Ki Mobility ROGUE XP Installation and operation manual

1
Thank you for purchasing a Rogue XP or XPe wheelchair!
Please do not use this wheelchair without first reading this entire manual. BEFORE
riding, you should be trained in the safe use of this chair by an Assistive Technology
Practitioner (ATP) or clinical professional.
If you have any questions or concerns about any aspect of this wheelchair, this manual,
or the service provided by us or your retail supplier, please do not hesitate to contact
us by telephone at:
715-254-0991
In writing at:
Ki Mobility
5201 Woodward Drive
Stevens Point, WI 54481
U.S.A
Or via email at:
[email protected]
Or via our Authorized EU Representative:
James Leckey Design
19C Ballinderry Road
Lisburn
BT28 2SA
Phone: [phone] (UK) or 1800 626020 (ROI)
www.leckey.com
I. INTRODUCTION

2
I. INTRODUCTION
II. TABLE OF CONTENTS
III. NOTICE - READ BEFORE USE
A. Your Safety and Stability ...................................................................... 4
IV. WARNINGS
A. Signal Words........................................................................................ 5
B. General Warnings................................................................................. 6
C. Positioning Belts .................................................................................. 7
D. Riding Your Wheelchair........................................................................ 8
E. Power Drives........................................................................................ 9
F. Ascending Stairs .................................................................................. 9
G. Descending Stairs................................................................................ 9
H. Transfers............................................................................................. 10
I. Your Wheelchair and the Environment................................................. 10
J. Modifying your Wheelchair .................................................................. 11
K. Wheelchair Stability ............................................................................. 11
V. SET UP & USE OF YOUR WHEELCHAIR
A. Your Rogue XP & It’s Parts ................................................................. 14
B. Transit Use.......................................................................................... 15
C. Height-Adjustable T-Arms ................................................................... 18
D. Padded Swing-Away Adjustable Armrests .......................................... 19
E. Pediatric T-Arm Adjustment ................................................................ 20
F. Armrest Warnings ............................................................................... 21
G. Center of Gravity Adjustment .............................................................. 21
H. Wheel Camber .................................................................................... 23
I. Wheelbase Width Adjustment ............................................................. 24
J. Setting Toe to Zero ............................................................................. 25
K. Replacing the Camber Tube................................................................ 26
L. Front Seat Height Adjustments............................................................ 30
M. Rear Seat Height Adjustment .............................................................. 31
N. Caster Angle Adjustment..................................................................... 32
O. Wheel Installation & Removal............................................................... 33
P. Adjusting the Footrest ......................................................................... 34
Q. Optional Angle Adjustable Footplate.................................................... 35
R. Folding Backrest ................................................................................. 36
S. Backrest Angle Adjustment ................................................................. 37
T. Adjusting Backrest Height................................................................... 39
U. Adjusting, Removing and Replacing Backrest Release Cable for Width
Growth................................................................................................ 40
II. TABLE OF CONTENTS

3
V. Adjusting Backrest Position................................................................. 41
W. Replacing Adjustable Backrest Rigidizer Bar ....................................... 42
X. Wheel Locks ....................................................................................... 43
Y. Growing Your Rogue XP in Width........................................................ 44
Z. Anti-Tips ............................................................................................. 45
AA. Cushion Installation ............................................................................. 46
BB. Upholstery Fabric................................................................................ 47
CC. Adjusting and/or Growing Seat Upholstery.......................................... 47
DD. Rogue XP Standard 5th Wheel (Optional) ............................................ 49
EE. Rogue XP Dynamic 5th Wheel (Optional)............................................. 50
FF. Inserting Growth Spacer into Cross Tube............................................ 52
VI. MAINTENANCE
A. Inspecting Your Rogue XP Wheelchair ................................................ 53
B. Cleaning Your Rogue XP Wheelchair................................................... 55
C. Storage............................................................................................... 55
VII. WARRANTY ................................................................................................. 56
II. TABLE OF CONTENTS

4
III. NOTICE - READ BEFORE USE
A. Your Safety and Stability
Ki Mobility manufactures many different wheelchairs that might meet your needs. You should
consult an Assistive Technology Professional when selecting which model would best meet your
particular requirements and how the wheelchair should be set up and adjusted. Final selection of
the type of wheelchair, options and adjustments rests solely with you and your medical
professional. The options you choose and the set-up and adjustment of the wheelchair have a
direct impact on its stability. Factors to consider that affect your safety and stability are:
a. Your personal abilities and capabilities including strength, balance and coordination.
b. The types of hazards and obstacles you might encounter during your day.
c. Thespecificdimensions, optionsand setup. In particular, theseat height, seatdepth, seat
angle, back angle, size and position of the rear wheels and size and position of the front
casters. Any change to any of these items will change the stability of your wheelchair. You
should only make changes after consulting with a qualified professional.

5
IV. WARNINGS
A. Signal Words
Within this manual you will find what are referred to as “Signal” words. These words are used to
identify and convey the severity of varying hazards. Before using this chair you, and each person
who may assist you, should read this entire manual. Please note the Signal word and consider any
warnings, cautions or dangers. Make sure to follow all instructions and use your chair safely. The
Signal word refers to a hazard or unsafe practice that may cause severe injury or death to you or
to other persons. The “Warnings” are in three main categories, as follows:
DANGER– Danger indicates an imminently hazardoussituationwhich, if notavoided, will resultin
serious injury or death.
WARNING – Warning indicates a potentially hazardous situation which, if not avoided, could
result in serious injury or death.
CAUTION – Caution indicates a potentially hazardous situation which, if not avoided, could result
in injury or damage to your wheelchair.
These signal words will be placed throughout the manual, where appropriate to highlight the
hazardoussituation.Referto thefollowinglistforhazardoussituationsthatwillapplytothe general
use of this wheelchair.

6
IV. WARNINGS
B. General Warnings
WARNING: Do not exceed the weight limit of 200 pounds for the Rogue XP. This is the
combined weight of user and all items carried. Exceeding the weight limit can cause
damage to your chair or increase the likelihood of a fall or tip back resulting in severe injury
or death to the user or others.
DANGER: Do not use this chair for weight training.The movement of the additional weight
will alter the center of gravity of the wheelchair increasing the likelihood of a tip-over which
can cause damage to your chair or cause severe injury or death to the user or others.
WARNING: If your wheelchair is equipped with inflatable tires, make sure the tires have
been inflated to the correct tire pressure as indicated on the side wall of the tire. Your
wheelchair provider can determine if you have inflatable tires. Using your wheelchair without
properly inflated tires can have an effect on the stability of the wheelchair causing it to tip over
resulting in death or injury to the user or others.
DANGER: Do not attempt to push your wheelchair up or down ramps or traverse across a
slope of greater than 9 degrees. This is dangerous and increases the likelihood of a fall or tip
back resulting in severe injury or death to the user or others.
WARNING: Do not attempt to push your wheelchair up an incline that is slick or coated
with ice, oil or water. This can cause an unstable situation resulting in death or injury to the
user or others.
DANGER: Do not lean over the side or back of the wheelchair to extend your reach. This
may cause you to fall out of the wheelchair or the wheelchair to tip over resulting in injury or death.

7
IV. WARNINGS
B. General Warnings
DANGER: Do not attempt to the lift the wheelchair by holding on to removable parts such
as the arms or footrests. Only lift the wheelchair by holding on to the frame. This may cause a fall
or loss of control and result in serious injury or death.
CAUTION: Do not over tighten the bolts and hardware that attaches various components
together on the frame. This could cause serious damage and affect the safety and durability of
the wheelchair.
C. Positioning Belts
Positioning belts are designed to assist with proper positioning within the wheelchair. They are
not designed as seat belts. Use positioning belts ONLY to help support the user’s posture.
Misuse of positioning belts may cause severe injury to or death of the user.
• Ensure the user does not slide underneath the positioning belt in the wheelchair seat. If this
occurs, the user’s breathing may be hampered causing death or serious injury.
• The positioning belt should have a snug fit; tight enough to hold their position, but not so
tightas to restrict breathing. Y o u s h o u l d b e a b l e t o s l i d e y o urhand between the positioning
belt and the user.
•NEVER Use Positioning Belts:
a. As a restraint. A restraint requires a doctor’s order.
b. On a user who is unconscious.
c. As an occupant restraint in a motor vehicle. A positioning belt is not designed to
replace a seat belt that is attached to the frame of a vehicle, which would be required
of an effective seat belt. During a sudden stop, with the force of the stop, the user
would be thrown forward. Wheelchair seat belts will not prevent this, and further
injury may result from the belts or straps.
DANGER: Failure to comply with the instruction above could result in serious injury or death.

8
IV. WARNINGS
D. Riding Your Wheelchair
Your chair is designed for use on solid, flat surfaces such as concrete, asphalt and flooring. Use
caution if you push your wheelchair on a wet or slick surface.
WARNING: Do not push your chair in sand, loose soil or over rough terrain. This may cause
a loss of stability and result in a fall or loss of control and cause serious injury or death.
DANGER: In most states, wheelchairs are not legal for use on public roads. If you find you must
push on a public road, be alert to the danger of motor vehicles. Use of a wheelchair on a public
road can cause serious injury or death.
WARNING: Obstacles and road hazards (such as potholes and broken pavement) can
damage your chair and may cause a fall, tip-over or loss of control. Failure to comply with
this instruction could result in serious injury or death.
DANGER: Do not ride your wheelchair on an escalator. Use of a wheelchair on an escalator can
cause serious injury or death.
To minimize these risks:
1) Keep a lookout for danger-scan the area well ahead of your chair as you ride.
2) Make sure the floor areas where you live and work are level and free of obstacles.
3) Remove or cover threshold strips between rooms.
4) Install a ramp at entry or exit doors. Make sure there is not a drop off at the bottom
of the ramp.
5) To Help Correct Your Center of Balance:
a. Lean your upper body FORWARD slightly as you go UP over an obstacle.
b. Press your upper body BACKWARD as you go DOWN from a higher to a
lower level.
6) If your chair has anti-tip tubes, lock them in place before you go UP over an obsta-
cle.
7) Keep both of your hands on the handrims as you go over an obstacle.
8) Never push or pull on an object (such as furniture or a doorjamb) to propel your
chair.
9) Do not operate your wheelchair on roads, streets or highways.
10) Do not attempt to push over obstacles without assistance.

9
IV. WARNINGS
E. Power Drives
Ki Mobility does not recommend the installation of power drive systems on any Rogue XP
wheelchair.
Rogue XP wheelchairs have not been designed or tested as power wheelchairs. If you add a
power drive system to a Rogue XP wheelchair, be sure the manufacturer of the power drive
system has validated and approved the combination of the power drive system and Rogue XP
wheelchair as safe and effective.
WARNING: Use of a power drive system that has not been properly validated could result
in serious injury or death.
F. Ascending Stairs
• Have at least two people, who have sufficient strength and skill to handle the weight of the
user and wheelchair, assist when trying to go up a set of stairs in this wheelchair.
• Move the wheelchair and user backwards up the stairs.
• Position one person behind the user, one person in front. The person in front must hold
onto a non-removable part of the wheelchair.
• The rear attendant tilts the chair back and they both lift together. Take one step at a time.
• This may require the anti-tips be flipped up or removed. Make sure the anti-tips are
reattached or flipped back down before using the wheelchair.
DANGER: Failure to comply with the instructions above could result in serious injury or death.
G. Descending Stairs
• When descending a set of stairs the user should be facing forward.
• A person behind the user, who has sufficient strength and skill to handle the weight of the
user and the wheelchair, should tilt the chair backward and let the chair down the stairs
one step at a time on the rear wheels.
• This may require that anti-tips be flipped up or removed. Make sure the anti-tips are
reattached or flipped back down before using the wheelchair.
DANGER: Failure to comply with the instructions above could result in serious injury or death.

10
IV. WARNINGS
H. Transfers
A transfer requires good balance and stability. You should receive training from your therapist
before attempting to do a transfer on your own.
• Before transferring out of your wheelchair every caution should be taken to reducethe gap
between the two surfaces.
• Engage the wheel locks to lock the rear wheels.
• Rotate the casters forward to increase the wheelbase of the wheelchair.
• Remove or swing away the footrests.
• Have someone assist you unless you are well experienced in transfers.
It is dangerous to transfer on your own. It requires good balance and agility. Be aware there is a
point during every transfer when the wheelchair seat is not below you.
WARNING: Failure to comply with the instructions above may cause a fall or loss of
control, which may result in serious injury or death.
I. Your Wheelchair and the Environment
• Your wheelchair is made of many different materials including metal and fabric.
Exposure to water or excessive moisture may cause the metal in the wheelchair to rust
or corrode and the fabric to tear. Dry your chair as soon as possible if exposed to water.
•DO NOT USE YOUR WHEELCHAIR IN A SHOWER, POOL OR BODY OF WATER. This will
cause your wheelchair to rust or corrode and eventually fail.
• Do not operate your wheelchair in sand. Sand can get into the wheel bearings and moving
parts. This will cause damage and eventually will cause the wheelchair to fail.
• Make sure any ramp, slope or curb cut you may attempt to ride on is compliant with ADA
guidelines. Riding across, up or down any slope that is too great may cause a loss of
stability.
ADA Guidelines and more information about accessible design are available at:
http://www.ada.gov/
WARNING: Failure to comply with the instructions above may cause a fall or loss of
control, which may result in serious injury or death.

11
IV. WARNINGS
J. Modifying your Wheelchair
Yourwheelchairwasengineeredandmanufacturedunders t r i c t d e s i g n c o n t r o l s . A n i n t e g r a l p a r t o f
thisprocessisensuringthe variouscomponentsworktogethercorrectly;theyhavebeentested to
various standards to ensure quality and are approved to work together.
YOU SHOULD NOT CHANGE, ADD OR REMOVE COMPONENTS OR OTHERWISE MODIFY
THIS WHEELCHAIR. NO ONE SHOULD MODIFY THIS WHEELCHAIR EXCEPT BY
ASSEMBLING APPROVED OPTIONS. THERE ARE NO APPROVED OPTIONS THAT INVOLVE
DRILLING OR CUTTING THE FRAME BY ANYONE OTHER THAN A TRAINED KI MOBILITY
ASSOCIATE. Contact Ki Mobility or an authorized Ki Mobility supplier before adding any
accessories or components not provided by Ki Mobility.
DANGER: Failure to comply to these instructions may cause the wheelchair to fail and result in
serious injury or death.
K. Wheelchair Stability
To ensure proper stability of your wheelchair, you must make sure the center of gravity and the
wheelchairs baseofsupport iscorrectforyour balance andabilities.Manyfactors can affectthese
two elements;
Generally, the most important factor is the position of the rear wheels for rearward stability. There
are other actions than can have an adverse effect on your stability. You should consult with your
wheelchairproviderandcliniciansfamiliar withyourneedsandcapabilities indetermininghowthis
affects your use.
WARNING: Moving the rear wheels forward increases the likelihood of the wheelchair
tipping backwards. Make small adjustments and proceed slowly until you learn the new balance
point of your wheelchair. Failure to comply with the instruction above could result in serious injury
or death.
WARNING: The farther rearward you place the front casters the greater the likelihood of
the wheelchair tipping forwards. If possible, have your casters mounted forward and whenever
doing a static activity which involves shifting your weight, rotate the casters forward to increase
your wheel base. Failure to comply with this instruction above could result in serious injury or
death.
• Seat height •Size and position of rear wheels
• Size and position of front casters
• Any seating system components
•Seatdepth
•Backangle

12
IV. WARNINGS
K. Wheelchair Stability
WARNING: Always have a qualified technician set up your wheelchair with the accessories
you plan to use daily.
Changes to how you sit or changes in your weight require your chair to be readjusted by a
qualified technician. Always use anti-tips while you acclimate to any changes in your chair set
up. Failure to comply with the instruction above could result in serious injury or death.
WARNING: Changes to your Center of Gravity during your daily activities may occur many
times a day, changing and affecting the stability of your wheelchair. You should be aware of
these activities and take precautions to minimize the risk of a fall. Failure to comply with
the instruction above could result in serious injury or death.
WARNING: Dressing in your wheelchair produces movements and momentary positions that
can reduce stability. Ensure that your anti-tips are in place and rotate your casters forward.
Failure to comply with the instruction above could result in serious injury or death.
WARNING: Be very careful when reaching for objects if this movement requires you to shift
in your seat. This changes your center of gravity. Ensure that your anti-tips are in place.
Failure to comply with the instruction above could result in serious injury or death.
WARNING: Pushing up an incline shifts your center of gravity rearward and can reduce
stability. Ensure your anti-tips are in place. Failure to comply with the instruction above
could result in serious injury or death.
WARNING: If attempting a wheelie to get over a curb or obstacle, ensure your anti-tips are in
place and lean forward. Do not attempt a wheelie unless you have been trained and always
have an attendant behind you to provide assistance if needed. Failure to comply with the
instruction above could result in serious injury or death.

13
IV. WARNINGS
K. Wheelchair Stability
WARNING: Placing items on the back or front of your wheelchair, such as a backpack or
briefcase, alters the balance and center of gravity of the wheelchair. Since the weight of
these items can vary greatly at each use do not assume you are accustomed to the balance
point. Failure to comply with the instruction above could result in serious injury or death.
BE AWARE THAT CARRYING HEAVY OBJECTS ON YOUR WHEELCHAIR CAN HAVE AN
ADVERSE EFFECT ON THE BALANCE WHICH MAY CAUSE A TIP-OVER WHICH MAY
RESULT IN SERIOUS INJURY OR DEATH TO THE USER.
WARNING: Ensure your anti-tips are in place. You should discuss how you plan to use your
wheelchair or any changes you are planning with your clinician. Failure to comply with this
instruction may create a potential hazardous situation which, if not avoided, could result in
serious injury or death.

14
V. SET UP & USE OF YOUR WHEELCHAIR
A. Your Rogue XP & It’s Parts
1. Inspect and maintain this chair. See MAINTENANCE on page 53.
2. If you detect a problem, make sure to service or repair the chair before use.
3. Have a complete inspection, safety check and service of your chair performed by an
authorized supplier annually.
WARNING: Failure to read or comply with these instructions may result in damage to your
wheelchair, a fall, or loss of control causing severe injury to the user or others.

15
V. SET UP & USE OF YOUR WHEELCHAIR
B. Transit Use
It is always safest to transfer out of your wheelchair onto a seat in a motor vehicle with appropriate
seat and shoulder belts. Never use this wheelchair as a seat in a motor vehicle unless it has
been equipped with the Transit Option.
The Rogue XP Series wheelchair equipped with the Transit Option has been tested to and passed
the RESNA WC-4:2012, Section 19: Wheelchairs used as seats in motor vehicles and ISO
7176-19:2008 Wheelchairs -- Part 19: Wheeled mobility devices for use as seats in motor
vehicles. RESNA and ISO standards are designed to test the structural integrity of the wheelchair
as a seat for use in a motor vehicle. These standards are also designed to create compatibility with
Wheelchair Tie-down and Occupant Restraint Systems (WTORS).
Not all configurations of the Rogue XP Series wheelchairs are compatible with the Transit Option. Ki
Mobility manages the configuration and does not offer the Rogue XP Series wheelchair except in
compatible configurations. If you make changes to your Rogue XP Series wheelchair after your
receive it, you should contact your wheelchair provider or Ki Mobility to make sure it is appropriate to
continue to use your wheelchair as a seat in a motor vehicle.
If your Rogue XP Series wheelchair is equipped with the Heavy Duty Option and the Transit Option
you should not use it as a seat in a motor vehicle if you weigh more than 200 lbs.
Aftermarket seating may have replaced the original equipment seat and back support designed and
tested as part of the Transit Option. Your wheelchair provider should tell you if the seating they
provided is original equipment or replacement aftermarket seating. A complete system of wheelchair
frame, seating, Wheelchair Tie-down and Occupant Restraint Systems and a properly equipped
motor vehicle, that have all complied with the standards mentioned in this section, should be in place
before using a Rogue XP Series wheelchair equipped with the Transit Option as a seat in a motor
vehicle.
When using your wheelchair as a seat in a motor vehicle you should always observe the following
instructions:
• The rider must be in a forward-facing position.
• The rider and all items carried must not weigh more than 200 lbs.
• Backpacks and pouches should be removed and secured separately in the motor vehicle. In
the event of an accident these items can become dangerous projectiles, which may injure or
kill you or other occupants of the motor vehicle.
• The rider must use a Wheelchair Tie-down and Occupant Restraint System that complies with
RESNA WC-4:2012, Section 18: Wheelchair tie-down and occupant restraint
systems for use in motor vehicles or ISO 10542-1:2012 Technical systems and aids
for disabled or handicapped persons -- Wheelchair tie-down and occupant-restraint
systems -- Part 1: Requirements and test methods for all systems.
• Attach wheelchair tie-downs to the four securement points (two front, two rear) on the Rogue
XP Series wheelchair with the Transit Option (Fig. 1) in accordance with the wheelchair tie-
down manufacturer’s instructions and RESNA WC-4:2012, Section 18 or ISO 10542-
1:2012 - Part 1.
• Attach occupant restraints in accordance with the occupant restraint manufacturer’s
instructions and RESNA WC-4:2012, Section 18 or ISO 10542-1:2012, Part 1.

16
V. SET UP & USE OF YOUR WHEELCHAIR
B. Transit Use
• Use of lap belts, chest straps, shoulder
harnesses, any other positioning strap system
or positioning accessory should not be used,
or relied on as an occupant restraint, unless it
is marked as such by the manufacturer in
accordance with RESNA WC-4:2012,
Section 18 or ISO 10542-1:2012, Part 1.
• Use of headrests, lateral supports or other
positioning accessories should not be used,
or relied on as an occupant restraint, unless it
is marked as such by the manufacturer in
accordance with RESNA WC-4:2012,
Section 18 or ISO 10542-1:2012, Part 1 or RESNA WC-4:2012, Section 20:
Wheelchair seating systems for use in motor vehicles or ISO 16840-4:2009
Wheelchair seating -- Part 4: Seating systems for use in motor vehicles.
• After being fitted and adjusted, the top of the original equipment back upholstery should be
within 3 inches of the top of your shoulder.
• Any aftermarket seating should be tested to comply with RESNA WC-4:2012, Section 20
or ISO 16840-4:2009 - Part 4.
• Attach the seating to the wheelchair frame in accordance with the seating manufacturer’s
instructions and RESNA WC-4:2012, Section 20 or ISO 16840-4:2009 - Part 4.
• Use of lap belts, chest straps, shoulder harnesses, any other positioning strap system or
positioning accessory should not be used, or relied on as an occupant restraint, unless it is
marked as such by the seating manufacturer in accordance with RESNA WC-4:2012,
Section 20 or ISO 16840-4:2009 - Part 4.
• Use of headrests, lateral supports or other positioning accessories should not be used, or
relied on as an occupant restraint, unless it is marked as such by the seating manufacturer
in accordance with RESNA WC-4:2012, Section 20 or ISO 16840-4:2009 - Part 4.
• Aftermarket accessories such as trays, oxygen tank holders, oxygen tanks, IV poles, back
packs, pouches and other items not manufactured by Ki Mobility should be removed and
secured separately in the motor vehicle. In the event of an accident, these items can
become dangerous projectiles which may injure or kill you or other occupants of the motor
vehicle.
• If the wheelchair has been involved in an accident, you should not continue to use it, as it
may have suffered fatigue that may not be visible.
Fig. 1

17
V. SET UP & USE OF YOUR WHEELCHAIR
B. Transit Use
DANGER: Failure to comply with transit use instructions, on pages 15 and 16, could result in
severe injury or death!
NOTE: To obtain copies of RESNA or ISO standards please contact the standards organizations
below:
RESNA
1700 North Moore St., Suite 1540
Arlington, VA 22209
Phone: [phone]
Fax: [phone]
Email: technicalst[email protected]
ANSI/RESNA Standards:
RESNA WC-4:2012, Section 18:
Wheelchair tie-down and occupant restraint systems for use in motor vehicles.
RESNA WC-4:2012, Section 19:
Wheelchairs used as seats in motor vehicles.
RESNA WC-4:2012, Section 20:
Wheelchair seating systems for use in motor vehicles.
International Organization for Standardization (ISO)
ISO Central Secretariat
1, ch. de la Voie-Creuse
CP 56
CH-1211 Geneva 20 Switzerland
Phone: [phone]
Fax: [phone]
Email: [email protected]
ISO Standards:
ISO 10542-1:2012 Technical systems and aids for disabled or handicapped person --
Wheelchair tie-down and occupant-restraint systems -- Part 1:
Requirements and test methods for all systems.
ISO 16840-4:2009 Wheelchair seating -- Part 4:
Seating systems for use in motor vehicles.
ISO 7176-19:2008 Wheelchairs -- Part 19:
Wheeled mobility devices for use as seats in motor vehicles.

18
V. SET UP & USE OF YOUR WHEELCHAIR
C. Height-Adjustable T-Arms
1. Installation
a. Slide the outer armpost into the receiver mounted to the wheelchair frame.
b. The armrest will automatically lock into place. Check to make sure the locking lever is as
shown (Fig. 2:C).
2. Height Adjustment
a. Rotate release lever (Fig. 2:A).
b. Slide armrest pad up or down to desired height.
c. Return lever to locked position against arm post.
d. Push arm pad until upper arm post locks firmly into place. Check to make sure the locking
lever is shown (Fig. 2:A).
3. Removing Armrest
a. Squeeze release lever (Fig. 2:B) and remove the armrest.
4. Replacing Armrest
a. Slide armrest back into receiver.
b. The armrest should lock back into place.
DANGER: Failure to comply with the instructions above may result in the armrest accidentally
disconnecting from the wheelchair and result in a fall or loss of control and may cause serious
injury or death.
DANGER: Never attempt to lift the chair by the armrests; they may break or disconnect resulting
in a fall or loss of control and may cause serious injury or death.
Fig. 2
A
B
C
