Keysight 1000A Series User manual

Keysight 1000A Series
Oscilloscopes
Service
Guide

2 Keysight 1000A Series Oscilloscopes Service Guide
Notices
© Keysight Technologies, Inc. 2009, 2013
No part of this manual may be reproduced in
any form or by any means (including elec-
tronic storage and retrieval or translation into
a foreign language) without prior agreement
and written consent from Keysight Technolo-
gies, Inc. as governed by United States and
international copyright laws.
Manual Part Number
54130-97015
Edition
Third Edition, April 2013
Printed in Available in electronic format only
Keysight Technologies, Inc.
1900 Garden of the Gods Road
Colorado Springs, CO 80907 USA
Warranty
The material contained in this document is
provided “as is,” and is subject to being
changed, without notice, in future editions.
Further, to the maximum extent permitted by
applicable law, Keysight disclaims all war-
ranties, either express or implied, with regard
to this manual and any information contained
herein, including but not limited to the
implied warranties of merchantability and fit-
ness for a particular purpose. Keysight shall
not be liable for errors or for incidental or
consequential damages in connection with
the furnishing, use, or performance of this
document or of any information contained
herein. Should Keysight and the user have a
separate written agreement with warranty
terms covering the material in this document
that conflict with these terms, the warranty
terms in the separate agreement shall con-
trol.
Technology Licenses
The hardware and/or software described in
this document are furnished under a license
and may be used or copied only in accor-
dance with the terms of such license.
Restricted Rights Legend
If software is for use in the performance of a
U.S. Government prime contract or subcon-
tract, Software is delivered and licensed as
“Commercial computer software” as defined
in DFAR 252.227-7014 (June 1995), or as a
“commercial item” as defined in FAR 2.101(a)
or as “Restricted computer software” as
defined in FAR 52.227-19 (June 1987) or any
equivalent agency regulation or contract
clause. Use, duplication or disclosure of
Software is subject to Keysight Technologies’
standard commercial license terms, and
non-DOD Departments and Agencies of the
U.S. Government will receive no greater than
Restricted Rights as defined in FAR
52.227-19(c)(1-2) (June 1987). U.S. Govern-
ment users will receive no greater than Lim-
ited Rights as defined in FAR 52.227-14
(June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any tech-
nical data.
Safety Notices
CAUTION
A CAUTION notice denotes a hazard.
It calls attention to an operating
procedure, practice, or the like that,
if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a haz-
ard. It calls attention to an operat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in personal
injury or death. Do not proceed
beyond a WARNING notice until the
indicated conditions are fully
understood and met.
See also Appendix A, “Safety Notices,”
starting on page 41.

Keysight 1000A Series Oscilloscopes Service Guide 3
Keysight 1000A Series Oscilloscopes—At a Glance
The Keysight 1000A Series oscilloscopes are low-cost portable digital storage
oscilloscopes (DSOs) that deliver these powerful features:
• Two and four-channel, 60 MHz, 100 MHz, and 200 MHz bandwidth models.
• Bright 5.7 inch QVGA (320 x 240) TFT color LCD display and small footprint (to
save bench space).
•Upto2GSa/ssamplerate.
• Up to 20 kpts memory.
• Up to 400 wfms/s refresh rate.
• Automatic voltage and time measurements (22) and cursor measurements.
• Powerful triggering (edge, pulse width, video, pattern, and alternate modes)
with adjustable sensitivity (to filter noise and avoid false triggers).
• Math function waveforms: add, subtract, multiply, FFT.
• USB ports (2 host, 1 device) for easy printing, saving, and sharing of
waveforms, setups, screen BMP files, and CSV data files.
• Internal storage for 10 waveforms and 10 setups.
• Special digital filter and waveform recorder.
• Built-in 6-digit hardware frequency counter.
• Multi-language (11) user interface menus and built-in help.
Table 1 Keysight 1000A Series Oscilloscope Models
Channels
Input Bandwidth (Maximum Sample Rate, Memory)
200 MHz
(1-2 GSa/s,
10-20 kpts)
100 MHz
(1-2 GSa/s,
10-20 kpts)
60 MHz
(1-2 GSa/s,
10-20 kpts)
4 channel DSO1024A DSO1014A DSO1004A
2 channel DSO1022A DSO1012A DSO1002A

4 Keysight 1000A Series Oscilloscopes Service Guide
In This Book
This guide contains service information for the Keysight 1000A Series
oscilloscopes.
1Service
Describes oscilloscope maintanance, performance testing, and what to do if your
oscilloscope requires service.

Keysight 1000A Series Oscilloscopes Service Guide 5
Contents
Keysight 1000A Series Oscilloscopes—At a Glance 3
In This Book 4
Figures 7
Tables 9
1Service11
Cleaning the Oscilloscope 12
Testing Performance 13
Before Testing Performance 14
To test DC gain accuracy 16
To test analog bandwidth, maximum frequency 21
To test time scale accuracy 29
To test trigger sensitivity 32
Performance Test Record 35
Returning the Oscilloscope to Keysight for Service 39
Contacting Keysight 40
ASafetyNotices41
Warnings 41
Safety Symbols 42
Index 43

6 Keysight 1000A Series Oscilloscopes Service Guide
Contents

Keysight 1000A Series Oscilloscopes Service Guide 7
Figures
Figure 1. Averages Menu Item 17
Figure 2. Connecting Equipment for DC Gain Accuracy Test 18
Figure 3. Vavg Menu Item 19
Figure 4. Connecting Equipment for Maximum Frequency Check Test 23
Figure 5. Channel 1 Vertical Scale Setting 24
Figure 6. Channel 1 Horizontal Scale Setting 24
Figure 7. Averages Menu Item 25
Figure 8. Signal Generator Waveform 26
Figure 9. Connecting Equipment for Time Scale Accuracy Test 30
Figure 10. Connecting Equipment for Trigger Sensitivity Test 33

8 Keysight 1000A Series Oscilloscopes Service Guide
Figures

Keysight 1000A Series Oscilloscopes Service Guide 9
Tables
Table 1. Keysight 1000A Series Oscilloscope Models 3
Table 2. Equipment Required to Perform All Tests 14
Table 3. DC Gain Accuracy Specification 16
Table 4. Equipment Required for DC Gain Accuracy Test 16
Table 5. Analog Bandwidth Specification 21
Table 6. Equipment Required for Analog Bandwidth Test 22
Table 7. Oscilloscope Models and Signal Generator Frequency 27
Table 8. Time Scale Accuracy Specification 29
Table 9. Equipment Required for Time Scale Accuracy Test 30
Table 10. Trigger Sensitivity Specification 32
Table 11. Equipment Required for Trigger Sensitivity Test 32
Table 12. Performance Test Information 35
Table 13. DC Gain Test 35
Table 14. Analog Bandwidth - Maximum Frequency Check 37
Table 15. Time Scale Accuracy 38
Table 16. Trigger Sensitivity 38

10 Keysight 1000A Series Oscilloscopes Service Guide
Tables
