selection
»Off: TCP/IP enabled; RS-232 disabled
»On: RS-232 enabled; TCP/IP disabled ( =Default)
›Pin 8: TCP/IP Reset
»Off: TCP/IP normal ( =Default)
»On: TCP/IP reset

8 9
KD-X16x16Rx HDBaseT HDMI Extender
Connections
Please follow the instructions below for the KD-X16x16RX extenders:
›One CAT5e/6 UTP or STP cable needs to be used.
›Use the shortest possible HDMI cable when connecting the Extender to the Display. Key Digital
recommends cables 6 ft. or shorter for optimum performance.
›Ensure the CAT5e/6 cable is run directly from the switcher to the Extender.
›Do not use patch panels, punch downs, keystones, couplers, wall plates, etc..
»Key Digital recommends the use of CAT5e/6 STP cable with shielded RJ45 connectors for
optimum performance and distances from your Extender.
›Provided 12V/1.25A power supply is required for each extender.
Control
›To extend control signals, follow the instructions in the Extending Control Signals section below
›Each extender has an IR sensor to send IR control signals back to the KD-HD16x16ProK
3 Pin Dip Switch
There is a 3 pin dipswitch on the back right of the unit.
Flipping a pin down is “ON” and up is “OFF”.
›Pins 1 and 2 are used when upgrading firmware
» Off/Off: Normal use mode (Default)
» On/Off: Firmware upgrade via external RS-232 connection
» Off/On: Firmware upgrade remotely from the RS-232 port
of the KD-HD16x16ProK
»Note: If switches are left in firmware settings, RS-232 ports are disabled
›Pin 3: Long Range Mode
» Off: Normal mode (Default)
» On: Long Range Mode ON (Note: you must also enable the Long Range Mode switch on
the corresponding output on the back of the KD-HD16x16ProK
Extending Control Signals
›The KD-HD16x16ProK allows you to bi-directionally (from switch-to-zone and/or zone-to-switch)
extend IR and RS-232 control signals.
›The KD-HD16x16ProK can extend incoming IR/RS-232 signals to control any display/output
device or any source/input device via the single CAT5/6 cabling
›Signals extend from point-to-point (Output 1 ➔ Output 1, Output 2 ➔ Output 2…
Output 16 ➔ Output16)
›When connecting an IR Emitter to a device, make sure to find the IR receiver area on the device
Control Extension from External I/O Ports:
›There are 48 total control extension 3.5mm I/O ports (32 IR and 16 RS-232)
»These ports are labeled “IR 1,” “IR 2,”…“IR 16” and “RS-232 1,” RS-232 2,”…“RS-232 16”
›The “IR In” port on the back of the matrix extends signals to the “IR Out” port on the
corresponding extender.
»Example: The “IR In 3” port on the matrix sends control signals to the “IR Out” port on the
extender connected to output 3.
›The “RS-232” port extends signals to the DB9 connector on the corresponding extender
»Example: The “RS-232 4” port sends control signals to the DB9 connector on the extender
connected to output 4.
Extending IR
›Connect the 3.5mm cable from your powered IR connecting block or master controller,
to the “IR In” port.
›Connect your IR emitter to the “IR Out” port of respective Rx extender
Extending RS-232
›Use the appropriate cable to connect the RS-232 output of your master controller to the desired
3.5mm RS-232 input port on the back of the matrix
›Connect a DB9 cable from the receiver extender to the DB9 port of the device you wish to control
Matrix Ports
Tip Ring Sleeve
IR In +5V IR Signal Ground
IR Out Ground IR Signal N/C
RS-232 Tx Rx Ground
Rx Extender Ports
Tip Ring Sleeve
IR In +5V IR Signal Ground
IR Out Ground IR Signal N/C
RS-232
Pin 2 Pin 3 Pin 5
Tx Rx Ground

10 11
RS-232 and TCP/IP Commands
The KD-HD16x16ProK provides access to all functions when used with an RS-232 control system.
Connection protocol is as follows:
›Baud Rate = 57600 bits per second
›Data Bits = 8
›Stop Bits = 1
›Parity = None
›Flow Control = None
›Carriage Return: Required
›Line Feed: Required
All RS-232 commands commands are case-sensitive. Spaces must be included
where shown. Do not send the (‘) and (‘) characters; they are shown only for clarity.
A carriage return is required at the end of each string.
RS-232 Command Description
Switching Commands
SPO xx yy
Set Output xx t Input yy (xx = 01-16, yy = 01-16)
Example: SPO 01 02
SPOA yy
Set All Output to Video Input yy (yy = 01-16)
Example: SPOA 16
SPO xx ON
Set Output xx ON (xx = 01-16)
Example: SPO 01 ON
SPO xx OFF
Set Output xx OFF (xx = 01-16)
Example: SPO 01 OFF
SPOA ON
Set All Outputs ON
Example: SPOA ON
SPOA OFF
Set All Outputs OFF
Example: SPOA OFF
EDID Setup
SPCDF Reset to Factory Default with EDID change
(Default EDID 04)
SPCEDIDA 00 Copy EDID from Output 01 to All Inputs
Example: SPCEDIDA 00
SPCEDIDA zz Copy Default EDID zz to All Inputs, zz = 01-15
Example: SPCEDIDA 04
Pin 5 – Ground
Pin 3 – Receive
Pin 2 – Transmit
RS-232 cable pin out
Network Setup (TCP/IP Port)
SPCETIPA xxx.xxx.xxx.xxx Set IP Address xxx.xxx.xxx.xxx; xxx = 000 ~ 255
Example: SPCETIPA 192.168.000.239
SPCETIPM.xxx.xxx.xxx.xxx Set Net Mask xxx.xxx.xxx.xxx; xxx = 000 ~ 255
Example: SPCETIPM 255.255.255.000
SPCETIPR xxx.xxx.xxx.xxx Set Router IP Address xxx.xxx.xxx.xxx; xxx = 000 ~ 255
Example: SPCETIPR 192.168.000.001
Status/System Commands
STA Show Global System Status
H
Help
SPC FHPD ON/OFF Set Forced HPD ON/OFF
SPC DF Reset to Factory Defaults
Video Switch
‘SPO xx yy’ : To switch the desired video output (xx) to the desired input (yy)
»xx= the output number (00-16)
»yy= the input number (00-16)
»Example: To switch output 3 to input 1, issue the command: ‘SPO 03 01’
‘SPOA yy’ : To switch all outputs to a desired input
»Example: To switch all outputs to input 3, issue the command: ‘SPOA 03’
EDID Commands
‘SPCEDIDA 00’ : Will copy EDID from output 1 to all inputs
‘SPCEDIDA zz ’: Will copy the EDID setting zz (01-15) from the default library to all inputs (see
EDID chart below)
›Note: The default EDID is No. 4: 1080p, 2ch. Audio
11080i, 2CH AUDIO 10 4Kx2K, 2CH AUDIO
21080i, DOLBY/DTS 5.1 11 4Kx2K, DOLBY/DTS 5.1
31080i, HD AUDIO 12 4Kx2K, HD AUDIO
4
1080p, 2CH AUDIO (DEFAULT) 13 1280x1024 DVI
51080p, DOLBY/DTS 5.1 14 1920x1080 DVI
61080p, HD AUDIO 15 1920x1200 DVI
73D, 2CH AUDIO
83D, DOLBY/DTS 5.1
93D, HD AUDIO

12 13
Help
‘H’: Returns a list of every available RS-232 command.
Status
‘STA’: Get global system status.
Factory Reset
‘SPCDF’: Reset the unit to factory default settings.
TCP/IP Settings
The KD-HD16x16ProK does not support DHCP. TCP/IP settings can only be changed via IP.
Follow the Network Setup commands above to configure your unit’s network settings.
Default TCP/IP Settings:
»IP Address: 192.168.0.239
»Network Mask: 255.255.255.0
»Router Address: 192.168.0.1
»TCP Port: 23
Firmware Update
Your KD-HD16x16ProK firmware is updated through a Web portal. You may also adjust your
device’s IP settings in this portal.
›Open your web browser and type your unit’s IP (default IP: 192.168.0.239)
The Main page gives you basic device information:
The “F/W Upgrade” tab is used to update your device’s firmware:
The “Network” tab allows you to adjust the device’s IP settings:
The “IPM Upgrade” tab is used to upgrade the device’s IP module. The IP Module is used
for TCP/IP communication with the KD-HD16x16ProK.

14 15
Specifications
Technical:
»Inputs: 16 HDMI Connectors, Type A, 19 Pin Female
»Outputs: 16 Shielded HDBaseT RJ45
»Bandwidth: TMDS bandwidth 10.2 Gb/s
»Control: Pushbutton/LCD front, Optical IR, Serial IR, RS-232, TCP/IP
»Wired IR: Modulated IR signal input, 0-5V TTL or -10to +10V
»Control Extension: Bi-directional IR & RS-232
»Deep Color Support: Up to 12 bits/color
»HDMI Video/Audio Signal: Input Video Signal - 1.2 Volts p-p
»DDC Signal (Data): Input DDC Signal - 5 Volts p-p (TTL)
»DDC Communication: EDID and HDCP Bi-directional Transparency from Display to Source
»Power: AC Power Supply (100V ~ 240V)
General:
»Regulation: CE, RoHS, WEEE
»Rack Mount: 3U, Full Rack Width (rack ears included)
»Enclosure: Black Metal
»KD-HD16x16ProK Dimensions: 17” x 13.3” x 5.1”, Weight: 16.5 lbs
»KD-HD16x16ProK Shipping Dimensions: 22.8” x 19.4” x 9.2”, Weight: 25 lbs
»KD-X16x16Rx Dimensions: 5.9” x 3.1” x 0.9”, Weight: 0.6 lbs
»KD-X16x16Rx Shipping Dimensions (16 Units): 20” x 16.2” x 12”, Weight: 30 lbs
Important Product Warnings:
1. Connect all cables before providing power to the unit.
2. Test for proper operation before securing unit behind walls or in hard to access spaces.
3. If installing the unit into wall or mounting bracket into sheet-rock, provide proper screw support
with bolts or sheet-rock anchors.
Safety Instructions:
Please be sure to follow these instructions for safe operation of your unit.
1. Read and follow all instructions.
2. Heed all warnings.
3. Do not use this device near water.
4. Clean only with dry cloth.
5. Install in accordance with the manufacturer’s instructions.
6. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
7. Only use attachments/accessories specified by the manufacturer.
8. Refer all servicing to qualified service personnel. Servicing is required when the device has
been damaged in any way including:
»Damage to the power supply or power plug
»Exposure to rain or moisture
Power Supply Use:
You MUST use the Power Supply provided with your unit or you VOID the
Key Digital®Warranty and risk damage to your unit and associated equipment.

16 17
How to Contact Key Digital
®
Technical Support
For technical questions about using Key Digital
®
products, please contact us at:
›Phone: [phone]
›E-mail: [email protected]
Repairs and Warranty Service
Should your product require warranty service or repair, please obtain a Key Digital
®
Return Material
Authorization (RMA) number by contacting us at:
›Phone: [phone]
›E-mail: [email protected]
Feedback
Please email any comments/questions about the manual to:
›E-mail: [email protected]
Warranty Information
All Key Digital
®
products are built to high manufacturing standards and should
provide years of trouble-free operation. They are backed by a Key Digital
Limited Lifetime Product Warranty Policy.
»http://www.keydigital.com/warranty.htm
